Nilfisk-ALTO ATTIX 961-01 User manual

ATTIX 961-01
ATTIX 963-21 ED XC
ATTIX 965-21 SD XC
auto
1074001235 A
Operating Instructions

1
ATTIX 9 STD
1) Optional accessories / Option depending on model
Contents
1 Important safety
instructions
2 Description
3 Before starting the
cleaner
4 Control / Operation
5 Applications and
methods
6 After using the cleaner
7 Maintenance
8 Troubleshooting
9 Further information
............................................................................................2
2.1 Operating elements ..............................................................6
2.2 Operating panel....................................................................7
3.1 Assembling the vacuum cleaner...........................................8
3.1.1 Taking accessories out of the packaging..............................8
3.1.2 Attaching the suction pipe holder to the suction pipe 1) ........8
3.1.3 Inserting the filter bag (ATTIX 961-01) .................................9
3.1.4 Inserting the disposal bag (ATTIX 965-21 SD XC).............10
3.1.5 Inserting the disposal bag (ATTIX 963-21 ED XC).............11
4.1 Connections .......................................................................12
4.1.1 Connecting the suction hose..............................................12
4.1.2 Electrical connection .........................................................12
4.2 Switching on the vacuum cleaner.......................................12
4.2.1 Switch " I-0-II " 1) .................................................................12
4.2.2 Switch „ auto-0-I “ 1) ............................................................12
4.2.3 Suction power control 1) ......................................................13
4.2.4 Auto-On/Off-Operation - "auto" switch position 1) ...............13
4.3 Cleaning the filter element .................................................14
4.3.1 Cleaning the filter element (Push&Clean System) 1) ..........14
4.3.2 Cleaning the filter element " XtremeClean "
(ATTIX 963-21 ED XC, ATTIX 965-21 SD XC) ...................14
5.1 Techniques .........................................................................15
5.1.1 Picking up dry substances..................................................15
5.1.2 Picking up liquids................................................................15
6.1 Switching the vacuum cleaner off and storage...................16
7.1 Maintenance plan...............................................................17
7.2 Maintenance work ..............................................................18
7.2.1 Emptying the dirt tank (ATTIX 961-01) ...............................18
7.2.2 Emptying the dirt tank (ATTIX 965-21 SD XC) ..................19
7.2.3 Replacing the filter bag(ATTIX 961-01) ..............................20
7.2.4 Replacing the disposal bag (ATTIX 965-21 SD XC)...........21
7.2.5 Replacing the disposal bag (ATTIX 963-21 ED XC)...........22
7.2.6 Replacing filter element......................................................23
..........................................................................................24
9.1 Recycling the vacuum cleaner ...........................................25
9.2 Guarantee ..........................................................................25
9.3 Tests and approvals............................................................25
9.4 EC declaration of conformity ..............................................25
9.5 Technical data ....................................................................26
9.6 Optional accessories..........................................................26

2
ATTIX 9 STD
1) Optional accessories / Option depending on model
1 Important safety instructions
Symbols used to mark
instructions
Prior to using the appliance for the first time, be sure to read
this document through and keep it ready to hand.
DANGER
Danger that leads directly to serious or irreversible injuries,
or even death.
WARNING
Danger that can lead to serious injuries or even death.
CAUTION
Danger that can lead to minor injuries and damage.
The appliance must
• only be used by persons, who have been instructed in its correct
usage and explicitly commissioned with the task of operating it
• only be operated under supervision
• not be used by children
1. Do not use any unsafe work techniques.
2. Never use the vacuum cleaner without a filter.
3. Switch off the appliance and disconnect the mains plug in the
following situations:
- Prior to cleaning and servicing
- Prior to replacing components
- If foam develops or liquid emerges
Besides the operating instructions and the binding accident preven-
tion regulations valid in the country of use, observe recognised regu-
lations for safety and proper use.
Purpose and intended use The appliance is suitable for picking up dry, non-flammable dust and
liquids.
Do not use the ATTIX 963-21 ED XC to pick up liquids.
The appliance is suitable for commercial use, such as e.g. in
• Hotels
• Schools
• Hospitals
• Factories
• Shops
• Offices
• Hire shops
Any other use is considered as improper use. The manufacturer ac-
cepts no liability for any damage resulting from such use. The risk
for such use is borne solely by the user.
Proper use also includes proper operation, servicing and repairs as
specified by the manufacturer.

