nilan CTS 602 User manual

VPM 120
VPM 240
VPM 480
VPM 560
Version: 10.00, 13-04-2015
Software-version: 2.30
User manual
CTS 602 by Nilan

Table of contents
Table of contents ............................................................................................................................ 2
Figure table .................................................................................................................................... 2
Introduction..................................................................................................................................... 3
Types of units ................................................................................................................................. 4
Review of the thermometer sensors ............................................................................................... 5
CTS 602 panel ............................................................................................................................... 6
How to use the menu:................................................................................................................. 6
Review of the menus ...................................................................................................................... 7
Menus......................................................................................................................................... 7
Operating mode.............................................................................................................................. 8
Main menu.................................................................................................................................. 9
Show alarms............................................................................................................................. 10
Show data................................................................................................................................. 13
User select................................................................................................................................ 14
Setting of clock.......................................................................................................................... 15
Week programme ..................................................................................................................... 16
Factory settings for the 3 weekly programs:.............................................................................. 16
Cooling ..................................................................................................................................... 19
Night Cooling ............................................................................................................................ 20
Humidity.................................................................................................................................... 21
CO2........................................................................................................................................... 22
Air exchange............................................................................................................................. 23
Air filter ..................................................................................................................................... 24
Temp. control............................................................................................................................ 25
Setting of language................................................................................................................... 26
Accessories/spare parts ............................................................................................................... 27
Figure table
Figure 1: Types of units .................................................................................................................. 4
Figure 2: Thermometer sensors...................................................................................................... 5
Figure 3: CTS 602 panel................................................................................................................. 6
Figure 4: Menu headlines ............................................................................................................... 7
Figure 5: Main menu....................................................................................................................... 8
Figure 6: Headlines in the ”Main menu” .......................................................................................... 9
Figure 7: The ”Show alarms” menu............................................................................................... 10
Figure 8: The ”Show data” menu .................................................................................................. 13
Figure 9: The ”User select” menu ................................................................................................. 14
Figure 10: Setting of clock ............................................................................................................ 15
Figure 11: The “Week program” menu .......................................................................................... 17
Figure 12: The ”Heating surface” menu ........................................................................................ 18
Figure 13: The ”Cooling” menu ..................................................................................................... 19
Figure 14: The ”Night Cooling” menu............................................................................................ 20
Figure 15: The " Humidity " menu ................................................................................................. 21
Figure 16: The "CO2" menu .......................................................................................................... 22
Figure 17: The ”Air exchange” menu ............................................................................................ 23
Figure 18: The ”Air filter” menu ..................................................................................................... 24
Figure 19: The ”Temp. control” menu............................................................................................ 25
Figure 20: The ”Language” menu ................................................................................................. 26

May be subject to change page 3 af 28
Introduction

Please control that the following documents have been delivered together with the unit:
- Directions for assembly and use
- CTS 602 directions (this document)
- Electrical chart
The purpose of this manual is to clearly show the menus and possibilities of the CTS 602 control.
This manual may describe functions that are not accessible in your unit.
The directions can be used for all types of units described in figure 1 page 4.
PLEASE NOTE: If the system is damaged in any way, it must be inspected and repaired by li-
censed personnel.

May be subject to change page 4 af 28
Types of units
The control is made for the following ventilation units.
The above figure shows the respective options of each model.
The cooling option is achieved by installing a four-way valve that renders is possible to turn the
process from heating to cooling.
Nr.
Type
Heated air
Heating surface, water
Heating surface, electrical
Frost-protected heating coil
Option for cooling air
Low pressure protection
High pressure protection
Compressor
De-icing
1
VPM 120
x
x
x
x
x
x
x
x
x
1
VPM 240
x
x
x
x
x
x
x
x
x
1
VPM 360
x
x
x
x
x
x
x
x
x
1
VPM 480
x
x
x
x
x
x
x
x
x
1
VPM 560
x
x
x
x
x
x
x
x
x
Figure 1: Types of units

May be subject to change page 5 af 28
Review of the thermometer sensors
Figure 2: Thermometer sensors
Explanation for figure 2:
T1- is the thermometer sensor for the fresh air and should be placed at the north side of the
building.
T2 - is the thermometer sensor for the inlet air at the fan (without heating surface).
T5 - shows the temperature of the condenser.
T6 - shows the temperature of the evaporator.
T7 - is the thermometer sensor for the inlet air after a heating surface.
T10 - is the thermometer sensor for the exhaust air in a room (accessory).
T15 - is the thermometer sensor in the CTS 602 panel.
The temperature of the sensors can be read in the “Show data” menu.

