Nobu GR-10L User manual

MODELS/ΜΟΝΤΕΛΑ: GR-10L
For correct use of this unit, please read this manual carefully and keep it for future reference.
Για τη σωστή χρήση της μονάδας, παρακαλούμε διαβάστε προσεκτικά το εγχειρίδιο
και φυλάξτε το για αναφορά στο μέλλον.
Pentru o utilizare corecta, va rugam sa cititi cu atentie acest manual
si sa il pastrati pentru o consultare ulterioara.
English/Ελληνικά/Română
Dehumidier
User’s Manual
Αφυγραντήρας
Εγχειρίδιο Χρήσης
Dezumidicator
Manual de utilizare


3
SOCIABLE REMARK
When using this dehumidier in the European countries, the following information must
be followed:
DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such waste
separately for special treatment is necessary.
It is prohibited to dispose of this appliance in domestic household waste.
For disposal, there are several possibilities:
A) The municipality has established collection systems, where electronic waste can be dis-
posed of at least free of charge to the user.
B) When buying a new product, the retailer will take back the old product at least free of
charge.
C) The manufacture will take back the old appliance for disposal at least free of charge to
the user.
D) As old products contain valuable resources, they can be sold to scrap metal dealers.
Wild disposal of waste in forests and landscapes endangers your health when hazardous sub-
stances leak into the ground-water and nd their way into the food chain.


5
CONTENTS
SAFETY PRECAUTIONS
Warning ..................................................................................................................................... 6
Caution ...................................................................................................................................... 6
Electrical information ................................................................................................................. 8
WARNINGS (for using R290/R32 refrigerant only) .................................................................... 9
CONTROL PADS ON THE DEHUMIDIFIER
Indicator lights ............................................................................................................................ 15
Control pads ............................................................................................................................... 15
Other features............................................................................................................................. 16
IDENTIFICATION OF PARTS
Identication of parts .................................................................................................................. 16
Positioning the unit ..................................................................................................................... 17
OPERATING THE UNIT
When using the unit.................................................................................................................... 17
Removing the collected water .................................................................................................... 18
CARE AND MAINTENANCE
Care and cleaning of the dehumidier........................................................................................ 20
TROUBLESHOOTING TIPS
Troubleshooting tips ................................................................................................................... 22
Read This Manual
Inside you will nd many helpful hints on how to use and maintain your dehumidier properly.
Just a little preventive care on your part can save you a great deal of time and money over the
life of your dehumidier. You’ll nd many answers to common problems in the chart of trouble-
shooting tips. If you review our chart of Troubleshooting Tips rst, you may not need to call for
service at all.

6
SAFETY PRECAUTIONS
To prevent injury to the user or other people and property damage, the following instructions must
be followed. Incorrect operation due to ignoring of instructions may cause harm or damage.
■ The seriousness is classied by the following indications.
■ Meanings of symbols used in this manual are as shown below.
WARNING This symbol indicates the possibility of death or serious injury.
CAUTION This symbol indicates the possibility of injury or damage to property.
Never do this.
Always do this.
WARNING
CAUTION
Do not exceed the rating of the
power outlet or connection device. Do not operate or stop the unit by
switching on or off the power. Do not damage or use an unspec-
ied power cord.
• Otherwise, it may cause electric
shock or re due to excess heat
generation.
• It may cause electric shock or re
due to heat generation. • It may cause electric shock or re
Do not modify power cord length
or share the outlet with other
appliances
Do not insert or pull out plug with
wet hands. Do not place the unit near a heat
source.
• It may cause electric shock or re
due to heat generation. • It may cause electric shock. • Plastic parts may melt and cause a
re.
Disconnect the power if strange
sounds, smell, or smoke comes
from it.
You should never try to take apart
or repair the unit by yourself. Before cleaning, turn off the pow-
er and unplug the unit.
• It may cause re and electric shock. • It may cause failure of machine or
electric shock. • It may cause electrical shock or
injury.
Do not use the machine near am-
mable gas or combustibles, such
as gasoline, benzene, thinner, etc.
Do not drink or use the water
drained from the unit. Do not take the water bucket out
during operation.
• It may cause an explosion or re. • It contains contaminants and could
make you sick. • It may cause bucket full protect of
the unit and cause electric shock.
Do not use the unit in small
spaces. Do not put in places where water
may splash onto the unit. Place the unit on a level, sturdy
section of the oor.
• Lack of ventilation can cause over-
heating and re. • Water may enter the unit and de-
grade the insulation. It may cause an
electric shock or re.
• If the unit falls over, it may cause wa-
ter to spill and damage belongings,
or cause electrical shock or re.

