Nikon Super Coolscan 9000 ED Operating instructions

作成承認印 配布許可印
Copyrigh ｃ2004 by Nikon Corporation.
All Rights Reserved.
無断転載を禁ず !!
Printed in Japan March 2004
VRA51701-R.3607.A
VRA51701
REPAIR MANUAL
Ｍ
サービス
計画課

VRA51701-R.3607.A
-LS-9000 -
CONTENTS
SPECIFICATIONS M1-M3
DISASSEMBLING
External cover D1
Main PCB, Power-PCB D2
Illumination unit, Base unit D3
Stage carriage unit D4
Stage carriage lead screw D5
AF carridge unit D6
AF carriage unit D7
Lead screw, AF motor, mirror uni D8
ASSEMBLY
Mirror / AF sensor A1
Assemble AF screw shaft A2
Assemble AF screw shaft A3
Assemble AF motorA4
AF carriage unit A5
Assemble AF carriage unit A6
AF carriage unit connections A7
Stage carriage A8
Stage carriage screw shaft unit A9
Assemble Screw shaft A10
Procedure for mounting SCAN motor unit A11
Stage carriage unit A12-A13
Holder motor unit A14
Illumination unit A15
Assemble Illumination unit A16
Base unit A17
Main PCB / Power unit A18
Front panel A19-A21
External view A22
Adjustments A23-A50
ELECTRICITY
Block diagram E1
Wiring E2
INSPECTION STANDARD & TOOL
Inspection Standard R1-R5
Tool List T1-T2

VRA51701-R.3607.A
- M1 ･ -
LS-9000
Media Negatives and positives, in color and monochrome
35-mm lm 1–2 strips of 1–6 frames. Up to 3 frames of 24 × 48 mm or 24 × 65 mm panorama
lm can be scanned with optional FH-869GR lm holder.
35-mm slides 1–5 slides with mounts 1.0–3.2 mm thick.
Medium-format lm 1–4 frames (6 × 4.5), 1–3 frames (6 × 6), or 1–2 frames (6 × 7, 6 × 8, or 6 × 9).
Medium-format slides Slides with mounts 1.0–3.2 mm thick can be scanned with optional FH-869M
lm holder.
Scanning system Fixed optical, movable media, parallel single-pass scanning system
Light source Red, Green, Blue, and Infrared (RGBIr) LEDs; slit light source with rod and dis-
perser
Image sensor 10,000 pixel three-line monochrome linear CCD image sensor
Color separation Performed by RGB LEDs
Optical resolution Up to 4000 pixels per inch
Analog-to-digital (A/D)
conversion
16 bits per color
Output Full color or greyscale at 8 or 16 bits per channel
Focus Auto and manual
Interface IEEE 1394
Power supply AC 100–240 V, 50/60 Hz
Operating environment +10–+35 °C (+50–+95 °F) at a humidity of 20–60%
Size and weight 249 × 498.5 × 202 mm/9.8˝ × 19.6˝ × 8.0˝ (W × H × D), 9 kg/19.8 lb (approx.)
16-mm lm 1–3 strips of 1–20 frames can be scanned with optional FH-816 lm holder.
Glass microscope slides 1–3 prepared glass microscope slides (26 × 76 mm, 0.8–1.5 mm thick) can be
scanned with optional FH-8G1 lm holder.
FH-
835S
FH-
835M
FH-869S, FH-869G
Aperture (mm)
Scan range (pixels) 4000
×
5904
5905
×
4032
8964
×
6696
25.4
×
37.5
37.5
×
25.6
56.9
×
42.5
Aperture/scan range
6 × 4.5
8964
×
8964
56.9
×
56.9
6 × 6
8964
×
11016
56.9
×
70.0
6 × 7
8964
×
12204
56.9
×
77.5
6 × 8
8964
×
13176
56.9
×
83.7
6 × 9
8964
×
13176
56.9
×
83.7
5.9×8.2
2362
×
3384
15.0
×
21.48
FH-
816
7248
×
3780
46.02
×
24.0
FH-
8G1
Power consumption 27 W or less; 14 W or less in standby mode
Specication