May be subject to change page 6 af 28
CTS 602 panel
On the CTS 602 control panel, press:
- ESC to return to the previous menu
- qp to scroll upwards or downwards through the menus or to
adjust the setting of an activated menu option
- ENTER to activate a menu option
- ENTER to confirm a new menu option setting
- OFF to switch off the controls
- ON to switch on the controls
Figure 3: CTS 602 panel
The following is indicated by the light-emitting diode at the front of the CTS 602 panel:
Constant yellow light: the compressor is in operation
Flashing yellow: the unit is in alarm condition
The panel can show 2 lines of text with each 8 characters.
The upper line shows a guiding text.
The bottom line shows the matching values to the guiding text.
The text in the display in “on” as long as there is power to the unit and will not turn off even though
the unit is set to “off” or has not been operated for a longer period of time.
How to use the menu:
It is possible to adjust a value or a function by finding the matching menu via por q.
To activate the desired menu press ENTER.
To adjust the settings of the value press ENTER until the value flashes.
The adjustment can now be done viapq.
To save the chosen value press ENTER.
It is advisable to have the panel and/or the review of the menus near by during the reading of the
menus.
If none of the press buttons are activated for one minute the control will automatically return to the
main menu.
If you are in the middle of the programming when the control returns to the main menu all data will
be saved if they previously are saved by pressing ENTER. It is always possible to return to the
programming to continue.

May be subject to change page 7 af 28
Review of the menus
Menus
The control will have the main menu as starting point, (the menu in the full-drawn frame). From
here it is possible to go through the other menus via pq.
Option for choosing a low ventilation level at a low outside temperature.
Main menu: displays operating status.
Press ESC to return to the main menu.
Operating mode (heat, auto, cool), temperatures, fan speed, type of unit and
software version.
Alarm display and reset.
Alarm log containing the latest16alarms.
SHOW
ALARMS
SHOW
AUTO
>2< 19°C
USER Options: exhaust, inlet, ventilation, OFF. The function selected is activated via a
switch or pressure.
10-09-13
TM .. 12:10 Date and time settings. The time and date must be reset if the system has been
without power for more than24 hours. Summer and winter time must also be set
manually.
Weekly program can be set to ON or OFF. When the program is active, 1, 2
or 3 is displayed in the main menu.
SELECT
WEEK
PROGRAM
COOLING Option for choosing a higher ventilation level when the system is
cooling via open bypass valve.
AIR
EXCHANGE
AIR
FILTER
TEMP.
CONTROL
LANGUAGE
ENGLISH
The controls are factory set to activate a filter alarm every 90 days. The alarm
is reset in the VIEW ALARMS menu.
Setting the minimum temperature required in order for the bypass valve to
close. Maximum inlet air temperature can be set for a heating element.
Select the required language: English,German,French,Swedish,
Danish,Norwegian or Finnish.
HEATING The system has a heating surface installed. The heating surface can be
chosen ON/OFF. Frost-protection is still active when OFF is chosen.
SURFACE
DATA
HUMIDITY Offers the option to set a higher/lower fan speed at a high/low humidity level
CO2The menu is only accessible when the unit has CO2-sensors
installed
NIGHT Setting of the temperature for passive cooling at night
COOLING
Figure 4: Menu headlines

May be subject to change page 8 af 28
Operating mode
The main menu shows 3 different values: operating mode, ventilation step and temperature. Those
values indicate the state of the unit and are selected by the user.
The main menu is automatically shown 15 seconds after the unit is electrically connected and is
now ready to be set.
By pressing ESC one or more times you will automatically return to the main menu.
AUTO *
>2< 19°C
Ventilation step
* : the ”USER
SELECT” menu is
active
1,2,3 : week
programme
is active
L: low ventilation
step at low outdoor
temperature
Operating mode: OFF
AUTO
COOL
HEAT
Desired
roomtemperature
(5-30°C).
Figure 5: Main menu
Desired room temperature can be adjusted by pressing ENTER once. The number at °C flashes
and the value can be set via pq. The desired value must be approved by pressing ENTER once.
The operating mode can be adjusted by pressing ENTER twice. The actual mode is flashing and
can be set via pq and approved by pressing ENTER once. In “AUTO”-mode the bypass-draught
control is automatically opened or closed according to the temperature setting.
The ventilation step can be adjusted by pressing ENTER three times. The actual ventilation step is
flashing and can be set via pq and approved by pressing ENTER once.