3
ATTIX 9 STD
1) Optional accessories / Option depending on model
Transport 1. Before transporting the dirt tank, close all the locks.
2. Do not tilt the cleaner if there is liquid in the dirt tank.
3. Do not use a crane hook to lift the cleaner.
Storage 1. Store the appliance in a dry place, protected from frost.
Electrical connection 1. It is recommended that the vacuum cleaner should be connected
via a residual current circuit breaker.
2. Arrange the electrical parts (sockets, plugs and couplings) and
lay down the extension lead so that the protection class is main-
tained.
3. Connectors and couplings of power supply cords and extension
leads must be watertight.
Extension lead 1. As an extension lead, only use the version specified by the man-
ufacturer or one of a higher quality. See operating instructions.
2. When using an extension lead, check the minimum cross-sec-
tions of the cable:
Cable lenth Cross section
< 16 A < 25 A
up to 20 m 1.5 mm22.5 mm2
20 to 50 m 2.5 mm24.0 mm2
Guarantee Our general conditions of business are applicable with regard to the
guarantee.
Unauthorised modifications to the appliance, the use of incorrect
brushes in addition to using the appliance in a way other than for the
intended purpose exempt the manufacturer from any liability for the
resulting damage.

4
ATTIX 9 STD
1) Optional accessories / Option depending on model
Risks
DANGER
Electric shock due to faulty mains connecting lead.
Touching a faulty mains connecting lead can result in seri-
ous or even fatal injuries.
1. Do not damage the mains power lead (e.g. by driving
over it, pulling or crushing it).
2. Regularly check whether the power cord is damaged or
shows signs of ageing.
3. Have the faulty mains connecting lead replaced by your
Nilfisk-Alto service representative or a qualified electri-
cian prior to using the appliance again.
DANGER
The upper section of the vacuum cleaner contains live com-
ponents.
Contact with live components leads to serious or even fatal
injuries.
1. Never spray water on to the upper section of the vacuum
cleaner.
CAUTION
Appliance socket 1)
The appliance socket is only designed for the purposes de-
fined in the operating instructions.
1. The connection of different appliances can result in dam-
age.
2. Prior to plugging in an appliance, always switch off the vac-
uum cleaner and the appliance that is to be connected.
3. Read the operating instructions to the appliance to be con-
nected and observe the safety notes contained in these.
CAUTION
Damage due to unsuitable mains voltage.
The appliance can be damaged as a result of being connected
to an unsuitable mains voltage.
1. Ensure that the voltage shown on the rating plate corre-
sponds to the voltage of the local mains power supply.
Electrical components

5
ATTIX 9 STD
1) Optional accessories / Option depending on model
Emptying dirt tank CAUTION
Picking up environmentally hazardous materials.
Materials picked up can present a hazard to the environ-
ment.
1. Dispose of the dirt in accordance with legal regulations.
Hazardous materials WARNING
Hazardous materials.
Vacuuming up hazardous materials can lead to serious or
even fatal injuries
1. The following materials must not be picked up by the
vacuum cleaner:
- hazardous dust
- hot materials (burning cigarettes, hot ash, etc.)
- flammable, explosive, aggressive liquids (e.g. petrol,
solvents, acids, alkalis, etc.)
- flammable, explosive dust (e.g. magnesium or alumini-
um dust, etc.)
Spare parts and accessories CAUTION
Spare parts and accessories.
The use of non-genuine spare parts and accessories can
impair the safety of the appliance.
1. Only use spare parts and accessories from Nilfisk-Alto.
2. Use only the brushes supplied with the vacuum cleaner
or specified in the operating manual.
Picking up liquids CAUTION
Picking up liquids.
ATTIX 965-21 SD XC: Due to their construction vacuum clean-
ers with a removable tank (SD) do not have an automatic level
indicator. There is a risk of damage to the vacuum cleaner due
to overfilling or of damage due to leakage of the picked up liq-
uid.
1. Never pick up more than 40 litres at once.
2. Switch off the vacuum cleaner and empty the dirt tank.