7
SAFETY PRECAUTIONS
CAUTION
Do not cover the intake or exhaust
openings with cloths or towels. Care should be taken when using
the unit in a room with the follow-
ing persons:
Do not use in areas where chemi-
cals are handled.
• A lack of air ow can lead to over-
heating and re. • Infants, children, elderly people, and
people not sensitive to humidity. • This will cause the unit deteriora-
tion due to chemicals and solvents
dissolved in the air.
Never insert your nger or other
foreign objects into grills or
openings. Take special care to
warn children of these dangers.
appliances
Do not place heavy object on the
power cord and take care so that
the cord is not compressed.
Do not climb up on or sit on the
unit.
• It may cause electric shock or
failure of appliance. • There is danger of re or electric
shock. • You may be injured if you fall or if the
unit falls over.
Always insert the lters securely.
Clean lter once every two weeks. If water enters the unit, turn |Q the
unit off and disconnect the power,
contact a qualied service techni-
cian.
Do not place ower vases or
other water container on top of
the unit.
• Operation without lters may cause
failure. • It may cause failure of appliance or
accident. • Water may spill inside the unit, caus-
ing insulation failure and electrical
shock or re.
!CAUTION
• This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall
not be made by children without supervision. (be applicable for the European Countries )
• This appliance is not intended for use by persons (including children) with reduced physical
,sensory or mental capabilities or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance. (be applicable
for other countries except the European Countries )
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or simi-
larly qualied persons in order to avoid a hazard.
• The appliance shall be installed in accordance with national wiring regulations.
• The appliance with electric heater shall have at least 1 meter space to the combustible materials.
• Contact the authorised service technician for repair or maintenance of this unit.
• Do not use the socket if it is loose or damaged.
• Do not operate your air conditioner in a wet room such as a bathroom or laundry room.
• Do not use this product for functions other than those described in this instruction manual
• Contact the authorised installer for installation of this unit.
• If the air conditioner is knocked over during use, turn off the unit and unplug it from the main
power supply immediately. Visually inspect the unit to ensure there is no damage. If you suspect
the unit has been damaged, contact a technician or customer service for assistance.
• In a thunderstorm, the power must be cut off to avoid damage to the machine due to lightning.
• To reduce the risk of re or electric shock, do not use this fan with any solid-state speed control
device.

8
• Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar cover-
ings. Do not route cord under furniture or appliances. Arrange cord away from trafc area and
where it will not be tripped over.
• Do not open the unit during operation.
• When the air lter is to be removed, do not touch the metal parts of the unit.
• Hold the plug by the head of the power plug when taking it out.
Electrical Information
• The manufactures nameplate is located on the rear panel of the unit and contains electrical and
other technical data specic to this unit.
• Be sure the unit is properly grounded. To minimize shock and re hazards, proper grounding is
important. The power cord is equipped with a three-prong grounding plug for protection against
shock hazards.
• Your unit must be used in a properly grounded wall receptacle. If the wall receptacle you intend
to use is not adequately grounded or protected by a time delay fuse or circuit breaker(the fuse or
circuit breaker needed is determined by the maximum current of the unit. The maximum current is
indicated on the nameplate located on unit), have a qualied electrician install the proper recepta-
cle.
• Ensure the receptacle is accessible after the unit installation.
• Do not use extension cords or an adapter plugs with this unit. However, if it is necessary to use
an extension cord, use an approved Dehumidier extension cord only (available at most local
hardware stores).
• To avoid the possibility of personal injury, always disconnect the power supply to the unit, before
installing and/or servicing.
• All wiring must be performed strictly in accordance with the wiring diagram located on the middle
bafe of the unit (behind the water bucket).
Take note the fuse specications
The unit s circuit board (PCB) is designed with a fuse to provide overcurrent protection. The speci-
cations of the fuse are printed on the circuit board, such as: T 3.15A/250V (or 350V), etc.
NOTE: All the pictures in the manual are for explanation purposes only. The actual shape of the
unit you purchased may be slightly different, but the operations and functions are the same.
Note About Fluorinated Gasses
-Fluorinated greenhouse gases are contained in hermetically sealed equipment. For specic infor-
mation on the type, the amount and the CO2 equivalent in tonnes of the uorinated greenhouse
gas (on some models), please refer to the relevant label on the unit itself.
-Installation, service, maintenance and repair of this unit must be performed by a certied techni-
cian.
-Product uninstallation and recycling must be performed by a certied technician.
SAFETY PRECAUTIONS

