Nibe Contura C556T User manual

C 556T
www.contura.eu
Installation
Instructions

GB
50 CERTIFICATE
PRODUCT
Product type Stove lit with solid biofuels
Type designation Contura 556
Manufacturing number See rating plate on the stove
Intended area of use Heating of rooms in residential buildings
Fuel Wood
MANUFACTURER
Name NIBE AB / Contura
Address Box 134, Skulptörvägen 10
SE-285 23 Markaryd, Sweden
CHECKS
According to AVCP System 3
European standard EN 13240:2001 / A2:2004
Test institute Rein-Ruhr Feuerstätten Prüfstelle, NB 1625,
has checked declared performance and issued test report no. RRF-40 15 3859
PERFORMANCE DECLARATION
No. C556-CPR-130601-SE-2
DECLARED PERFORMANCE
Essential characteristics Performance Harmonised technical
specification
Reaction to fire A1 WT
Minimum distance to combustible material 100 mm to rear
500 mm to side
Other safety distances according to
the installation instructions
Risk of falling embers Approved
Emissions from combustion CO 0.09 %
NOx 94 mg/m3
OGC 73 mg/m3
PM 12 mg/m3
Surface temperatures Approved
Cleaning options Approved
Mechanical durability Approved
Emissions of hazardous substances Approved
Nominal output 5 kW
Efficiency 80 %
Flue gas temperature in connector at nominal
output
299°C
EN 13240:2001 / A2:2004
The undersigned is responsible for the manufacture and conformity with the declared performance.
Niklas Gunnarsson, Business area manager NIBE STOVES
Markaryd, March 17, 2015

GB
51
Table of contents
Technical details 52
Prior to installation 53
Connection to chimney 54
Supply of combustion air 55
Installation distances 56
Assembly 57
Installation of the door 59
Removing the hearth surround 59
A warm welcome to Contura.
A warm welcome to the Contura family. We hope
you will get a great deal of pleasure from your new
stove. As a new owner of a Contura stove you have
secured a product with timeless design and long
service life. Contura also has combustion that is both
environmentally friendly and efficient for the best heat
production.
Read through these installation instructions carefully
before installation. Read how to best light your stove
in the lighting instructions.
CONTENTS

GB
52
NOTE!
Report the installation of a stove to your local
authority.
The owner of the house is personally responsible
for ensuring compliance with the mandatory safety
requirements and must have the installation approved by
a qualified inspector. Your local chimney sweep must also
be informed about the installation as this will affect the
routines for regular chimney-sweeping services.
WARNING!
The stove becomes very hot
During operation, certain surfaces of the stove become
very hot and can cause burn injury if touched. Be aware
of the strong heat radiated through the hatch glass.
Placing flammable material closer than the safe distance
indicated may cause a fire. Pyre lighting can cause quick
gas ignition with the risk of damage to property and
personal injury.
FACTS
Installation by authorised
technician
This manual contains instructions about
how the stoves must be assembled and
installed. To ensure the function and safety
of the stove, we recommend that the
installation is carried out by an authorised
technician. Contact one of our dealers who
can recommend suitable technicians.
Building application
These main instructions may give guidance
which would contravene national building
regulations. Please refer to supplementary
instructions or ask your local authority for
advice regarding building regulations.
Before installing a stove or erecting a
chimney it is necessary for you to make
a building application permission to your
local authority.
Structural support
Check that the wood joists are strong
enough to bear the weight of the stove and
chimney. The stove and chimney can usually
be placed on a normal wooden joist in a
single occupancy house if the total weight
does not exceed 400 kg.
Hearth plate
Due to the risk of falling embers, a
flammable floor must be protected by a
hearth plate. It must extend 300 mm in
front of the stove and 100 mm on each side
of the stove, or have a 200 mm extension
on each side of the opening. The hearth
plate can consist of natural stone, concrete,
metal plate or glass. A painted metal
or glass hearth plate is available as an
accessory for these models.
Important to remember!Technical details
Effect 3-7kW
Nominal effect 5 kW
Efficiency up to 80%
Model 556T
Height (mm) 1083
Width (mm) 542
Depth (mm) 463
Weight (kg) 175
Type approved in accordance with:
European standard EN-13240
Swedish environmental marking
NS 3059 (Norway)
DIN Plus (Germany)
Art. 15a B-VG (Austria)
Clean Air Act. (UK)

1
2
4
5
3
803388
803381
803386
803383
803378
GB
53
PRIOR TO INSTALLATION
Prior to installation
If the insert needs to be put down to
be moved, loose components should
be removed. Removal of the hearth
cladding is described at the end of
these installation instructions.
1 Fire bars
2 Grate disc
3 Hot air grate
4 Fire bricks (Vermiculite)
5 Type plate
Name of the soapstone

