Nitto APS-125 User manual

Due to continuous product development/improvement the specifications and configurations in
this document are subject to change without prior notice.
Manufactured by :
NITTO KOHKI Co., Ltd.
2-9-4, Nakaikegami, Ohta-ku,
Tokyo, 146-8555, Japan
Tel : [phone]
Fax : [phone]
E-mail : [email protected]
URL : www.nitto-kohki.co.jp
PNEUMATIC ORBITAL SANDER
Please read this manual carefully before you attempt to use
your tool so that you may use it properly and safely.
PALM OBITAL SANDER
Model APS-125,APS-150 (Non Vacuum Type)
Model APS-125SV,APS-150SV (Self Vacuum Type)
Model APS-125CV,APS-150CV (Central Vacuum Type)
PROFESSIONAL TOOL
Keep the manual handy – so you can use it whenever necessary.
Original Instructions
Specifications
Model APS-125 APS-150
Maximum Operating Pressure 0.6 MPa
Air Consumption(No Load) 0.45 m3/min
Rated Speed
(No Load)
Non Vacuum Type 10,000 min-1(r/min) 10,000 min-1(r/min)
SV Type 11,000 min-1(r/min) 11,000 min-1(r/min)
CV Type 10,000 min-1(r/min) 10,000 min-1(r/min)
Orbit Diameter O.D.5mm
Pad Size O.D.125mm(5”) O.D.150mm(6”)
Pad Mass(Weight) 0.1 kg 0.12 kg
Sound Pressure Level 77 dB(A) 77 dB(A)
Sound Power Level 88 dB(A) 88 dB(A)
Vibration Level 1.6 m/s23.7 m/s2
Mass(Weight) Non Vacuum Type 0.69 kg 0.72 kg SV Type 0.73 kg 0.76 kg
CV Type 0.71 kg 0.73 kg
Thread Size of Air Inlet Rc1/4
APS-125SV

1
The following Safety notations are used throughout the manual to highlight safety precautions for the user and for
the tool.
WARNING: Indicates a potentially hazardous situation which, if not avoided by following the
instructions given, could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided by following the
instructions given, could result in injury or material damage.
Please note, however, that failure to observe safety precautions under the “ Caution” category could result in a
serious occurrence depending on the situation: please observe all safety precautions in the manual.
Caution: Important precautions for tool setup, operation and maintenance.
Thank you very much for your purchase of this
Nitto Kohki product.
Before using your tool, please read this manual
carefully so that you may use it properly to get
the most out of it.
Please keep the manual handy - so you can
use it whenever necessary.
・English : Please ask your dealer or
distributor for instruction manual
in local language(s).
・German : Bitte fragen Sie lhren Händler
nach eine Betriebsanleitung in
Landessprache.
・French : S'il vous plait, veuillez demandez
á votre foumisseur de manuel
instruction en langue locale.
・Spanish : Por favor, cantacte con su
distribuidor para el manual de
instrucciones en español.
・Portuguese : Por favor pessa ao seo agente
ou distribuidor o manual de
instrucces ih linguagen local.
・Italian : Per Manuale Istruzioni in lingua
locale Vi preghiamo di rivolgervi
al rivenditore o distributore.
・Dutch : Vraag uw handelaar
om een nederladstalige
gebruiksaanwijzing.
・Swedish : Be er lokala Åtreförsäljare eller
distributör om manualer pá
svenska.
・Danish : Venligst henvend Dem til den
danske distributør for instructions
manualer.
・Polish : Prosze pytac swojego dealera
lub dystrybutora o instrukcje
obslugi w jezyku localnym.
