Night Stick NSR-9910 User manual

BAYCO • 640 South Sanden Blvd. • Wylie, TX 75098 • 1-800-233-2155 • 00+1+ 469-326-9400 • www.baycoproducts.com
Operating Instructions for Models
NSR-9910 / 9912 / 9914
Flashlight • Floodlight • Dual-Light • Strobe
Rechargeable Personal / Patrol Size Flashlight
Multiple Patents Pending
INS-9910-12B
CAUTION: DO NOT use in explosive atmospheres, near flammable liquids,
or where explosion proof lamps are required
DO NOT use in the proximity of vehicles or equipment when there is a risk of flammable
liquids coming into contact with the flashlight.
WARNING: NOT FOR USE ABOVE HAZARDOUS LOCATIONS
Thank you for selecting this Nightstick product. Save this instruction.
Please read these instructions before using your Nightstick. It includes
important safety and operation information. Be sure to charge the Nightstick
fully before the first use. A battery is fully charged when the charger light is
green.
Record the serial number and
date of purchase in the space
provided on the back. Then
register your Nightstick online
for warranty coverage. See
information below.
Record the serial number and
date of purchase in the space
provided below.. Then register
your Nightstick online for
warranty coverage. See
information below.
Items in the box
CHARGING
Initial Use
Fully charge the Nightstick before the first use. If the battery is new or has been
unused for several months, several charge and discharge cycles may be
needed to reach full battery capacity. To reach maximum performance, run the
light to completely discharge the battery and then recharge. Each charge cycle
will extend the operation time until maximum capacity is achieved. The charge
time for maximum capacity is approximately 3 hours.
Regular Use
Use only the supplied Nightstick charge platform, battery and AC or DC
adapter. The maximum allowable DC input is 15VDC.
For best performance, charge the Nightstick when the LED’s start to dim.
Connect the AC power adapter to the charging platform. The green
indicator will light.
With the floodlight facing forward, slide the Nightstick into the charging
platform until the contacts snap into place.
The red light on the charging platform indicates the Nightstick is properly
inserted into the charging platform and charging. The light remains red until
the battery is fully charged. At full charge, the light turns green. The total
time to full charge varies depending on the remaining charge in the battery
pack.
The charging platform provides a trickle charge to a fully charged battery
pack.
PERFORMANCE ALL MODELS
SAFETY
CAUTION BRIGHT LED RADIATION: AVOID DIRECT EYE EXPOSURE.
Nightstick is a Class 2 LED product per IEC 60825-1 Edition 1.2.2001.
Do not use or charge this Nightstick in explosive or hazardous areas.
Do not attempt to repair or disassemble the Nightstick, the charger
platform, battery or the power supply.
Use only the Nightstick charging platform, AC or DC adapters and battery
pack.
Using this Nightstick product for other than a lighting device is not
recommended. Bayco specifically disclaims liability for other than intended
use.
OPERATION of NSR-9910 / 9912 / 9914
There are two Nightstick product configurations. Both have the Flashlight •
Floodlight • Dual-Light • Strobe modes. For maximum user safety the flashlight
and floodlight can operate simultaneously in the Dual-Light mode. The strobe
flashes at approximately 2 flashes per second.
NSR-9910 / 9912: Single body switch
NSR-9914: Dual-Switches. Tandem control.
NSR-9910 / 9912 - Single body switch
The five light modes are controlled by the body switch. After being in any mode
longer than 3/4 second: The next press turns the light OFF. The strobe-light
function overrides any other mode. Strobe is accessed from any mode. Lightly
press the body switch for momentary flashlight operation.
First Press – Flashlight On
Second Press – Floodlight On
Third Press – Dual-light On
Fourth Press – All Off
Press and Hold– Strobe On
Press Again – Strobe Off
NSR-9914 – Dual Switches. Tandem control
The five light modes are identical to the NSR-9910 / 12 and controlled by either
the body or tail switch. Lightly press the body or tail switch for momentary
flashlight operation.
LIGHT MODE NiMH Lithium CR123
Lumens Run-time
Hrs Lumens Run-time
Hrs
FLASHLIGHT • Momentary
220 5 220 2
FLASHLIGHT • Constant
220 5 220 2
FLOODLIGHT • Constant
180 5 180 2
DUAL-LIGHT • Flashlight &
Floodli
g
ht
230 5 230 2
FLASHLIGHT STROBE
220 16 220 7

BAYCO • 640 South Sanden Blvd. • Wylie, TX 75098 • 1-800-233-2155 • 00+1+ 469-326-9400 • www.baycoproducts.com
ADDITIONAL 9910 / 12 / 14 FEATURES
Chemical Resistance
The housing is resistant to most automotive and industrial chemicals. For
example: Potassium hydroxide, hydrochloric acid, sulfuric acid, isopropyl
alcohol, Freon, gasoline, kerosene, diesel fuel, antifreeze, hydraulic fluid and
others. Avoid prolonged exposure and clean immediately.
