OWNER’S MANUAL “PANTHER”
Radiant Heater: wall or ceiling mounting
AC 220-240V, 2000, 2600, 3200 watts
WARNING
Read and understand this entire owner’s manual, including all safety
information, before plugging in or using this product. Failure to do so could
result in fire, electrical shock, or serious personal injury.
CAUTION
Keep this owner’s manual for future reference. If you sell or give this product
away, make sure this manual accompanies this product.
Please keep the complete model number (located on the product card) and
the date you have received the product for your records, as well as your
purchase receipt, warranty and service information. Keep these documents in
case of a warranty claim.
model: 2000W2600W 3200W

1
IMPORTANT SAFETY INFORMATION!
WARNING
⚫Read all instructions before using this radiant heater!
⚫Use only the voltage specified on the rating plate of the heater.
⚫DO NOT cover the grilles, block entry or outlet of the airflow by placing the appliance against
any surface. Keep all objects at least 1 meter from the front, side and rear of the appliance.
⚫DO NOT place the product close to a radiant heat source.
⚫DO NOT use it in areas where gasoline, paint, or flammable liquids are used or stored.
⚫When the heater is in use please DO NOT touch the hot surface with bare skin to avoid burns.
Switch the appliance off and let it cool down before moving it.
⚫DO NOT immerse in liquid or allow running into the interior of the heater, as this may result in
electric shock.
⚫DO NOT operate any appliance with a damaged cord, plug or after the appliance has
malfunctioned or has dropped or been damaged in any matter. Return to a qualified electrical
person for examination, electrical of mechanical adjustment, service or repair.
⚫DO NOT touch the appliance with wet hands.
⚫The most common cause of overheating are dust or lint deposits in the heater. Ensure these
deposits are removed regularly by unplugging the heater and vacuuming the air vents and
grilles.
⚫DO NOT use abrasive cleansers. Clean the device with a damp cloth (not wet) that has only
been rinsed in soapy water. Always remove the plug from the socket before cleaning.
⚫DO NOT connect the appliance to the mains voltage before it has been completely installed
and adjusted.
⚫DO NOT use the product in the immediate surrounding of bathrooms, showers,
swimming pools or similar environment.
⚫DO NOT disconnect the power cord while operating this heater, as this may pose a
hazard.
⚫Using an extension cord for this product is not recommended.
⚫CAUTION: This heater is not suitable for long pile carpets or flokati rugs.
⚫DO NOT allow the power cord to come into contact with heated surfaces during
operation.
⚫DO NOT run power cord under carpeting or similar floor coverings or under furniture.
Arrange power cord away from traffic area, and where it will not be tripped over.
⚫DO NOT twist, bend or wrap the cable around the heater, as this may cause the
insulation to break. Always make sure that the complete cable has been removed from
the cable storage area.

2
⚫DO NOT store the heater while it is still hot.
⚫This appliance should NOT be used by young children or infirm persons without supervision.
⚫DO NOT install this unit directly under a wall outlet.
⚫DO NOT use this device with any other programmer, timer, or other device that automatically
turns the heater on, as there is a fire hazard if the heater is covered or misplaced.
⚫All cover of this appliance is intended to protect access to the heating elements and must be in
place when the appliance is in operating condition.
⚫Please use this product only as described in this manual. Any other use is NOT recommended
by the manufacturer and may cause fire, electric shock or injury.
⚫This device may be used by children 8 years old or older and persons with reduced physical,
sensory or mental capabilities or a lack of experience or knowledge, if they have been
instructed in the safe handling of the device and have been advised of any dangers. Children
are not allowed to play with the device. Cleaning and user maintenance must not be performed
by children without supervision.
⚫Children under the age of 3 should not be left unattended near the device. Children from the
age of 3 years and under the age of 8 may only switch the device on and off if it has been
placed and installed in its intended operating position and if they have been instructed in the
safe and proper use of the device to understand the hazards involved. Children from 3 years
and under 8 years may not connect, regulate and clean the device or carry out maintenance
work.
⚫CAUTION - Some parts of this product may become very hot and cause burns. Special
attention is needed when children and vulnerable people are present.
⚫The radiant heater must be installed at least 1.8 m above the ground.
⚫If the power cord is damaged, it must be replaced by the manufacturer, its service agent or a
similarly qualified person to avoid danger.
•SAVE THESE INSTRUCTIONS!