6
ATTIX 9 STD
1) Optional accessories / Option depending on model
2 Description
2.1 Operating elements
auto
13
1
19
18
12
14
16
15
17
3
5
7
6
8
10
15
19
13
18
12
14
8
2
4
5
6
20
1
2
4
5
6
8
7
14
1
19
18
12
9
11
15

7
ATTIX 9 STD
1) Optional accessories / Option depending on model
1 Handle
2 Appliance socket 1)
3 Applicance switch "I-0-II" 1)
4 Applicance switch with suction power control 'auto-0-I" 1)
5 Receptacle for electrical lead
6 Inlet fitting
7 Dirt tank
8 Castor with brake
9 Swivel bar to remove dirt tank 1)
10 Grip to empty tank 1)
11 Handle to remove dirt tank 1)
12 Retaining clamp
13 Suction pipe support 1)
14 Bracket for floor nozzle 1)
15 Accessory holder
16 Clamps and hinges for dirt tank 1)
17 Operating knob for filter cleaning 1)
18 Inlet for fresh air
19 Outlet for waste air
20 Disposal bag
2.2 Operating panel
ATTIX 961-01
ATTIX 963-21 ED XC, ATTIX 965-21 SD XC

8
ATTIX 9 STD
1) Optional accessories / Option depending on model
3.1 Assembling the
vacuum cleaner
3.1.1 Taking accessories out
of the packaging
1. Take vacuum cleaner and
accessories out of the pack-
aging.
2. The mains plug should not
yet be inserted into a socket.
3. Apply parking brakes (A) on
both castors.
4. Open the retaining clamps
(B) and remove the upper
section of the vacuum clean-
er.
5. Take the accessories 1) out of
the dirt tank and the packag-
ing.
x
auto
1. Attach the suction pipe hold-
er to the suction pipe.
Accessory
diameter
Distance (x)
from pivot
joint to the
floor nozzle
cm
38 52
50 47
3.1.2 Attaching the suction
pipe holder to the
suction pipe 1)
3 Before starting the cleaner
A
A
B B
x
auto

9
ATTIX 9 STD
1) Optional accessories / Option depending on model
3.1.3 Inserting the filter bag
(ATTIX 961-01)
1. The mains plug should not
yet be inserted into a socket.
2. Apply parking brakes (A) on
both castors.
3. Open the retaining clamps
(B) and remove the upper
section of the vacuum clean-
er.
A
A
B B
BB
4. Insert the filter bag (C) in the
dirt tank.
5. Attach the upper section of
the vacuum cleaner.
6. Close the retaining clamps
(B). Ensure that the retaining
clamps fit properly.

10
ATTIX 9 STD
1) Optional accessories / Option depending on model
3.1.4 Inserting the
disposal bag
(ATTIX 965-21 SD XC)
1. The mains plug should not
yet be inserted into a socket.
2. Apply parking brakes (A) on
both castors.
3. Swing the bar (B) upwards.
4. Use the handle (C) to pull the
dirt tank out of the vacuum
cleaner.
5. Insert the disposal bag (D) in
the dirt tank.
6. Fold the top edge of the dis-
posal bag over the rim of the
dirt tank.
7. Push the dirt tank as far as
possible into the vacuum
cleaner.
8. Swing the bar (B) downwards
without forcing it.
A
A
B
C
D
B
C

11
ATTIX 9 STD
1) Optional accessories / Option depending on model
1. The mains plug should not
yet be inserted into a socket.
2. Apply parking brakes (A) on
both castors.
3. Open clamping ring (B).
3.1.5 Inserting the
disposal bag
(ATTIX 963-21 ED XC)
4. Insert disposal bag (C) into
clamping ring.
5. Fold the top edge of the dis-
posal bag over the rim of the
clamping ring.
6. Attach the new disposal bag
(C) onto the storage contain-
er (D).
7. Close clamping ring (B).
C
C
A
A
B
D
B

