Nilfisk-ALTO Buddy 15 User manual

Service Manual
Buddy 15/18
Aero 20-01/INOX
Aero 20-11/-21/-21INOX
Aero 25-11/-21

A. Preface / Safety Instructions
B. Technical data
C. Troubleshooting
D. Service
E. Tools
F. Wiring
Index

Nilfisk
AL O
T
r1Buddy/Aero_Ve.1.0_17006
A Preface / Safety Instructions .......................................................................... 4
B Technical data .......................................................................... 5
C Troubleshooting 1 Buddy 15/18, Aero 20/25-01/11
- Motor not working........................................... 8
2 Aero 20/25-21
- Motor not working with switch set to “I”........... 9
3 Aero 20/25-21/-21INOX
- Motor not working with switch set to “II”.......... 10
D Service 1 Suction head (Buddy)..................................... 11
1.1 Disassembling / assembling the intake fitting....11
1.2 Disassembling / assembling the cover.............. 11
2 Container (Aero).............................................. 12
2.1 Disassembling / assembling the container ring
( Aero 20 Inox only)........................................... 12
2.2 Disassembling / assembling the intake fitting
(Aero 20 Inox only)............................................ 12
2.3 Disassembling / assembling the intake fitting in
the plastic container...........................................13
3 Suction head / electrical components (Aero)14
3.1 Disassembling / assembling the cover.............. 14
3.2 Disassembling / assembling the locking clamp 14
3.3 Disassembling / assembling the power cord.... 15
3.4 Disassembling / assembling the switch.............16
3.5 Disassembling / assembling the socket
(Aero 20/25-11/21 only).....................................16
3.6 Disassembling / assembling the start-up unit... 17
3.7 Disassembling / assembling the clamping plate17
3.8 Disassembling / assembling the motor..............18
4 Filter cleaning (Aero)..................................... 19
4.1 Disassembling / assembling filter cleaning
(tappet).............................................................. 19
4.2 Disassembling / assembling filter cleaning
(flap).................................................................. 19
E Tools 1 Special tools.................................................... 20
F Wiring 1 Wiring diagram................................................ 21
1.1 Wiring diagram Buddy 15/18,
Aero 20/25-01/INOX..........................................21
1.2 Wiring diagram Aero 20/25-11.......................... 22
1.3 Wiring diagram Aero 20/25-21/-21INOX............23
ont
C ents
3/23

A
f s
Nil i k
ALTO
Bud /Aero_ r1.0_1706dy Ve 01
Safety Instructions
Preface
This repair manual contains a detailed description of the main repair work for wet and dry clea-
ners of the Nilfisk-ALTO Buddy andAero Series.
Repair work requires a suitable testing workplace with the necessary power supply.
If operating errors are evident, refer the customer to the operating instructions.
A fault in the equipment can have a number of causes. Chapter “C” Troubleshooting will help you
here.
Refer to the illustrated spare parts lists during repairs. They show the assembly position and the
sequence in which the individual components should be assembled.
Always observe “Technical Information” sheets! They contain information on technical modifica-
tions made after publication of this repair manual.
Technical Information sheets are also valid as a supplement to the spare part list until publication
of a new edition!
Repair manuals and technical information sheets should be available at the site where repairs
are carried out.
It is not permitted to give them to third parties.
Use original Nilfisk-ALTO spare parts only!
For your own safety!
Repairs should only be made by someone who
has received proper instructions for the job or
who is a qualified electrician.
After the repair or modification an electrical
examination is to be performed according to
DIN VDE 0701 / 0702.
Before using the cleaner, always read the
operating instructions and keep them rea-
dily available.
Only allow the vacuum cleaner to be used
by persons who have been trained in its use
and who have been explicitly authorized to
use it.
Observe national safety directives and regulations
for the electrical engineering trade, in particular:
IEC 60335-2-69
EN 60335-2-69
DIN VDE 105 Part 1:
Operation of power Installation.
DIN VDE 0701/0702:
Repairing, modifying and testing electrical installa-
tions.
o
Preface / Safety instructi ns
4/23

