Nikon COOLSCAN LS-10 User manual

z
.....I
.....I
(f)
z
Nikon ®
Coolscan ™
Installation
Guide
for
Windows ™ ikon
ELECTRONIC IMAGING

I
I
I
I
I
I
I
Coolscan™ Installation Guide
I for the Windows™ Operating System
I
I
I
I
I
I
I~--------------~

FCC Radio Frequency Interference Statement for Coolscan
This equipment has been tested and fo u nd to comply with the limits for a class B digital
device, pursuant to Part
15 of the FCC R ul es. These limits are designed to provide reason-
able protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
ac cordance with the instructions, may cau se harmful interference to radio communica-
tions. However, there
is no guarantee that interference will not occur in a particular instal-
lation.
If this equipment does cause harmful interference to radio or television reception,
which can
be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more
of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
Installation Safety Regulation of Coolscan Internal Model
This scanner has been approved by the Underwriters Laboratories, Inc., in the U.S., the
Canadian Standards Association, and
as a class B device under Part 15 of the FCC
(Federal Communications Commission) Rules. This unit should only be installed in
equipment that
has been approved according to the same standards.
AC Line Cord
Note that different power cords are needed for different line voltage. If the line voltage is
greater than 125V AC, the plug should be rated for 250V AC and 15A (NEMA 6P-15),
this cord insulation should
be at least STV type, and the gauge of the cord should be at
least AWG 18.
If the line voltage is 125V AC or less , the plug should be rated for 125V
AC and
lOA with SVT type resistance for the cord insulation and a gauge of at least A WG
18 , and the cord should meet the safety standards of the country where the unit is used.
When Taking this Product Out of the Country
The use of this product may violate local laws and restrictions in some countries. If this is the
case, Nikon cannot bear any responsibility for any violations resulting from the use of this
product. Note that, in some countries, this product can
be made to conform with regula-
tions through an internal adjustment. Therefore, before taking this product out
of the
country, consult with your Nikon service representative.
P age !!
Nlkon Co ols can I ns tallat ion Guidefor Wi nd ows
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I

