Nobles Speed Scrub 3301 Product manual

ENGLISH - ESPAÑOL
Speed Scrubt
Model No.:
608695 – 2701
608696 – 2701 Pac
609239 – 2701 Can. Pac
608275 – 3301
608276 – 3301 Pac
609238 – 3301 Can. Pac
608290
Rev. 02 (06-01)
CUSTOMER SERVICE: 1-800-365-6625
FAX: [phone]
NOBLES
12875 RANSOM STREET
HOLLAND MI 49424 U.S.A.
Automatic Floor Scrubber
Fregadora Automática
Operator and Parts Manual
Manual de Operación y de Piezas
2701/3301

OPERATION
SpeedScrubt2701/3301 (06–01)
2
This manual is furnished with each new model. It
provides necessary operation and maintenance
instructions and a parts list.
Read this manual completely and understand the
machine before operating or servicing.
When ordering parts, use the illustrated Parts Lists in
this manual. Before ordering parts or supplies, be sure
to have your machine model number and serial
number handy. Parts and supplies may be ordered by
phone or mail from any authorized Service Center or
Distributor.
This machine will provide excellent service. However,
the best results will be obtained at minimum costs if:
SThe machine is operated with reasonable care.
SThe machine is maintained regularly Ć per the
maintenance instructions provided.
SThe machine is maintained with manufacturer
supplied or equivalent parts.
MACHINE DATA
Pleasefill out at time of installation for future reference.
Model No.-
Install. Date -
Serial No.-
E2001 Tennant Company Printed in U.S.A.
Nobles is a registered United States trademark of Tennant Company.
Speed Scrub is a United States trademark of Tennant Company.
TABLE OF CONTENTS (ESPAÑOL ÍNDICE....19)
SAFETY PRECAUTIONS 3. . . . . . . . . . . . . . . . . . . .
MACHINE COMPONENTS 4. . . . . . . . . . . . . . . . . . .
MACHINE INSTALLATION 5. . . . . . . . . . . . . . . . . . .
UNCRATING MACHINE 5. . . . . . . . . . . . . . . . . .
ATTACHING SQUEEGEE ASSEMBLY 5. . . . .
INSTALLING BATTERIES 5. . . . . . . . . . . . . . . .
MACHINE SETUP 6. . . . . . . . . . . . . . . . . . . . . . . . . .
PRE–OPERATION CHECKS 6. . . . . . . . . . . . . .
INSTALLING BRUSH OR PAD DRIVERS 6. . .
FILLING SOLUTION TANK 7. . . . . . . . . . . . . . .
MACHINE OPERATION 8. . . . . . . . . . . . . . . . . . . . .
WHILE OPERATING MACHINE 9. . . . . . . . . . .
CIRCUIT BREAKERS 9. . . . . . . . . . . . . . . . . . . .
DRAINING TANKS 10. . . . . . . . . . . . . . . . . . . . . . . . . .
DRAINING RECOVERY TANK 10. . . . . . . . . . . .
DRAINING SOLUTION TANK 10. . . . . . . . . . . . .
BATTERY CHARGING 11. . . . . . . . . . . . . . . . . . . . . .
MACHINE MAINTENANCE 12. . . . . . . . . . . . . . . . . .
DAILY MAINTENANCE 12. . . . . . . . . . . . . . . . . . .
WEEKLY MAINTENANCE 12. . . . . . . . . . . . . . . .
MONTHLY MAINTENANCE 12. . . . . . . . . . . . . . .
QUARTERLY MAINTENANCE 12. . . . . . . . . . . .
BATTERY MAINTENANCE 13. . . . . . . . . . . . . . .
DRIVE CHAIN MAINTENANCE 13. . . . . . . . . . .
TRANSPORTING MACHINE 14. . . . . . . . . . . . . . . . .
STORING MACHINE 14. . . . . . . . . . . . . . . . . . . . . . . .
RECOMMENDED STOCK ITEMS 14. . . . . . . . . . . . .
TROUBLE SHOOTING 15. . . . . . . . . . . . . . . . . . . . . .
SPECIFICATIONS 17. . . . . . . . . . . . . . . . . . . . . . . . . .
ELECTRICAL DIAGRAMS 36. . . . . . . . . . . . . . . . . . .
PARTS LIST 38. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
REPLACEMENT BRUSHES AND PAD
DRIVER GROUP 38. . . . . . . . . . . . . . . . . . . . . . . .
RECOVERY TANK GROUP 40. . . . . . . . . . . . . . .
CHASSIS GROUP 42. . . . . . . . . . . . . . . . . . . . . . .
CONTROL CONSOLE GROUP 44. . . . . . . . . . .
LEVER GROUP 46. . . . . . . . . . . . . . . . . . . . . . . . .
ELECTRICAL PANEL GROUP 48. . . . . . . . . . . .
DRIVE WHEEL GROUP 50. . . . . . . . . . . . . . . . . .
BRUSH DRIVE AND SOLUTION HOSE
GROUP 52. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SKIRT GROUP 54. . . . . . . . . . . . . . . . . . . . . . . . . .
SQUEEGEE CONTROL GROUP 56. . . . . . . . . .
CURVED SQUEEGEE GROUP 58. . . . . . . . . . .
OPTIONS 60. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
EStKIT 60. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SQUEEGEE WAND ASSEMBLY 62. . . . . . . . . .

