Nilox NX-POS15PCAP User manual

Hard disk installation
1. Remove screw.
2. Move from both sides up.
3. Loosen the screw.
4. Grab the handle and pull up or down. Remove
or install the hard drive.
RAM Instalation
1. Loosen the screw.
2. Grasp both sides and pull down on the back
cover.
3. Loosen the screw.
4. Replace or install the memory.
Caution
Security notice
Read carefully and strictly comply with the use of the following
instructions before using the printer.
 Warning: Disconnect the adapter power supply before
opening any part of the system.
 Warning: The power supply is always in standby, it is
on, after plugging in the adapter.
 Warning: It can cause permanent damage to your
system when you open any part of it.
Recomendations
1. The POS should be installed in a firm place and avoid
vibrations and shaking.
2. Do not use the product in areas with high temperature or
high humidity since it may cause a malfunction in the
equipment.
3. The POS power supply must be connected to a suitable
earth connection. Avoid using the same plug with other
large electrical machines or this equipment could cause
voltage fluctuation.
4. Use only the standard power supply supplied with the POS.
5. Do not disassemble this product. Incorrect mounting can
cause an electric shock. Leave it to qualified personnel if
necessary.
6. Do not allow water or conductive material such as metal
inside the POS, if it occurs, turn off the power supply
immediately.
7. Unplug this product from the mains before cleaning it. Do
not use cleaning liquid or aerosol cleaner. Use a damp cloth
to clean the cover.
8. The screen is tactile, as the name indicates must be used
with your finger or pointers specially designed for it. Never
use metal, sharp objects, plastics, cards, ... that could
damage the screen. This can significantly shorten the life of
the screen and the loss of the warranty.
9. Make sure that the POS is switched off when you connect
the RS232 (COM) connections.
Quick Guide POS
NX-POS15PCAP

Key features and
specifications
● Robust design with metal housing
● Without mechanical parts (Without fan and SSD hard
disk)
● Exquisite and beauful exterior design
● Low noise level (no fan)
● Screen without mulpoint borders
● Great connecvity: 2 LAN, 6 USB, 3 COM, ...
● Mulple accessories: Customer display, magnec
stripe reader, second monitor, ...
Content
We recommend that the user check that the
box includes all the items listed here:
 POS (1 Unit)
 Power supply (1 Unit)
Mains power cable to power supply
(1 unit)
 CD (Optional)
Diagram
1. Wired cover
2. Slot reader magnetic stripe cards
3. Slot customer display or second
screen
4. Vesa 75
5. Vesa 100
Installation of peripherals
1. Disconnect the power adapter before opening
any part of the system. The power is always on
and waiting after plugging in the adapter.
2. It can cause permanent damage to your system
when you open any part of the system.
3. To install the peripheral cables, follow the
method described below.
3.1
Open the cable cover and
the hinge cover
3.2
Follow the shape of
the drawing for the
wiring
3.3
Plug all
the cables into the
ports
3.4
Final result