I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
TRANTOR-New Horizons in SCSI Design SOFIWARE LICENSE AGREEMENT
IMPORTANT:
YOU SHOULD CAREFULLY READ THE FOLLOWIN G TERMS AND CONDITIONS BEFORE OPENING OR USING THIS
PRODU CT. IT CONTAINS SOFTWARE ("Software Program"), THE USE OF WHICH IS LICENSED BYTRANTOR SYSTEMS,
LTD. ("Trantor"),
TO ITS CUSTOMERS FOR THEIR USE ONLY AS SET FORTH BELOW. OPENING THIS PACKAGE INDI-
CATES THAT YOU ACCEPT THE TERMS OF THIS AGREEMENT. IF YOU DO NOT ACCEPT THESE TERMS, RETURN
TH IS PACKAGE UNOPENED WITHIN A REASONABLE TIME AND YOUR MONEY WILL BE REFUNDED.
TERMS
AND CONDITIONS
You ma y: 1. Use rh e sofrware program on a single personal compurer. 2. Make one (I) copy of rhe program for backup or modificarion
purposes
in S Upp Of[ of your internal u se of rh e program. This software program is copyrighred. Unaurborized copying of rh e sofrware pro-
gram, including software rhar h
as been modified, merged or included wirh orher sofrware is forbidden. 3. Modify and lo r Merge rhe pro-
gram into anorher program
for your u se on a single co mpurer. Any porrion of rhis program merged infO anorher program will co nrinue ro
be subjecr [Q rh e rerms and condirions of rhe Agreement." 4. Transfer rhe program and li ce nse [Q anorber party ifrhe orher party agrees [Q
accept [he terms and condidons of this Agreement. If you transfer (he program. you must at the same time either transfer any copy to the
sa me parry or destroy any copy nO[ transferred: this includes all modifications and portions of the program contained or merged into other
programs. Any aurhorized [Cansferee of rhe Sofrware Program sh all be bound by rhe rerms and condidons of mis Agreemem.
(") You mllSf reproduce and include rhe copyrighr norice on a ny copy, modific ar ion or ponion merged imo anorher program.
Uses nor permirred:
1. Excepr
as expressly provided for in rhis license, yo u may nor use, copy, modify, adapr, [Cansl are, re verse engineer, decompile, disassemble
or create derivacive works.
OWNERSHIP
Tramor reserves rhe righr and ririe ro rhis sofrware producr, and all subsequenr copies including ririe [Q rhis Sofrware Program and [Q rhe
medium on which
ir is encoded. You ha ve purcha se d only a license [Q use rhi s copy, which is leased ro you by Tramor . TRANTOR
OWNS THIS CO PY AND ALL BACK-UP CO PIES; YOU ONLY HAVE THE LIMITED RIGHTS GRANTED BYTHIS LICENSE.
TERM
The licen se is effecrive umil rerminared. TH IS LICENSE WILL TERMINATE AUTOMATICALLY WITHOUT NOTICE FROM
TRANTOR IF YOU FAIL TO COMPLY WITH ANY PROVISION OF THIS LICENSE. You agree upon such rerminarion [Q desrroy
rh e program rogerher wirh a ll copies, modificarions and merged ponions in any form.
DIS CLAIMER OF WARRANlY AND LIMITED WARRANlY
THE SOFTWARE PROGRAM IS PROVIDED " AS IS" WITHOUT WARRANlY OF ANY KIND. THE ENTIRE RISK AS TO
THE QUALITY AND PERFORMANCE OF THE PROGRAM IS WITH YOU. SHOULD THE PROGRAM PROVE DEFECTIVE,
YOU (AND
NOT TRANTOR) ASSUME THE ENTIRE COST OF ALL NECESSARY SERVICING, REPAIR OR CORRECT ION .
FURTHER,
TRANTOR DOES NOT WARRANT, GUARANTEE, OR MAKE ANY REPRESENTATIONS REGARDING THE
USE, ORE THE RESULTS OF THE USE, OF THE SOFTWARE PRO GRAM IN TERMS OF CORRECTNESS, ACCURACY,
RELIABILITY, CURRENTNESS,
OR OTHERWISE.
Trantor warrants {he diskette (5) on which the program is furnished to be free from defects in materials and workmanship under normal use
for a period of ninety (90) da ys from rhe dare of delivery to you as evidenced by a copy of your receipr.
THE ABOVE ARE THE ONLY WARRANTIES OF ANY KlND, EITHER EXPRESS OR IMPLIED, I NCLUDING BUT NOT LIM-
ITED
TO THE WARRANTIES OF MERCHANTABILIlY AND FITNESS FOR A PARTICULAR PURPOSE.
LIMITATIONS OF REMEDIES
Tramor's emire Iiabiliry and
yo ur excl usive remedy shall b e:
I. The replacement of any diskette not meeting Trantor 's "Limited Warranty" a nd which is returned to Tranmr with a copy of your
receipt, or
2. IfTramor is unable ro deliver a replacemenr diskette which is free of defects in marerials or workmanship, you may rerminare rhis
Agreemem by <erurning me program, and your money
wi ll be refunded.
3. If fa ilu re of rh e diskerre has resulred from accidenr, misuse or misapplicadon, Tranror shall ha ve no responsibility to replace rhe diskerre
or refund the purchase price.
4. Any replacemem diskette wi ll be warramed for rhe remainder of rhe original warranty period or rhirty (30) days, whichever is longer.
IN
NO EVENT WILL TRANTOR BE LIABLE TO YOU FOR ANY DAMAGES, INCLUDING ANY LOST PROFITS, LOST SAV-
INGS OR OTHER INCIDENTAL OR CONSEQUENT IAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE
SUCH SOFTWARE PROGRAM, EVEN IF TRANTOR OR ANY AUTHORIZED TRANTOR DEALER HAS BEEN ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES. OR FOR ANY CLAIM BY ANY OTHER PARTY.
This agreemem
wil l be governed by rhe laws of rhe Sra!e of California.
You acknowledge rh ar yo u h ave read rhis Agreemem, undersrand ir , and agree ro be bound by its terms and co ndirions. You furrher ag ree
rhar ir is rhe complere and exclusive Sfaremem of rhis Agreemenr berween us which supersedes any proposal or prior agreemenr, oral or
written, and any other communications between us relating to the subject matter of this Agreemenr.
Tramor Systems, Lrd.· 54 15 Randall Place · Fremonr, CA 94538 USA
Nlkon Coolscan Installation Guide for Windows
Page 111