9
!
WARNINGS (for using R290/R32 refrigerant only)
-Do not use any other means other than the recommended to expedite the defrosting process or to
perform a cleaning of the unit, other than those recommended by the manufacturer.
- This device should never be stored in an area in combination with other ignition sources (for
example: a gas appliance an electrical heater, open ames etc.)
- Do not attempt to penetrate the unit with a tool or try to burn
- Be extra cautious as refrigerant gas may be odorless.
-Appliance should be installed, operated and stored in a room with a oor area larger than 4m2.
- It is necessary to always comply with national gas regulations.
- Keep air ventilation clear of any obstructions
- The unit should be placed in storage in such a manner as to prevent any mechanical damage
from occurring.
- Always operate this unit in a well-ventilated area, where the room size corresponds to the
specications of the device for optimal performance.
-Any persons involved with the operation and handling of the refrigerant circuit of this unit, should
be certied by the related accredited industry, and authorized as competent to handle refrigerants,
safely, and in accordance to the safety standards of the industry.
- Servicing should be performed only by a certied technician as per the Mnaufacturers
reccomendations. Any maintenance or repair required, should be performed by skilled personnel
who are competent in the use of ammable refrigerants.
IMPORTANT NOTE: Please read this manual carefully
prior to installing and operating your device! It is
recommended to keep this manual for future reference.
Caution: Risk of re/ ammable
materials (Required for R32/
R290 units only)
Description of displayed Symbols (*Only applicable to units with R32/R290 Refrigerant)
WARNING This symbol indicates the use of a ammable refrigerant. If any leakage
occurs, or if exposed to an external ignition source, a re risk is possible.
CAUTION This symbol indicates that the user’s manual should be read carefully.
CAUTION This symbol indicates that a professional service technician should
handle this unit with reference to the user’s manual
CAUTION This symbol indicates the presence of a user’s or installation manual
SAFETY PRECAUTIONS

