NIPROS HDM-90WV User manual

HDM-90WV
HDMonitor
Volume1,1steditionVer.1.0
Operating Instructions
Beforeoperatingthesystem,pleasereadthismanual
thoroughlyandremainitforfuturereference.
TM

WARNING
For the customers in the U.S.A.
This equipment has been tested and found
to comply with the limits for a Class A
digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against
harmful interference when the equipment is
operated in a commercial environment.
This equipment generates, uses, and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instruction manual, may cause harmful
interference to radio communications.
Operation of this equipment in a residential
area is likely to cause harmful interference
in which case the user will be required to
correct the interference at his own ex-
pense.
You are cautioned that any changes or
modifications not expressly approved in
this manual could void your authority to
operate this equipment.
All interface cables used to connect periph-
erals must be shielded in order to comply
with the limits for a digital device pursuant
to Subpart B of Part 15 of FCC Rules.
To reduce the risk of fire or electric
shock,do not expose this apparatus to rain
or moisture.
To avoid electrical shock, do not open the
cabinet. Refer servicing to qualified per-
sonnel only.
WARNING
When installing the unit, incorporate a
readily accessible disconnect device in the
fixed wiring, or connect the power plug to
an easily accessible socket-outlet near the
unit. If a fault should occur during opera-
tion of the unit, operate the disconnect
device to switch the power supply off, or
disconnect the power plug.
Do not install the appliance in a confined
space, such as book case or built-in cabi-
net.
IMPORTANT
The nameplate is located on the bottom.
WARNING
Excessive sound pressure from earphones
and headphones can cause hearing loss.In
order to use this product safely, avoid
prolonged listening at essive sound pres-
sure levels.This equipment shall not be
exposed to excessive heat such as sun-
shine, fire or the like.
02

WARNING
For the customers in the U.S.A.
This equipment has been tested and found
to comply with the limits for a Class A
digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against
harmful interference when the equipment is
operated in a commercial environment.
This equipment generates, uses, and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instruction manual, may cause harmful
interference to radio communications.
Operation of this equipment in a residential
area is likely to cause harmful interference
in which case the user will be required to
correct the interference at his own ex-
pense.
You are cautioned that any changes or
modifications not expressly approved in
this manual could void your authority to
operate this equipment.
All interface cables used to connect periph-
erals must be shielded in order to comply
with the limits for a digital device pursuant
to Subpart B of Part 15 of FCC Rules.
To reduce the risk of fire or electric
shock,do not expose this apparatus to rain
or moisture.
To avoid electrical shock, do not open the
cabinet. Refer servicing to qualified per-
sonnel only.
WARNING
When installing the unit, incorporate a
readily accessible disconnect device in the
fixed wiring, or connect the power plug to
an easily accessible socket-outlet near the
unit. If a fault should occur during opera-
tion of the unit, operate the disconnect
device to switch the power supply off, or
disconnect the power plug.
Do not install the appliance in a confined
space, such as book case or built-in cabi-
net.
IMPORTANT
The nameplate is located on the bottom.
WARNING
Excessive sound pressure from earphones
and headphones can cause hearing loss.In
order to use this product safely, avoid
prolonged listening at essive sound pres-
sure levels.This equipment shall not be
exposed to excessive heat such as sun-
shine, fire or the like.
02

各部名称と働き
NamesandFunctionsofParts
接続方法
Connection
調整および設定
AdjustmentandSetting
外形寸法図
OutsideView&Dimmensions
仕様
Specifications
40
41
4
22
18
HDM-90WV目次
Tableofcontents目次
HDM-90WV
Frontpanel 4
Rearpanel 6
Functions(MENU) 10
機能(メニュー)
フロントパネル
リアパネル
3

HDM-90WV各部名称と働き
NamesandFunctionsofParts各部名称と働き
4
HDM-90WV
フロントパネル
Frontpanel
Screen
Thedisplayscreenis9.0inchesdiagonalLCD(Activearea:198.7mm111.7mm）.
スクリーンは9インチ液晶、画面寸法198.7mm111.7mmです。
POWERswitchandPOWERIndicatorLED
TurnonthepowersupplythroughtheDCIN(12V)connector.
Whenthepowerissupplied,thePOWERindicatorLEDlightson.
電源スイッチをONすると、電源表示LEDが点灯します。
TALLYindicator
LightsupwhenatallysignalisinputtoPARALLELREMOTEconnectorontherearpanel.
背面のPARALLELREMOTEコネクタに入力されるタリー信号により点灯します。
MENUbuttonandRETURNbutton
＜MENU＞
BypressingandholdingthisbuttondisplaytheMENUonthescreen.
Andthenbyrotatingitselectthemenuitemandbypressingitsetthesetting.
BypressingtheRETURNbuttonreturnthecursor.
FortheinformationontheMENU,seepage11-18.
＜FRONTVOLUMEandPICTUREFunctions＞
BypressingthisbuttondisplaytheVOLUMEorPICTUREfunctionasfollowsinsequence.
Andthenbyrotatingitadustthelevel.Evenifthedisplayhasdisappeared,byrotatingitthefuction
appearesonthescreen.
VOLUME15
PEAKINGWHITE0
BRIGHT50
CONTRAST80
CHROMA50
メニュー:11〜18ページ参照
メニューボタンを長押しすると、メニューが画面にでます。
メニューボタンを押すと、VOLUME、PICTURE項目が画面にでます。