B
Nilfisk
ALTO
Buddy/Aero_ver.1.0_170106
Version / Type
Country
Variants
GB
230V ZA AU
Voltage V240
Frequency Hz
Fusing A13 16
Power consumption PIEC W
Connected load for
appliance socket W
Total connected load W
Power cord lenght m
Power cord type
Protection class
Protection category
Width mm
Depth mm
Hight mm
Weight kg
Tank volume l
Air volume flow l/min
Static wate lift (max.) Pa
Sound pressure level at
1m, EN 60704-1 dB(A)
Operating noise dB(A)
Buddy 18Buddy 15
Electricaldata
50/60
EU EU JP
100230
16
Protec-
tion
II
IPX4
15 18
420
3,9
320
385
455
4,2
Unit-specific
data
3600
72
69
16000
15
1000
-
5,5
-
H05VV-F 2x0,75 AWG
18/2
Dimensions
andwight
Technical data
5/23

B
Nilfisk
ALTO
Buddy/Aero_ver.1.0_170106
Version /
Type
Country
Variants EU GB 230V
GB
110V JP ZA GB 230V EU DK CH AU
Voltage V110 100 240
Frequency Hz
Fusing A16 13 16 15 13 16 15
Power consumption PIEC W
Connected load for
appliance socket W2000 1300
Total connected load W3000 2300
Power cord lenght m
Power cord type H07BQ-
F2x1,0
AW G 14-
3 SJTW
H05VV-
F3G1,5
H05VV-
F3G1,5
Protection class
Protection category
Width mm
Depth mm
Hight mm
Weight kg
Tank volume l
Air volume flow l/min
Static wate lift (max.) Pa
Sound pressure level at
1m, EN 60704-1 dB(A)
Operating noise dB(A)
70
67
-
5,7
20
3600
485
375
Aero 25-01Aero 20-01 *INOX*
16
ZAEU
50/60
H05VV-F2x0,75 H05VV-
FG1,0
5,7
-
5,5
Dimensions
andwight
Unit-specific
data
5,9
H05VV-
F2x0,75
IPX4
Protec-
tion
18000
Electricaldata
10001000
Aero 20-01
2200
230
10
1150
Aero 20-11
230
1200
II I
380
6,7
545 485
19000 18000
25 20
Technical data
6/23

B
Nilfisk
ALTO
Buddy/Aero_ver.1.0_170106
Version /
Type
Country
Variants EU FR EU DK FR US EU DK GB 230V FR CH AU JP US
Voltage V120 240 100 120
Frequency Hz
Fusing A10 16 15 16 10 13 16 10
Power consumption PIEC W
Connected load for
appliance socket W1300 2000 800 2000 1150 1800 2000 1150 2000 500 800
Total connected load W2200 3000 1800 3150 2300 2950 3150 2300 3150 1500 1800
Power cord lenght m
Power cord type H05VV-
F3G1,5
AWG
14-3
SJTW
H05VV-
F3G1,5
H05VV-
F3G1,0
H05VV-
F3G1,0
H05VV-
F3G1,5
AWG
14-3
SJTW
AWG
14-3
SJTW
Protection class
Protection category
Width mm
Depth mm
Hight mm
Weight kg
Tank volume l
Air volume flow l/min
Static wate lift (max.) Pa
Sound pressure level at
1m, EN 60704-1 dB(A)
Operating noise dB(A)
Aero 20-21
*INOX*
5,5
H05VV-
F3G1,5
Aero 25-11 Aero 20-21 Aero 25-21
15
1150 10001000
25
5,7
375
380
Unit-specific
data
3600
18000 19000
70
67
Dimensionsand
weight
20
I
IPX4
545 485 545
Protec-
tion
6,7 5,9
Electricaldata
230 230
H05VV-
F3G1,5
H05VV-
F3G1,0
1150
2000
50/60
16
3000
Technical data
7/23