May be subject to change page 9 af 28
Main menu
The main menu is displayed approx. 15 seconds after the power has been connected. Options that
flash are indicated by ” ”.
The options available on the main menu are shown in the figure below:
You will always return to the main menu if you press ESC one or more times.
On the CTS 602 control panel, press:
- ESC to return to the previous menu
- qp to scroll upwards or downwards through the menus or to
adjust the setting of an activated menu option
- ENTER to activate a menu option
- ENTER to confirm a new menu option setting
- OFF to switch off the controls
- ON to switch on the controls
AUTO
>2< ”19°C”
AUTO
”>3<” 19°C
”COOLING”
>2< 19°C
”HEAT”
>2< 19°C
”AUTO”
>2< 19°C AUTO
”>2<” 19°C
ENTER ENTER
AUTO
>2< 19°C
AUTO
>2< ”5-30°C”
ENTER
In AUTO mode the unit
automatically choses
cooling or heating
according to the desired
room temperature. Week
programme is possible.
Heating according to the
desired room
temperature.
Week programme is
NOT optional.
Cooling according to the
desired room
temperature + neutral
zone (+5 °C).
Week programme is
NOT optional.
The indicated ventilation
step applies for the
exhaust.
Figure 6: Headlines in the ”Main menu”

May be subject to change page 10 af 28
Show alarms
If the unit is in a state of alarm the yellow light-emitting diode on the front of the CTS 602 panel will
flash.
The ”Show alarms” menu indicates the type of alarm and the time of the alarm. This is also the
menu where the alarm should be reset.
06-05-30
TI 11:32 ENTER
06-05-30
TI 10:28
STATUS
ALARM
T1 20°C
T2 20°C
T3 0,00
T4 0,00
OUT 1-8
00000000
OUT 9-16
00000000
OUT 17-24
00000000
ALARMLOG:
Is retained after
power has been
disconnected.
Contains the latest 16
alarms. AL 1 is the
most recent.
ALARM
DFR EXCH
SHOW
ALARMS ENTER ENTER
ALARM 7
FROST
ALARM 19
FILTRE
ALARMLOG AL 1:
DEFROST
AL 2:
FILTER
AL 3:
FROST
ALARM LIST:
Displays 0-3 active
alarms.
The most recent and
most critical are
displayed first. The
list is deleted if power
is disconnected.
ALARMLOGDATA:
Data readings at the
time the alarm was
activated.
ENTERENTER
00-00-00
TI 00:00
Alarm reset: Alarms must be reset
individually. Only inactive alarms
can be reset. All alarms when
Alarm 0 None is displayed.
71
Figure 7: The ”Show alarms” menu

May be subject to change page 11 af 28
Alarm codes are given because of a fault situation or when it is important to inform the user.
The alarms are divided into the following categories:
C Critical Operation is partly or completely stopped as long as the alarm is active.
W Warning These types of alarms will become critical if the problem is not solved
quickly.
I Informative Normal operation is not affected. Alarm disappears when it is reset.
Alarm
code
Categori
Text in
display
Description/ cause
How to remedy alarms
00
--
--
No alarms
01
C
HARDWARE
Error in control hardware
Contact service if reset
does not help
02
C
TIMEOUT
Warning alarm W has become
a critical alarm.
Note and reset the alarm.
Contact service if alarm
does not disappear.
03
C
FIRE
Critical alarm.
The system has stopped be-
cause the fire thermostat has
been activated.
If there has not been a fire
please contact service.
04
C
PRESSURE
High or low pressure switch in
the cooling circuit has been
triggered, probably caused by:
High pressure:
Extreme hot
Cloaked filter
Defective fan
Low pressure:
Extreme cold
Unit might have lost coolant
Cloaked filter
Defective fan
Check for errors and reset
alarms.
If you are unable to reset
the alarm or if the alarm
occurs often please contact
service.
05
C
DOOR
The inspection door is open
Close the door
06
C
DEFROST
The unit is defrosting.
The frost protection of the heat
recovery system is insufficient
and the unit will stop. This can
be caused by extreme low
outdoor temperatures
Contact service if reset
does not help. Note the
actual sensor temperatures
from the menu “Show data”
to help service.
07
C
FROST
1) Frost-protection of heating
surface: the inlet air over
the heating surface is too
cold which can be caused
because the by-pass
damper is open.
2) The water from the central
heating is too cold.
1) Close by-pass damper,
activate heating surface
and reset alarm.
2) Check that the heating
supply for the heating
surface is OK. Reset
alarm when fault has
been repaired.
08
C
FROST
One of the temperature sen-
sors in the unit is short circuit
or defect.
Note the sensor and contact
service.
10
C
OVERHEAT
Electrical heating surface has
been overheated due to lack of
airflow.
Check filters, air intake and
ventilators. Reset alarm.
Contact service centre if
system fails to operate sat-