12
ATTIX 9 STD
1) Optional accessories / Option depending on model
4.2 Switching on the
vacuum cleaner
4.2.1 Switch " I-0-II " 1)
Switch
position Function
IMaximum
suction
Switch
position Function
IReduced
suction
0Off
II Maximum
suction
4.2.2 Switch „ auto-0-I “ 1)
4 Control / Operation
4.1 Connections
4.1.1 Connecting the suction
hose
4.1.2 Electrical connection
The operating voltage shown on
the rating plate must correspond
to the voltage of the mains power
supply.
1. Ensure that the cleaner is
switched off.
2. Insert the power cord into a
properly installed and fused
socket with earthing contact.
1. Connect the suction hose.

13
ATTIX 9 STD
1) Optional accessories / Option depending on model
4.2.3 Suction power control 1) Switch
position Function
The suction
power control
switch allows
precise
adaptation of
the suction
power for
different
cleaning tasks.
4.2.4 Auto-On/Off-Operation
- "auto" switch
position 1)
The vacuum cleaner is switched
on and off by the power tool con-
nected. Dirt is picked up from the
source of dust immediately.
To comply with regulations, only
approved dust producing tools
should be connected.
The maximum power consumption
of the connected electrical appli-
ance is stated in section 9.5 "Tech-
nical data".
Before switching the switch to po-
sition „auto“, ensure that the tool
connected to the appliance socket
is switched off.
1. Switch off the vacuum clean-
er.
2. Switch off the power tool.
3. Connect the power tool and
the vacuum cleaner with a
suction hose.
4. Insert the plug of the power
tool into the tool socket on
the operating panel of the
vacuum cleaner.
5. Switch on the vacuum clean-
er. Switch in "auto" position.
6. Switch on the power tool.The
vacuum cleaner motor starts
when the connected power
tool is switched on.
When the power tool is
switched off, the vacuum
cleaner continues to run for
a short moment so that any
dust in the suction hose is
conveyed to the filter bag.
auto

14
ATTIX 9 STD
1) Optional accessories / Option depending on model
4.3 Cleaning the filter
element
4.3.1 Cleaning the filter
element (Push&Clean
System)1)
Only for vacuum cleaning without a
filter bag and without a cloth insert
filter.
If suction performance drops:
1. Turn switch to position "II" (maximum suction power).
2. Close the nozzles or suction hose opening with the palm of your
hand.
3. Press the button to start filter cleaning three times. The resulting
stream of air removes attached dust from the slats of the filter
elements.
4.3.2 Cleaning the
filter element
" XtremeClean "
(ATTIX 963-21 ED XC,
ATTIX 965-21 SD XC)
Only for vacuum cleaning without a
cloth insert filter.
10 sec .
To ensure that suction performance is always at its best, the filter
element is automatically cleaned during operation. We recommend
complete cleaning if the filter element becomes extremely dirty.
1. Switch off the vacuum cleaner
2. Close the nozzles or suction hose opening with the palm of your
hand.
3. Turn the switch to position „I“ and let the cleaner operate for ap-
prox. 10 seconds with the suction hose opening closed.

15
ATTIX 9 STD
1) Optional accessories / Option depending on model
5 Applications and techniques
5.1 Techniques If used correctly, additional accessories, suction nozzles and suc-
tion hoses can enhance the cleaning action and reduce the cleaning
effort.
Effective cleaning is achieved if you follow just a few guidelines in
combination with your own practical experience in special fields.
Here are some basic tips.
5.1.1 Picking up dry
substances
CAUTION!
Do not pick up flammable substances.
Before picking up dry substances, always ensure that a filter bag is
inserted in the tank (see section 9.6 "Accessories" for order number).
Disposal of the picked up material is then simple and hygienic.
After picking up liquids, the filter element is wet. A damp filter ele-
ment clogs more quickly when dry substances are picked up. For this
reason the filter element should be washed and dried or replaced by
a dry element before dry substances are picked up.
5.1.2 Picking up liquids CAUTION!
Do not pick up flammable liquids.
Do not use the ATTIX 963-21 ED XC to pick up liquids.
Before liquids are picked up, always remove the filter bag/disposal
bag.
The use of a separate filter element or filter screen is recommend-
ed.
If foam appears, stop work immediately and empty the tank.
To reduce the amount of foam, use foam killer Alto Foam Stop (see
section 9.6 "Accessories" for order number).