・中文 :請向當地供應商或経銷商詢問中
文使用説明書
CONTENTS page
IMPORTANT SAFETY INSTRUCTIONS ……………………2
GENERAL: TOOLS …………………………………………… 2
GENERAL: PNEUMATIC TOOLS …………………………3
INSTRUCTIONS FOR THIS TOOL …………………………4
1. USAGE ……………………………………………………4
2. CHECK THE CONTENTS OF THE PACKAGE ……… 4
3. AIR SUPPLY ……………………………………………… 4
4. PREPARATIONS …………………………………………4
5. ATTACH ABRASIVE PAPER ……………………………5
6. HOW TO OPERATE THE TOOL ………………………5
7. REPLACING THE PAD ………………………………… 5
8. STORAGE …………………………………………………6
9. ORDERING SERVICE PARTS …………………………6
10. EXPLODED DIAGRAM …………………………………7
PICTOGRAM
Warning: It might be dangerous to operate the tool if
the instructions supplied are not followed.
Using this tool improperly could result in serious injury.
Read the instruction manual before using.
Always wear suitable eye protection.
Always wear suitable hearing protection.
Always wear respiratory protective equipment (PPE).

2
IMPORTANT SAFETY
INSTRUCTIONS
When using the tool, please observe the safety
precautions below to prevent possible accident or
injury.
GENERAL: TOOLS
WARNING
TO OPERATORS
●Wear proper clothing for the type of work being
done.
Take care so that clothing, ties, hair etc. will not
become entangled with the moving parts. If items
become entangled it will cause the operator to be
pulled towards the tool and lead to possible cause of
accident or injury.
●Always wear suitable eye protection.
Remember, regular glasses are not safety glasses.
The lenses are only shock resistant, which will not
give you sufficient eye protection you may need in
your working environment.
●Always wear suitable hearing protection.
●Wear respiratory protective equipment (PPE).
Wear respiratory protective equipment (PPE) when
working in an environment where dust particles are
generated in operation.
●Avoid working posture that is too stressful.
Always ensure a firm footing and well balanced
posture.
●Do not operate the tool if you are too tired.
●Never touch any moving parts of the tool when
running.
ABOUT WORK AREA
●Keep the work area clean.
Cluttered work areas (e.g. workbench) invite
accidents.
●Carefully select the work area.
Do not expose tool to rain.
Do not use tool in a wet or soaked area.
See that the work area is adequately illuminated.
●Never work near inflammable liquid or in a
potentially explosive atmosphere.
●Keep children away from the work area.
Keep children and unauthorized people away from
the work area to avoid accident or injury.
BEFORE OPERATION
●Inspect tool before use.
Before using, check that screws are securely
tightened, that any protective cover or guard is
securely in place, other parts are free from damage
and that the tool runs as it should.
Check that moving parts are properly adjusted for
positioning and tightened, that parts are free from
damage and properly mounted, and that all other
parts are in good condition for normal operation.
Should you find any damage to the protective
cover or other part, replace it in accordance with
the Operation Manual. If there are no instructions
in the Manual, please contact the sales agent
through which you have purchased your tool or an
authorized dealer near you for repair.
Likewise, if a switch failure occurs, contact sales
agent through which you have purchased your tool
or an authorized dealer near you for repair.
Do not use the tool if it does not start or stop with
the start/stop switch.
●Securely mount cutter
An improperly mounted cutter may fly out, causing
possible damage to the tool or injury to the operator.
●Always remove spanner, wrench, etc., once
adjustment has been made with them.
●Use a tool appropriate for the application.
Avoid heavy-duty application that is beyond the
capacity of tool.
●Do not use the tool for purposes other than what
it is designed for.
●Do not abuse tool.
Use tool in accordance with the specifications: you’ll
get the most out of it while ensuring safety.
●Securely fasten workpiece in place.
Use a vice or clamp to securely fasten the workpiece in
place. It is much safer this way than holding it in your
hand, allowing you to operate the tool with both hands.
ABOUT HANDLING
●How to store tool.
When the tool is not used, store it in a dry area and
out of reach of children.
●How to carry tool.
Do not touch the start switch while the tool is being
carried.
●Do not leave the tool unattended while it is
running.
Turn off the start switch and disconnect the tool from
power source. Do not leave the work area until the
tool comes to a complete stop.