May be subject to change page 12 af 28
isfactorily.
11
C
AIRFLOW
Lack of airflow in inlet. See
alarm code 10.
See alarm code 10
12
C
THERMO
Relay is triggered ventilation.
This may be due to defects in
the fan or low voltage
Contact service
14
C
SENSOR
The selected steering sensor is
faulty
Contact service
15
W
ROOM LOW
When room temperature drops
below 10°C the unit will stop in
order to protect the house from
further cooling down. The func-
tion is useful when the house is
not occupied and the main heat-
ing has stopped.
Heat up the house and
reset the alarm
16
I
SOFTWARE
Error in software
Contact service
17
I
WATCHDOG
Error in software
Contact service
18
I
CONFIG
Parts of the programming are
lost and can be caused by a
longer period of power failure or
lightning. The unit will keep on
operating on standard pro-
gramming.
Reset alarm
Re-programme the week
programme.
Contact service if the
unit does not operate as
before. Supplementary
programs can be lost.
Only service can access
the supplementary pro-
grams and menus.
19
I
FILTER
The system is set to activate an
alarm for filter inspec-
tion/replacement after a specific
number of days (30, 90, 180 or
360 days).
The default setting is 90 days.
Clean/replace filter.
Reset alarm.
21
I
SET TIME
Occurs during power failure.
Check weekly program
settings and reset if
necessary.
Reset alarm.
22
I
T AIR
The heating of the set tempera-
ture cannot be reached. Heating
surface and system cannot lift
the temperature to the required
level.
Set a lower inlet temper-
ature. Reset alarm
27-57
C
TxSHORT
One of the temperature sensors
connected to the system has
short-circuited/is defective.
Short-circuited sensor = +99°C
Make a note of which
sensor (Tx) has short-
circuited (e.g. T1 short)
and contact service cen-
tre.
28-58
C
Tx OPEN
One of the temperature sensors
connected to the system has
been disconnected/is defective.
Disconnected sensor = -40°C
Make a note of which
sensor (Tx) has become
disconnected (e.g. T1
discon) and contact ser-
vice centre.
91
I
OPTIO
Accessories circuit board
Contact service centre.
92
I
PRESET
Error by writing or input of the elec-
trician’s adjustments
Contact service centre.

May be subject to change page 13 af 28
Show data
The actual operation data can be read in the ”Show data” menu.
SHOW
DATA
FRESHAIR
T1 40°C
STATUS
HEATING
PANEL
T15 20°C
INLET
T7 50°C
EXTERNAL
T10 9°C
Room temperature
recorded by T15
(sensor in CTS 600
control panel).
The software version
used by the system.
The software
version used by
the controls.
INLET
FLOW 3
SOFTWARE
1 2.21
EXHAUST
FLOW 3
EVAP
T6 40°C
SOFTWARE
2 1.02
ENTER
COND
T5 25°C
TYPE
VPM/28EC
T10 is an external sensor that can be
installed in an exhaust fitting in the
sitting area. T10 can be chosen as a
controlling room sensor in the service
menu.See the installation instruction
For systems without
heating element, T2 is
shown. For systems
with heating element,
T7 is shown.
HUMIDITY %
100
CO2 588ppm
WATER
T9 25°C
Figure 8: The ”Show data” menu

