NICOR TPE Series User manual

NICOR, Inc. 2200 Midtown Place NE, Albuquerque, NM 87107 P: 800.821.6283 F: 800.892.8393 www.nicorlighting.com March 9, 2018 3:29 PM rev 1.0
TPE Frame Kit
INSTALLATION INSTRUCTIONS
The installation must only be performed by a licensed electrician.
To prevent death, injury or damage to property, this product must be installed in accordance to National Electrical Code (NFPA70) in the US
or Canadian Electrical Code (CSA 22.1) in Canada.
Disconnect power before installing the product or servicing it.
Wait until xture has cooled down before installing or servicing the xture.
MIN. 90°C SUPPLY CONDUCTORS
What’s In The Box Tools & Materials Needed
This Frame kit requires very few tools for installation. A drill or a
screwdriver and a pair of wirecutters, and appropriate fasteners
for mounting surface
Two (2) End Pieces Two (2) Side Pieces
Carefully unpack the xture from its packaging. Inspect product
for defects due to shipping.
Assemble the Frame kit using hardware provided.
1
2
Install frame onto desired location using appropriate fasteners (not provided).
3
Turn o power to appropriate
circuit at the breaker box.
1
Eight (8) Screws
*Dimensions

NICOR, Inc. 2200 Midtown Place NE, Albuquerque, NM 87107 P: 800.821.6283 F: 800.892.8393 www.nicorlighting.com March 9, 2018 3:29 PM rev 1.0
67
Lift xture into frame, Tilt or angle
xture as need.
Alternatively, drop xture into frame
from above.
Turn power on and verify that the panel is lit.
4Remove access plate from junction-box (do not discard)
by removing screw.
Connect wiring as shown in wiring diagram, then reattach
junction box cover and secure with screw.
5
LED Driver
INPUT
Black
Red
OUTPUT
Gray
Purple
GND
Black
White
Junction Box
DIM +
DIM -
LED +
LED -
GND
WE WOULD LIKE TO HEAR FROM YOU
Scan QR Code or Visit
nicorlighting.com/support/survey
WRITE A REVIEW
Thank You
For Your Purchase!
WIRING DIAGRAM
Trim Dimensions
Series (W) Width (L) Length
TPE10FK14 13 3/8” (340 mm) 49 3/8” (1254 mm)
TPE10FK22 25 3/8” (645 mm) 25 3/8” (645 mm)
TPE10FK24 25 3/8” (645 mm) 49 3/8” (1254 mm)
Ceiling Opening Dimensions
Series (W) Width (L) Length
TPE10FK14 12 3/4” (324 mm) 48 3/4” (1238 mm)
TPE10FK22 24 3/4” (629 mm) 24 3/4”(629 mm)
TPE10FK24 24 3/4” (629 mm) 48 3/4” (1238 mm)