3
MAINTENANCE/SERVICE
●Do not take apart or modify tool.
Disassembly or modification carried out without
the supervision of a qualified or authorized service
engineer could result in an accident or injury.
●Inspect cutting tool and accessories, etc.
Always check to see that cutting tool and
accessories, etc. are in good operating condition
without damage or deterioration before you mount
them on the tool. Should you find any damage to
an accessory or part, please contact sales agent
through which you have purchased your tool or an
authorized dealer near you for repair.
●Check parts for damage.
When you have found damage to accessory or other
part, carefully check the damaged part to determine
the extent of influence it has upon the functions
of the tool – that is, determine whether it can still
perform its normal functions.
Check to see that the linkage of the moving parts
is OK, that all parts are OK without damage,
that they are properly mounted, and that the tool
functions normally. Should you find any damage
to an accessory or part that may hamper proper
functioning of the tool, please contact sales agent
through which you have purchased your tool or an
authorized dealer near you for repair.
●Have your tool repaired at an authorized Nitto
Service Center.
For repair or parts replacement, please contact the
sales agent through which you have purchased your
tool or an authorized dealer near you.
●Use only Nitto genuine parts.
Use of improper parts may result in serious accident.
To obtain a Nitto genuine part, consult this Manual
or contact the sales agent from which you have
purchased your tool directly.
●Do not detach label or nameplate from tool.
When a label/nameplate gets damaged, worn or
becomes missing, contact the sales agent through
which you have purchased your tool or Nitto Kohki
Co. Ltd, directly for a replacement.
DISPOSAL
●When a tool is taken permanently out of service, it
is advised that the tool is disassembled, degreased
and parts separated by material and recycled locally
in the appropriate manner.
GENERAL: PNEUMATIC
TOOLS
WARNING
●Use appropriate air pressure.
Excessively high air pressure will increase the tool
number of revolutions or strokes causing not only
potential premature failure/breakage but could also
lead to an unexpected accident or injury.
●Connect tool to air supply line.
There are various types of pipes running in a factory
in addition to the pneumatic line (such as oxygen,
nitrogen, gas and water). For this reason, always
ensure that you are connecting to the pneumatic
line.
●Start tool properly.
Turn the start switch OFF before connecting to the
air supply line.
●Always disconnect the tool from the air supply
line before putting on/taking off any accessory
and prior to carrying out any maintenance work.
●Avoid exposure to exhaust air.
Pneumatic tool exhaust air contains oil and
contaminated moisture. Make sure the exhaust air is
not directed towards your face or anyone else within
the work area.
●Keep tool off electricity.
This pneumatic tool is not electrically insulated. To
avoid a potential electric shock do not use where
there is a possibility of coming into contact with live
electricity.
CAUTION
●Handle tool carefully.
Abusive use of tool could invite failure or accident.
Do not throw, drop or shock the tool.
●Handle connecting hose carefully.
Do not carry the tool by the air hose.
Do not pull the air hose to disconnect.

4
INSTRUCTIONS FOR
THIS TOOL
About Your Tool
WARNING
●Wear protective glasses and a dustproof mask
Operation generates chips and dust particles, etc.
which may cause eye and/or respiratory injury.
Always use PPE (Personal Protective Equipment)
for eye and respiratory protection.
●Always turn off the air supply and disconnect the
air supply hose beforehand whenever replacing
Abrasive Papers.
●Be sure to keep hands clear of moving parts.
●After mounting Pad, hold the Palm Orbital
Sander under a steel workbench or safety place
and run it for at least one minute.
Make certain no one is within the operating direction
of the Pad. If the Pad is defective, improperly
mounted or the wrong size and speed, this is the
time it will usually fail.
●Air pressure at the sander inlet must not exceed
0.6 MPa.
●Always replace damaged, bent or severely worn
Pads.
Do not use a Pad that has been subjected to an
Abrasive Paper failure.