VRA51701-R.3607.A
- M2 ･ -
LS-9000
* Times for positive lm scanned at input resolution of 4000 dpi (2000 dpi when FH-869S is used with Digital DEE) and bit depth of 16 bits (CMS
on) using Nikon Scan 4 on Pentium 4 3.06 GHz FSB 533 MHz computer with 1 GB RAM, Windows XP Professional, IEEE 1394 interface, and
1024 × 768 display.
† Input resolution set to 2000 dpi
Scanning time
(Time to display image
when Preview button is
clicked, or when Scan
button is clicked follow-
ing preview. Times do
not include autofocus or
holder positioning.)*
With FH-835M 35-mm slide mount holder
With FH-869S 120/220 lm holder
Supplied Film Holders
FH-835S 35-MM STRIP FILM HOLDER
Size and weight 130 × 320 × 17 mm/5.1˝ × 12.6˝ × 0.7˝ (W × H × D), 200 g/7.1 oz. (approx.)
Film 1–2 strips of 35-mm lm, each with 1–6 frames
FH-835M 35-MM MOUNTED FILM HOLDER
Film 1–5 35-mm slides with mounts 1.0–3.2 mm thick and 49.0–50.8 mm wide
Size and weight 130 × 345 × 17 mm/5.1˝ × 13.6˝ × 0.7˝ (W × H × D), 180 g/6.3 oz. (approx.)
FH-869S 120/220 STRIP FILM HOLDER
Size and weight 130 × 320 × 17 mm/5.1˝ × 12.6˝ × 0.7˝ (W × H × D), 290 g/10.2 oz. (approx.)
6 × 4.5
6 × 6
6 × 7, 6 × 8, 6 × 9 1–2 frames
1–3 frames
1–4 frames
Film Medium-format (120/220) lm, 5.9 × 8.2 cm electron microscope lm
DEE Preview Scan
40 s
52 s
41 s
57 s
1 min 27 s
1 min 31 s
13 s
28 s
12 s
14 s
14 s
26 s
Off
Off
Off
Off
Off
On
GEM
Off
Off
Off
Off
Off
On
Scan Image
Enhancer ROC
Off
On
Off
Off
Off
Off
Off
On
Off
Off
Off
Off
ICE
Off
Off
On
Off
Off
Off
2 min 33 s
33 s
On
On
On
On On
DEE Preview Scan
3 min 05 s
8 min 55 s
3 min 14 s
7 min 05 s
2 min 20 s
11 min 40 s
38 s
1 min 26 s
38 s
40 s
38 s
1 min 26 s
Off
Off
Off
Off
Off
On†
GEM
Off
Off
Off
Off
Off
On
Scan Image
Enhancer ROC
Off
On
Off
Off
Off
Off
Off
On
Off
Off
Off
Off
ICE
Off
Off
On
Off
Off
Off
16 min 00 s
2 min 24 s
Off
On
On
On On
Supplied Film Holders

