Niles SmartDock 2 User manual

Switches Your iPod Connection Between Your Computer andYour Niles MultiZone System
iPod Connectivity Solutions
Docking Station for iPod
SPECIFICATIONS SHEET
•Syncs an iPod with iTunes without disconnecting it from your Niles MultiZone System
•Illuminated light switch toggles between your Niles MultiZone System and your computer
SmartDock®

Features
•Syncs an iPod to a computer without disconnecting it from the
Niles MultiZone System
•Adjustable iPod support accommodates different iPod sizes
and shapes
•When switched to Computer, the iPod charges from the
computer’s USB connection
•When switched to Niles System, the iPod charges from the Niles
MultiZone System
•The light switch illuminated green indicates the computer mode
•The light switch illuminated blue indicates the Niles MultiZone
System mode
Specifications
•Power: USB Charging from connected computer or Niles
MultiZone System
•Dimensions: 4" W x 1.7" H x 3.7" D
(10.2cm W x 4.32cm H x 9.4cm D)
•Warranty: Two-year limited
•Shipping weight: 1 lb. (.5 Kg)
Docking Station for iPod
Stock Number
FG01575
i P od®CONNECTIVITY SOLUTIONS
Switches Your iPod Connection Between Your Computer and Your Niles MultiZone System
SmartDock2 Connection Diagram
Specifications Sheet
Stereo System or
Computer Speakers Loudspeakers
SmartDock2
iPod
(Not Included)
GXR2
Computer
iWARE ES2 Extender System (sold separately)
Extend your iPod connection
to anywhere in your home
Requires dual run of CAT-5 cable
Niles MultiZone System Compatible with iPod
2 meter iWARE Cable included in SmartDock2
©2009 Niles Audio Corporation. All Rights Reserved. Niles, the Niles logo, iWARE and SmartDock are registered trademarks of
Niles Audio Corporation. iPod and iTunes are trademarks of Apple Inc, registered in the U.S. and other countries. CS0283B
Niles Audio CorporAtioN 12331 SW 130 Street, Miami, FL 33186 1-305-238-4373 • 1-800-BUY-HIFI – www.nilesaudio.com
LED Button
Switches Between Your
Niles System and
Your Computer
Computer Niles System
For a complete list of all SmartDock2-compatible iPods, go
to www.nilesaudio.com, select iWARE from the products
menu, and then select SmartDock2.

Extend your iPod Connection to Anywhere in Your Home
iPod Connectivity Solutions
Wall-Mount Extender System for iPod
SPECIFICATIONS SHEET
•Extend the reach of any IntelliControl®ICS or Niles ZR-6 system to an iPod from 2 meters to 100 meters
•Balanced/differential audio to preserve audio quality and reject noise and hum pickup
•Utilizes dual-runs of CAT-5 cabling up to 100m (330')
ES

Features
•Extend the reach of any IntelliControl ICS or ZR-6 MultiZone
receiver, to an iPod from 2 meters to 100 meters
•Balanced/differential audio to preserve audio quality and
reject noise and hum pickup
•LEDs on the input and output wall plates indicate that the
12V power supply is connected and the output wallplate is
connected
•Includes power supply and 30-pin cable
•Power connection is available on both the front and back of
input plate
Specifications
•Power: 12V DC @ 250mA (minimum)
•Dimensions: 2.75” W x 4.5” H (7 cm W x 11.43 cm H)
•Warranty: Two-year limited
•Shipping weight: 1 lb. (.5Kg)
Wall-Mount Extender
System for iPod
Stock Number
FG01574
i P od®CONNECTIVITY SOLUTIONS
Extend your iPod Connection to Anywhere in Your Home
ES2 Connection Diagram
Specifications Sheet
When not using a SmartDock2, use the cable included with Niles MultiZone System to connect to the iPod.
Optional iWARE SmartDock®2
Dual-run of CAT-5
cables up to 100 meters
ES2
Input Wall Plate
ES2
Output Wall Plate
Niles MultiZone System Compatible with iPod
2 meter iWARE cable
included with ES2
iPod
(Not Included)
iPod
(Not Included)
2 meter iPod cable from
Niles MultiZone System
2 meter iWARE cable
included with SmartDock®2
iPod
or
System
Loudspeakers
GXR2
Power
Supply
(Included)
For a complete list of all ES2-compatible iPods, go to
www.nilesaudio.com, select iWARE from the products
menu, and then select ES2.
Niles Audio CorporAtioN 12331 SW 130 Street, Miami, FL 33186 1-305-238-4373 • 1-800-BUY-HIFI – www.nilesaudio.com
©2009 Niles Audio Corporation. All Rights Reserved. Niles, the Niles logo, iWARE and SmartDock are registered trademarks of
Niles Audio Corporation. iPod and iTunes are trademarks of Apple Inc, registered in the U.S. and other counties. CS0282B