5
フロントパネル
Frontpanel
F1/2/3/4/5/6/7/8/9(USERASSIGNPresetFunction)buttonsandindicationLEDs
PressingabuttonexecutesthefunctionassignedtoeachbuttoninMENUsetting.
Whenthefuncionoperates,theindicationLEDonthekeylightsup.
ThefunctionsthatcanbeassignedtothePresetFunctionbuttonsfromF1toF9areasfollows.
FortheinformationontheUSERASSIOGN,seepage30-31.
メニューのUSERASSIGNの設定でF1〜F9に割り振られているファンクションの実行をON/OFFします。
ONのとき表示LEDが点灯します。F1〜F9に割り振られるファンクションの項目は次の通りです。
参照30,31ページ
HDM-90WV各部名称と働き
HDM-90WV
LED
＜PresetFunctionitem＞
USERASSIGNPresetFunctions
MFGDEFAULTSetting
F1［SDI1］
F2［SDI2］
F3［SCAN］
F4［ASPECT］
F5［MARKER］
F6［MAGNIFY］
F7［WAVEFORMMON］
F8［VECTORSCOPE］
F9［AUDIOMETER］
プリセットファンクションデフォルト設定
Monitorspeaker
UsedtomonitortheaudiosignalselectedbypressingtheVOLUME/PUSHSELECTswitch.
Whenaheadphoneisconnectedtothejack,themonitorspeakerdoesnʼtwork.
VOLUME/PUSHSELECT(ボリューム/切替)スイッチを押して選択した音声信号をモニターします。
ヘッドホンが差し込まれていると、モニタースピーカーからは音はでません。
Headphonejack(φ3.5stereojack)
UsedtomonitortheaudiosignalsselectedontheMENUandoutputtotheAUDIOOUTconnector.
TheaudiooutputvolumelevelisadjustedontheMENU.
メニューで選択し、AUDIOOUTコネクタへ出力されるオーディオ信号を出力します。ボリューム調整はメニューボタンで行います。
SDI1
SDI2
GAMMA1.0/1.8/2.0/2.2/2.4/2.6/2.35
WHITEBALD65
WHITEBALD93
MONO
COLORCHANNEL
SCAN
ASPECT
MAGNIFY
HVDELAY
PIXELBYPIXEL
MARKER
USERMARKER
AUDIOMETER
AUDIOPEAKLOG
AUDIOPHASEMON
AUDIOPRESET1/2/3/4/5/6/7/8
AUDIOMUTE
LAYOUTWFM
LAYOUTWAV
LAYOUTVS
LAYOUTALM16
LAYOUTQUAD
LAYOUTQUAD2
WAVEFORMMON
VECTORSCOPE
ClipGuide
TIMECODE
HISTOGRAM
FALSECOLORTG
FALSECOLORMTF
PEAKINGCOLOR
3DREVIEW
ANAGLYPH
FANSTOP
HIDEALLUTIL
3DLEFTEYE
3DRIGHTEYE
3DBLENDING
3DLUMADIFF
3DCHROMADIFF
GLYPHCOLOR
GLYPH1/2COLOR
GLYPHOPTIMIZED
GLYPHGRAY

HDM-90WV各部名称と働き
6
HDM-90WV
リアパネル
Rearpanel
AUDIOOUTconnector(Unbalancedstereooutput)(φ3.5stereojack)
UsedtooutputtheHD-SDIembeddedaudiosignalsselectedontheMENU.
Theaudiooutputchannelselection,thevolumeleveladjustment,etc.operateintheMENU.
メニューで選択したHD-SDIエンベデッドオーディオ信号を出力します。オーディオ出力のCH選択、ボリューム調整等、
はメニューで行います。
DCIN12Vconnector(XLR4-pin)
ConnecttothesuppliedACAdaptortosupplyDC12Vpower.
ACアダプタを接続して電源を供給します。
SDI(3G/HD/SD)IN1/2connectors(BNCtype)
UsedtoinputHD/SD-SDIsignal.SelectaninputsignalontheMENUorbyFunctionbutton.
HD/SD-SDI信号を入力します。入力信号の選択は、メニューまたはユーザープリセットファンクションボタンで行います。
SDI(3G/HD/SD)OUTconnector(BNCtype)
UsedtooutputtheHD/SD-SDIsignaldisplayedonthescreen.
選択されて画面に表示されているHD/SD-SDI入力信号が出力されています。