Acknowledgments
Nikon acknowledges with gratitude the contributions of the Design, Planning and
Production Sections
of the Electronic Image Engineering Division of Nikon Corp. and the
Marketing & Development
Group at Nikon Electronic Imaging. Nikon Electronic Imaging
would also like to
thank all those who helped test Coolscan and its software.
This manual may
not , in whole or in part, be copied, photocopied, reproduced, translated,
or converted to any electronic or machine readable form
without prior written consent of
Nikon Inc.
The accompanying 35mm slide is for instructional purposes only and may not be copied,
reproduced, translated, or converted to any electronic or machine readable form for any other
usage without prior written consent.
The slide is © 1993, John Harcourt.
P age IV
Trademark Information
Coolscan™ is a trademark of Nikon Inc.
Nikon LS_lO TM and Nikon LS-lOP Mare trademarks ofNikon Corporation.
ImageAccesl" is a trademark ofAXS/Optical Technology Resource, Inc.
Macintosh™
is a trademark of Apple Computer, Inc.
Windows TM is a trademark of Microsoft® Corporation.
Photoshop™
is a trademark of Adobe Systems Inc.
PhotoStyler™
is a trademark of Aldus Corporation.
PublisherTM is a trademark of Micrografx, Inc.
Centronics™ is a trademark of Centronics.
Microchannel™
is a trademark of IBM.
IBM_PC™
is a trademark ofIBM.
T_130™and T-228 ™are trademarks ofTrantor Systems, Ltd.
Nikon Inc.
Electronic Imaging
Department
1300 Walt Whitman Road
Melville, NY 11747
516-54 7 -4355
© 1993, Nikon Inc. All rights reserved.
Printed in the United States
of America.
Nlkon Coolscan Installation Guidefor Windows
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I

I Table of Contents
I
Table of Contents
i-Introduction .................................................................................................................1
About this Manual ..............................................
.. ........................................... .. ..........1
Unpacking ...
.. .......... .. ... .. . .. .. .. ............ .. ............... .. ...................... .. ....... .. ........ .. ........ .. ..2
Registration
.. ........................................................................................... .. .. .................3
I Software Backups .......................................................
.. ................... .. . ... .... .. .... .......... .. 3
Minimum
PC System Requirements ............................................................................3
2-Setting Up Coolscan .....................................................................................................5
I
The Front Panel .................................................................................... .. ................. .. ..5
Film S
lo t ..................... .. ........................ .. ............. .. ..............................................5
Focus Wheel
.. ............................ .. . .. .....................................................................6
I Power/Busy/Error Indicator Light
.. .....................................................................6
The Rear Panel- LS-I0E ...... .. .....................................................................................6
The Rear
Panel- LS-I0 ...............................................................................................7
I Orientation and Placement
of the LS-l OE ....................................................................8
Proper Orientation ..........................................................
.. . .. .. ..... .. .................... .. 8
I Proper Placement ................................
.. .. ................................... .. ............ .. ..........9
Transporting Coolscan ............
.. .... .. .......................... .. ........................ .. ..... .. ..............10
Connecting AC Power to the LS-l
OE ........................................ .. ........ .. .... .. .. ............ 10
Safery Precautions When Connecting AC Power to the LS-l OE .. .................... .. ........ 11
I
I AC Power Safery Precautions -LS-lOE ......................................................................
11
General Safery Precautions .................... .. ................... .. . .. .......... .. .......... .. .. ...... .. . .. .. .. .. 12
Installation Precautions .. .... .. ......... .. ....... .. . .. . .. ......... .. .. ............. .. ............... .. . .. .. .. ........ 13
3-The SCSI Interface ...................................................................................................... 15
System Requirements for SCSI Installation ............................. .. .. ........................ .. ..... 15
I Setting the SCSI
ID .................................................................... .. ............................. 15
Determining Which SCSI ID Number to Use ................................................... 16
Setting the SCSI ID -LS-l OE .. .. .......................................................................17
Setting the SCSI ID -LS-l0 ..........................
.... ...............................................17
I Terminating the SCSI Chain ................................
.. .... .. .......................................... .. . 18
Terminating the LS-I0E .... ................................................................................ 19
Terminating the LS-l0 .. .. ...... ........ .. .................................................................. 19
I SCSI Cables ..........................
.. .. .. .. ............................ .. ...... .. .. .. .. .. ............ .. . .. .. ............20
SCSI Cables Used
With the LS-I0E .......................... .. .. .. ..................................20
SCSI Cables Used
With the LS-I0 ...................................................... .. ............ 21
I
The PC 's External SCSI Connector ...................... .. ...................................................22
The PC's Internal SCSI Connector ............................................................................23
I
I Nlkon
Coolscan Inst a llation GuidI: for Windows
P age V