OPERATION
Speed Scrubt2701/3301 (11–99) 3
SAFETY PRECAUTIONS
This machine is suited to scrub floors in a indoor
environment and is not constructed for any other use.
Use only recommended pads and cleaning solutions.
All operators must read, understand and practice the
following safety precautions.
The following safety alert symbols are used throughout
this manual as indicated in their description.
WARNING: To warn of hazards or unsafe
practices which could result in severe personal
injury or death.
FOR SAFETY: To identify actions which must be
followed for safe operation of equipment.
The following information signals potentially dangerous
conditions to the operator or equipment:
FOR SAFETY:
1. Do not operate machine:
–Unless trained and authorized.
–Unless operation manual is read and
understood.
–In flammable or explosive areas unless
designed for use in those areas.
2. Before starting machine:
–Make sure all safety devices are in place
and operate properly.
3. When using machine:
–Go slow on inclines and slippery surfaces.
–Use care when reversing machine.
–Report machine damage or faulty
operation immediately.
–Always follow safety and traffic rules.
–Follow mixing and handling instructions
on chemical containers.
4. Before leaving or servicing machine:
–Stop on level surface.
–Turn off machine.
5. When servicing machine:
–Avoid moving parts. Do not wear loose
jackets, shirts, or sleeves.
–Block machine tires before jacking
machine up.
–Use hoist or jack of adequate capacity to
lift machine.
–Disconnect battery connections before
working on machine.
–Wear protective gloves when handling
batteries or battery cables.
–Avoid contact with battery acid.
–Use manufacturer supplied or approved
replacement parts.
WARNING: Batteries emit hydrogen gas.
Explosion or fire can result. Keep sparks and
open flame away. Keep battery compartment open
when charging.
WARNING: Flammable materials can cause
an explosion or fire. Do not use flammable
materials in tank(s).
WARNING: Flammable materials or reactive
metals can cause explosion or fire. Do not pick
up.

OPERATION
SpeedScrubt2701/3301 (06–01)
4
MACHINE COMPONENTS
1
2
8910
14
11
12
16
15
7
17
13
26
5
6
3
4
19
18
20
25
22
24
25
23
21
1. Control Console
2. Control Grips
3. Main/Drive ON/OFF switch
4. Vacuum ON/OFF Switch
5. Brush ON/OFF Switch
6. Battery Meter
7. Circuit Breakers
8. Squeegee Lift Lever
9. Squeegee Release Lever
10. Solution Flow Lever
11. Solution Flow Adjustment Knob
12. Adjustable Control Console Levers
13. Scrub Head Lift Foot Pedal
14. Recovery Tank Drain Hose
15. Solution Tank Drain Hose with Gallon
Markers
16. Rear Fill Port
17. Squeegee Assembly
18. Recovery Tank
19. Recovery Tank Lid
20. Solution Fill Door
21. Safety Lights
22. Rear Casters
23. Skirt Housing
24. Scrub Head Skirt
25. Wall Rollers
26. Brush Pressure Lever

OPERATION
SpeedScrubt2701/3301 (06–01) 5
MACHINE INSTALLATION
UNCRATING MACHINE
Carefully check carton for signs of damage. Report
damages at once to carrier. Check carton contents to
ensure all accessories are included. Squeegee is
packaged with machine. Batteries, battery charger and
pad driver(s) are packaged separately. (Batteries not
included with Pac #609238 or 609239)
ATTENTION: Battery installation must be
accomplished after removing machine from
shipping crate.
To uncrate your machine, remove shipping straps and
raise brush head. To raise brush head, step down
firmly on the bottom brush lift foot pedal until pedal
locks into the raised position. Carefully lift or make a
ramp using crate boards to remove machine from
pallet.
ATTENTION: Do not roll machine off pallet,
damage may occur.
ATTACHING SQUEEGEE ASSEMBLY
1. Pull back on squeegee lift lever to raise squeegee
mount bracket.
2. Loosen two thumb knobs on squeegee and slide
squeegee into slots at rear of squeegee mount
bracket. Be certain that squeegee roller wheels
are toward the rear (Figure 1).
FIG. 1
3. Tighten thumb knobs securely.
INSTALLING BATTERIES
WARNING: Batteries emit hydrogen gas.
Explosion or fire can result. Keep sparks and
open flame away. Keep battery compartment open
when charging.
FOR SAFETY: When servicing machine, wear
protective gloves when handling batteries or
battery cables. Avoid contact with battery acid.
Recommended Battery Specifications:
Four 6 volt, deep cycle, 305 amp hour batteries. Part
Number #130870. Maximum battery dimensions are
178mm (7 in) W x 308mm (12.13 in) L x 356mm
(14 in) H.
1. Turn all switches to the OFF position and pull out
the Main Power circuit breaker button as shown
(Figure 2).
FIG. 2
ATTENTION: To prevent motors from accidental
starting, be certain to pull out the “MAIN”circuit
breaker button before installing batteries.
2. Carefully hinge open recovery tank to access
battery compartment. Make sure recovery tank is
empty before opening. Remove loose battery
cables from compartment (Figure 3).
FIG. 3