3
PRODUCT INSTRUCTION
PRODUCT INS
PRODUCT SIZE
Model
Power
Length (mm)
Width (mm)
Height (mm)
PANTHER 2000
2000 W
1240
200
50
PANTHER 2600
2600 W
1540
200
50
PANTHER 3200
3200 W
1840
200
50
CIRCUIT DIAGRAM
Covering
Heating Plate
Control Box
Power Switch
Sensor

4
PRODUCT CONTROL PANEL & OPERATION GUIDE
•Before the first use, please read this manual.
•Remove the heater from the carton carefully. Please keep the carton for off-season storage.
•Install the heater firmly in accordance with the installation instructions.
•Do not use the same socket with other high-power appliance to avoid overloading.
•WARNING:
This heater heats up when in use. To avoid burns do not touch the hot surface.
Switch ON
1. The heating is supplied with electricity.
2. Turn the power switch on, the screen shows the temperature of the room.
Temperature setting
Press the power button (number 1) on the remote control. Press “SET”(number 5), then press
the up or down button (number 2) to increase or decrease the temperature. Finally set the
temperature to the required temperature. The system will automatically save the set temperature
and automatically return to operational status and displays the room temperature. Indicator light
will blink.
If the room temperature is higher than the present temperature, the heater won’t start to work.
The maximum temperature is 45°C, the lowest is 5°C.
Lock function
First press “SWITCH”(number 4) while operating, then press the power button (number 1) and
the heater is locked. All keys are invalid when the “Lock function”is activated. To activate all keys
again press “SWITCH”(number 4) and then the power button (number 1).
Timer setting
Press two times “SET”(number 5) and “00”will flash. Then press the up or down button (number
2) and the time can be set. The minimum set-up time is one hour, the maximum is 24 hours.
Every time you press the up or down button (number 2) the time will increase or decrease by 1
hour. After the time is set, the system will automatically save the timer setting for the next use.

5
Display screen ON/OFF function
The function to switch on the screen:
Press “DISPLAY”(number 6), the screen will power off, but indication light will be lighting.
Press “DISPLAY”(number 6) again, the screen turns on again.
Open window detection
In case the temperature reduces 3°C or more within 2 minutes the heater stops working. The LED
lights flash and there is a click sound.
High/Low setting
With the high/low function, the radiant heater can heat in two different intensities. While operating
press “HIGH/LOW SWITCH BUTTON”(number 3) to select high or low heating intensity.
WIFI reset setting
While operating, press “SWITCH”(number 4) within 5 seconds, press “HIGH/LOW SWITCH
BUTTON”(number 3), then press the “UP BUTTON”(number 2) within 10 seconds. WIFI will
reset. When the radiant heater is connected to the WIFI, the indicator lights up permanently. If the
WIFI reset was successful, the WIFI indicator will blink.
(How to connect the heater with WIFI please see point “APP OPERATION”)
Switch OFF
The radiant heater can be switched off separately via the app. If you would like to turn off the
display press the “DISPLAY”(number 6) button.
•SERVICE
When you require service contact the retailer or a qualified service center.
•REPLACEMENT OF POWER CORD
A damaged power cord must be replaced by a service agent or equivalent persons in order to
prevent a hazard.
•CHILD SUPERVISION
This appliance is not intended to be used by children or infirm persons without supervision.

6
INSTALLATION GUIDE
Model
L (mm)
L1 (mm)
PANTHER 2000
1240
1007
PANTHER 2600
1540
1307
PANTHER 3200
1840
1607
Step one:
Take the 2 threaded mounting brackets and insert them into the rail provided on the unit and secure
the mounting brackets with 2 wing screws each. (Figure A)
Step two:
Take the other two mounting brackets and fix them to the wall or ceiling with appropriate mounting
hardware. (Figure B)
Please note a mounting height of at least 1.8 m.
Step three:
Connect the mounting brackets from the wall/ceiling with the mounting brackets from the heater with
2 wing screws and butterfly nuts each. (Figure C)

7
Option 1: CEILING INSTALLATION
Please keep a minimum distance of 20 cm to each side.
Option 2: WALL MOUNTED INSTALLATION
The ceiling height must be at least 210 cm.
The minimum distance to the ceiling must be at least 20 cm and the distance to the ground must be
at least 180 cm.

8
Option 3: EXTENDED INSTALLATION
Use suitable mounting material for ceiling suspension. (A1)
Insert holder into the rail on the device and secure with 2 wing screws each. (B1)
Mount the radial heater only on even ceiling.

9
APP Download
1. Apple and android system users can use the mobile phone by scanning the icon below to
download the APP.
2. Download the APP by using the following link: https//smartapp.tuya.com/smartlife
APP Operation
•Open the Smart Life APP.
•Create a new account or register.
•Enter the interface and click the “+”icon in the upper right corner.
•Choose “small household appliance”and click “Oil Heater”
•Next Step
•Connect now
•Enter your WIFI password.
•The radiant heater will be connected to the App.
•Click “DONE”

10
WARNING
1. Securely fix the heater to the wall or place the heater in the correct position.
2. The heater must be installed so that the controls cannot be touched by persons
currently taking a bath or shower.
3. The heater is to be installed so that it is not directly located under a socket-outlet.
4. Contact a qualified electrician or service technician if the power cord is damaged.
5. Always store the heater when not in use.
6. Make sure the heater has cooled down before storing it away.
7. Do not use the heater unattended.
8. Make sure that the heater is at a certain distance from other furniture or equipment to
avoid danger.
DO NOT dispose of electrical appliances as unsorted municipal waste, use
separate collection facilities. Contact your local government for information
on available collection systems. When disposing of electrical appliances,
hazardous substances can enter the groundwater and get into the food
chain, damaging your health and well-being. When replacing old appliances
with new ones, the retailer is legally obliged to take back your old appliance
for disposal at least for free of charge.