Table of Contents I
Connecting to the Internal SCSI Connector ......................................................23
The SCSI Controller Card ..................................................................... .. ................ .. 26 I
Setting th e SCSI Controller Card Configuration ...............................................28
Installing the SCSI Controller Card Into the Computer ................................
.... .. .......29
Setting Up the SCSI Chain - LS-10E ......................................................................
.. 31
I
Connecting Two SCSI Devices .. .. .. ..... .. . .. .......... .. .................. .. . .. ... .. ................ .. 31
Connecting Multiple SCSI Devices ...................................................................32
Setting Up the SCSI Chain -LS-IO ...................................
.. ......................................33 I
Connecting Two SCSI Devices ..........................................................................33
Con necting Multiple SCSI Devices ......................................................... .... ......34
Important Information About the SCSI Interface ..................................
.. .. .... ............36 I
4-Mounting the LS-IO .................................................................................................39
Overview ................. .. ........................................................................................ .. .......39
The Guide R ails ....................................................... .. .. ..............................................40 I
Procedure 4.1 -Mounting the Guide Rails .. .... ................................................... .. ....40
Before Inserting Coolscan into the
Dr ive Ba y ........................................... .. .... .. .... .. ....43
Procedure 4.2 -Installing Coolscan into the Drive
Ba y ............................................43 I
5-Software Installation ................................................................................................47
Nikon Scanner Plug-in Software ......................................... .. ...................... .. .....47
Coo
lsc an Control Software .......... .. . .. ........ .. . .. ................. .. ... .. ...... .. .. .. .. .. ............47 I
Eject.EXE Software .. ....... .... .. .. ........ .. ..................................................... .. ....... .. .47
Nik on Installer Software ........................................................................... .. .. .. .. .... .. .. .48
Sys tem Requirements ........ .. .... .. . .. ..... .. . .. ............... .. .. ....... .. .. ...... .. ..............................48 I
The Distribution Diskette .... ................... .. ................ .. . .. .. .. .. .. ....... .. .......... .. .. ....48
Running the Nikon Installer .....
.. . .. .. .. .......... .. ..... .... .. ..... .. . .. .. ..... .. ..............................48
The Software Installer Dialog ............................................................................50 I
The Product Selection Dialog ..................... .. ................................................ .. ... 51
The Installation Options Dialog .. ...... .. ................................................... .. .........52
The Path Selection for Files Dialog ....................................................................52 I
Installing Third-Party Applications ................................. .. ................................. .. . .. . .. 55
The Path Selection for Installer Dialog .............................................................. 55
The Installation Method Dialog .. ................ .. .. ......... .. .. ........... .. . .. . .. . .. . .. ...... .. . .. .56 I
Installing the SCSI Driver Software ................................................................... 58
Conclusion ......... .. ........... .. .......... .. ................. .. ........ .. ................... .. ............... .. .59
Troubleshooting ..........................................................................................................61 I
I
Page VI Nlkon
Coolscan In stallat ion Guide for Windows
I

I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
Chapter 1 Introduction
Introduction
Thank you for purchasing the Nikon Coolscan™ 35mm Film Scanner, and wel-
come
to our family of electronic imaging products. We are confident that Coolscan will
meet and exceed the high standard
of quality, reliability, innovative design, and ease of
u se which you have come to expect from Nikon.
Before proceeding, make sure that you have read the Open
Me First documents
enclosed with Coolscan, including a Packing List and important operator safety
precautions.
Before You Begin
The installation procedures for Coolscan are straightforward. The instructions
provided in this manual will lead you through these procedures and have you scanning
within an hour. However,
if you are not comfortable mounting hardware into your
computer, please contact a qualified service person to assist in the installation of your
scanner.
There are two models
of Coolscan. The first is the IS-10 Internal model, which is
mounted into your computer just like a floppy disk drive. The other is the IS-JOE
Externalmodel, which
is a peripheral device and cannot be mounted into your comput-
er.
As you follow the installation procedures in this guide, refer only to the sections
which are appropriate
to the Coolscan model you have purchased. In this guide, the
Coolscan internalmodel will always be referred to as "LS-lO." The Coolscan external
model will always be referred to as "LS-10E," in which the "E" designates "external." If
you are uncertain of which model you are installing, refer to the sticker on the base of
the scanner, which will indicate either "L5-1O" or "L5-lOE."
About this Manual
The function of this manual is to provide both the novice and expert user with
information to successfully install Coolscan. A complete description of scanner hard-
ware installation and scanner software installation
is provided.
Very important informational items are printed in boldfaced type with a
triangular alert icon located in the margin.
Following
is a summaty of the contents of this manual:
Nlkon Coolscan Installation Guide for Windows
Page 1