C
fsNil i k
ALTO
Budy/Aero_V r.1.0_17 106d e 0
1 Buddy 15/18, Aero 20/25-01/11- Motor not working
Troubleshooting Buddy / Aero-01/11
Ch c:ek
-Ma n v l age p ese ti s o tr n ?
-Powe co d p u g d in?
r r lge
-Sw tch Q1 opera e ?i t d
P we at switcho r
Q1?
C eck ai s ug ndh m n pl a
po er co d; repl fw r ace i
necessary
Power at motor
M?1
Check switch Q1;
replace if necessary
ke u r n
Chec saf ty req i emets
Yse
No
sY e
oN
Ys
e
No
Mor M1ot
wrk ng? oi
eck o MCh mtor 1;
ep ecessarr lace if n y
Troubleshooting
8/23

C
f s
Nil i k
ALTO
Bud y/Aero_Vr.1.0_17106
de0
2 Aero 20/25-21- Motor not working with switch set to “I”
Troubleshooting / Aero-20/25-21
Po or
ower at mt ? R ac st t up t
1.
epl e
ar - uni A
ec
Ch k:
ai vol a pr nt - M ns tge ese ?
d u i - Power cor pl gged n?
i ch 1set t “ ?
- Sw t S o I”
Pwe at switch
or
S?
1
Ceck ai s ug
nd
hmn pl a
po er co d; repl f
wr ace i
necessary
Power at s a t- tr
u nit
A ?
p u 1Check switch Q1;
e cr pla e if necessary
cs f u rmtsChe k a ety
req i e en
Ys
e
No
sY e
oN
Yes
No
or M o -Mot 1
w rk
ing?
1
Check
motor M ;
epl ir ace f necessary
No
Yes
Troubleshooting
9/23

C
f s
Nil i k
ALTO
Bud y/Aero_Vr.1.0_17106
de0
Pow at er
mor?ot Rac st t up iepl e
ar - un t A1.
Check:
-Ma ns volt ge present
i a ?
-Power cord p ugged in?l
-Sw tc S1 et to “II”?i h s
-Sw tc ed-on l ad ih at lea ti h o wt s
20 W pl gged into coup er soc etu l k ?
Pwe at switch
or
S?
1
Ceck ai s ug
nd
hmn pl a
po er co d; repl f
wr ace i
necessary
Power at start-u unit
p
A1 d
sket X2?
an oc
Check switch S1;
e cr pla e if necessary
Check safety requirements
sY e
No
sY e
oN
Yes
No
Mor M1 ork-
ot w
ing?
eck ot M Ch mor 1;
epl ecessar race if n y
No
Yes
3 Aero 20/25-21- Motor not working with switch set to “II”
Troubleshooting / Aero-20/25-21
Troubleshooting
10/23

D
fsNil i k
ALTO
Budy/Aero_V r.1.0_17 106d e 0
1.1 Disassembling/assembling the intake fitting
1.2 Disassembling/assembling the cover
1.) Press the two snap-in lugs (3) of the intake
fitting (1) outwards with special pliers (2) (see
E/1, page 19) while pulling the intake fitting (1)
frontally out of the suction head.
2.) Assembly:
Hold the intake fitting (1) correctly positioned and
push it into the container head (4) until the fitting
(1) audibly clicks into place.
1.) Remove the intake fitting (see D/1.1, page 11)
2.) Undo the two screws (1) with a Phillips
screwdriver.
3.) Press the locking button (2) located above the
cable entry (3) inwards with a small screwdriver
and lift off the cover (4).
4.) Assemble in the reverse order.
Cover / intake fitting
Intake fitting (1) in cover (4) .
Retaining screws (1) of Buddy cover.
Lifting off cover (4).
1 Suction head (Buddy)
Locking button (2) and cable entry (3) at
rear part of cover (4).
Aero 4040
3
2
Aero 4036
1
1
Aero 4034
3
4
Aero 4031
1
3
2
3
4
1
Se vice
r
11/23

