NISBETS ESSENTIALS DF673 User manual
Model:
DF673
Mini Infrared
Thermometer
Instruction manual
DF673_EN_A5_v3_20201030.indb 1DF673_EN_A5_v3_20201030.indb 1 2020/10/30 13:492020/10/30 13:49
2
EN
Function Diagram
A. LCD display
B. °C/°F unit selector button
C. Laser hole
D. Trigger
E. Battery compartment cover
A
B
C
D
E
1
2
3
4
5
67
1. Battery power icon
2. Scan lock
3. Backlight indicator
4. °C / °F
5. Current temperature reading
6. The maximum display
7. The maximum state
Operation
1. Remove the battery compartment cover. Install the batteries and replace the cover.
2. Press the trigger to turn on.
3. Aim at target and press the trigger for 1 second. Temperature reading will show once trigger is released.
4. To select between °C and °F, use selector button (°C/°F) on front of thermometer.
5. Thermometer will automatically turn off after being idle for 30 seconds.
Specifications
• Temperature range: -50°C to 520°C (-58°F to 968°F)
• Temperature Resolution: 0.1°C (0.2°F)
• Accuracy: ±2%
• Laser Wavelength: 635~650um, power ≤ 1mw
• Ideal Ambient Conditions for use:
0°C ~ 40°C, humidity ≤ 85%
• Storage Temperature: ≤ 60°C
• Power: 2x 1.5V (AAA battery)
Distance to Spot Ratio (12:1)
DF673_EN_A5_v3_20201030.indb 2DF673_EN_A5_v3_20201030.indb 2 2020/10/30 13:492020/10/30 13:49
3
EN
Cleaning, Care and Maintenance
• Lens cleaning – remove loose particles using clean compressed air, gently brush remaining debris away
using soft clean brush.
• Clean the case with a damp cloth and warm water.
• DO NOT USE SOLVENTS TO CLEAN LENS.
• DO NOT SUBMERGE THERMOMETER IN WATER.
• AVOID ELECTROMAGNETIC FIELDS SUCH AS INDUCTION COOKERS.
• DO NOT POINT LASER DIRECTLY OR INDIRECTLY TOWARDS EYE.
Compliance
Dispose of depleted batteries in accordance with local regulations, within the EC there are nominated disposal
points for batteries.
The WEEE logo on this product or its documentation indicates that the product must not
be disposed of as household waste. To help prevent possible harm to human health and/or
the environment, the product must be disposed of in an approved and environmentally safe
recycling process. For further information on how to dispose of this product correctly, contact
the product supplier, or the local authority responsible for waste disposal in your area.
Nisbets Essentials parts have undergone strict product testing in order to comply
with regulatory standards and specifications set by international, independent, and
federal authorities.
Nisbets Essentials products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic, mechanical,
photocopying, recording or otherwise, without the prior written permission of Nisbets Essentials.
Every effort is made to ensure all details are correct at the time of going to press, however, Nisbets Essentials reserve the right to change
specifications without notice.
DF673_EN_A5_v3_20201030.indb 3DF673_EN_A5_v3_20201030.indb 3 2020/10/30 13:492020/10/30 13:49
DECLARATION OF CONFORMITY
• Conformiteitsverklaring • Déclaration de conformité • Konformitätserklärung • Dichiarazione di conformità •
• Declaración de conformidad • Declaração de conformidade
Equipment Type • Uitrustingstype • Type d'équipement • Gerätetyp
• Tipo di apparecchiatura • Tipo de equipo • Tipo de equipamento
Model • Modèle • Modell • Modello
• Modelo • Malli
Mini Infrared Thermometer
DF673
Application of Territory Legislation &
Council Directives(s)
Toepassing van Europese Richtlijn(en)
• Application de la/des directive(s) du
Conseil • Anwendbare EU-Richtlinie(n)
• Applicazione delle Direttive
• Aplicación de la(s) directiva(s) del
consejo • Aplicação de directiva(s) do
Conselho
Electro-Magnetic Compatibility (EMC) Directive 2014/30/EU - recast of 2004/108/EC
EN 61000-3-2:2014
EN 61000-3-3:2013
EN 61326-1:2013
EN 61000-4-2:2009
EN 61000-4-3:2006 +A1:2008 +A2:2010
EN 61000-4-4:2012
EN 61000-4-5:2014
EN 61000-4-6:2014
EN 61000-4-8:2010
EN61000-4-11:2004
Restriction of Hazardous Substances Directive (RoHS) 2015/863 amending Annex II to
Directive 2011/65/EU
Producer Name • Naam fabrikant • Nom du producteur • Name des Herstellers
• Nome del produttore • Nombre del fabricante • Nome do fabricante
Nisbets Essentials
I, the undersigned, hereby declare that the equipment specified above conforms to the above Territory Legislation, Directive(s)
and Standard(s).
Ik, de ondergetekende, verklaar hierbij dat de hierboven gespecificeerde uitrusting goedgekeurd is volgens de bovenstaande
Richtlijn(en) en Standaard(en).
Je soussigné, confirme la conformité de l'équipement cité dans la présente à la / aux Directive(s) et Norme(s) ci-dessus
Ich, der/die Unterzeichnende, erkläre hiermit, dass das oben angegebene Gerät der/den oben angeführten Richtlinie(n) und
Norm(en) entspricht.
Il sottoscritto dichiara che l'apparecchiatura di sopra specificata è conforme alle Direttive e agli Standard sopra riportati.
El abajo firmante declara por la presente que el equipo arriba especificado está en conformidad con la(s) directiva(s) y
estándar(es) arriba mencionadas.
Eu, o abaixo-assinado, declaro que o equipamento anteriormente especificado está em conformidade com a(s) anterior(es)
Directiva(s) e Norma(s)
Date • Data • Date • Datum • Data •
Fecha • Data
23rd October 2020
Signature • Handtekening • Signature
• Unterschrift Firma • Firma •
Assinatura
Full Name • Volledige naam • Nom et
prénom • Vollständiger Name • Nome
completo • Nombre completo • Nome
por extenso
Ashley Hooper
Eoghan Donnellan
Josie Holt
Position • Functie • Fonction • Position
• Qualifica • Posición • Função
Technical & Quality
Manager
Commercial Manager/
Importer
Commercial Manager/
Responsible Supplier
Producer Address • Adres fabrikant •
Adresse du producteur • Anschrift des
Herstellers • Indirizzo del produttore •
Dirección del fabricante • Morada do
fabricante
Fourth Way,
Avonmouth,
Bristol,
BS11 8TB
United Kingdom
42 North Point Business
Park
New Mallow Road
Cork
Ireland
15 Bagdally Road,
Campbelltown
NSW 2560
DocuSign Envelope ID: 5F615EAA-1BB3-4AD8-9F4B-BF92FD6A90EC
DF673_EN_A5_v3_20201030.indb 4DF673_EN_A5_v3_20201030.indb 4 2020/10/30 13:492020/10/30 13:49
UK
+44 (0)845 146 2887
Eire
NL 040 – 2628080
FR 01 60 34 28 80
BE-NL 0800-29129
BE-FR 0800-29229
DE 0800 – 1860806
IT N/A
ES 901-100 133
AU 1300 225 960
DF673_EN_A5_v3_20201030.indb 5DF673_EN_A5_v3_20201030.indb 5 2020/10/30 13:492020/10/30 13:49