OPERATION
SpeedScrubt2701/3301 (06–01)
6
3. Carefully install batteries into compartment and
arrange battery posts as shown (Figure 4).
FRONT
FIG. 4
ATTENTION: Do not drop batteries into
compartment, battery and machine housing
damage may result. This damage in not covered
by warranty.
4. Connect cables to battery posts in numerical order
as labeled (RED TO POSITIVE & BLACK TO
NEGATIVE). (Figure 4)
5. Double check cable connections before closing up
battery compartment.
6. Reset the “MAIN”circuit breaker button.
7. Turn “MAIN”switch on, and check battery meter
charge level to ensure batteries are fully charged.
If batteries need charging, see BATTERY
CHARGING.
MACHINE SETUP
PRE–OPERATION CHECKS
1. Sweep and dust mop floor to remove particles and
other debris.
2. Check battery meter charge level to ensure
batteries are fully charged. (See BATTERY
CHARGING)
3. Check that pads or brushes are installed.
4. Check that squeegee is installed.
INSTALLING BRUSH OR PAD DRIVERS
1. Turn Main switch to the “OFF”position and pull
out the Main Power circuit breaker button.
FOR SAFETY: Before leaving or servicing
machine, stop on level surface and turn off
machine.
ATTENTION: To prevent accidental starting, pull
out the Main Power circuit breaker button before
installing brush or pad drivers. Circuit breaker
button is located a rear of control housing.
2. Raise scrub head. Step down firmly on bottom
brush lift foot pedal to raise (Figure 5).
FIG. 5
3. Unfasten black latch at front of machine and hinge
open skirt housing to access motor hub (Figure 6).
FIG. 6
4. Select recommended pad or brush that best
meets your cleaning needs.
NOTE: Consult your authorized distributor for
pad/brush recommendations.

OPERATION
SpeedScrubt2701/3301 (06–01) 7
5. (For Pad Installation) Attach pads to pad drivers
before connecting drivers to motor hub. To attach
pad to driver, remove plastic centerlock ring from
pad driver. Position pad on pad driver and replace
centerlock ring (Figure 7).
FIG. 7
6. Attach brush/pad drivers to motor hubs. Align (3)
mounting studs with slots in motor hub. Give driver
a quick turn toward spring clip located on motor
hub. Be certain pad driver is securely fastened
and spring clip locks into one of the studs before
operating machine (Figure 8).
FIG. 8
NOTE: Always make sure pad driver and motor hub
surfaces are always clean before installing drivers.
Keeping surfaces clean will make it easier when
removing pad drivers.
7. Close skirt housing and refasten latch.
FILLING SOLUTION TANK
1. Transport machine to filling station. Raise
squeegee and brush when transporting.
2. Turn off machine.
FOR SAFETY: Before leaving or servicing
machine, stop on level surface and turn off
machine.
3. Shut off solution flow. Pull solution flow lever
completely back to shut off (Figure 9).
FIG. 9
4. Open solution fill door at front of machine and fill
solution tank with clean water, 60°C (140°F)
maximum temperature. Or you can fill solution
tank using hose fill port at rear of machine. Twist
off plug and insert hose to fill. The clear tube
below the fill port has 19L (5 gallon) increment
markers to indicate amount of water in tank
(Figure 10).
FIG. 10
NOTE: If filling with a bucket be certain that bucket is
clean. This will prevent possible solution line clogs.
5. Add cleaning chemical. See proper dilution ratio
instructions on bottle.
FOR SAFETY: When using machine, follow mixing
and handling instructions on chemical containers.
ATTENTION: Use only recommended cleaning
chemicals, DO NOT use substitutes. Consult an
authorized distributor to assist you with the
recommended cleaning chemicals.
WARNING: Flammable materials can cause
an explosion or fire. Do not use flammable
materials in tanks.

OPERATION
SpeedScrubt2701/3301 (06–01)
8
MACHINE OPERATION
FOR SAFETY: Do not operate machine unless
operator manual is read and understood.
1. Adjust control grips to a comfortable operating
height (three settings). Squeeze two levers
together, located under console, to raise and lower
control grips (Figure 11).
FIG. 11
2. Lower squeegee. Depress thumb lever on
squeegee lift lever to lower (Figure 12).
FIG. 12
3. Lower scrub head. Depress top brush lift foot
pedal forward to lower (Figure 13).
FIG. 13
4. Turn on the MAIN, VACUUM and BRUSH
switches.
NOTE: The brush motors will not start until control
grips are rotated.
5. Activate solution flow. Push solution flow lever
slightly forward to activate. The further the lever is
pushed forward the more solution will flow. Push
completely forward for maximum flow. Solution will
immediately begin to flow once lever is activated
(Figure 14).
FIG. 14
NOTE: To increase or decrease the maximum solution
flow, turn solution flow adjustment knob. Turn knob
clockwise to decrease solution flow or
counterclockwise to increase (Figure 15).
FIG. 15
6. Slowly rotate control grips forward to begin
scrubbing. The machine will continue to gain
speed the further you rotate grips. To drive
machine in reverse; simply rotate control grips
backwards.