10
!Warnings (for using R290/R32 refrigerant only)
1. Transport of equipment containing ammable refrigerants
Determined by local regulations.
2.Marking of equipment using signs
See local regulations
3. Discarded appliances supplies ammable refrigerants
See National Regulations.
4. Storage of equipment/appliances
The storage of equipment should be in accordance with the manufacturer’s instructions.
5. Storage of packed (unsold) equipment
Storage package protection should be constructed such that mechanical damage to the
equipment inside the package will not cause a leak of the refrigerant charge.
The maximum number of pieces of equipment permitted to be stored together will be determined
by local regulations.
6.Information on servicing
1. Checks to the area
Prior to beginning work on systems containing ammable refrigerants, safety checks are
necessary to ensure that the risk of ignition is minimized. For repair to the refrigerating system,
the following precautions shall be complied with prior to conducting work in the system.
2. Work procedure
Work shall be undertaken under a controlled procedure so as to minimize the risk of a ammable
gas or vapor being present while the work is being performed.
3. General work area
All maintenance staff and others working in the local area shall be instructed on the nature
of work being carried out. Work in conned spaces shall be avoided. The area around the
workspace shall be sectioned off. Ensure that the conditions within the area have been made
safe by control of ammable material.
4. Checking for presence of refrigerant
The area shall be checked with an appropriate refrigerant detector prior to and during work,
to ensure the technician is aware of potentially ammable atmospheres. Ensure that the leak
detection equipment being used is suitable for use with ammable refrigerants, i.e. nonspeaking,
adequately sealed or intrinsically safe.
5. Presence of re extinguisher
If any work is to be conducted on the refrigeration equipment or amy associated parts,
appropriate re extinguishing equipment shall be available to hand. Have a dry powder or CO2
re extinguisher adjacent to the charging area.
6. No ignition sources
No person carrying out work in relation to a refrigeration system which involves exposing any
pipe work that contains or has contained ammable refrigerant shall use any sources of ignition
in such a manner that it may lead to the risk of re or explosion. All possible ignition sources,
including cigarette smoking, should be kept sufciently far away from the site of installation,
repairing, removing and disposal, during which ammable refrigerant can possibly be released
to the surrounding space. Prior to work taking place, the area around the equipment is to be
SAFETY PRECAUTIONS

11
surveyed to make sure that there are no ammable hazards or ignition risks.”No Smoking” signs
shall be displayed.
7. Ventilated area
Ensure that the area is in the open or that it is adequately ventilated before breaking into the
system or conducting any hot work. A degree of ventilation shall continue during the period
that the work is carried out. The ventilation should safely disperse any released refrigerant and
preferably expel it externally into the atmosphere.
8. Checks to the refrigeration equipment
Where electrical components are being changed, they shall be t for the purpose and to the
correct specication. At all times the manufacturer’s maintenance and service guidelines shall be
followed. If in doubt consult the manufacturer’s technical department for assistance.
The following check shall be applied to installations using ammable refrigerants:
--the charge size is in accordance with the room size within which the refrigerant containing parts
are installed;
--the ventilation machinery and outlets are operating adequately and are not obstructed;
9. Checks to electrical devices
Repair and maintenance to electrical components shall include initial safety checks and
component inspection procedures. If a fault exists that could compromise safety, then no
electrical supply shall be connected to the circuit until it is satisfactorily dealt with. If the fault
cannot be corrected immediately but it is necessary to continue operation, an adequate
temporary solution shall be used . This shall be reported to the owner of the equipment so all
parties are advised.
Initial safety checks shall include:
--that capacitors are discharged; this shall be done in a safe manner to avoid possibility of
sparking;
--that there no live electrical components and wring are exposed while charging, recovering or
purging the system;
--that there is continuity of earth bonding.
7. Repairs to sealed components
During repairs to sealed components, all electrical supplies shall be disconnected from the
equipment being worked upon prior to any removal of sealed covers, etc. If it is absolutely
necessary to have an electrical supply to equipment during servicing, then a permanently
operating form of leak detection shall be located at the most critical point to warn of a potentially
hazardous situation.
Particular attention shall be paid to the following to ensure that by working in electrical
components, the casing is not altered in such a way that level of protection is affected. This
shall include damage to cables, excessive numble of connection, terminals not made to original
specication, damage to seals, incorrect tting of glands, etc.
Ensure that seals or sealing materials have not degraded such that they no longer serve the
purpose of preventing the ingress of ammable atmospheres. Replacement parts shall be in
accordance with the manufacturer’s specications,
NOTE The use of silicon sealant may inhibit the effectiveness of some types of leak detection
equipment. Intrinsically safe components do not have to be isolated prior to working on them.
8. Repair to intrinsically safe components
Do not apply any permanent inductive or capacitance loads to the circuit without ensuring that
this will not exceed the permissible voltage and current permitted for the equipment in use.
9. Cabling
Check that cabling will not be subject to wear, corrosion, excessive pressure, vibration, sharp
SAFETY PRECAUTIONS