1. USAGE
This tool is for sanding workpieces using Abrasive
Paper.
WARNING
This tool is not designed for water sanding.
Never use for water sanding.
2. CHECK THE CONTENTS OF THE PACKAGE
Check the contents and make sure that the tool
does not have any damage which may have
occurred during transportation. The contents should
correspond to the list as 7-8 pages parts list. In case
of damage/missing parts, please contact the sales
agent from whom you purchased the tool.
3. AIR SUPPLY
3-1. Air Pressure
Adjust air pressure with the air regulator to the
appropriate level for the pneumatic tool used.
Air pressure that is too low will stop the tool from
operating at full capacity.
Air pressure that is too high may cause damage to
the tool.
3-2. Air Line (Fig.1)
Use a 9.5 mm (3/8”) I. D. connecting hose between
the compressor and the tool.
Drained water, etc., if flown into the tool, could
cause tool failure. Install an air filter between the
compressor and the tool.
גͺ͵
Fig. 1
3-3. Lubrication
Install an oiler between the compressor and the tool.
Use the machine oil ISO VG-10. Failure to lubricate
as required may result in damage to the tool. Use of
oil that is too thick will reduce the performance of the
tool.
4. PREPARATION
WARNING
Always turn off the air supply and disconnect
the air supply hose.
4-1. How to assemble Dust Connection Hose and
Bag (APS-125SV, APS-150SV)
Insert one end of the Dust Connection Hose to the
exhaust of the tool and tighten securely. Connect
another end of the Hose to the Dust Connection Bag
or dust collector.
4-2. How to install Dust Collector (APS-125CV,
APS-150CV)
Securely install the hose end of Dust Collector (under
operation by the customer) on the hose mounting
port of this tool. The hose mounting port diameter is
26mm. If it dose not fit with the hose port diameter of
the Dust Collector correctly, use the Adapter.

5
Fig. 2
CAUTION
Always keep the inside of the Dust Connection
Hose Clean. Accumulated dust inside of the
Hose will decrease not only the efficiency of
dust connection but also the performance of the
tool itself.
4-3. Thread Size of Hose Fitting
The product comes with a metal fitting with
Rc(metric) thread. Connect the Bushing R thread x
NPT thread included as standard accessories, if you
would like to have American NPT thread instead.
5. ATTACH ABRASIVE PAPER
WARNING
Always turn off the air supply and disconnect the
air supply hose beforehand whenever replacing
Abrasive Papers.
Put the Abrasive Paper on the Pad so that the paper
holes and pad holes will properly align. Misalignment
of those holes will decrease the performance of dust
collection.
Abrasive Paper
Fig. 3
6. HOW TO OPERATE THE TOOL
6-1. Start and Stop
To Start: Hold the tool and press the Throttle Lever.
To stop: Leave the hand off the Throttle Lever.
Fig. 4
6-2. Speed Adjustment
WARNING
Be sure to keep hands clear of moving parts.
The Speed can be adjusted with a Regulator.
Select a desired Speed by adjusting the Regulator.
Maximum Speed: Turn the Regulator dial clockwise
Minimum Speed: Turn the Regulator dial
counterclockwise
Fig. 5
6-3. How to Operate
After the tool is turned on, slightly press the material
to be ground during operation.
7. REPLACING THE PAD
WARNING
Always turn off the air supply and disconnect the
air supply hose beforehand whenever replacing
the Pad.
Tighten the Pad securely. Insufficient tightening
of screws may lead to unintended accidents.

6
To remove the Pad, hold the Spindle with the accessory
Spanner 17 and turn the Pad counterclockwise by
hand.
To attach the Pad, lock the Spindle with the
accessory Spanner 17 and insert the screw located
in the center of the Pad into the Spindle and fix by
turning the Pad clockwise.
Fig. 6
8. STORAGE
CAUTION
When tool is not used, store it out of reach of
children.