OPERATION
SpeedScrubt2701/3301 (06–01) 9
WARNING: Flammable materials or reactive
metals can cause explosion or fire. Do not pick
up.
ATTENTION: Always start machine out slowly to
prevent machine from leaping forward.
7. View amount of solution flow on floor and adjust
solution control lever to desired solution flow.
8. To stop scrubbing, release control grips.
WHILE OPERATING MACHINE
FOR SAFETY: When using machine, go slow on
inclines and slippery surfaces.
1. Periodically check for foam buildup in recovery
tank (look through clear lid). If excessive foam
buildup begins to develop, pour a recommended
foam control solution into recovery tank.
ATTENTION: Do not allow foam or water to enter
vacuum standpipe, vacuum motor damage will
result. Ball float shutoff will not keep foam out of
standpipe. Vacuum damage due to foam or water
is not covered by warranty.
2. If more scrubbing pressure is needed for small
heavily soiled areas, follow steps below:
a. Lower brush.
b. Lift brush pressure lever to the locked position
(Figure 16).
NOTE: Brush MUST be down to allow brush pressure
lever to be lifted to the locked position. Do not leave
lever in the lock position when brushes are raised.
FIG. 16
3. If squeegee leaves streaks, raise and wipe blades
with a cloth. Pre–sweep area to prevent streaking.
4. Before stopping or turning machine around, pull
back on solution control lever to shut off solution
flow.
5. During brief stops, you do not have to turn off
brush switch, the brush will automatically stop
when control grips are released.
6. While cleaning, view clear tube gallon marker for
remaining cleaning solution. Each mark on hose
indicates 19 liters (5 gal).
7. Periodically check battery meter discharge level.
When needle drops to the red zone, recharge
batteries.
ATTENTION: Do not continue to run machine
when battery meter needle is in the red zone,
battery damage will result.
8. When solution tank runs dry, turn off brush switch,
shut off solution control lever and continue to
vacuum until all dirty water is consumed. Then
drain recovery tank. (See DRAINING TANKS).
CIRCUIT BREAKERS
The machine is equipped with (4) circuit breakers to
protect motors from damage. If circuit breakers trip,
they cannot be reset immediately. Determine reason
why breaker tripped, allow motor to cool and then
reset. Brush motor circuit breakers will trip due to
excessive overload on pad. Clean or change pad if
breaker should trip. Circuit breaker buttons are
located at rear of machine as shown (Figure 17).
FIG. 17
NOTE: When servicing machine or when machine is
left unattended, pull out the Main Power circuit breaker
button. This will shut off all power to machine.

OPERATION
SpeedScrubt2701/3301 (06–01)
10
DRAINING TANKS
FOR SAFETY: Before leaving or servicing
machine, stop on level surface and turn off
machine.
DRAINING RECOVERY TANK
Recovery tank must be emptied prior to refilling
solution tank. To drain recovery tank, perform the
following steps:
ATTENTION: If recovery tank is not emptied
between fill–ups, foam or water will enter vacuum
standpipe and damage vacuum motor. Float
shut–off screen will not keep foam out of
standpipe. Vacuum damage due to foam or water
is not covered by warranty.
1. Remove drain hose from holder, position hose
over floor drain and twist off drain hose plug. To
completely drain recovery tank, hinge open tank
and flip up tank support stand to rest tank on
(Figure 18).
NOTE: If using a bucket to drain machine, do not use
same bucket for filling solution tank. This will prevent
possible solution line clogs.
FIG. 18
2. Rinse out recovery tank after each use. This will
prevent foul odor buildup. Use a hose to rinse out
the recovery tank. Be careful not to spray water
into shut–off float screen.
3. Replace drain hose plug tightly when tank is
empty.
DRAINING SOLUTION TANK
To drain leftover cleaning solution from solution tank,
follow steps below:
1. Pull clear hose off hose barb at rear of machine
and drain solution into floor drain or bucket
(Figure 19).
FIG. 19
2. Rinse out solution tank with clean water after each
use and flush out solution flow system by pushing
solution flow lever forward. This will prevent
clogging due to chemical buildup. Use clear hose
to drain solution tank.
3. Reconnect clear hose to hose barb. Be certain
hose is completely pushed onto hose barb.

OPERATION
SpeedScrubt2701/3301 (06–01) 11
BATTERY CHARGING
The following charging instructions are intended
for supplied chargers only. If you don’t have a
supplied battery charger, use a charger with the
following specifications listed below. Improper
charger may cause battery damage.
CHARGER SPECIFICATIONS:
SOUTPUT VOLTAGE –24 VOLTS
SOUTPUT CURRENT –25 AMPS
SAUTOMATIC SHUT–OFF CIRCUIT
SFOR LEAD ACID DEEP CYCLE BATTERY CHARGING
NOTE: Recharge batteries ONLY after a total of 30
minutes or more of use. This will prolong battery life.
WARNING: Batteries emit hydrogen gas.
Explosion or fire can result. Keep sparks and
open flame away. Keep battery compartment open
when charging.
FOR SAFETY: When servicing machine, wear
protective gloves when handling batteries or
battery cables. Avoid contact with battery acid.
1. Transport machine to a well ventilated area when
charging.
2. Turn machine power off.
FOR SAFETY: Before leaving or servicing
machine, stop on level surface and turn off
machine.
3. Hinge open recovery tank to access batteries.
Make sure recovery tank is empty before opening
(Figure 20).
FIG. 20
4. Before charging batteries, check fluid level (A) in
each battery cell. If battery plates (B) are exposed,
add just enough distilled water to cover plates,
level (A). Never add acid to batteries. DO NOT
overfill. Batteries can overflow during charging due
to expansion. Do not charge batteries unless fluid
is slightly covering battery plates (B). Replace cell
caps before charging (Figure 21).
A
B
FIG. 21
5. With charger’s power supply cord unpluged,
connect battery charger to machine. Flip up tank
support stand and rest tank on stand (Figure 22).
FIG. 22
6. Plug battery charger cord into a grounded wall
outlet (Figure 23).
Grounded Outlet
Grounding
Edge/hole
Grounded
3 Hole Outlet
Ground Pin
(120V) (230V)
FIG. 23