HDM-90WV各部名称と働き
7
HDM-90WV
リアパネル
Rearpanel
RearTALLYIndicator(REDonly)
LightsuptoREDwhenthetallysignalisinputtothePARALLELREMOTEconnector.
SetthetallyfunctionsintheMENU,REMOTE.
ThebrightnessisexchangeabletoOFF/L(low)/H(high)bytheTALLYOFF/L/Hdisplayselectswitch.
リアタリー(レッドのみ)は、PARALLELREMOTEのタリー信号で点灯します。メニューのREMOTEでセットします。
切替スイッチでOFF(消灯)/L(low減光)/H(high)に切り替えることができます。
TALLYOFF/L/Hdisplayselectswitch
Thebrightnessofthereartallyindicator(REDonly)canbeselectedasfollows.
H:Thetallyindicatorlightsupbrightly.
L:Thetallyindicatorisdimmedtothelowerbrightness.
OFF:Thetallylampispreventedfromlighting.
リアタリー(レッドのみ)を(OFF(消灯)/L(low:減光)/H(high))に切替えます。
TALLYHOLDER
Whenthereartallyisnotused,thetallyluminousplateisheld.
リアタリーを使用しないとき、タリーの発光プレートを収納します。
tallyluminousplate

HDM-90WV各部名称と働き
8
HDM-90WV
リアパネル
Rearpanel
PARALLELREMOTE(remotecontrolsignalinput)connector(8-pin,RJ-45)
Usedfortheremotecontrol:e.g.forinputoftheTALLYsignal,INPUTsignalselectionand
PresetFunctionoperation.
Thepinassign,defaultsettingisasthetableshows.
Thecontrolsignalistoshort-circuiteachpinwithPIN5.
リモートコントロール-例えば,タリー信号入力,入力切替え,プリセットファンクションのON/OFF等に使用します。
ピンアサインはデフォルトでは表のようになっています。
コントロール信号は各ピンと5番ピンとのショートです。
PIN1［RTALLY］
PIN2［GTALLY］
PIN3［BTALLY］
PIN4［MARKER］
PIN5［GROUND］
PIN6［SDI1］
PIN7［SDI2］
PIN8［ASPECT］
PinAssign
PIN1［レッドタリー］
PIN2［グリーンタリー］
PIN3［ブルータリー］
PIN4［マーカー］
PIN5［GROUND］
PIN6［SDI1］
PIN7［SDI2］
PIN8［アスペクト比］
ピンアサイン
RTALLY
GTALLY
BTALLY
LEFTRTLY
LEFTGTLY
LEFTBTLY
RIGHTRTLY
RIGHTGTLY
RIGHTBTLY
SDI1
SDI2
GAMMA1.0
GAMMA1.8
GAMMA2.0
GAMMA2.2
GAMMA2.4
GAMMA2.6
GAMMA2.35
WHITEBALD65
WHITEBALD93
MONO
SCAN
ASPECT
MAGNIFY
HVDELAY
REDONLY
BLUEONLY
GREENONLY
PIXELBYPIXEL
MARKER
USERMARKER
AUDIOMETER
AUDIOPEAKLOG
AUDIOPHASEMON
AUDIOPRESET1
AUDIOPRESET
AUDIOPRESET3
AUDIOPRESET4
AUDIOPRESET5
AUDIOPRESET6
AUDIOPRESET7
AUDIOPRESET8
AUDIOMUTE
LAYOUTWFM
LAYOUTWAV
LAYOUTVS
LAYOUTALM16
LAYOUTQUAD
LAYOUTQUAD2
WAVEFORMMON
VECTORSCOPE
ClipGuide
TIMECODELTC
TIMECODEVITC1
TIMECODEVITC2
HISTOGRAM
FALSECOLORTG
FALSECOLORMTF
3DLEFTEYE
3DRIGHTEYE
3DBELDING
3DLUMADIFF
3DCHROMADIFF
GLYPHCOLOR
GLYPH1/2COLOR
GLYPHOPTIMIZED
GLYPHGRAY
HIDEALLUTIL
＜Assignablefunctionitem＞

