Ninja StormSweeper NWCU1300N User manual

MODELS:
NWCU1300N
10070780
CUS
3146518
Operating instructions (ENG)
Read these instructions before using the machine.
86329640-B
10/06/09

2 86329640 NINJA STORM SWEEPER
Machine Data Log / Overview
OVERVIEW
The Storm Sweeper is an electric powered water recovery system intended for commercial use. This appliance
vacuums excess water from carpet and hard surfaces into the recovery tank.
Model:
Date of Purchase:
Serial Number:
Dealer:
Address:
Phone Number:
Sales Representative:

86329640 NINJA STORM SWEEPER 3
Table of Contents
Machine Data Log / Overview. . . . . . . . . . . . . . . . . .2
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . .3
How to Use This Manual . . . . . . . . . . . . . . . . . . . . . .4
Safety
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . .5
HAZARD INTENSITY LEVEL. . . . . . . . . . . . . . . . . .6
Safety Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Grounding Instructions . . . . . . . . . . . . . . . . . . . . . . .8
Operations
Technical Specifications . . . . . . . . . . . . . . . . . . . . . .9
Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Machine Operation . . . . . . . . . . . . . . . . . . . . . . . . .11
Recovery System . . . . . . . . . . . . . . . . . . . . . . . . . .11
Auto Pump-out . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Pre-Run Inspection. . . . . . . . . . . . . . . . . . . . . . . . .11
Equipment Set-up. . . . . . . . . . . . . . . . . . . . . . . . . .11
Maintenance
Periodic Maintenance . . . . . . . . . . . . . . . . . . . . . . .12
Daily/Regular Maintenance. . . . . . . . . . . . . . . . . . .12
Vacuum Motor Replacement . . . . . . . . . . . . . . . . .13
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . .14
PARTS
Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Housing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Pump-out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Recovery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Vacuum. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Suggested Spare Parts. . . . . . . . . . . . . . . . . . . . . 34
Serial Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

4 86329640 NINJA STORM SWEEPER
How to Use This Manual
This manual contains the following sections:
• How to Use This Manual
•Safety
• Operations
• Maintenance
•PartsList
The HOW TO USE THIS MANUAL section will tell you
how to find important information for ordering correct
repair parts.
Parts may be ordered from authorized dealers. When
placing an order for parts, the machine model and
machine serial number are important. Refer to the
MACHINE DATA box which is filled out during the
installation of your machine. The MACHINE DATA box
is located on the inside of the front cover of this manual.
The model and serial number of your machine is
located approximately where shown.
Model:
Date of Purchase:
Serial Number:
Dealer:
Address:
Phone Number:
Sales Representative:
The SAFETY section contains important information
regarding hazardous or unsafe practices of the
machine. Levels of hazards are identified that could
result in product damage, personal injury, or severe
injury resulting in death.
The OPERATIONS section is to familiarize the operator
with the operation and function of the machine.
The MAINTENANCE section contains preventive main-
tenance to keep the machine and its components in
good working condition. They are listed in this general
order:
• Periodic Maintenance
• Daily/Regular Maintenance
• Vacuum Motor Replacement
• Troubleshooting
The PARTS LIST section contains assembled parts
illustrations and corresponding parts list. The parts lists
include a number of columns of information:
•REF – column refers to the reference number
on the parts illustration.
•PART NO. – column lists the part number for
the part.
•PRV NO. – reference number.
•QTY – column lists the quantity of the part used
in that area of the machine.
•DESCRIPTION – column is a brief description
of the part.
•SERIAL NO. FROM – If this column has an (*)
and a Reference number, see the SERIAL
NUMBERS page in the back of your manual. If
column has two asterisk (**), call manufacturer
for serial number. The serial number indicates
the first machine the part number is applicable
to. The main illustration shows the most current
design of the machine. When a boxed illustra-
tion is shown, it displays the older design.
•NOTES – column for information not noted by
the other columns.
NOTE: If a service or option kit is installed on your
machine, be sure to keep the KIT INSTRUCTIONS
which came with the kit. It contains replacement parts
numbers needed for ordering future parts.
NOTE: The manual part number is located on the
lower left corner of the front cover.
Serial Number
Tag