OPERATION
SpeedScrubt2701/3301 (06–01)
12
7. Charger will automatically begin charging and
automatically shut off when fully charged.
8. After charger has turned off, unplug from wall
outlet first then disconnect charger from machine.
9. Recheck battery fluid level after charging. If
needed, add distilled water to bring level of fluid to
bottom of sight tubes. Be certain to replace cell
caps securely and to wipe off the top of batteries
with a clean cloth.
MACHINE MAINTENANCE
To keep machine in good working condition, simply
follow daily, weekly and monthly maintenance
procedures.
FOR SAFETY: Before leaving or servicing
machine, stop on level surface and turn off
machine.
FOR SAFETY: When servicing machine,
disconnect battery connections before working on
machine.
ATTENTION: Contact an Authorized Service
Center for machine repairs. Machine repairs
performed by other than an authorized person will
void your warranty.
DAILY MAINTENANCE
(Every 4 Hours of Use)
1. Remove and clean pads or brushes. Never use
soiled pads when cleaning. Replace pads when
they become loaded with residue.
2. Remove and clean lint from float shut–off screen
located in recovery tank (Figure 24).
FIG. 24
3. Drain and rinse tanks thoroughly. After draining
tanks, hinge recovery tank until you can see
vacuum intake hole at rear of tank. Remove any
clogging debris in hole if necessary.
4. Raise squeegee and wipe it down with a dry cloth.
Store squeegee in the up position to prevent
squeegee damage.
5. Clean machine housing with a nonabrasive,
non–solvent cleaner.
6. Recharge batteries if needed.
WEEKLY MAINTENANCE
(Every 20 Hours of Use)
1. Check water level in battery cells. (See BATTERY
MAINTENANCE).
2. Clean battery tops to prevent corrosion.
3. Check for loose or corroded battery cables.
MONTHLY MAINTENANCE
(Every 80 Hours of Use)
1. Flush solution system. Pour 11.3 liters (3 gal) of
hot water, 60_C (140_F) max. temperature, into
solution tank. Add an acetic acid solution
according to mixing instructions. Over a floor
drain, operate machine for 30 seconds. Turn
machine off and leave overnight. Next day,
disperse solution and rinse solution system.
FOR SAFETY: When using machine, follow mixing
and handling instructions on chemical containers.
2. Check drive chain for excess slack and lubricate
with a water resistant grease. If chain needs
tightening, see DRIVE CHAIN MAINTENANCE.
3. Lubricate axle and caster grease fittings with a
water resistant grease.
4. Lubricate all linkage pivot points with silicone
spray then coat with a water resistant grease to
maintain a smooth operation.
5. Check machine for water leaks and loose nuts and
bolts.
QUARTERLY MAINTENANCE
(Every 250 Hours of Use)
1. Check drive and brush motors for carbon brush
wear, replace brushes if worn.
2. Check vacuum motor for carbon brush wear,
replace brushes when worn to a length of 10 mm
(0.38 in) or less.

OPERATION
SpeedScrubt2701/3301 (06–01) 13
BATTERY MAINTENANCE
WARNING: Batteries emit hydrogen gas.
Explosion or fire can result. Keep sparks and
open flame away. Keep battery compartment open
when charging.
FOR SAFETY: When servicing machine, wear
protective gloves when handling batteries or
battery cables. Avoid contact with battery acid.
1. Always follow proper charging instructions. (See
BATTERY CHARGING)
2. Each week after charging, check water level (A) in
each battery cell of all batteries. Water level
should reach bottom of sight tubes (B). If needed,
add just enough distilled water to reach bottom of
sight tubes. DO NOT overfill (Figure 25).
A
B
FIG. 25
3. Keep battery tops and terminals clean and dry.
To clean batteries:
a. Mix a strong solution of baking soda and
water.
b. Brush solution sparingly over battery tops,
terminal and cable connectors.
NOTE: Do not allow baking soda solution to enter
battery cells.
c. Use wire brush to clean terminal post and
cable connections.
d. After cleaning, apply a coating of clear battery
post protectant to terminals and cable
connections.
4. Check for loose or worn cables. Replace if worn.
DRIVE CHAIN MAINTENANCE
Inspect drive chain periodically for proper tension.
Chain should flex between 6.35mm (0.25 in) and
12.7mm (0.50 in) from center. If chain flexes more
than 12.7mm (0.50 in), chain should be tightened. To
tighten chain, follow steps below:
1. Turn machine power off.
2. From operators right side of machine, locate and
loosen 4 motor mount bolts, do not remove bolts.
3. Loosen locking nut on tension bolt (Figure 26).
FIG. 26
4. Turn tension bolt clockwise until chain is taut.
5. Retighten locking nut and 4 motor mount screws.
6. Lubricate chain with a water resistant oil.