May be subject to change page 14 af 28
User select
The menu CUSTOM OPTIONS overrides the operating mode of the main menu by activating an
external switch.
There are four custom options: ”exhaust” and ”inlet”, ”extend” and “OFF”
”VENTILAT”: There is a possibility here to run with a higher or lower speed on the air exhaust and
air inlet for a limited amount of time. The external pressure will activate the function. The function
has high priority.
”EXHAUST” and ”INLET”: These two options increase or reduce the velocity of the exhaust or inlet
air respectively for a limited period of time. The remaining functions of the operating mode remain
unaltered. An external switch activates the timer function.
Another external switch ensures that the fans remain at the desired ventilation level until the switch
is turned off.
”EXTEND”: This option controls the velocity of the exhaust and inlet air and can be used to change
the temperature of the inlet air for a limited period of time. An external switch activates the timer
function.
“OFF”: Deactivates the external switch.
Options that flash are indicated by ” ”.
On the CTS 602 control panel, press:
- ESC to return to the previous menu
- qp to scroll upwards or downwards through the menus or to
adjust the setting of an activated menu option
- ENTER to activate a menu option
- ENTER to confirm a new menu option setting
- OFF to switch off the controls
- ON to switch on the controls
Time and speed must
be set in the same
way as described
under SELECT
EXTEND.
Required period in
which the selected
function is to remain
operative: stated in
hours and minutes.
Max 8 hours.
Switches user option
off.
Required ventilation
step: 1-4.
OFF allows the system
to be shut down via an
external switch.
TIME
FLOW
ENTER ENTER
TEMP
TIME 00:00
FLOW >4<
TEMP 23
ENTER
ENTER
ENTER
”00:00"
”OFF”
ENTER
ENTER
ENTER
°C
”>4<”
”23" °C
SELECT
SELECT
SELECT
SELECT
”EXTEND”
”INLET”
”EXHAUST”
SELECT
”EXTEND”
USER
SELECT
Required room temperature
(5-30°C).
T15 is the temperature sensor to
be used to control the system.
”VENTILAT” ENTER
SELECT Possibility to run at
a higher or lower
rate. High priority.
Figure 9: The ”User select” menu

May be subject to change page 15 af 28
Setting of clock
In case of power cut the clock will function for at least 24 hours. If the time function is lost there will
be a alarm.
Changing to daylight saving time has to be done manually.
” ” indicates that the menu point flashes and can be set to another value.
On the CTS 602 control panel, press:
- ESC to return to the previous menu
- qp to scroll upwards or downwards through the menus or to
adjust the setting of an activated menu option
- ENTER to activate a menu option
- ENTER to confirm a new menu option setting
- OFF to switch off the controls
- ON to switch on the controls
Is only shown the first
time after setting up
the time function.
06-05-30
TI 12.10 YEAR 06 ENTERENTER YEAR ”06"
MONTH
”05"
Seconds are being reset
when minutes are adjusted
MONTH 05
DAY 30
WEEK
DAY 2
HOUR 12
MINUTE 10
DAY
”30"
HOUR
”12"
MINUTE
”10"
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
Figure 10: Setting of clock

May be subject to change page 16 af 28
Week programme
The unit is equipped with 3 standardized week programmes. See page 17.
The unit is set to programme 1 from the factory.
In addition to these programmes it is possible to programme your own week programme which can
be one of the standard programmes with minor alterations.
” ” indicates that the menu point flashes and can be set to another value.
Factory settings for the 3 weekly programs:
Program 1 is suitable for the working family
Program 2 is suitable for the non-working family
Program 3 is suitable for offices
Program
Week day
Function
Time
Ventilation
Temperature
Program 1
Monday -
Friday
1
2
3
4
6.00
8.00
15.00
22.00
3
1
3
1
21
21
21
21
Saturday -
Sunday
1
2
8.00
23.00
3
1
21
21
Program 2
Monday -
Sunday
1
2
8.00
23.00
3
1
21
21
Program 3
Monday -
Friday
1
2
7.00
16.00
3
OFF
21
21
MO 1 08.00
>1< 17°C
Time of program step activation.
If a program step should not be used
OFF should be chosen.
(OFF is located instead of 24.00)
Required room
temperature.
Week
day.
Program step.
6 program steps are
available each day.
Fan speed.
Weekly program settings