86329640 NINJA STORM SWEEPER 5
Safety
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precaution
must always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE.
This machine is for commercial use.
To reduce the risk of fire, electric shock, or injury:
Connect to a properly grounded outlet. See Grounding Instructions.
Do not leave the machine unattended. Unplug machine from outlet when not in use and before mainte-
nance or service.
Use only indoors. Do not use outdoors or expose to rain.
Do not allow machine to be used as a toy. Close attention is necessary when used by or near children.
Use only as described in this manual. Use only manufacturer's recommended components and attach-
ments.
Do not use damaged electrical cord or plug. Follow all instructions in this manual concerning grounding
the machine. If the machine is not working properly, has been dropped, damaged, left outdoors, or
dropped into water, return it to an authorized service center.
Do not pull or carry machine by electrical cord, use as a handle, close a door on cord, or pull cord around
sharp edges or corners.
Do not run machine over cord. Keep cord away from heated surfaces.
Do not unplug machine by pulling on cord. To unplug, grasp the electrical plug, not the electrical cord.
Do not handle the electrical plug or machine with wet hands.
Do not operate the machine with any openings blocked. Keep openings free of debris that may reduce
airflow.
This machine is intended for cleaning carpet only.
Do not vacuum anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
This machine is not suitable for picking up health endangering dust.
Turn off all controls before unplugging.
Machine can cause a fire when operating near flammable vapors or materials. Do not operate this
machine near flammable fluids, dust or vapors.
This machine is suitable for commercial use, for example in hotels, schools, hospitals, factories,
shops and offices for more than normal housekeeping purposes.
Maintenance and repairs must be done by qualified personnel.
If foam or liquid comes out of machine, switch off immediately.
SAVE THESE INSTRUCTIONS

6 86329640 NINJA STORM SWEEPER
Safety
The following symbols are used throughout this guide as indicated in their descriptions:
HAZARD INTENSITY LEVEL
There are three levels of hazard intensity identified by signal words -WARNING and CAUTION and FOR
SAFETY. The level of hazard intensity is determined by the following definitions:
WARNING - Hazards or unsafe practices which COULD result in severe personal injury or death.
CAUTION - Hazards or unsafe practices which could result in minor personal injury or product or
property damage.
FOR SAFETY: To Identify actions which must be followed for safe operation of equipment.
Report machine damage or faulty operation immediately. Do not use the machine if it is not in proper
operating condition. Following is information that signals some potentially dangerous conditions to the
operator or the equipment. Read this information carefully. Know when these conditions can exist. Locate
all safety devices on the machine. Please take the necessary steps to train the machine operating
personnel.
FOR SAFETY:
DO NOT OPERATE MACHINE:
Unless Trained and Authorized.
Unless Operation Guide is Read and understood.
In Flammable or Explosive areas.
In areas with possible falling objects.
WHEN SERVICING MACHINE:
Avoid moving parts. Do not wear loose clothing; jackets, shirts, or sleeves when working on the
machine. Use only manufacturer approved replacement parts.

86329640 NINJA STORM SWEEPER 7
Safety
Safety Labels
NOTE: These drawings indicate the location of safety labels on the machine. If at any time the labels
become illegible, promptly replace them.
Label Warning
86244300
PRV # 500955

8 86329640 NINJA STORM SWEEPER
Safety
Grounding Instructions
THIS PRODUCT IS FOR COMMERCIAL
USE ONLY.
ELECTRICAL:
In the USA this machine operates on a standard 15
amp 115V, 60 hz, A.C. power circuit. The amp, hertz,
and voltage are listed on the data label found on each
machine. Using voltages above or below those
indicated on the data label will cause serious damage
to the motors.
EXTENSION CORDS:
If an extension cord is used, the wire size must be at
least one size larger than the power cord on the
machine, and must be limited to 50 feet (15.5m) in
length.
GROUNDING INSTRUCTIONS:
This appliance must be grounded. If it should malfunc-
tion or break down, grounding provides a path of least
resistance for electric current to reduce the risk of
electric shock. This appliance is equipped with a cord
having an equipment-grounding conductor and
grounding plug. The plug must be inserted into an
appropriate outlet that is properly installed and
grounded in accordance with all local codes and ordi-
nances.
This appliance is for use on a nominal 120-volt circuit,
and has a grounded plug that looks like the plug in "Fig.
A". A temporary adaptor that looks like the adaptor in
"Fig. C" may be used to connect this plug to a 2-pole
receptacle as shown in "Fig. B", if a properly grounded
outlet is not available. The temporary adaptor should
be used only until a properly grounded outlet (Fig. A)
can be installed by a qualified electrician. The green
colored rigid ear, lug, or wire extending from the
adaptor must be connected to a permanent ground
such as a properly grounded outlet box cover.
Whenever the adaptor is used, it must be held in place
by a metal screw.
Improper connection of the equipment-grounding
conductor can result in a risk of electric shock.
Check with a qualified electrician or service person
if you are in doubt as to whether the outlet is
properly grounded. Do not modify the plug
provided with the appliance - if it will not fit the
outlet, have a proper outlet installed by a qualified
electrician.