HDM-90WV各部名称と働き
9
HDM-90WV
リアパネル
Rearpanel
Fan
Fanworkswhenthepowerswitchisturnedon.
ThefanoperationcanbesettoAUTO,MAXorOFF,ontheMENU,SETUP,FANCONTROL..
AndFANSTOPfunctioncanbeassignedtothefunctionbutton,F1toF9onthefrontpanel.
ファンはPOWERスイッチONのとき動作します。ファンの動作は、AUTO/MAX/OFFにメニューで設定できます。
FANSTOP機能がフロントパネルのファンクションボタンにユーザー設定できます。
Handle
Usedforcarrying.
持ち運び用取っ手。
BaseStand(Locationstand)
Thedisplayangleofthescreencanbechanged(angleofelevation=20）.
スタンドは、画面の角度を変えることができます。(仰角20)
Camerascrewholes(2-w1/4(top,bottom)and2-w  3/8(top,bottom))
Usedtobefittedtoatripodortothesupplieduniversalhead.
三脚等またはユバーサルヘッドへの取り付けに使用します。
(bottom) (top)
w 3/8
w 1/4
TALLYHOLDER
RearTALLY
TALLYOFF/L/Hswitch
w 3/8
w 1/4

HDM-90WV各部名称と働き
10
HDM-90WV
［1］MENUOperation
MENU:PresstheMENUbutton
PressandholdtilltheMENUisdisplayedonthescreen.
INFO［1080i/60］
INPUT［SDI1］
COLOR［D65/709］
SCREEN［16:9］
MARKER［OFF］
AUDIO［15］
AUDIOUTIL
WAVEFORM［ON］
VECTORSCOPE［ON］
ClipGuide［OFF］
USERASSIGN
REMOTE
SDISTATUS［OFF］
IMD［OFF］
SETUP
MODELPMD-9900L
INPUTSDI1
FORMAT1080i/59.94
COLORMATRIX709
COLORTEMPD65
3DREVIEWOFF
ANAGLYPHOFF
AUDIOPEAKLOGOFF
AUDIOPHASEMONOFF
SDIERRORCOUNT0
SDILEVELHD
UNKNOWNUNKNOWN
VERSION###
Displaysthevideoformat
oftheinputsignal.
メニューの操作について
＜MENUItem＞メニュー項目
＜MENUSettingItem＞設定項目 ＜SettingValue＞設定値
RETURN
COLORMATRIX［709］
COLORTEMP［D65］
REDBIAS［0］
GREENBIAS［0］
BLUEBIAS［0］
REDGAIN［1.00］
GREENGAIN［1.00］
BLUEGAIN［1.00］
AUTO
RGB
BT.601
BT.709
入力信号のビデオフォーマット
が表示されます。
無信号のときは”NOSYNC”
［confirm］
Press
Rotate
MENUItemSlection:RotatetheMENUbutton
Rotatetomovethecursortothedesiredsettingitem.
MENUSetting:PresstheMENUbutton
Presstoconfirmtheselecteditemorsettingvalue.
RETURN:PresstheRETURN(F9)button
PresstoreturnthecursorandtheMENUdisappears.
MENUの表示:MENUボタンを長押しするとメニューが画面に表示されます。
項目の選択:MENUを回して設定したい項目にアクセスします。
設定:MENUボタンを押すとその項目、設定が確定されます。
設定項目で押すと、その項目の設定（設定値）が表示されます。
設定（設定値）で押すと、その設定（設定値）が確定（入力）され、
カーソルが左（設定項目）へもどります。
リターン:RETURN(F9)ボタンを押すとカーソルがもどります。
Press
Rotate
INFO［1080i/60］
INPUT［SDI1］
COLOR［D65/709］
SCREEN［16:9］
MARKER［OFF］
AUDIO［15］
AUDIOUTIL
WAVEFORM［ON］
VECTORSCOPE［ON］
ClipGuide［OFF］
USERASSIGN
REMOTE
SDISTATUS［OFF］
IMD［OFF］
SETUP
＜MENUItem＞メニュー項目
Rotate
Rotate
Press Press Press
Whennosignalisinput,
“NOSYNC”isdisplayed.
(PressandholdtilltheMENUisdisplayedonthescreen)
FALSECOLORMTF
FALSECOLORTG
CIED65
JPD93
USER
CALD65/D93
CALD65
CALD93
inputsignal
Rotate Rotate