May be subject to change page 17 af 28
On the CTS 602 control panel, press:
- ESC to return to the previous menu
- qp to scroll upwards or downwards through the menus or to
adjust the setting of an activated menu option
- ENTER to activate a menu option
- ENTER to confirm a new menu option setting
- OFF to switch off the controls
- ON to switch on the controls
Once settings have been made for
Monday , the values can be copied
to any other day the same settings
are to apply using in the copy
function.
System operation in
accordance with main
menu settings
”PROG 1"
MO1 06.00
>3 < 21°C
”CLEAR”
TU1 06.00
>3 < 21°C
MO TU
COPY
ENTER
ENTER
ENTER
”PROG 2"
MO2 08.00
>1 < 17°C
”PROG 3"
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER ENTER
MO TU
”COPY”
TU WE
COPY
TU2-6
SELECT
OFF ENTER ENTER
MO4-6
MO3 AUS
>1 < 17°C
PROG 1
WEEK
PROGRAM SELECT
”OFF”
SELECT
SELECT
SELECT
SELECT SELECT
Here it is possible to make your own
programme or adjust one of the
standard programmes. If there is more
than one function at the same time only
the last one is active.
Here it is possible to
chose one of the 3
standard programmes.
The 3 programmes can
be altered but not deleted.
The original programme
can always be found.
Here it is possible to delete all
user made programmes. The unit
will continue in AUTO mode
without any week programme.
Figure 11: The “Week program” menu

May be subject to change page 18 af 28
Heating surface
The menu HEATING SURFACE is only accessible when the system has a heating surface in-
stalled and when the control has been set up to a heating surface in the SERVICE MENU.
” ” indicates that the menu point flashes and can be set to another value.
On the CTS 602 control panel, press:
- ESC to return to the previous menu
- qp to scroll upwards or downwards through the menus or to
adjust the setting of an activated menu option
- ENTER to activate a menu option
- ENTER to confirm a new menu option setting
- OFF to switch off the controls
- ON to switch on the controls
HEATING
SURFACE SELECT ON
SELECT
”OFF”
SELECT
”ON”
ENTER ENTER
ENTER
ENTER
When a heating surface is
installed T2 is replaced
with T7, which is the
sensor placed in the inlet
at the heating surface.
If you wish to disconnect the
heating surface this position should
be chosen.
The frost-protection is still active
and T7 is the active temperature
sensor for the inlet air.
Figure 12: The ”Heating surface” menu

May be subject to change page 19 af 28
Cooling
The cooling menu makes it possible to choose at which elevated temperature in relation to the
room temperature the ventilation unit should start cooling
” ” indicates that the menu point flashes and can be set to another value.
On the CTS 602 control panel, press:
- ESC to return to the previous menu
- qp to scroll upwards or downwards through the menus or to
adjust the setting of an activated menu option
- ENTER to activate a menu option
- ENTER to confirm a new menu option setting
- OFF to switch off the controls
- ON to switch on the controls
COOLING TEMP
SET +3 TEMP ”SET +3”
ENTER ENTER ENTER
SET: the chosen temperature
in the main menu.
+5: allows cooling via
compressor 5 °C above
the chosen roomtemperature
The value can be set to:
OFF, 0, +1, +2, +3,+4,+5,+7,+10.
VENTILAT
HIGH OFF
Here it is possible to chose
high ventilation step when
cooling.
The value can be set to:
OFF, 2, 3, 4.
VENTILAT
HIGH ”OFF”
ENTER ENTER
Figure 13: The ”Cooling” menu
Example : Desired room temperature in main menu = 21°C
Cooling set = 5°C
Starting of compressor, cooling = 26°C

May be subject to change page 20 af 28
Night Cooling
The NIGHT COOLING menu makes it possible to select passive night cooling, provided that the
outdoor temperature on the day before has exceeded the day temperature limit set in the NIGHT
COOLING menu for at least one hour.
During the night cooling period, the compressor cooling is suspended and the room setpoint is
lowered to the temperature set in the NIGHT COOLING menu.
The limit set for the minimum intake temperature is not observed during night cooling, but the sys-
tem may run compressor heating if the room temperature falls below the night cooling setpoint.
No special account is taken of whether the room temperature is above or below the outdoor tem-
perature, i.e. whether a cooling effect from the outdoor air can actually be achieved.
When the night cooling period is over, the system will run as normal again, with compressor heat-
ing and cooling according to the normal setpoint.
Outdoor temperature as requirement NIGHT COOLING
New ROOM SET for NIGHT COOLING
Outdoor temperature as
requirement NIGHT COOLING
OFF, 20….40°C
DAY TEMP
25 °C ENTER
NIGHT
COOLING ENTER ENTER
ENTER ENTER
DAY TEMP
”25 °C”
”18 °C”
ROOM SET
18 °C
New ROOM SET for NIGHT
COOLING
OFF, 20….40°C
ROOM SET
Figure 14: The ”Night Cooling” menu