Avoid storing the tool in a location subject to high
humidity. If the tool is left as it is used, residual
moisture on the inside can cause rusting. Before
storing, and after operation, oil the tool at the air inlet
with machine oil ISO VG-10 and run it for a short
time.
9. ORDERING SERVICE PARTS
For further operational and handling information or
for replacement of parts and components, contact
the company from whom you purchased the tool or
an authorized dealer.
In ordering parts and components give each part
number, part name and quantity required.
Use only NITTO genuine parts.

7
10. EXPLODED DIAGRAM : APS-125,APS-125SV,APS-125CV,APS-150,APS-150SV,APS-150CV
WARNING
This diagram is for your reference only. Do not attempt to service or repair the Tool. Do not take the Tool apart.
Contact an authorized Nitto dealer for all service and repair of the Tool. Improper service and repair can cause
accidents and service injuries. Never attempt to modify the Tool. Never attempt service or repair the Tool yourself.
（34）
（33）
（30）
（31）
（32）
（47）
（46）
（2）
（54）
（26）
（27）

8
The part numbers with ( ) are included in the Ass’y parts written above them.
・APS-125
No. Part No. Description Qty Price
1TB03669 Pad 5” V-5H Ass’y 1set
TB03801 Pad 5” L-5H Ass’y (NVL5H)
2 (TQ05090) Label Caution APS 1
4 TQ04650
Internal Retaining Ring IRTW-28 1
5 TQ04648 Spindle 1
6 TP05650 Ball Bearing 6001D 2
8 TP03546 External Retaining Ring C-12 1
9 TQ04647 Counter Shaht 5” 1
10 CP23473 Needle Roller 3×13.8 1
11 TQ04669 Cover 1
12 TQ05817 Lock Ring 1
13 CQ05893 O-Ring S-44 1
14 TP03790 O-Ring S-56 1
15 TQ04657 Ball Bearing 6000LLU 1
16 TQ04652 End Plate B 1
17 TB04867 Blade Ass’y (5 pcs.) 1set
18 TQ06477 Rotor 1
19 TQ04684 Cylinder 1
20 TQ04655 Backbone 1
21 TP12004 O-Ring P-10 2
22 TQ04651 End Plate A 1
23 TP01913 Ball Bearing 6000ZZ 1
24 TQ04656 Bent Retaining Ring BG-10 1
51 TQ04764 Spacer 52×38×0.5 1
25 TB08655 Housing Ass’y 1set
26 (TQ12695) Label Nitto 1
27 (TQ12694) Label Model Number 1
54 (TQ06276) Label Lubrication 1
28 TQ04771 Grip Rubber 1
29 TB03695 Adjust Valve Ass’y 1set
30 (TQ04670) Adjust Valve 1
31 (CP20531) O-Ring P-9 1
32 (TP20521) O-Ring P-8 1
49 TB03696 Throttle Lever Ass’y 1set
33 (TQ04663) Throttle Lever 1
34 (TQ04661) Spring Pin 3×36 AW 1
35 TP15729 Spring Pin 3×14 AW 1
36 TQ04671 Seal Sheet 9×13.9×2 1
37 TQ04664 Valve 1
38 TQ04665 Conical Spring 0.8×6.4×11.6×
21.8 1
39 TQ04666 Bushing M16×Rc1/4 1
41 TB03593 Muffler Ass’y 1set
53 TQ05088 O-Ring SS-100 1
42 TQ04667 Cap 1
・APS-150
No. Part No. Description Qty Price
1 TB03650 Pad 6” V-6H Ass’y 1set
2 (TQ05090) Label Caution APS 1
4 TQ04650
Internal Retaining Ring IRTW-28 1
5 TQ04648 Spindle 1
6 TP05650 Ball Bearing 6001D 2
8 TP03546 External Retaining Ring C-12 1
9 TQ04679 Counter Shaht 6” 1