16
ATTIX 9 STD
1) Optional accessories / Option depending on model
6 After finishing work
6.1 Switching the vacuum
cleaner off and storage
1. Switch off the cleaner and
pull the mains plug out of the
socket.
2. Wind up the power cord and
hang it on the handle (A).
Begin winding up the cord at
the cleaner end and not the
plug end to prevent the pow-
er cord from tangling up.
3. Empty the dirt tank and clean
the vacuum cleaner.
4. After picking up liquids: Store
the upper section of the vac-
uum cleaner separately so
that the filter element can
dry.
5. Hang the suction hose with
the floor nozzle (B) in the
brackets and pack the acces-
sories (C) away.
6. Store the cleaner in a dry
room where it is protected
from unauthorized use.
auto
A
B
C

17
ATTIX 9 STD
1) Optional accessories / Option depending on model
7 Maintenance
7.1 Maintenance plan
ATTIX 961-01:
After finishing work When required
7.2.1 Emptying dirt tank 
7.2.3 Replacing the filter bag 
7.2.6 Replacing filter element 
ATTIX 965-21 SD XC:
After finishing work When required
7.2.2 Emptying dirt tank 
7.2.4 Replacing the disposal bag 
7.2.6 Replacing filter element 
ATTIX 963-21 ED XC:
After finishing work When required
7.2.5 Replacing the disposal bag 
7.2.6 Replacing filter element 

18
ATTIX 9 STD
1) Optional accessories / Option depending on model
7.2 Maintenance work
7.2.1 Emptying the dirt tank
(ATTIX 961-01)
After emptying the tank: clean the
rim of the tank and the seals in the
intermediate ring and the upper
section of cleaner before refitting
them.
If the seal or groove is dirty or dam-
aged, the suction performance will
be reduced.
Before reinserting the suction hose:
clean the inlet fitting and hose col-
lar.
1. Switch off the vacuum clean-
er and pull the mains plug
out of the socket.
2. Apply parking brakes
(A) on both castors.
3. Open the retaining clamps
(B) and remove the upper
section of the vacuum clean-
er.
Tilting the dirt tank:
4. Pull the lever in the handle
(C) upwards and tilt the tank.
5. Tip out the collected dirt.
6. Dispose of the dirt in accord-
ance with legal regulations.
or
Removing the dirt tank:
4. Open the tank locks (D).
5. Use the handles (E) to lift the
tank out of the frame.
6. Tip out the collected dirt.
7. Dispose of the dirt in accord-
ance with legal regulations.
8. Place the empty tank in the
frame and close the locks
(D).
9. Attach the upper section of
the vacuum cleaner.
10.Close the retaining clamps
(B). Ensure that the retaining
clamps fit properly.
A
A
D
E
E
D
C
B B
BB

19
ATTIX 9 STD
1) Optional accessories / Option depending on model
7.2.2 Emptying the dirt tank
(ATTIX 965-21 SD XC)
1. Switch off the vacuum clean-
er and pull the mains plug
out of the socket.
2. Apply parking brakes (A) on
both castors.
Removing the dirt tank:
3. Swing the bar (B) upwards.
4. Use the handle (C) to pull the
dirt tank out of the vacuum
cleaner.
5. Tipping out the collected
dirt: WARNING! If heavy dirt
has been picked up, never
lift the dirt tank alone. Use
the FORKLIFT (D), which is
available as an accessory.
6. Use a crane or fork lift truck
to position the FORKLIFT
above the dirt tank.
7. Attach the tank to the acces-
sory.
8. Dispose of the dirt in accord-
ance with legal regulations.
Inserting the dirt tank:
9. Clean the dirt tank.
10.Check the seals (E) between
the tank and the upper sec-
tion of the vacuum cleaner.
11.Push the dirt tank as far as
possible into the vacuum
cleaner.
12.Swing the bar (B) downwards
without forcing it.
A
A
B
C
D
E