Ø
ca 180 mm
Ø
ca 180 mm
2 31
5 6
4
!
GB
54 CHIMNEY
Connection to chimney
Rear connection to a masonry chimney
Top connection to the chimney Make sure that the connector
gasket does not work loose when
the connection pipe is placed
on the connector. If further
sealing material is required, heat-
resistant sealant may be used.
The hot air grille must be installed before chimney top
connection.
• The stove meets the requirements for connecting to chimneys
dimensioned for 350°C flue gas temperature.
• The external diameter of the connection sleeve is 150 mm.
• The stove requires a draft in the chimney of at least –12 Pa. The
draft is affected both by the length and area of the chimney, and
by how well sealed it is. Minimum recommended chimney length
is 3.5 m and suitable cross section area is 150-200 cm² (140-160
mm in diameter).
• A flue with sharp bends and horizontal routing reduces the
draught in the chimney. Maximum horizontal flue is 1 m, on the
condition that the vertical flue length is at least 5 m.
• It must be possible to sweep the full length of the flue and the
soot hatches must be easily accessible.
• Carefully check that the chimney is sealed and that there is no
leakage around soot hatches and flue connections.
In the bag with these installation instructions
are two wing screws for the cover.

!
HK
HK
40 mm
HK
40 mm
HK
40 mm
GB
55
SUPPLY AIR/ACCESSORY
Supply of combustion air
When a stove is installed in a room, the demand for air supply to the room
increases. Air can be provided indirectly via a vent in the outer wall or via a
duct from the outside that is connected to the connector on the underneath
of the stove. The amount of air needed for combustion is 15 m3/h.
The connector has an external diameter of 67 mm. When duct routing
further than 1 m the pipe diameter must be increased to 100 mm and a
correspondingly larger wall vent must be selected.
In hot areas the duct should be insulated with 30 mm mineral wool covered
with a moisture inhibitor (plastic). It is important that the lead-in between
the pipe and the wall (or floor) is sealed using jointing compound.
A 1 m length of condensation insulated ducting for combustion air is
available as an accessory.
Through the external wall.
Indirect air supply through the external wall.
Through floor and foundation slab.
Through floor and wall-and-cavity foundation.
Installation variants
Leave a 40 mm gap between
the condensation insulation
and the bottom of the stove.
Outside air can be connected through the floor
plate or at two different heights through the
two panels in the back of the stove. Tap out the
knockout using a hammer.

13
13
VANADI UM
No. 7
CHROME
C 556T
!
GB
56 INSTALLATION DISTANCES
The minimum distance in front of
the stove opening to combustible
parts of the building or interior
decoration must be at least 1 m.
The dimension diagrams only
show the minimum permitted
installation distances for the
stove. When connecting to a steel
flue, also note the safety distance
requirements of the flue. The
safety distance between an un-
insulated flue and a combustible
part of the building should be at
least 450 mm.
Installation distances
WHEN INSTALLING TURNTABLE (OPTION) the fol-
lowing installation distances do not apply.
See the separate turntable installation instructions.
A = height from floor to chimney
connection upwards
B = height from floor to c/c chimney
connection rear
C = height from floor to air inlet
D = height from floor to lower edge
of hatch
A separate glass hearth
plate (accessory)
increases the connection
height to the chimney
by 10 mm. The spacers
supplied with the hearth
plate are installed on the
stove before connection.
Permitted area for
combustible parts of
the building
1083
542
2000*
D 367
74
201
Combustible roof
140
100
B 920*
A 1015*
C 383
35
463
Air inlet Ø67
Ø150
410
175 100
717
400
902
Combustible wall
285
50
592
725
800
800
Fire-retardant wall of
brick or concrete
450**
850
1100
179**
190
50
Fire-retardant wall of
brick or concrete
750
479
240
100
400
400
Combustible wall
INSTALLATION AGAINST COMBUSTIBLE WALLS INSTALLATION AGAINST FIREWALLS
* If the stove is placed on a hearth plate made of glass for example (accessory), the height from the floor is affected by a distance corresponding to the thickness of the hearth plate, for a free standing
glass hearth plate this is 10 mm.
** To prevent discolouration of painted non-flammable walls we recommend that the same side distance as to combustible walls is used.

13
13
VANADI UM
No. 7
CHROME
1 2
525 mm
4 5
3
6
515 mm
!
!
GB
57
ASSEMBLY
Assembly

9
87
10
GB
58
Final inspection of the installation
It is extremely important that the installation is inspected by an authorised chimney sweep before
the stove is used. Also read the ”Lighting instructions”, before lighting for the first time.
READY!
If the stove’s loose components are removed these
must be reinstalled in reverse order when the stove is
put in place.
ASSEMBLY
Where necessary, use
the shims supplied to
align the stones and
the side lights.

1
23
1
3
2
2
1
GB
59
REMOVAL
How to remove the hearth surround
(Vermiculite)
Handle the vermiculite with care. Lift the smoke baffle with one
hand whilst removing the sides pieces. Reinstall in reverse order
Installation of the door
The door can be held in the open position using the push
button on the underside of the stove.
Removing the hearth
surround

811260 IAV SE-EX C556T Style-2
2015-07-02
Contura reserves the right to change dimensions and
procedures described in these instructions at any time without
special notice. The current edition can be downloaded from
www.contura.eu
NIBE AB · Box 134 · 285 23 Markaryd · Sweden
www.contura.eu