10 CP23473 Needle Roller 3×13.8 1
11 TQ04669 Cover 1
12 TQ05817 Lock Ring 1
13 CQ05893 O-Ring S-44 1
14 TP03790 O-Ring S-56 1
15 TQ04657 Ball Bearing 6000LLU 1
16 TQ04652 End Plate B 1
17 TB04867 Blade Ass’y (5 pcs.) 1set
18 TQ06477 Rotor 1
19 TQ04684 Cylinder 1
20 TQ04655 Backbone 1
21 TP12004 O-Ring P-10 2
22 TQ04651 End Plate A 1
23 TP01913 Ball Bearing 6000ZZ 1
24 TQ04656 Bent Retaining Ring BG-10 1
51 TQ04764 Spacer 52×38×0.5 1
25 TB08658 Housing Ass’y 1set
26 (TQ12695) Label Nitto 1
27 (TQ12699) Label Model Number 1
54 (TQ06276) Label Lubrication 1
28 TQ04771 Grip Rubber 1
29 TB03695 Adjust Valve A’ssy 1set
30 (TQ04670) Adjust Valve 1
31 (CP20531) O-Ring P-9 1
32 (TP20521) O-Ring P-8 1
49 TB03696 Throttele Lever Ass’y 1set
33 (TQ04663) Throttle Lever 1
34 (TQ04661) Spring Pin 3×36 AW 1
35 TP15729 Spring Pin 3×14 AW 1
36 TQ04671 Seal Sheet 9×13.9×2 1
37 TQ04664 Valve 1
38 TQ04665 Conical Spring 0.8×6.4×11.6×
21.8 1
39 TQ04666 Bushing M16×Rc1/4 1
41 TB03593 Muffler Ass’y 1set
53 TQ05088 O-Ring SS-100 1
42 TQ04667 Cap 1
・APS-125SV
No. Part No. Description Qty Price
25 TB08657 Housing Ass’y 1set
26 (TQ12695) Label Nitto 1
27 (TQ12698) Label Model Number 1
54 (TQ06276) Label Lubrication 1
43 TQ04685 Stopper M16×11(P1.5) 1
45 TB03594 Ejector Ass’y 1set
50 TA99239 Hose Ass’y 1set
46 (TP05662) Hose Band 1
47 (TP14835) Hose 1
48 TP14836 Dust Bag 1
52 LQ02848 P-Tite Screw 1
・APS-150SV
No. Part No. Description Qty Price
25 TB08660 Housing Ass’y 1set
26 (TQ12695) Label Nitto 1
27 (TQ12701) Label Model Number 1
54 (TQ06276) Label Lubrication 1
43 TQ04685 Stopper M16×11(P1.5) 1
45 TB03594 Ejector Ass’y 1set
50 TA99239 Hose Ass’y 1set
46 (TP05662) Hose Band 1
47 (TP14835) Hose 1
48 TP14836 Dust Bag 1
52 LQ02848 P-Tite Screw 1
・APS-125CV
No. Part No. Description Qty Price
25 TB08656 Housing Ass’y 1set
26 (TQ12695) Label Nitto 1
27 (TQ12697) Label Model Number 1
54 (TQ06276) Label Lubrication 1
41 TB03593 Muffler Ass’y 1set
44 TQ04682 Ejector 1
52 LQ02848 P-Tite Screw 1
53 TQ05088 O-Ring SS-100 1
・APS-150CV
No. Part No. Description Qty Price
25 TB08659 Housing Ass’y 1set
26 (TQ12695) Label Nitto 1
27 (TQ12700) Label Model Number 1
54 (TQ06276) Label Lubrication 1
41 TB03593 Muffler Ass’y 1set
44 TQ04682 Ejector 1
52 LQ02848 P-Tite Screw 1
53 TQ05088 O-Ring SS-100 1
・ACCESSORIES
No. Part No. Description Qty Price
TP00474 Spanner 17 1
TP02236 Bushing R 1/4×NPT 1/4 1
TQ12696 Instruction Manual 1
TQ12714 Declaration of Conformity 1
・ACCESSORIES
No. Part No. Description Qty Price
TP00474 Spanner 17 1
TP02236 Bushing R 1/4×NPT 1/4 1
TQ12696 Instruction Manual 1
TQ12714 Declaration of Conformity 1

Printed in JAPAN TQ12696-1
EC DECLARATION OF CONFORMITY
We hereby declare that the following our product conforms with the essential health and safety requirements of
EEC Directives.