OPERATION
SpeedScrubt2701/3301 (06–01)
14
TRANSPORTING MACHINE
When transporting machine by use of trailer or truck,
be certain to follow tie–down procedures below:
FOR SAFETY: When using machine, go slow on
inclines and slippery surfaces.
1. Remove squeegee from machine and raise brush
head. Leave pad or brush installed.
2. Load machine using a recommended loading
ramp.
3. Position front of machine up against front of trailer
of truck. Once machine is positioned, lower brush
head.
4. Place a block behind the drive wheel and the rear
casters.
5. Place tie–down straps over top of machine and
secure straps to floor. It may be necessary to
install tie–down brackets to the floor of your trailer
or truck.
STORING MACHINE
1. Before storing machine, be certain to flush tanks
and drain machine of all water.
2. Store machine in a dry area with squeegee
removed and pad driver in the raised position.
3. Remove recovery lid to promote air circulation.
4. When storing machine for short periods, raise pad
driver and squeegee off floor to prevent damage.
ATTENTION: If storing machine in freezing
temperatures, be certain to drain machine of all
water. Damage due to freezing temperatures is not
covered by warranty.
RECOMMENDED STOCK ITEMS
Refer to the Parts List section for recommended stock
items. Stock Items are clearly identified with a bullet
preceding the parts description. See example below:

OPERATION
SpeedScrubt2701/3301 (11–97) 15
TROUBLE SHOOTING
PROBLEM CAUSE SOLUTION
No power, nothing runs. Batteries need charging. See CHARGING BATTERIES.
Faulty battery(s). Replace battery(s).
Loose battery cable. Tighten loose cable.
Battery connection is improper. See BATTERY INSTALLATION.
Faulty main switch Contact Service Center.
Main Power circuit breaker has
tripped. Determine cause and reset circuit breaker button.
Brush motor does not run. Brush circuit breakers have
tripped, or has been pulled out. Clean or change to a less aggres- sive pad. Also, release brush
pressure lever if it’s in the up posi-
tion. Reset breaker button.
Loose wire connection. Contact Service Center.
Drive roll grips are not twisted. Drvie roll grips must be twisted to
activate brushes.
Faulty brush motor or wiring. Contact Service Center.
Faulty brush switch. Contact Service Center.
Carbon brushes worn. Contact Service Center.
Faulty solenoid. Contact Service Center.
Vacuum motor does not run. Vacuum circuit breaker has
tripped. Remove obstruction and reset breaker.
Faulty vacuum switch. Contact Service Center.
Faulty wiring. Contact Service Center.
Faulty vacuum motor. Contact Service Center.
Faulty solenoid. Contact Service Center.
Carbon brushes worn. Contact Service Center.
Short run time. Batteries not fully charged. Charge batteries.
Bad cell in one or more batteries. Replace battery.
Batteries need maintenance. See BATTERY MAINTENANCE.
Faulty charger. Replace battery charger.
Poor squeegee pick up. Recovery tank is full. Empty recovery tank.
Ball float shutoff screen inside
recovery tank is clogged. Remove screen and clean.
Squeegee is clogged with debris. Clean squeegee.
Squeegee blades are worn. Replace squeegee blades.
Squeegee thumbscrews are loose. Tighten thumbscrews.
Vacuum hose connections are
loose or hose has a hole. Push hose cuffs firmly on connec- tions. Replace hose if damaged.
Vacuum hose is clogged with
debris. Remove clogged debris.
Tank gasket is defective. Replace gasket.

OPERATION
SpeedScrubt2701/3301 (11–97)
16
TROUBLE SHOOTING –continued
PROBLEM CAUSE SOLUTION
Poor squeegee pick up. Recovery tank water inlet is
plugged. Inlet is located at bottom
of recovery tank.
Empty recovery tank and tilt it
sideways to locate inlet hole,
remove clogged debris.
Drain hose plug is loose. Tighten drain plug.
Clear recovery tank lid is loose. Tighten lid.
Vacuum motor is loose. Contact Service Center.
Battery charge is low. Charge batteries. Do not run
machine when battery meter is in
the red zone.
Faulty vacuum motor. Contact Service Center.
Drive motor does not run. MAIN circuit breaker has tripped
or is pulled. Determine cause and reset breaker.
Faulty MAIN switch. Contact Service Center.
Faulty speed control circuit board
or connection. Contact Service Center.
Faulty solenoid. Contact Service Center.
Faulty wiring. Contact Service Center.
Faulty drive motor. Contact Service Center.
Worn carbon brushes. Contact Service Center.
Drive motor runs, but not correctly. Faulty potentiometer or speed
control board. Contact Service Center.
Faulty resistor. Contact Service Center.
Little or no solution flow. Solution flow lever in not activated. Push solution flow lever forward.
Solution line or filter is clogged. Remove hose and blow com-
pressed air through it. Flush solu-
tion tank after each use.
Solution valve is clogged. Remove valve and clean. Do not
scratch or damage inside of valve.
Solution flow adjustment knob
needs adjusting. Turn solution flow knob clockwise to increase flow.
Safety lights do not work. Flasher is burned out. Contact Service Center.