VRA51701-R.3607.A
- M3 ･ -
LS-9000
Optional Film Holders
FH-869M 120/220 MOUNTED FILM HOLDER
Size and weight 130 × 320 × 17 mm/5.1˝ × 12.6˝ × 0.7˝ (W × H × D), 170 g/6.0 oz. (approx.)
Film One 6 × 4.5 or 6 × 6 slide and one 6 × 7, 6 × 8, or 6 × 9 slide
FH-8G1 MEDICAL HOLDER
Size and weight 130 × 345 × 17 mm/5.1˝ × 13.6˝ × 0.7˝ (W × H × D), 190 g/6.7 oz. (approx.)
Slide
Slide cover
Total thickness No more than 2 mm, including adhesive
25 × 60 mm with thickness of 0.18 mm or less
26 × 76 mm, 0.8–1.5 mm thick
Media 1–3 prepared glass microscope slides
FH-869G 120/220 STRIP FILM HOLDER WITH GLASS
Size and weight 130 × 300 × 17 mm/5.1˝ × 11.8˝ × 0.7˝ (W × H × D), 300 g/10.6 oz. (approx.)
6 × 4.5
6 × 6
6 × 7, 6 × 8, 6 × 9 1–2 frames
1–3 frames
1–4 frames
Film Medium-format (120/220) lm, 5.9 × 8.2 cm electron microscope lm
FH-869GR ROTATING 120/220 STRIP FILM HOLDER WITH GLASS
Angle adjustment ±5 °
6 × 4.5
6 × 6
6 × 7, 6 × 8, 6 × 9 1–2 frames
1–3 frames
1–4 frames
Film Medium-format (120/220) lm, 5.9 × 8.2 cm electron microscope lm, 35-mm
panorama lm with frame size of 24 × 48 mm or 24 × 65 mm
Size and weight 130 × 320 × 17 mm/5.1˝ × 12.6˝ × 0.7˝ (W × H × D), 330 g/11.6 oz. (approx.)
FH-816 16-MM STRIP FILM HOLDER
Film 1–3 strips of 16-mm lm, each with 1–20 frames
Size and weight 130 × 375 × 17 mm/5.1˝ × 14.8˝ × 0.7˝ (W × H × D), 250 g/8.8 oz. (approx.)
Optional Film Holders

VRA51701-R.3607.A
- Ｄ1 ･ -
LS-9000
Disassembly
Notes: ① Be sure to remove the power wire before disassembly.
② When disassembling, make sure to memorize the processing state of wires and FPCs, screws to be xed
and their types, etc.
③ Because ICs are easily damaged by static electricity, be sure to get yourself earthed/grounded when
holding the main PCB and FPCs.
External cover
・Take out 8 screws at the back (#192) and 10 screws at the bottom (#192), then remove the side cover by sliding it.
(Removing 2 rubbers (#36) is unnecessary except when they are replaced.）
・Remove the rear panel (#32) by taking out 3 screws (#192) and 2 screws (#188). The connector shield-plate (#46)
comes off accordingly.
・Remove the connector on the main PCB A-part (which is connected from the front cover).
・Uncover the front cover by taking out 4 screws (#192).
#188
ICE
ABS
#31
#192 x8
#192 x4
#32
#36 x2
#192 x10
#46
#192 x3
x2
Front cover
Main PCB A-part
#192×8
#192×10
#36×2
#31
#188×2
#192×4
#46
#32
#192×3

VRA51701-R.3607.A
- Ｄ2 ･ -
LS-9000
B
#560
A
ABS
#50
#522
#197
#192 x4
A
B
#35
#541
#192 x6
#45
#43
#42
#516
#551 #192 x4
#517
#510
#509
・ Remove the main PCB (#541) by taking out 6 screws (#192).
・ Disconnect 6 connectors on the main PCB (#560, #551, #516, #509, #510, and #517), then remove the main PCB.
･ Remove the spring (#45) and unhook the A-part of the power SW (#42).
･ Remove the power-PCB (#522) and insulating sheet (#50) by taking out 1 screw (#197) and 4 screws (#192).
･ Remove the power base (#35) by taking out 4 screws (#192).
Main PCB, Power-PCB

VRA51701-R.3607.A
- Ｄ3 ･ -
LS-9000
#47
#197
x4
#192 x2
#192
x2
#192 x6
#34
#48 x4
Illumination unit, Base unit
・ Remove the relay-FPC from the connector of the illumination-PCB.
・ Remove the illumination unit from the base unit (#121) by taking out 4 screws (#192).
･ Remove the base unit from the bottom plate (#34) by taking out 4 screws (#197).
･ Remove the PCB support-plate (#47) by taking out 6 screws (#192).
Illumination PCB
Illumination unit
＃121
Relay-FPC
Connector

VRA51701-R.3607.A
- Ｄ4 ･ -
LS-9000
Stage carriage unit
・ Disconnect the connector of the holder motor by pulling it in the
direction indicated by the arrow.
・ Remove the holder motor unit by taking out 3 screws (#194).
・ Take out 4 screws (#194) and remove 4 retaining springs (#104).
･ Take out 2 screws (#191) then the stage carriage comes off with 2
guide shafts (#123) attached.
・ Pull out 2 guide shafts (#123).
#194×3
Connector
Stage carriage Holder motor unit
Screw shaft
#194×3
#191×3
#194×4
#104×4
#123×2