HDM-90WV各部名称と働き
11
HDM-90WV
RETURN
INPUT［SDI1］
SDI1
SDI2
RETURN
BRIGHT［50］
CONTRAST［80］
CHROMA［50］
SHARPNESS［50］
PEAKING［0］
PEAKINGMODE［NORMAL］
GAMMA［2.20］
RESETTODEFAULT＞
RETURN
COLORMATRIX［709］
COLORTEMP［D65］
REDBIAS［0］
GREENBIAS［0］
BLUEBIAS［0］
REDGAIN［1.00］
GREENGAIN［1.00］
BLUEGAIN［1.00］
INPUT
0.500/-----1.992
FALSECOLORMTF
FALSECOLORTG
CIED65
JPD93
USER
CALD65/D93
CALD65
CALD93
AUTO
RGB
BT.601
BT.709
0/-----/100
1.00/----/3.00
COLOR
＜MENUItem＞メニュー項目 ＜MENUSettingItem＞設定項目 ＜SettingValue＞設定値
-128/-----/127
-128/-----/127
-128/-----/127
0.500/-----1.992
0.500/-----1.992
0/-----/100
0/-----/100
0/-----/100
［2］MENUContents メニューの内容(項目および設定値)について
入力
ピクチャー
色
0/-----/100
NORMAL/MONO
INFO［1080i/60］
INPUT［SDI1］
COLOR［D65/709］
SCREEN［16:9］
MARKER［OFF］
AUDIO［15］
AUDIOUTIL
WAVEFORM［ON］
VECTORSCOPE［ON］
ClipGuide［OFF］
USERASSIGN
REMOTE
SDISTATUS［OFF］
IMD［OFF］
SETUP
MODELPMD-9900L
INPUTSDI1
FORMAT1080i/59.94
COLORMATRIX709
COLORTEMPD65
3DREVIEWOFF
ANAGLYPHOFF
AUDIOPEAKLOGOFF
AUDIOPHASEMONOFF
SDIERRORCOUNT0
VPIDDETECTOFF
SDILEVELHD
UNKNOWNUNKNOWN
VERSION###
Displaysthevideoformat
oftheinputsignal.
入力信号のビデオフォーマット
が表示されます。
無信号のときは”NOSYNC”
Whennosignalisinput,
“NOSYNC”isdisplayed.
INFOMATION インフォメーション
inputsignalselected

HDM-90WV各部名称と働き
12
HDM-90WV
SCREEN
RETURN
SCAN［NORMAL］
ASPECT［16:9］
MONO/COLOR［RGB］
HVDELAY［OFF］
SHIFTH［0］
SHIFTV［0］
3DREVIEW［OFF］
ANAGLYPH［OFF］
NORMAL
OVERSCAN
MAGNIFY
PXBYPX
AUTO
4:3
16:9
PAYLOAD
RGB
MONO
RED
GREEN
BLUE
ON/OFF
-128/-----/127
-128/-----/127
画面
OFF
LEFTEYE
RIGHTEYE
BLENDING
LUMINANCEDIFF.
CHROMADIFF.
OFF
COLOR
HALFCOLOR
OPTIMIZED
GRAY
MARKER
RETURN
MARKER［OFF］
CENTER［ON］
ASPECT［OFF］
SAFTYASPECT［OFF］
RATIO［95%］
CROSSHATCH［OFF］
MARKERMAT［CLEAR］
LINETHICKNESS［2］
LINETYPE［WHITE］
ON/OFF
ON/OFF
OFF
4:3
16:9
1.85:1
2.35:1
4:3&1.85
4:3&2.35
80%/---/99%/OFF/USER
CLEAR
HALFTONE
BLACK
1/2/3
GRAY
HALFTONE
WHITE
INVERT
マーカー
OFF
SMALL
MEDIUM
LARGE
INFO［1080i/60］
INPUT［SDI1］
COLOR［D65/709］
SCREEN［16:9］
MARKER［OFF］
AUDIO［15］
AUDIOUTIL
WAVEFORM［ON］
VECTORSCOPE［ON］
ClipGuide［OFF］
USERASSIGN
REMOTE
SDISTATUS［OFF］
IMD［OFF］
SETUP
3DREVIEW
ANAGLYPH
3Dレビュー
アナグリフ
OFF
4:3
16:9
USER