86329640 NINJA STORM SWEEPER 9
Operations
Technical Specifications
ITEM MEASURE
Electrical 115 Volt, 60 hz, 12A
Recovery Capacity 11 Gal
Height 43 inches
Length 30 inches
Width 22 inches
Vacuum Motor Single 3 Stage
Weight-Empty 107 lbs
Power Cord 1 x 40 feet in-line GFCI
Auto Pump-out 2 x 5.0 GPM Diaphragm Pumps
Height
Length
Width

10 86329640 NINJA STORM SWEEPER
Operations
Controls
1. Vacuum Accessory Tool Hook-up
2. Vacuum Circuit Breaker
3. Vacuum Switch
1234
5
4. Auto Pump-out Switch
5. Auto Pump-out Connection

86329640 NINJA STORM SWEEPER 11
Operations
Machine Operation
Recovery System
The recovery system uses suction from the vacuum
motor to draw water and debris into the recovery tank.
Large debris is collected in the mesh bag attached to
recovery inlet. The recovery tank may be emptied
manually using the gate valve or continuously using the
auto pump-out system. A shutoff float will impede the
vacuum flow when the recovery tank is full.
Auto Pump-out
The auto pump-out system uses a run-dry diaphragm
pump. The pump will run whenever the pump-out
switch is turned on. The primary strainer is located in
the recovery tank. A secondary strainer is attached to
the pump head to protect the pump from a damaged or
improperly installed primary strainer.
Do not turn on auto pump-out with cap attached to
the pump-out fitting. Pump-out system damage
may occur from excessive pressure.
Pre-Run Inspection
1. Check all fittings and connectors for proper
assembly.
2. Check all hoses for leaks. Repair or replace any
damaged hoses.
3. Check power cord(s) for any damage. If damaged,
replace.
Equipment Set-up
1. Plug power cord from machine into properly
grounded wall outlet.
2. Turn vacuum motor switch on and off to make sure
there is electrical power at machine.
3. If using the auto pump-out feature, connect pump-
out hose to pump-out fitting on control panel. Place
opposite end of pump-out hose in appropriate drain
area.
4. Connect vacuum hose to machine. Slide the swivel
cuff over the outlet on the tank,
5. Turn pump and vacuum switches to the on
position.

12 86329640 NINJA STORM SWEEPER
Maintenance
Periodic Maintenance
Twice a month, flush a white vinegar solution (one
quart vinegar to two gallons of water) or anti-browning
solution (mixed as directed) through the machine. This
will prevent build-up of alkaline residue in the system.
Periodically inspect all hoses, electrical cables and
connections on your machine. Frayed or cracked hoses
should be repaired or replaced to eliminate vacuum or
solution pressure loss. The electrical cable must be
well insulated and cable connector screw kept tight. If
the cable insulation is broken or frayed, repair or
replace immediately. Don't take chances with electrical
fire or shock.
SERVICE SCHEDULE DAILY WEEKLY QUARTERLY
Check machine for cord damage *
Check recovery dome and gasket for damage and cleanliness *
Check hoses for wear, blockages, or damage *
Check handles, switches, and knobs for damage *
Clean out recovery tank and check float valve to make sure it moves freely *
Clean outside of all tanks and check for damage *
Clean recovery mesh bag *
Clean pump-out strainers and run clean water through pump-out system *
Run vac motor for at least one minute to allow motor to dry *
Store with dome off tank to allow the tank to dry *
Check all gaskets for wear and leakage *
Check cables for fraying *
Check overall performance of machine *
Check vac motor carbon brushes *
Daily/Regular Maintenance
Before making any repairs or adjustments to the
machine, disconnect the power cords from the
electrical source.
1. Inspect and clean recovery mesh bag and pump-
out strainer.
2. Flush pump-out system with 1 to 2 gallons of clean
water.
3. After each use, rinse tank with fresh water. Periodi-
cally inspect the recovery tank and decontaminate
if necessary, using a Hospital Grade Virucide or a
10-1 bleach to water solution. Waste water should
be disposed of properly.
Do not allow machine to freeze.

86329640 NINJA STORM SWEEPER 13
Maintenance
Only qualified maintenance personnel are to
perform the following repairs.
Vacuum Motor Replacement
1. Turn off all switches and unplug machine.
2. Remove hardware under front of machine to
access component compartment.
3. Remove vacuum motor cover and disconnect
motor wires.
4. Remove the vacuum motor.
5. Reverse process to install vacuum motor.
Vacuum Motor Carbon Brushes Replacement
3
8[9.5mm]
Carbon
Brushes
End Cap
WARNING: The
green ground wire
must be attached for
safe operation. See
wiring diagram.
If armature commutator is grooved, extremely pitted
or not concentric, the motor will need to be replaced
or sent to a qualified service center.
Important:
These brushes wear quicker as the length shortens
due to increased heat. Spring inside brush housing
will damage motor if brushes are allowed to wear
away completely.
Periodically check the length of the carbon brushes.
Replace both carbon brushes when either is less than
3/8" (9.5mm) long.