Product䋺PNEUMATIC ORBITAL SANDER
Model䋺PALM ORBITAL SANDER: APS-125, APS-125SV, APS-125-CV
APS-150,APS-150SV,APS-150-CV
Serial No䋺X
X X X X X
Consecutive numbers (00001䌾99999)
Christian era’s last digit (0䌾9)
Manufacturer䋺NITTO KOHKI Co., Ltd.
2-9-4, Nakaikegami, Ohta-ku, Tokyo, 146-8555, Japan
Masatoshi Ogue
President
NITTO KOHKI EUROPE Co., Ltd.
Unit21, Empire Centre, Imperial Way, Watford Hertfordshire, WD24 4TS, UK
Tel:[phone] Fax:[phone]
Directive䋺98/37/EC and 2006/42/EC Machinery Directive
The above product has been evaluated for conformity with above directives using the following European standards.
The technical construction file (TCF) for this product is retained at the above manufacturer’s location.
Machinery Directive䋺EN ISO12100-1:2003, EN ISO12100-2:2003,
EN ISO14121-1:2007, EN792-8:2001+A1:2008, others
Sound Pressure/Power Level䋺EN ISO15744:2008, EN ISO4871:1996
Vibration Level䋺EN28662-1:1992, EN ISO8662-8:1997
Name䋺K.Kishi
Title: GENERAL MANAGER MACHINE TOOLS DIV.
Being the responsible person appointed and employed the manufacturer.
i
Authorised Compiler n he Community䋺
t
NITTO KOHKI U.S.A ., Inc.
4525 Turnberry Drive, Hanover Park, IL 60133, U.S.A
Tel: [phone] Fax:[phone]
http://www.nittokohki.com/index.html
Unit 21, Empire Centre, Imperial Way,
Watford Hertfordshire, WD24 4TS, United Kingdom
Tel: [phone] Fax:[phone]
http://www.nitto.co.uk/
NITTO KOHKI DEUTSCHLAND GmbH
Lerchenstr. 47, D-71144 Steinenbronn, Germany
Tel: [phone] Fax:[phone]
http://www.nitto-kohki.de/
NITTO KOHKI AUSTRALIA Pty. Ltd.
77 Brandl Street, Eight Mile Plains QLD 4113,
Australia
Tel: [phone] Fax:[phone]
http://www.nitto-australia.com.au/
NITTO KOHKI Co., Ltd. Singapore Branch
10 Ubi Crescent #01-62, Ubi Techpark Lobby D,
Singapore 408564
Tel: [phone] Fax:[phone]
http://www.nitto-kohki.co.jp/e/nksb/
NITTO KOHKI Co., Ltd. Shanghai Representative Office
#1117 Ruijing Building, Maoming South Road,
Shanghai 200020 China
Tel: [phone] Fax:[phone]
http://www.nitto-kohki.cn/
NITTO KOHKI Co., Ltd. Shenzhen Representative Office
#0726 International Culture Building, 3039, Shennan
Zhong Rd., FutianDistrict, Shenzhen, 518003 China
Tel: [phone] Fax:[phone]
http://www.nitto-kohki.cn/
NITTO KOHKI Co., Ltd. Bangkok Representative Office
38Q, House Convent Bldg, 7th Floor, Unit 7A,
Convent Rd, Silom, Bangkok,10500 Thailand
Tel: (66)- 2 -632-0307 Fax:[phone]
http://www.nittobkk.com/eng_index.htm
عOverseas Affiliates / Offices
NITTO KOHKI EUROPE Co., Ltd.