HDM-90WV各部名称と働き
13
HDM-90WV
AUDIO
RETURN
FRONTVOLUME［15］
HEADROOMSTART［-20dB］
HEADROOMEND［-6dB］
LEFTCHANNEL［1CH］
RIGHTCHANNEL［2CH］
LOADCHPRESETFROM＞
SAVECHPRESETTO＞
CHPRESET［UNLOCKED］
-60dB/----
----/0dB
PRESET1/---/8
LOCK/UNLOCK
CHANNEL1/-----/16
CHANNEL1/-----/16
PRESET1/---/8
0/-----/40
オーディオ
1/-----/16
RETURN
LEVELMETER［ON］
BACKGROUND［ON］
DECAY［FAST］
DISPLAYCHANNELS［8］
DISPFILTER［ALL］
COLUMNS［DUAL］
DISPTYPE［OVERLAP］
AUDIOPEAKLOG［OFF］
LOGSPEED［4S］
SIZE［SMALL］
POSITION［LEFTBOT］
AUDIOPHASEMON［OFF］
DISPPERSISTENCY［1］
SIZE［MEDIUM］
POSITION［LEFTTOP］
DISPTYPE［OVERLAYP］
ON/OFF
ON/OFF
ACTIVE/ALL
DUAL/QUAD
OVERLAP/OVERLAY
4S
8S
20S
60S
120S
300S
FAST/MEDIUM/SLOW
ON/OFF
OFF/ON1/2/4/8
SMALL/MEDIUM/LARGE
LEFTTOP
LEFTBOT
RIGHTTOP
RIGHTBOT
OVERLAY/OVERLAP
SMALL/LARGE
LEFTTOP
LEFTBOT
RIGHTTOP
RIGHTBOT
1FRAME
4FRAME
8FRAME
16FRAME
AUDIOUTIL オーディオユーティリティー
INFO［1080i/60］
INPUT［SDI1］
COLOR［D65/709］
SCREEN［16:9］
MARKER［OFF］
AUDIO［15］
AUDIOUTIL
WAVEFORM［ON］
VECTORSCOPE［ON］
ClipGuide［OFF］
USERASSIGN
REMOTE
SDISTATUS［OFF］
IMD［OFF］
SETUP
AUDIOLEVELMETER
AUDIOPEAKLOG
AUDIOPHASEMONITOR
オーディオレベルメーター
オーディオピークログ
オーディオフェーズモニター

HDM-90WV各部名称と働き
14
HDM-90WV
＜MENUItem＞ ＜MENUSettingItem＞ ＜SettingValue＞
VECTORSCOPE
ON/OFF
RETURN
LAYOUT［NORMAL］
VECTORSCOPE［ON］
SIZE［MEDIUM］
POSITION［LEFTBOT］
DISPTYPE［OVERLAY］
GAIN［1.00］
SMALL
MEDIUM
LARGE
LEFTTOP
LEFTBOT
RIGHTTOP
RIGHTBOT
OVERLAY/OVERLAP
1.00/-----/4.98
ClipGuide
RETURN
ClipGuide［OFF］
MODE［LUMA&CHROMA］
DISPTYPE［ZEBRA］
YUPPERLIMIT［103.2%］
YLOWERLIMIT［-0.9%］
CUPPERLIMIT［240］
CLOWERLIMIT［16］
LUMA(Y)
LUMA(Y)ONMONO
CHROMA(C)
CHROMA(C)ONMONO
Y&C
Y&CONMONO
ZEBRA/FILL
0/-------/255
ON/OFF
-7.3/------/109.1
-7.3/------/109.1
0/-------/255
ベクトルスコープ
クリップガイド(ゼブラ)
OFF
WHITE
PARADE
WAVEFORM
RETURN
LAYOUT［NORMAL］
WAVEFORM［ON］
SIZE［MEDIUM］
POSITION［RIGHTBOT］
DISPTYPE［OVERLAY］
YOVERLIMIT［103.2%］
YUNDERLIMIT［-0.9%］
HISTOGRAM［OFF］
POSITION［RIGHTBOT］
NORMAL
WFM
WAV
VS
ALM16
QUAD
QUAD2
SMALL
MEDIUM
LARGE
LEFTTOP
LEFTBOT
RIGHTTOP
RIGHTBOT
OVERLAY/OVERLAP
-7.3/-------/109.1
-7.3/-------/109.1
ウェーブフォーム
ON/OFF
LEFTTOP
LEFTBOT
RIGHTTOP
RIGHTBOT
NORMAL
WFM
WAV
VS
ALM16
QUAD
QUAD2
INFO［1080i/60］
INPUT［SDI1］
COLOR［D65/709］
SCREEN［16:9］
MARKER［OFF］
AUDIO［15］
AUDIOUTIL
WAVEFORM［ON］
VECTORSCOPE［ON］
ClipGuide［OFF］
USERASSIGN
REMOTE
SDISTATUS［OFF］
IMD［OFF］
SETUP