14 86329640 NINJA STORM SWEEPER
Maintenance
Troubleshooting
PROBLEM CAUSE SOLUTION
Loss of Power Unit not plugged in Connect unit to 3 prong grounded outlet. Dead electrical circuit Check building circuit breaker or fuse box.
Faulty power cord Replace
Electrical shock Receptacle not grounded Contact an electrician to check building's wiring
Internal wiring problem Have a trained service technician check
machine's wiring
Vac motor speed
varies or doesn't run
Vacuum circuit breaker tripped Reset Breaker
Faulty vacuum motor Replace
Faulty switch Replace
Loss of vacuum
Loose vacuum dome Center and seal dome over tank
Crack in dome of poor joint Replace or repair using acrylic plastic cement
only
Lint or dirt clogging vacuum screen With power off clean screen
Loose cuffs on vacuum hose Tighten cuffs turning counterclockwise
Vac motor seals leaking Replace
Floor tool vac chamber clogged Wash out with hose. Pick lint out with a wire
Vacuum hose damaged Replace
Recovery tank full / Float ball stuck in
the up position Turn off power, drain recovery tank.
Pump-out system has
no flow
Faulty pump-out switch Replace pump-out switch
Faulty pump-out pump Replace pump-out pump
Blown fuse Replace fuse
Pump-out system has
low flow Clogged primary strainer Clean primary strainer
Clogged secondary strainer Clean secondary strainer

86329640 NINJA STORM SWEEPER
PARTS

16 86329640 NINJA STORM SWEEPER
Control Panel
4
7
8
10
11 12
13
10
2
1
9
3
6
5

86329640 NINJA STORM SWEEPER 17
Control Panel
REF PART NO. PRV NO. QTY DESCRIPTION SERIAL NO.
FROM NOTES
1 86328340 - 1 PANEL, CONTROL, STORM
2 86327130 - 1 WASHER,.88IDX1.28ODX.062THK
NYL
3 86327080 - 1 HOSEBARB, 1/2 FPT X 1/2 BR
4 86318320 - 1 BREAKER, 13A, 250VAC, 32VDC
5 86313030 - 4 GASKET, .125 T X .25 W X 7.2
6 86313020 - 2 GASKET, .125 T X .25 W X 15.6
7 86173530 790506 1 ADAPTER, HOSE 1/2M X 3/4MGT
8 86008900 80845 1 BOOT, SEAL PUSH BUTTON 7/16
9 86007140 72130 2 SWITCH, SPST 2-POSITION
ROCKER
10 86276820 70740 6 SCR, 10-32 X 1/2 PTHMS BLK NP
11 86005700 57104 2 NUT, 10-32 HEX W/STAR
12 86005670 57040 1 NUT, 1/2 NPT CONDUIT
13 86002370 20035 1 CLAMP, 7/16 NYLON

18 86329640 NINJA STORM SWEEPER
Frame
1
2
34
5
67
8
9
10
11

86329640 NINJA STORM SWEEPER 19
Frame
REF PART NO. PRV NO. QTY DESCRIPTION SERIAL NO.
FROM NOTES
1 86199430 040-03 2 CASTER, SWIVEL 4" 250# CPCTY
2 86001660 41236 2 HUBCAP, 5/8 SHAFT
3 86005810 57245 8 NUT, 1/4-20 HEX NYLOCK SS
4 86276080 70595 1 SCR, 10-32 X 1” PPHMS GRN
5 86010630 87013 8 WASHER, 1/4 X 5/8 FLAT SS
6 86005700 57104 2 NUT, 10-32 HEX W/STAR
7 86010730 87088 4 WASHER, 5/8 X 1-3/16 FLAT SS
8 86300070 - 2 HUBCAP, 9.75" WHEEL, BLACK
9 86309790 - 2 WHEEL, 12" X 2.25”
10 86312830 - 1 FRAME, 5/8" AXLE, DUAL VAC
11 86277500 70853 8 SCR,1/4-20 X 5/8 CARR SS

20 86329640 NINJA STORM SWEEPER
Electrical
3
18
19
6
15
14
13
10
3
1
9
17
5
7
11
2
4
8
16
12