Water Resistance
The 9910 / 9912 / 9914 are not affected by fog, mist or intermittent spay.
EMI
The charging platform and light are electromagnetically compatible with FCC
regulations CFR-47, Part 15, Sub-Part B and Class A.
Battery
Nightstick is powered by a Nickel Metal Hydride (NiMH) battery pack and is
earth friendly so it can be disposed of in municipal waste without harm to the
environment. (Excluding California). An CR123 battery carrier is included to
provide back-up lighting power if needed.
9910 Magnetic Tail Cap
The 9910 has a powerful magnet built into the tail cap so the light can be
attached to a steel object and used hands-free.
CONNECTING THE CHARGER PLUG
CHARGER PLATFORM MOUNTING
Mounting the charger platform requires two #8 screws (not provided). Use the
Bayco supplied 12VDC fused auto adapter plug for temporary vehicle
installations. For permanent wiring, the installation must be fused using a 3-
amp in-line fuse. The DC input terminal that connects to the base of the
charger platform is center-positive. Installation should be performed by a
professional installer.
POWER ADAPTER FOR NORTH AMERICA AND EUROPE
The NSR-9910 / 9912 / 9914 include an AC power adapter that fits North
American and most European electrical outlets. Select the correct AC
connector and follow the instructions in the box.
LITHIUM CR123 BATTERY CARRIER
The CR123 battery carrier converts the 9910 / 9912 / 9914 from rechargeable
NiMH to replaceable Lithium battery operation. To load the carrier with
batteries, slide the carrier halves open. Load three CR123 Lithium batteries
with + terminal facing up.
TIPS TO EXTEND NiMH BATTERY LIFE
The Nightstick NiMH battery pack does not have a memory effect. Charging
the battery pack often helps extend its useful life.
A new Nightstick or one that has not been used for a long period of time,
may not accept a full charge initially. This is normal and does not indicate a
problem. Fully discharge and then charge the unit several times to
condition the battery pack for full capacity.
Charge the unit after each use, whether the Nightstick is fully discharged or
not.
Store the Nightstick at room temperature
WARRANTY
Product Registration Online
Go to www.baycoproducts.com and follow the easy to use instructions at
Warranty Registration.
Limited Lifetime Warranty
Product is warranted to be free from defects in workmanship and materials for
the lifetime of the original owner. Includes the housing, lenses, electronics and
switches. Rechargeable batteries and chargers are warranted for a period of
one year. Primary batteries, normal wear and abuse are excluded.
Product Use - If this product is used for rental purposes, the warranty term is
reduced to 90 days from the date of purchase.
Not Covered
The warranty does not cover normal wear and tear or cosmetic damage.
The warranty also does not cover damages which occurred in shipment or
failures which are caused by accidents, misuse, abuse, faulty installation
and lightning damage.
Consequential damages, incidental damages or incidental expenses,
including damage to property. Some states do not allow the exclusion or
limitation of incidental or consequential damages, so the above limitation or
exclusion may not apply to you. This warranty gives you specific legal
rights, which may vary from state to state.
This warranty does not apply to certain Bayco professional products that
carry a specific warranty unique to those products.
Warranty Claims – North America
Contact Bayco for USA warranty claims. Call 800-233-2155 or email
[e-mail] and Bayco Customer Service will provide a Return
Goods Authorization (RGA) to facilitate rapid warranty action. After receiving
the RGA, send the product (shipping prepaid) to BAYCO • 640 S. SANDEN
BLVD • WYLIE, TEXAS • 75098. Include a dated proof of purchase and a brief
description of the defect with your name, address and phone number. Your
product will either be repaired or replaced at the option of Bayco and returned
as soon as practical, but no later than 45 days after being received by Bayco.
WARRANTY QUESTIONS and INTERNATIONAL CLAIMS
If you live outside the USA or have questions about this warranty or an inquiry
about other Bayco products contact BAYCO • 640 S. SANDEN BLVD • WYLIE,
TEXAS • 75098 or call 00+1+469.326.9400.
PRODUCT INFORMATION
Serial Number _____________________________________________
Date of Purchase ____________________________________________