HDM-90WV各部名称と働き
15
HDM-90WV
USERASSIGN
RETURN
F1［SDI1］
F2［SDI2］
F3［SCAN］
F4［ASPECT］
F5［MARKER］
F6［MAGNIFY］
F7［WAVEFORMMON］
F8［VECTORSCOPE］
F9［AUDIOMETER］
ユーザーアサイン
(プリセットファンクション)
SDI1
SDI2
GAMMA1.0
GAMMA1.8
GAMMA2.0
GAMMA2.2
GAMMA2.4
GAMMA2.6
GAMMA2.35
WHITEBALD65
WHITEBALD93
MONO
COLORCHANNEL
SCAN
ASPECT
MAGNIFY
HVDELAY
PIXELBYPIXEL
MARKER
USERMARKER
AUDIOMETER
AUDIOPEAKLOG
AUDIOPHASEMON
AUDIOPRESET1
AUDIOPRESET2
AUDIOPRESET3
AUDIOPRESET4
AUDIOPRESET5
AUDIOPRESET6
AUDIOPRESET7
AUDIOPRESET8
AUDIOMUTE
LAYOUTWFM
LAYOUTWAV
LAYOUTVS
LAYOUTALM16
LAYOUTQUAD
LAYOUTQUAD2
WAVEFORMMON
VECTORSCOPE
ClipGuide
TIMECODE
HISTOGRAM
FALSECOLORTG
FALSECOLORMTF
PEAKINGCOLOR
3DREVIEW
ANAGLYPH
FANSTOP
HIDEALLUTIL
3DLEFTEYE
3DRIGHTEYE
3DBLENDING
3DLUMADIFF
3DCHROMADIFF
GLYPHCOLOR
GLYPH1/2COLOR
GLYPHOPTIMIZED
GLYPHGRAY
FunctionButtonsF1toF9
PresetFunction
(ManufacturingDefault)
＜Assignablefunctionitem＞
＜MENUItem＞
INFO［1080i/60］
INPUT［SDI1］
COLOR［D65/709］
SCREEN［16:9］
MARKER［OFF］
AUDIO［15］
AUDIOUTIL
WAVEFORM［ON］
VECTORSCOPE［ON］
ClipGuide［OFF］
USERASSIGN
REMOTE
SDISTATUS［OFF］
IMD［OFF］
SETUP

HDM-90WV各部名称と働き
16
HDM-90WV
＜MENUItem＞ ＜MENUSettingItem＞ ＜SettingValue＞
REMOTE
RETURN
PIN1［RTALLY］
PIN2［GTALLY］
PIN3［BTALLY］
PIN4［MARKER］
PIN5［GROUND］
PIN6［SDI1］
PIN7［SDI2］
PIN8［ASPECT］
リモート
PARALLELREMOTEconnector
PinAssign
(ManufacturingDefault)
＜Assignablefunctionitem＞
RTALLY
GTALLY
BTALLY
LEFTRTLY
LEFTGTLY
LEFTBTLY
RIGHTRTLY
RIGHTGTLY
RIGHTBTLY
SDI1
SDI2
GAMMA1.0
GAMMA1.8
GAMMA2.0
GAMMA2.2
GAMMA2.4
GAMMA2.6
GAMMA2.35
WHITEBALD65
WHITEBALD93
MONO
SCAN
ASPECT
MAGNIFY
HVDELAY
REDONLY
BLUEONLY
GREENONLY
PIXELBYPIXEL
MARKER
USERMARKER
AUDIOMETER
AUDIOPEAKLOG
AUDIOPHASEMON
AUDIOPRESET1
AUDIOPRESET2
AUDIOPRESET3
AUDIOPRESET4
AUDIOPRESET5
AUDIOPRESET6
AUDIOPRESET7
AUDIOPRESET8
AUDIOMUTE
LAYOUTWFM
LAYOUTWAV
LAYOUTVS
LAYOUTALM16
LAYOUTQUAD
LAYOUTQUAD2
WAVEFORMMON
VECTORSCOPE
ClipGuide
TIMECODELTC
TIMECODEVITC1
TIMECODEVITC2
HISTOGRAM
FALSECOLORTG
FALSECOLORMTF
3DLEFTEYE
3DRIGHTEYE
3DBLENDING
3DLUMADIFF
3DCHROMADIFF
GLYPHCOLOR
GLYPH1/2COLOR
GLYPHOPTIMIZED
GLYPHGRAY
HIDEALLUTIL
INFO［1080i/60］
INPUT［SDI1］
COLOR［D65/709］
SCREEN［16:9］
MARKER［OFF］
AUDIO［15］
AUDIOUTIL
WAVEFORM［ON］
VECTORSCOPE［ON］
ClipGuide［OFF］
USERASSIGN
REMOTE
SDISTATUS［OFF］
IMD［OFF］
SETUP