D
f s
Nil i k
ALTO
Bud y/Aero_Vr.1.0_17106
de0
2.1 Disassembling/assembling the container ring (Aero 20 INOX only)
Pulling off container ring (2) by hand from
container (1).
Container / intake fitting
1.) Remove the suction head from the container (1)
2.) Put down the container (1) on its side. Firmly
pull off the container ring (2) by hand downwards
from the container (1) and remove it.
3.) Assembly:
Place the container (1) with its opening facing
downwards and press the container ring (2) onto
the container (1) as far as it will go, making sure
the intake fitting (3) is “centred” (5) between two
castors (4).
Aligning castors (4) “centred” (5) to intake
fitting (3).
2.2 Disassembling/assembling the intake fitting (Aero 20 INOX only)
1.) Remove the suction head from the container.
2.) Undo the retaining ring (1) by turning it while
pulling it off to the rear.
3.) Remove the intake fitting (2) from the
container.
4.) Assemble in the reverse order, making sure
the retaining ring (1) is positioned correctly.
Pulling off retaining ring (1) by hand from
intake fitting (2).
2 Container (Aero)
Aero 4155
1
2
Aero 4161
1
2
Aero 4157
3
4
4
5
evc
Srie
12/23

D
f s
Nil i k
ALTO
Bud y/Aero_Vr.1.0_17106
de0
2.3 Disassembling/assembling the intake fitting in the plastic container
Intake fitting (1) in place in container (2).
Container / intake fitting
Disassembly:
The intake fitting is snapped onto the container
and can only be removed by breaking it.
Assembly:
Hold the intake fitting correctly positioned in the
container opening and push it in until it audibly
clicks into place.
Intake fitting (1) before assembly in
container (2).
Aero 4224
1
2
Aero 4225
1
2
evc
Srie
13/23

D
f s
Nil i k
ALTO
Bud y/Aero_Vr.1.0_17106
de0
3.1 Disassembling/assembling the cover
3.2 Disassembling/assembling the locking clamp
1.) Undo the two screws (1) at the handle with a
Phillips screwdriver.
2.) Lift off the cover and put it down to the side.
3.) Assemble in the reverse order, making sure
cables are not squashed or caught up.
1.) Remove the cover ( see D/3.1 page 14).
2.) Pull out the clamp (1) laterally upward of the
snap-on connection (2).
3.) Assemble in the reverse order.
Cover / Clamps
Cover (2) with handle (3).
Locking clamp (1) mounted correctly on the
base.
3 Suction head / electrical components (Aero)
Pull out the clamp of the snap-on connecti-
on (2)
Aero 4092
1
1
3
2
Aero 4292
1
1
22
Aero 4293
1
22
evc
Srie
14/23

D
f s
Nil i k
ALTO
Bud y/Aero_Vr.1.0_17106
de0
3.3 Disassembling/assembling the power cord
1.) Remove the cover (see D/3.1, page 14).
2.) Disconnect the earth lead (1) from the
socket (Aero 20/25-11/21 only).
3.) Disconnect the two leads (2) from the
switch.
4.) Lift the insulating material out of the cover
(see D/3.7 page 17).
5.) Remove the cable from the strain relief (3)
and pull it out through the opening in the
clamping plate (3).
6.) Assemble in the reverse order.
Earth lead connection (1) at socket and
power connection (2) at switch.
Power cord routed through opening (3) and
strain relief (3) on clamping plate.
Power cord
Aero 4095
3
3
Aero 4094
1
2
2
evc
Srie
15/23

D
f s
Nil i k
ALTO
Bud y/Aero_Vr.1.0_17106
de0
3.4 Disassembling/assembling the switch
3.5 Disassembling/assembling the socket ( Aero 20/25-11/21 only)
1.) Remove the cover (see D/3.1, page 14).
2.) Mark the position of the cable lugs (1) and
disconnect all lugs from the switch (2).
3.) Press the switch (2) downwards and out of
the shell opening.
4.) Assemble in the reverse order.
Switch / socket
1.) Open the hinged cover (1), undo the two
screws (2) with a Phillips screwdriver and
remove the socket (3) frontally from the cover.
2.) Mark the position of the leads (4), disconnect
them from the socket (3) and take off the socket
(3)
3.) Assemble in the reverse order, making sure
the socket dome plate (5) is correctly positioned
inside the cover (6).
Note:
The cover (6) must be removed to check the
dome plate (5) (see D/3.1, page 14).
Cable lugs (1) connected to switch (2).
Cable connections (4) at socket (3).
Two retaining screws (2) of socket under
hinged cover (1).
Dome plate (5) mounted correctly inside
cover (6).
Aero 4252
2
2
1
3
Aero 4257
4
4
4
3
Aero 4271
3
6
5
Aero 4100
2
1
evc
Srie
16/23