12
edges or any other adverse environmental effects. The check shall also take into account the
effects of aging or continual leaks. A halide torch (or any other detector using a naked ame) shall
not be used
10. Detection of ammable refrigerants
Under no circumstances shall potential sources of ignition be used in the searching for or
detection of refrigerant leaks. A halide torch (or any other detector using a naked ame) shall not
be used.
11. Leak detection methods
The following leak detection methods are deemed acceptable for systems containing ammable
refrigerants.
Electronic leak detectors shall be used to detect ammable refrigerants, but the sensitivity
may not be adequate, or may need re-calibrated.(Detection equipment shall be calibrated in a
refrigerant-free area.) Ensure that the detector is not a potential source of ignition and is suitable
for the refrigerant used. Leak detection equipment shall be set at a percentage of the LFL of the
refrigerant and shall be calibrated to the refrigerant employed and the appropriate percentage of
gas(25% maximum )is conrmed .
Leak detection uids are suitable for use with most refrigerants but the use of detergents
containing chlorine shall be avoided as the chlorine shall be avoided as the chlorine may react
with the refrigerant and corrode the copper pipe work.
If a leak is suspected, all naked ames shall be removed/extinguished.
If a leakage of refrigerant is found which requires brazing, all of the refrigerant shall be recovered
from the system, or isolated (by means of shut off valves) in a part of the system both before and
during the brazing process.
12. Removal and evacuation
When breaking into the refrigerant circuit to make repairs- or for any other purpose – conventional
procedures shall be used. However, it is important that best practice is followed since ammability
is a consideration. The following procedure shall be adhered to:
remove refrigerant;
purge the circuit with inert gas;
evacuate;
purge again with inert gas;
open the circuit by cutting or brazing;
The refrigerant charge shall be recovered into the correct recovery cylinders. The system shall be
“ushed’ with OFN to render the unit safe. This process may need to be repeated several times.
Compressed air or oxygen shall not be used for this task.
Flushing shall be achieved by breaking the vacuum in the system with OFN and continuing to ll
until the working pressure is achieved, then venting to atmosphere, and nally pulling down to
a vacuum. This processing shall be repeated until no refrigerant is within the system. When the
nal OFN charge is used, the system shall be vented down to atmospheric pressure to enable
work to take place. This operation is absolutely vital if brazing operations on the pipe-work are to
take place. Ensure that the outlet for the vacuum pump is not close to any ignition sources and
there is ventilation available.
13. Charging procedures
In addition to conventional charging procedures, the following requirements shall be followed.
-Ensure that contamination of different refrigerants does not occur when using charging
equipment. Hoses or lines shall be as short as possible to minimize the amount of refrigerant
contained in them.
-Cylinders shall be kept upright.
-Ensure that the refrigeration system is earthed prior to charging the system with refrigerant.
-label the system when charging is complete (if not already)
SAFETY PRECAUTIONS