Introduction Chapter 1
P age 2
Chapter One -Introduction • {this chapter} Provides an overview of the
Coolscan documentation package, product registration information, system require-
ments, and information
on backing up the sofrware.
Chapter Two -Setting Up Coolscan • Describes how to set up the scanner,
where to place the scanner, transporting the scanner, and safety notes regarding the
usage and installation
of the scanner.
Chapter Three - The SCSI Interface • Describes the SCSI Interface, including
setting up the SCSI ID, terminating the SCSI bus, how
to connect to the computer
SCSI bus, the SCSI chain, and a general description
of the pro's and con's of the SCSI
bus.
Chapter Four - Mounting the LS-10 • This chapter is for installing the
Coolscan internalmodel only. Proceed to Chapter Five if you are installing an LS-
10E model.
It details how to mount the scanner into the computer.
Chapter Five -Software Installation • Provides procedures for installing the
scanner sofrware. Included are the steps necessary
to copy the sofrware from the distrib-
ution diskette provided onto the hard drive.
Troubleshooting· Solutions to problems you may encounter in installing your
Coolscan.
Unpacking
Again, if you have not done so already, please review the Open Me First docu-
ments enclosed with your Coolscan before proceeding
in this manual.
Welcome back!
By this point you have:
1. Removed all packaging materials from the scanner and the interface kit.
2. Confirmed that you have received
all the parts that you were supposed to by
using the packing Check List.
3. Checked for damage to the scanner caused by shipping. If you noticed any
damage, you have notified the authorized Nikon reseller from whom you purchased the
scanner.
4. Saved
all shipping and packaging materials in case you need to ship the scanner
in the future.
Nlkon Coolscan In s tallation Guide for Windows
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I

I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
Chapter 1 Introduction
Reg istration
Completing and returning the enclosed Product Warranty Registration Card is
very important to you. It is the only way that we can ensure that you promprly receive
the latest information and software updates from Nikon.
We feel that it is so important
that
we are offering an added incentive -upon receipt of your completed card, we will
send you Nikon's Guide to Scanning , free of charge! This is an invaluable comprehensive
manual on scanning and color reproduction. So, please complete the Product Warranty
Registration Card and mail it today!
Software Backups
As is the practice with any software, it is strongly advised that you make a com-
plete backup
of the enclosed distribution software diskette and store the original master
diskette in a safe place. Always work with the backup copies when installing the Nikon
software.
Minimum PC System Requirements
As an absolute minimum, your PC or compatible computer system must be con-
figured with the following components:
• Microsoft Windows version 3.0 or later (version 3.1 recommended)
• 8 Megabytes
of RAM (16-32 recommended for best performance)
• 80 Megabyte
Hard Disk (300MB or more recommended)
I • Sufficient hard disk space for the Nikon Scanner plug-in, Coolscan Control soft-
ware, SCSI Driver, and resulting image
files
• 8-bit display (24-bit true-color display strongly recommended)
Suggested System Configurations
Following these suggestions will yield the best scanning results:
• Coolscan
is not guaranteed to operate with all third-party SCSI controller cards. It
is for this reason that Nikon has supplied you with a Nikon-approved SCSI con-
troller card for the installation of your scanner.
• For the most pleasing display, set your monitor to display the maximum number
Nlkon Coolscan Installation Guide for Windows
Page 3

Introduction Chapter 1 I
Page 4
of co lors avai lable. Thousands or millions of colors will provide an excellent display I
of your image. If your system only supports a maximum of256 colors you will see a
'dithered' image, which looks 'soft.' The monitor setting has no effect on the actual
quality of your image, which is always captured in 24-bit mode (16.7 million col- I
ors).
• Color images occupy large amounts
of disk space. So make sure your hard disk has I
sufficient free space to store the images you plan to scan. You should have at least
60 megabytes
of free space available if you plan on maximum resolution scans.
I
I
I
I
I
I
I
I
I
I
Nlkon Coolscan Installation Guidefor Windows
I