D
f s
Nil i k
ALTO
Bud y/Aero_Vr.1.0_17106
de0
3.6 Disassembling/assembling the start-up unit
1.) Remove the cover (see D/3.1, page 14).
2.) Disconnect the brown (1), blue (1) and black
(1) leads from the switch.
3.) Disconnect the black lead (2) from the socket
and pull it off.
4.) Lift the insulating material out of the cover
(see D3.7, page 17).
5.) Disconnect the two motor leads (3) from the
start-up unit (4).
6.) Pull the unit (4) upwards out of its holder and
remove it.
7.) Assemble in the reverse order.
Start-up unit / clamping plate
3.7 Disassembling/assembling the clamping plate
1.) Remove the cover (see D/3.1, page 14).
2.) Lift out the insulating material (1).
3.) Disconnect the two motor leads from the
start-up unit (see D/3.6, page 17) and remove
the leads from the clamp.
Continued on next page
Cable connections (1+2) for start-up unit
(4) at switch and socket.
Start-up unit (4) with motor cable connec-
tions (3), mounted on clamping plate.
Insulating material (1) in place on
clamping plate.
Aero 4120
1
2
1
1
Aero 4151
1
Aero 4121
3
3
4
evc
Srie
17/23

D
f s
Nil i k
ALTO
Bud y/Aero_Vr.1.0_17106
de0
Clamping plate / motor
3.8 Disassembling/assembling the motor
1.) Disassemble the clamping plate (see D/3.7,
page 17).
2.) Mark the position of the motor (1) in the
support plate (4) and lift out the motor (1).
3.) Assemble in the reverse order, making sure
the motor bearing rings (3+4) are positioned
correctly.
4.) Disconnect the power leads from the switch
and the socket (see D/3.3, page 15).
5.) Pull the start-up unit (4) upwards out of its
holder (see D/3.6, page 17) and remove it
together with the cover.
6.) Undo the two screws (2) from the clamping
plate with a Phillips screwdriver and lift off the
clamping plate.
7.) Assemble in the reverse order, making sure
the motor leads are located correctly in the
clamps (3).
Motor (1) in support plate (2).
Retaining screws (2) of clamping plate and
clamp (3) for motor leads.
Upper motor bearing ring (3), mounted on
clamping plate.
Lower motor bearing ring (O-ring) (4),
mounted on support plate.
Aero 4152
2
2
3
3
Aero 4131
4
Aero 4132
3
Aero 4128
1
2
evc
Srie
18/23

D
f s
Nil i k
ALTO
Bud y/Aero_Vr.1.0_17106
de0
4.1 Disassembling/assembling the filter cleaning (tappet)
Filter cleaning (tappet (4)) in clamping
plate (2).
Tappet / flap
1.) Disassemble the clamping plate (see D/3.7,
page 17).
2.) Use pointed-end pliers (3) to press the snap-
in lugs (1) at the tappet (4) together while pulling
out the tappet (4) downwards.
3.) When assembling, push in the tappet (4) in
the correct position until the snap-in lugs (1)
audibly click into place.
4.2 Disassembling/assembling the filter cleaning flap
1.) Disassemble the clamping plate (see D/3.7,
page 17).
2.) Pull off the deduster flap (1) with the tension
spring (2) upwards and remove the flap (1).
3.) Assemble in the reverse order.
Filter cleaning flap (1) with tension spring
(2).
4 Filter cleaning (Aero)
Aero 4133
1
1
3
4
2
Aero 4138
1
2
evc
Srie
19/23

E
fsNil i k
ALTO
Budy/Aero_V r.1.0_17 106d e 0
1 Special tools
1.) Special pliers (p/n: 302002482)
Special tools
Special pliers (p/n: 302002482) for removal
of intake fitting used for Buddy series.
Aero 4044
T ols
o