HDM-90WV各部名称と働き
17
HDM-90WV
＜MENUItem＞ ＜MENUSettingItem＞ ＜SettingValue＞
SETUP
RETURN
FORMATDISPLAY［AUTO］
VPID［OFF］
TIMECODE［OFF］
SIZE［SMALL］
POSITION［BOTTOM］
USERBIT［OFF］
POWERSAVE［ALWAYSON］
KEYLOCK［UNLOCKED］
PICTUREDELAY[NORMAL]
BACKLIGHT[100%]
RESETTOMFGDEFAULT＞
BACKUPUSERCONFIG＞
RESTOREUSERCONFIG＞
FANCONTROL［AUTO］
AUTO
ON
OFF
OFF
LTC
VITC1
VITC2
ALWAYSON
2MIN
5MIN
10MIN
30MIN
1HOUR
2HOUR
RESETNOW/CONFIRM
BACKUPNOW/CONFIRM
RESTORENOW/CONFIRM
セットアップ
ON/OFF
UNLOCK/LOCK
AUTO
MAX
OFF
SDISTATUS
RETURN
ERRORCOUNT0
RESETCOUNTER
DISPLAY［OFF］
OFF
ON
AUTO
SDIステータス
INFO［1080i/60］
INPUT［SDI1］
COLOR［D65/709］
SCREEN［16:9］
MARKER［OFF］
AUDIO［15］
AUDIOUTIL
WAVEFORM［ON］
VECTORSCOPE［ON］
ClipGuide［OFF］
USERASSIGN
REMOTE
SDISTATUS［OFF］
IMD［OFF］
SETUP
NOMAL
FAST
FASTEST
MIN(25)/-----/100%
RETURN
IMD［OFF］
COLOR［WHITE］
PRESETIMD［PMD-9900］
CUSTOMIMD［PMD-9900］
SIZE［SMALL］
POSITION［TOP］
ON/OFF
WHITE
RED
BLUE
GREEN
TOP
BOTTOM
SMALL
LARGE
ABCDEFGHIJKL
MNOPQRSTUVW
XYZ[]^abcd
efghijklmnopqr
stuvwxyz{|}~□!
”#$%&ʼ()*+,-./
0123456789:;<
=>?@
IMD
CAMERA1/2
MONITOR1/2
VTR1/2
PROGRAM
PREVIEW
AUX
RECORD
/
CUSTOMIMD:(文字の種類)
モニターの使用目的に合わせて
画面に表示する名称を書き換え
ることができます。
PRESETIMD:(プリセット)

HDM-90WV接続方法
Connection接続方法
18
HDM-90WV
電源の接続方法
PowerSupplyConnection
MakesuretoturnoffthePOWERswitchesofeachunitbeforeconnecting.
1
ConnecttheDCIN12Vconnector(XLR4-pin)ontherearpaneltothesuppliedACAdaptor.
リアパネルのDCIN12VコネクタにACアダプタ(付属)を接続します。
POWERswitch
DCIN(12V)connector
ACAdaptor(supplied)
WhenthePOWERswitchisturnedonandthepowerissupplied,thePOWERIndicatorLEDlightsup
andthefansontherearpanelturn.
2
XLR4-pin
POWERIndicationLED
電源スイッチがONされ、電源が供給されると電源表示LEDが点灯し、リアパネルのファンが回転します。
注意:機器を接続する前には、電源スイッチは必ずOFFしてください。
AC電源アダプタ(付属)
電源表示LED
電源スイッチ
Fan
ファン
ThefanoperationcanbesettoAUTO,MAXorOFF,ontheMENU,SETUP,FANCONTROL.
AndFANSTOPfunctioncanbeassignedtothefunctionbutton,F1toF9onthefrontpanel.
ファンの動作は、AUTO/MAX/OFFにメニューで設定できます。
FANSTOP機能がフロントパネルのファンクションボタンにユーザー設定できます。
Functionbutton
F1toF9
MENUbutton

HDM-90WV接続方法
19
HDM-90WV
ビデオ信号の入出力
VideoSignalInputandOutput
SDI(3G/HD/SD)inputconnector
Camera(orVTR,etc.)
HD-SDIoutput
IN1
IN2
SDI(3G/HD/SD)VIDEOSIGNALInput
SDI
(3G/HD/SD)
SDI(3G/HD/SD)outputconnector
OUT
SDI(3G/HD/SD)VIDEOSIGNALOutput
MonitororVTR,etc.
HD-SDIinput
1
ConnecttheSDI(3G/HD/SD)IN1/2connector,ANALOGY(CVBS),PB(Y)andPRconnectorsorHDMIIN
connectorontherearpanelwiththeoutputconnectorsofacamera(orVTR,etc.).
リアパネルの入力コネクタへカメラ等のoutputから接続します。
2
ConnecttheSDI(3G/HD/SD)OUTconnectororHDMIOUTconnectorontherearpaneltotheinputconnector
ofacamera(orVTR,etc.).
リアパネルの出力コネクタからモニター、VTR等のinputへ接続します。