I
Chapter 2 Setting Up Cooiscan
I Setting Up Coolscan
I
I
I
I
I
I
I
I
I
I
I
I
I
This chapter will introduce you to the main components of the LS-I0 and LS-
IOE models, proper placement of the LS-I DE, safely transporting your scanner, and pre-
cautions for safe operation.
The Front Panel
Let's take a look at Coolscan's front panel, as shown in Figure 2.1. The uncom-
plicated design
of the front panel is indicative of how simple Coolscan is to use. Note
that the front panel of the LS-I0 and LS-I OE is identical. The front panel consists of
the film slot, focus whee/, and power/busy/error indicator light.
Focus Wheel
Power/8usy/E
Indicator LED
rror
Film Slot
In sert Slide Here
---
Nlkon
IUCOOLSCAnUI
~
Figure 2.1 Coo l scan's from panel.
Film Slot
~
~
The film slot is the opening into which you insert yo ur slides or film strips (using
the enclosed film strip holder) for scanning. Slides and film strips are likewise ejected
from the film slot.
A high degree of care must be exercised with the film slot. Since this opening
allows the film to enter the scanner, it thus provides access to its delicate instrumenta-
tion.
Never insert any object into the film slot, other than mounted film or the provided
film strip holder. Flammable materials, metals, water, etc., will cause fire, electri-
cal shock and damage to the unit.
Nlkon Coolscan Insta llation Guide for Windows Page 5

Setting Up Cooiscan Chapter 2 I
Page 6
Focus Wheel I
The focus wheeL is used to fine-focus during scanning operation. This control is
provided because of the wide variery of film and film mounts available, which affect the I
focusing function of the scanner.
The focus wheel must be in its center position during power up. The center posi- I
tion is indicated by the black line across the focus wheel being centered in the visible
portion
of the focus wheel.
Power/Busy/Error Indicator Light I
The green power/busy/error indicator Light has several functions. First, during
power-up it blinks at one-second intervals until Coolscan's power-on self-test and auto- I
calibration has completed. Second, after the self-test and autocalibration is complete,
the light stays on constantly, indicating that Coolscan
is ready to scan. Third, during
scanning, the light will blink at two-second intervals, indicating that the scanning opera-
tion
is in progress. Lastly, the light will blink rapidly if an error is detected, in which I
case the scanner will either recover on its own, or may have ro be powered off and back
on ro effect a reset.
To summarize: I
Power-up: LED blinks at 1second intervals
Coolscan is read y: LED is on constantly
Coolscan is scanning: LED blinks at 2 second intervals
Err or co nditi on: LED blinks rapidly
If you are installing an LS-IO mod el, please pr oceed to the section "T he Rear
Panel- LS-I O. "
The Rear Panel - LS-l OE
The rear panel of the LS-10E is shown in Figure 2.2. Note that there are five
items of interest on the rear panel. These are the AC power switch, AC power connector,
the two SCSI connectors, the SCSI termination power switch, and the SCSIID switch.
Nlkon Coolscan Installation Guide for Windows
I
I
I
I
I
I
I

I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
Chapter 2 Setting Up Cool5can
SCSI Termination
Power Switch
-- ----- --- - --- ---- --,
AC Power Switch -._ - f;rrr~~~R((f~;;;;~;;;;~~~~i))]~~ONt?:OF;;F1
;0; ~:::::::::::::::::::::::::y ;0; $ cnnn $
1~:;:=~1 ERM. PWA,
II SCSI
AC Power Connector
SCSI Locking Clips ---- -.-J
SCSI Connectors ------ ---...I
SCSIID Switch ---- ---- ----------./
Figure 2.2 Cooiscan's rear panel- LS-I DE.
The AC power switch and AC power connector should be familiar to you. The AC
power switch
is used to turn power to the scanner on and off. The AC power connector
receives the female end
of the AC power cord.
The three SCSI-related items on the rear panel will be explained in detail in the
next chapter, "The SCSI Interface."
Please pr oceed to the section "Orientation and Placement of the LS-IOE."
Th e Rear Pan el - LS-l 0
The rear panel of the LS-IO is shown in Figure 2.3. Note that there are three
items
of interest on the rear panel. These are the DC power connector, SCSI connector,
and configuration DIP switch .
ector
ion DIP
SCSI
Pin I
SCSI Conn
Configurat
Switch
External C
Power
Con
onnector
nector
Ic::::t=
I \
I "
" \
~~ I~:·············""""":QI
..... . ........................
Figure 2.3 Coolscan'5 rear panel -LS-I D.
= 1
I I
L.J..J
The configuration DIP switch is shown in Figure 2.3. In almost all cases, the fac-
tory default settings of these switches will be proper for your installation. The default
settings for the configuration DIP switch block are shown
in Table 2.l.
Nlkon CooLscan Insta llation Guide for Windows
Pagel

