Magna Twin™Series:
specifications
Vacuum System 2600 2200 1600
Airflow at orifice 101 cfm / 2.86 m3/h 94 cfm / 2.66 m3/h 94 cfm / 2.66 m3/h
Vacuum motor amps 10 A 6.6 A 6.6 A
Vacuum motor diameter 5.7 in / 144.8 mm
Vacuum motor hp 1 hp
Vacuum motor stages 2 stage
Vacuum motor type Thru-flow, thermally protected with auto reset, UL recognized
Vacuum motor voltage 120 V
Vacuum motor watts 1200 watts 800 watts 800 watts
Waterlift at sealed orifice 114 in / 2895.6 mm 90.2 in / 2291.1 mm 90.2 in / 2291.1 mm
Debris Recovery System
Vacuum bag description Enviro-Filter, micro-lined 2-ply construction, destroys germs and bacteria
Vacuum bag filtration description 99.9% efficiency for particles of 0.3 micron. Optional Clean Air Exhaust Filter – 99%
efficiency at 0.3 microns. Capacity: 1/3 bushel / 10 L.
Brush Drive System
Brush design description Double bristle row, ABS core; spiral patterned
Brush length 24 in / 609.6 mm 20 in / 508 mm 14 in / 36 mm
Brush motor amps 1 A
Brush motor hp 0.2 hp
Brush motor RPM 1800 rpm
Brush motor type Permanent magnet DC, circuit breaker protected
Brush motor voltage 120 V
Brush motor watts 120 watts
Brush RPM 1200 rpm
Productivity
Cleaning width 26 in / 660.4 mm 22 in / 558.8 mm 16 in / 406.4 mm
Maximum coverage rate 11,000 ft2/h / 1022 m2/h 10,000 ft2/h / 929 m2/h 9,000 ft2/h / 836.1 m2/h
Power System
Power consumption amps 11 A 8.1 A 8.1 A
Power consumption volts 120 V 120 V 120 V
Power consumption watts 1320 watts 972 watts 972 watts
Power cord length 50 ft / 15.24 m
Power cord type 16 gauge, 3-wire, SJTO, non-marking safety yellow with grounded plug.
Dimensions / Weight / Sound level
Length 19 in /482.6 mm
Height 44 in / 1,120 mm
Width 26 in / 660.4 mm 22 in / 558.8 mm 16 in / 406.4 mm
Net weight 44 lb / 19.96 kg 42 lb / 19.06 kg 38 lb / 17.24 kg
Sound level 73 dBA
Warranty 3 years/2500 hrs on parts and labor (excluding batteries).
10 years on rotationally-molded polyethylene tanks.
Nobles | 701 N. Lilac Drive | P.O. Box 1452 | Minneapolis MN 55440-1452 | 800.553.8033 | www.nobles.com | [email protected]
Specifications subject to change without notice. REV 8.14.06