VRA51701-R.3607.A
- Ｄ5 ･ -
LS-9000
Stage carriage lead screw
・ Loosen 4 screws of the coupling (#137).
・ Take out 2 screws (#192) and remove the SCAN motor unit.
＊ Note:
Whenever the SCAN motor unit is detached, reassemble the motor unit by using the SCAN motor assembling tool.
・Take out 2 screws (#194) then remove 2 retaining springs (#104) and screw shaft.
＊ Note:
Remove the screw shaft with care because the bearing (#135), washer (#134) and spring (#136) jump out of the shaft.
・ Remove #151 by taking out the screw (#194).
#135
#136
#134
#137
Screw shaft SCAN motor unit
#194×2
#192×2
#104×2
#194
#151
4 screws (#137)

VRA51701-R.3607.A
- Ｄ6 ･ -
LS-9000
AF carridge unit
・ Turn the base unit upside down for disassembly.
・ Set aside the connector wire (#517) that is connected from the AF sensor by pulling it in the direction of the below arrow.
・ Separate the screw shaft and AF carriage by taking out 2 screws (#191).
・ Remove the AF carriage by taking out 4 screws (#194) and 4 retaining springs (#104).
・ Pull out 2 guide shafts (#103).
＊ Note:
Whenever the lens unit and CCD PCB are disassembled or replaced from the AF carriage, the CCD adjustment is necessary.
Screw shaft
AF carriage
Lens unit
CCD PCB
#517
#191×2
#106
#194×4
#104×4
#103×2

VRA51701-R.3607.A
- Ｄ7 ･ -
LS-9000
AF carriage unit
・ Remove the light-shielding cover (#110) by taking out 4 screws (#194).
・ Remove the CCD holder (#108) by taking out 3 screws (#193). The adjustment washers (#109A-G) come off accordingly.
・ Remove the CCD unit (#542) from #108 by taking out 2 screws (#181).
・ Remove the retaining plate (#B107) by taking out the screw (#192).
・ Remove the lens unit (#B91) by lifting it in the direction indicated by the arrow.
＊Note:
Whenever the lens unit (#B91) and the CCD holder (#108) and the CCD unit (#542) are disassembled or replaced, the CCD
adjustment (ref. "Adjustment" chapter) is necessary.
#B091
#181 x2
#193 x3
0
#192
#542
#B107
#194 x4
#110
#109A
#109B
#109C
#109D
#109E
#108
#106
#B107
#B91

VRA51701-R.3607.A
- Ｄ8 ･ -
LS-9000
Lead screw, AF motor, mirror unit
・ Remove the AF motor (#510) by taking out 2 screws (#192).
＊ Note:
Whenever the AF motor (#510) is disassembled or replaced, reassemble it by using the AF motor backlash adjustment
tool.
・ Remove the screw shaft by taking out 2 screws (#194) and 2 retaining springs (#104).
・ Remove the mirror G1 by taking out 2 screws (#194) and the spring (#153). (Be careful that the mirror G1 is glued.)
＊ Note:
Whenever the mirror G1 is disassembled or replaced from the base unit (#121), the CCD adjustment is necessary.
・ Remove the AF sensor unit (#525) by taking out the screw (#195).
Screw shaft
#194×2
#153
#121
#510
#192×2
#517
#525
#195
#194×2
#104×2

VRA51701-R.3607.A
- A1 ･ -
LS-9000
Assembly
Mirror / AF sensor
・ Fix the AF sensor (#525) with the screw (#195), and connect the cable (#517).
・ Mount the mirror (#G1) on the base (#121), and x it with the spring (#153) and 2 screws (#194).
＊ Note: Mount #G1 so that the mirroring side faces the base (#121).
#194 x2
#195
#525
#153
G1
#517
#121
Adhesive: EDA1021 Adhesive: EDA1021
・ Attach the mirror (#G1) and base (#121) at 4 parts (refer to below) with the adhesive (EDA1021), and leave it about 4
hours until the adhesive completely dries.