Setting Up Cooiscan Chapter 2 I
P age 8
The significance of the SCSI connector, DC power connector, and the configura- I
tion DIP switch is di sc ussed in greater detail in Chapter 3, " The SCSI Interface ." For
now, note that the scanner
is set at the factory to SCSI ID #5 and to termination OFF.
Disregard the external
connector at the bottom-left side of Figure 2.3. Th is connector is I
not used when installing the LS-l O.
DIP Sw it ch Def a ult
Us age
1 (Down)
On SCSI ID bit 0 =1
2 (Up)
Off
SCSI ID bit 1 =0
3 (Down)
On SCSI ID bit 2 =1
4 (Up)
Off SCSI Termination = Off
Ta ble 2.1 Factory defaulr setrings for configuration DIP switch block.
Both sides of the LS-l0 are identical. Note the set of two tapped hol es on each
side, ca
ll ed mounting ho l es, as shown in Figu re 2.4. One set of mounting holes on each
side
of the scanner will be used for the internal guide rails. This procedure will be
explained in detail in Chapter 4.
Mounti ng Holes -------,...
Gu ide Ra il ~
Locking Tab ~~
JI
LS - ~:PF:::~~anel --- ~ II ~ : -=====: J
Tapped Holes _____ ~======tL=----"""""""'=- --- -------'
Figu re 2.4 LS-J 0 - side view, with guide rail s.
Please proceed to the sec tion "T ransporting Coolscan."
Orientation and Placement of the lS-l OE
Proper Orientation
The fo ll owing guidelines and precautions should be adhered to when deciding on
orientation
of your LS-l OE.
Let's take a look at Coolscan, as shown in Figure 2.5. Although Coolscan can be
oriented on either of its sides, it is strongly recommended that you orient Coolscan on
Nlkon Coolscan Insta lla tion Guide for Windows
I
I
I
I
I
I
I
I
I
I
I
I

I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
Chapter 2 Setting Up Cool5(an
its base,
or feet, to ensure that it won't fall down. In this orientation, the "Nikon
Coolscan" label
on the front panel will read properly.
Figure
2.5 LS-\ OE, properly oriented.
Proper Placement
The following guidelines and precautions should be adhered to when deciding on
placement of your LS-l DE:
1. Place Coolscan near the computer so that the maximum suggested SCSI cable
length (6 feet)
is not exceeded.
2. Place the scanner
so that it is eas y to reach.
3. Coolscan should be placed on a flat, stable surface,
free from vibration.
4. Keep the scanner away from damaging liquids by locating it away from sinks, cof-
fee pots, etc.
5. Protect Coolscan from dampness, high humidity, and excessive dust or smoke.
Dust and smoke in particular can cause undesirable effects on the scanner's optical
systems, requiring extensive cleaning and maintenance to correct.
6 Avoid locations where a sudden change in temperature might cause condensation
inside the scanner.
7. Protect the front of the scanner from direct sunlight or bright lights.
Nlkon C ools can Insta llatio n Gui de fo r W in dows Pag e9

Setting Up Coolscan Chapter 2 I
Page 10
8. Avoid places with extremely hot or cold temperatures (below 10 degrees Celsius
or above 35 degrees Celsius).
9. Avoid placing Coolscan near heat sources.
10. Avoid any physical shocks to the scanner. Do not store the unit where it will be
subject to vibration.
11. Avoid placing Coolscan too close to other peripherals, and make sure there
is
sufficient air circulation on all sides of the scanner.
Transporting Coolscan
The following guidelines and precautions should be adhered to when transporting
your Coolscan:
1. Always use the original packaging materials.
2. If the original packaging materials are unavailable, use appropriate packaging
materials for precision instruments. If you are shipping your Coolscan back to
Nikon, Nikon will
not be responsible for damages incurred due to improper packag-
ing.
3. The focus wheel must be turned all the way downward to the end of its travel
before shipping.
4. Pay special attention to the air or courier service to ensure that they can properly
handle this precision instrument.
If y ou are installing an LS-10, please proceed to the secti on "General Safety
Precautions."
Connecting AC Power to the LS-l0E
I
I
I
I
I
I
I
I
I
I
The scanner's AC power cord is a standard three-wire grounding plug. This plug I
will fit only a grounded AC outlet. Intended to be a safety feature, the grounding connec-
tor should not be defeated. Additionally, an electronic surge protector is highly recom-
mended. I
I
Nlkon Coolscan Inst allation Guide for Windows
I