OPERATION
SpeedScrubt2701/3301 (06–01) 17
SPECIFICATIONS
MODEL SPEED SCRUBt2701 SPEED SCRUBt3301
LENGTH 1500 mm (59 in) 1500 mm (59 in)
WIDTH 740 mm (29 in) 890 mm (35 in)
HEIGHT 1040 mm (41 in) 1040 mm (41 in)
WEIGHT –
W/ BATTERIES 352kg (760 lbs) 355kg (765 lbs)
TANKS CAPACITY 102L (27 Gal) 102L (27 Gal)
SPEED CONTROL VARIABLE FWD/REV VARIABLE FWD/REV
CLEANING SPEED (MAX) 2787 sq. m.(30,000 sq. ft.)/hr. 3251 sq. m. (35,000 sq. ft.)/hr.
CLEANING PATH WIDTH 680 mm (27 in) 830 mm (33 in)
PAD DIAMETER 2 –355 mm (14 in) 2 –430 mm (17 in)
SQUEEGEE WIDTH 965 mm (38 in) 1067 mm (42 in)
DRIVE MOTOR .5 h.p., 0–1800 rpm, 24V, 10A .5 h.p., 0–1800 rpm, 24V, 10A
BRUSH MOTOR 2 –.75 h.p., 220 rpm, 24V, 20A, 550W 2 –.75 h.p., 220 rpm, 24V, 20A, 550W
VACUUM MOTOR .75 h.p., 3–stage 5.7”, 24V, 21A, 550W .75 h.p., 3–stage 5.7”, 24V, 21A, 550W
WATER LIFT 1720 mm (68 in) 1720 mm (68 in)
BATTERIES 4–305A/hr, 6V deep cyc 4–305A/hr, 6V deep cyc
RUN TIME on full charge 4.76 Hours 4.76 Hours
DECIBEL RATING AT OPERATOR’S
EAR, INDOORS ON TILE. <70dB(A) <70dB(A)

OPERATION
SpeedScrubt2701/3301 (10–00)
18

OPERACIÓN
Speed Scrubt2701/3301 (06–01) 19
Este manual acompaña a todos los modelos estándar
nuevos. En él se indican las instrucciones necesarias
para la utilización y el mantenimiento de la máquina.
Lea el manual entero para comprender el
funcionamiento de la máquina antes de utilizarla o
revisarla.
Esta máquina le proporcionaráun servicio excelente.
Sin embargo, obtendrálos mejores resultados al coste
mínimo si:
SUtiliza la máquina con un cuidado razonable.
SRevisa la máquina periódicamente - según las
instrucciones de mantenimiento adjuntas.
SRealiza el mantenimiento de la máquina con piezas
repuesto del fabricante suministradas por o
equivalentes.
DATOS DE LA MÁQUINA
ModeloNo.:
Fecha de preparación:
No. de serie:
Sírvase llenar los datos en el momento de la preparación para
referencia en el futuro.
ÍNDICE
MEDIDAS DE SEGURIDAD 20. . . . . . . . . . . . . . . . . .
COMPONENTES DE LA MÁQUINA 21. . . . . . . . . . .
INSTALACIÓN DE LA MÁQUINA 22. . . . . . . . . . . . .
DESEMBALADO DE LA MÁQUINA 22. . . . . . . .
FIJACIÓN DEL CONJUNTO DE LA
ESCOBILLA DE GOMA 22. . . . . . . . . . . . . . . . . .
INSTALACIÓN DE LAS BATERÍAS 22. . . . . . . .
PREPARACIÓN DE LA MÁQUINA 23. . . . . . . . . . . .
COMPROBACIONES PREVIAS A LA
PUESTA EN FUNCIONAMIENTO 23. . . . . . . . .
INSTALACIÓN DE LOS CEPILLOS O DE LOS
IMPULSORES DE LAS ALMOHADILLAS 23. . .
LLENADO DEL DEPÓSITO DE LA
DISOLUCIÓN25. . . . . . . . . . . . . . . . . . . . . . . . . . .
FUNCIONAMIENTO DE LA MÁQUINA 25. . . . . . . .
DURANTE LA UTILIZACIÓN DE
LA MÁQUINA 26. . . . . . . . . . . . . . . . . . . . . . . . . . .
CORTACIRCUITOS 27. . . . . . . . . . . . . . . . . . . . . .
VACIADO DE LOS DEPÓSITOS 28. . . . . . . . . . . . . .
VACIADO DEL DEPÓSITO DE
RECUPERACIÓN28. . . . . . . . . . . . . . . . . . . . . . .
VACIADO DEL DEPÓSITO DE
LA DISOLUCIÓN28. . . . . . . . . . . . . . . . . . . . . . . .
CARGA DE LAS BATERÍAS 29. . . . . . . . . . . . . . . . .
MANTENIMIENTO DE LA MÁQUINA 30. . . . . . . . .
MANTENIMIENTO DIARIO 30. . . . . . . . . . . . . . .
MANTENIMIENTO SEMANAL 30. . . . . . . . . . . . .
MANTENIMIENTO MENSUAL 31. . . . . . . . . . . .
MANTENIMIENTO TRIMESTRAL 31. . . . . . . . .
MANTENIMIENTO DE LA BATERÍA31. . . . . . .
MANTENIMIENTO DE LA CADENA
DE IMPULSIÓN32. . . . . . . . . . . . . . . . . . . . . . . . .
TRANSPORTE DE LA MÁQUINA 32. . . . . . . . . . . . .
ALMACENAMIENTO DE LA MÁQUINA 32. . . . . . .
ARICULOS RECOMENDADOS A
MANTENER EN EXISTENCIA 32. . . . . . . . . . . . . . . .
LOCALIZACIÓN DE AVERÍAS 33. . . . . . . . . . . . . . .
ESPECIFICACIONES 35. . . . . . . . . . . . . . . . . . . . . . .
DIAGRAMAS ELECTRICAS 36. . . . . . . . . . . . . . . . .
LISTA DE PIEZAS 38. . . . . . . . . . . . . . . . . . . . . . . . . .
CEPILLO DEL REEMPLAZO Y GRUPO
DEL MANDO DE LA ALMOHADILLA 38. . . . . . .
CONJUNTO DESPOSITO RECUPERAR 40. . .
CONJUNTO TELAIO 42. . . . . . . . . . . . . . . . . . . . .
CONJUNTO CONSOLA DE CONTROLES 44. .
CONJUNTO DE PALANCAS 46. . . . . . . . . . . . . .
CONJUNTO CONSOLA ELÉCTRICO 48. . . . . .
CONJUNTO RUEDA DE MANDO 50. . . . . . . . . .
ACCIONAMIENTO DEL CEPILLO Y GRUPO
DE MANGUERA DE SOLUCION 52. . . . . . . . . .
CONJUNTO JUEGO 54. . . . . . . . . . . . . . . . . . . . .
GROUPO DE CONTROL DE LA ESCOBILLA
DE GOMA 56. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CONJUNTO ENJUGADOR ENCORUADO 58. .
OPCIONES 60. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
EStJUEGO 60. . . . . . . . . . . . . . . . . . . . . . . . . . . .
GROUPE D’ASPIRATION ET
RACLETTE ÀMAIN 62. . . . . . . . . . . . . . . . . . . . . .