VRA51701-R.3607.A
- A2 ･ -
LS-9000
Complete AF screw shaft unit
Assemble AF screw shaft
・ Apply the grease on the screw shaft (#112), and turn the nut (#113) on it until reaching the below position.
・Put #114, #115, #116, #117, and #119 in order into the screw shaft (#112), then x them with the screw (#194).
(Apply the grease (G-94051) on the key part of the nut housing (#114), and assemble it with its inner shallower part facing
#113-side.)
#119
#194
#116
#112
#117
#114
#115
#116
#113
・ Insert #116. #116
・
Turn #113 until approximately the 5th pitch of the
screw thread (#112) can be seen, then enter the
key of #114 into the key groove of #113.
Grease: G-940501
Inner shallower part
Chamfer should face
#114-side.
Grease: G-940501
Grease: Sumitec 331 #112
#113
#113
#112 #114
Key part

VRA51701-R.3607.A
- A3 ･ -
LS-9000
Assemble AF screw shaft
・ Mount the AF screw shaft on the base (#121).
・ Attach 2 retaining springs (#104) with 2 screws (#194).
#194
#104
AF carriage screw shaft
#121

VRA51701-R.3607.A
- A4 ･ -
LS-9000
Assemble AF motor
・ Return the base (#121) to the correct position.
・ Attach the AF motor (#510) temporarily with 2 screws (#192).
【Adjustment】 AF motor backlash adjustment
1) Attach the AF motor backlash adjustment tool (J61191) to the base (#121) with the tool screw.
2) Loosen 2 screws (#192) and turn the AF motor clockwise. Then unhand and tighten 2 screws (#192).
(The backlash adjustment is made by the weight of the tool (J61191).)
#510
#192×2
J61191 Tool screw
#121
・ After the AF motor is attached, perform wiring work.
#121

VRA51701-R.3607.A
- A5 ･ -
LS-9000
#B091
#181 x2
#193 x3
0
#192
#542
#B107
#194 x4
#110
#109A
#109B
#109C
#109D
#109E
#108
#106
AF carriage unit
・
Assemble the lens unit (#B91) into the AF carriage (#106), and hook the A part of the retaining plate (#B107) to the groove
of #106. Then x it with the screw (#192). （＊ Note: Assemble #B91 with its marking just upward. )
・ Attach the light-shielding cover (#110) with 4 screws (#194).
・ Attach the adjustment washers (#109A-G) and the CCD holder (#108) with 3 screws (#193).
（Initial value of the adjustment washer: 2 mm (109F×1））
・ Attach the CCD unit (#542) with 2 screws (#181).
A
Marking
#B91
#109A ～G
＊ Note: Whenever the lens unit (#B91), CCD holder (#108), and CCD unit (#542) are disassembled or replaced, the CCD
adjustment (refer to "Adjustment" chapter) is necessary.

VRA51701-R.3607.A
- A6 ･ -
LS-9000
・ Insert 2 guide shafts (#103) into #106.
・ Turn the base (#121) upside down, and assemble the AF carriage unit.
Assemble AF carriage unit
＃121
AF carriage screw shaft
AF carriage unit

VRA51701-R.3607.A
- A7 ･ -
LS-9000
・ Apply the grease (SUMITEC331) on 8 contact-parts of the guide shaft (#103) and the AF carriage holes.
・ Fix 2 guide shafts (#103) with 4 retaining springs (#104) and 4 screws (#194).
・ Connect the screw shaft and the AF carriage unit with 2 screws (#191).
AF carriage unit connections
Grease (SUMITEC331)
8 parts in total
・Take A parts between forenger and thumb, and pull it in the direction indicated by the arrow. Check if the AF carriage
unit moves back smoothly when it is released.
・ Put the harness of #517 in position.
#103×2
#191×2
A
Harness of #517
#104×4
#194×4