I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
Chapter 2 Setting Up Coolscan
Safety Precautions When Connecting
AC Power to the LS-l0E
The following precautions should be complied with when connecting AC power
to the scanner:
1. Always use a proper power source of 100 to 240VAC, 50 to 60 Hz.
2.
Do not hold the cord itselfwhen plugging or unplugging the AC power. Hold
the plastic portion
of the connector itself rather than pulling on the cord.
3.
If you lose the supplied power cord, use an appropriate replacement that is subject
to the voltage
of the power source, using the following guidelines:
•
If 110V-250VAC power is u se d, make sure that the plug is rated at 250V AC,
15A (NEMA 6P-16).
•
If a 100-11 OV AC power source is used, the plug must be rated at 120V AC, 10A.
• The gauge of the cord must be at least 18 gauge (remember, the smaller the gauge,
the thicker the wire. For example,
18 gauge is thicker than 20 gauge).
•
The cord must be approved by the safety regulations of the country where it is
used.
• A properly grounded three-conductor AC power source
is required in order to
reduce electrical noise and the possibility
of electrical shock.
AC Power Safety Precautions - LS-l OE
The following safety guidelines should be adhered to concerning AC power and
Coolscan:
1. Once the AC power source is turned off, either through the Coolscan power
switch or other AC power switch, wait at least 5 seconds before powering on again
to ensure the proper power up sequence.
2. Don't unplug the AC power cord from the AC source or from the Coolscan AC
power connector while the Coolscan AC power switch
is on. To be completely safe,
don't unplug any other peripheral while Coolscan
is powered on.
3.
Do not move Coolscan while its power is on.
Nlkon Coolscan Installa tion Guide for Windows
Page 11

Setting Up Cooiscan Chapter 2
Page 12
4. Never disassemble the scanner. It is very dangerous to touch the devices inside
the unit due to high voltages, and there are no user serviceable parts inside. Such
action may be a violation
of your Nikon Limited Warranty, and would render the
warranty null and void.
General Safety Precautions
Always power off Coolscan and/or remove the power cord from the AC
source when anyone of the following occurs:
1. The AC power cord (LS-l DE only) or 4-pin DC power plug (LS-lDonly)
becomes damaged.
2. Any liquids are spilled into the scanner.
3.
The scanner is exposed to excessive moisture.
4.
The housing of the scanner has become damaged (LS-l DE only).
5.
The housing is opened (LS-IDE only).
6. You suspect the scanner
is not functioning properly.
7.
If something unusual occurs, such as abnormal noise, odor, or smoke. In this
case, bring your Coolscan to the dealer where it was purchased or to an authorized
Nikon repair facility.
8.
Do not attempt to insert slide mounts into Coolscan that are over 3mm thick.
Remount the
film into an appropriate holder.
9.
Do not attempt to insert slide mounts into Coolscan that are not flat. Remount
the
film into an appropriate holder.
10.
Do not force a slide or the film strip holder into the Coolscan film slot. A
smooth gliding action should be used during both insertion and removal.
11. Do not attempt to remove or reposition the slide or film strip holder in the
Coolscan film slot during the scanning process.
Nlkon Coolscan Installation Guide for Windows
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I

I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
Chapter 2 Setting Up Cooiscan
Installation Precautions
The following guidelines should be observed when installing Coolscan:
1. Make certain that power to all instrume nt s directly connected to Coolscan (via
SCSI)
is turned offbefore beginning the installation. This includes the AC power
switch on Coolscan (LS-I0E only).
If yo u are installing an L5-10, there is no AC power switch since it relies on the PC's
power. Therefore, make sure that the PC's power is off.
2. Turn offthe power to all peripherals connected to the computer (displa y, printer,
etc.).
3.
If yo ur PC has a key-lock facility, turn the key to the unlock position.
4. Unp lug the AC power cable to the Pc.
5. When mounting Coolscan into the PC (L5-10 only), be especially mindful to
eliminate electrostatic discharge, as it can damage the scanner.
Electrostatic discharge will damage the scanner if you touch its SCSI connector
pins.
Do not touch the pins.
Nlkon Coolscan Installation Guide for Windows Page 13