OPERACIÓN
Speed Scrubt2701/3301 (01–99)
20
MEDIDAS DE SEGURIDAD
Esta máquina ha sido diseñada para barrer suelos de
recintos cerrados y no debe utilizarse para ningún otro
uso.
Use solamente las almohadillas y las soluciones de
limpieza recomendadas.
Cualquier persona que use esta máquina debe leer,
comprender y poner en práctica las siguientes
precauciones de seguridad:
ADVERTENCIA: Para advertir sobre riesgos
o hábitos peligrosos que podrían causar lesiones
corporales graves o fatales.
PARA SU SEGURIDAD: Para indicar las
operaciones que deben realizarse para una
utilización segura del equipo.
La siguiente información indica las condiciones
potencialmente peligrosas para el equipo o el operario
del mismo.
PARA SU SEGURIDAD:
1. NO UTILICE, REVISE O REPARE LA
MÁQUINA:
–Salvo que estéadecuadamente entrenado
y autorizado para ello.
–Salvo que haya leído y comprendido el
manual del operario.
–Cuando la máquina no estéen buenas
condiciones de funcionamiento.
2. AL UTILIZAR LA MÁQUINA:
–Retire los objetos sueltos que se
encuentren en el suelo puesto que podrían
convertirse en peligrosos proyectiles al
chocar contra los cepillos o almohadillas
en movimiento.
–Mantenga pies y manos alejados de los
cepillos y almohadillas giratorios
–Mantenga la máquina en movimiento para
evitar que el suelo o su acabado se
deterioren.
–No utilice la máquina donde existan
líquidos y gases inflamables.
–No utilice la máquina en pendiente a
menos que estépresente el personal
adecuado para ayudarle.
3. ANTES DE ESTACIONAR O REVISAR LA
MÁQUINA
–Asegúrese de que la máquina esté
apagada, o tire hacia fuera del botón del
cortacircuitos principal (MAIN).
–Desconecte las baterías.
ADVERTENCIA: Alta tensión. Riesgo de
electrocución o descarga eléctrica. Desconecte
siempre las baterías antes de revisar la máquina.
ADVERTENCIA: Las baterías emiten gases de
hidrógeno que pueden provocar explosiones o
incendios. Manténgalas alejadas de chispas y
fuego.
ADVERTENCIA: Cargue las baterías en una
zona bien ventilada y mantenga abiertas las
cubiertas de la batería. Existe peligro se explosión
o fuego.
ADVERTENCIA: El ácido de la batería puede
causar quemaduras. Utilice guantes protectores y
protéjase los ojos al revisar las baterías.