13
-Extreme care shall be taken not to overll the refrigeration system.
Prior to recharging the system is shall be pressure tested with OFN. The system shall be leak
tested on completion of charging but prior to commissioning. A follow up leak test shall be carried
out prior to leaving the site.
14. Decommissioning
Before carrying out this procedure, it is essential that the technician is completely familiar with the
equipment and all its detail. It is recommended good practice that all refrigerants are recovered
safely. Prior to the task being carried out, an oil and refrigerant sample shall be taken is case
analysis is required prior to re-use of reclaimed refrigerant. It is essential that electrical power is
available before the task is commenced.
a) become familiar with the equipment and its operation.
b) Isolate system electrically.
c) Before attempting the procedure ensure that;
Mechanical handling equipment is available and being used correctly; the recovery process is
supervised at all times by a competent person; recovery equipment and cylinders conform to the
appropriate standards.
d) Pump down refrigerant system, if possible.
e) If a vacuum is not possible , make a manifold so that refrigerant can be removed from various
parts of the system.
f) Make sure that cylinder is situated on the scales before recovery takes place.
g) Start the recovery machine and operate in accordance with manufacturer’s instructions.
h) Do not overll cylinders. (No more than 80% volume liquid charge).
i) Do not exceed the maximum working pressure of the cylinder, even temporarily.
j) When the cylinders have been lled correctly and the process completed, make sure that
the cylinders and the equipment are removed from site promptly and all isolation valves on the
equipment are closed off.
k) Recovered refrigerant shall not be charged into another refrigeration system unless it has
been cleaned and checked.
15. Labeling
Equipment shall be labeled stating that it has been de-commissioned and emptied of refrigerant.
The label shall be dated and signed. Ensure that there are labels on the equipment stating the
equipment contains ammable refrigerant.
16. Recovery
When removing refrigerant from a system, either for servicing or decommissioning, it is
recommended good practice that all refrigerant into cylinders, ensure that only appropriate
refrigerant recovery cylinders are employed. Ensure that the correct number of cylinders for
holding the total system charge are available. All cylinders to be used are designated for the
recovered refrigerant and labeled for that refrigerant(i.e special cylinders for the recovery of
refrigerant). Cylinders shall be complete with pressure relief valve and associated shut-off valves
in good working order. Empty recovery cylinders are evacuated and , if possible, cooled before
recovery occurs.
The recovery equipment shall be in good working order with a set with a set of instructions
concerning the equipment that is at hand and shall be suitable for the recovery of ammable
refrigerants.
In addition, a set of calibrated weighing scales shall be available and in good working order.
Hoses shall be complete with leak-free disconnect couplings and good condition. Before using
the recovery machine, check that it is in satisfactory working order, has been properly maintained
and that any associated electrical components are sealed to prevent ignition in the event of a
refrigerant release. Consult manufacturer of in doubt.
The recovered refrigerant shall be returned to the refrigerant supplier in the correct recovery
SAFETY PRECAUTIONS

14
cylinder, and the relevant Waste Transfer Note arranged. Do not mix refrigerants in recovery units
and especially not in cylinders.
If compressors or compressor oils are to be removed, ensure that they have been evacuated
to an acceptable level to make certain that ammable refrigerant does not remain within the
lubricant. The evacuation process shall be carried out prior to returning the compressor to the
suppliers. Only electric heating to the compressor body shall be employed to accelerate this
process. When oil drained form a system, it shall be carried out safely.
SAFETY PRECAUTIONS

15
Indicator lights
➊ Bucket full indicator light
➋ Auto defrost indicator light
•
When auto defrost is operation on,the
indicator light illumunates.
•
The indicator light fashes at 0.5Hz under
refrigerant leakage detetcton.
•
The indicator light fashes at 5Hz under
room temperature sensor error.
•
The indicator light fashes at 5Hz under
evaporator temperature sensor error.
NOTE: If the auto defrost indicator light
ashes, unplug the unit and plug it back in.
If error repeats, call for service.
➌ Continuous operation on indicator light
➍ 40% humidity level setted mode operation
on indicator light
➎
50% humidity level setted mode operation
on indicator light
➏ 60% humidity level setted mode operation
on indicator light
Control pads
➐ Mode Pad
Press to select the operation mode:
continuously dehumidication➝40%
humidity level➝ 50% humidity level
➝60% humidity level➝continuously
dehumidication.
➑ POWER Pad
Press to turn the dehumidier on and off.
The control panel of the dehumidier you purchased may be look like one of the following:
123 54 6 7
8
CONTROL PADS ON THE DEHUMIDIFIER

16
IDENTIFICATION OF PARTS
Other features
Bucket Full Light
Glows when the bucket is ready to be
emptied, or when the bucket is removed
or not replaced in the proper position.
Auto Shut Off
The water level control switch shuts off the
dehumidier when the bucket is full, or when
the bucket is removed or not replaced in the
proper position. When the set humidity level
is reached, the unit will be shut off automati-
cally.
Wait 3 minutes before resuming operation
After the unit has stopped, it will not restart
operation for three minutes. This is to protect
the unit.
Operation will automatically start after 3
minutes.
Auto Defrost
When frost builds up on the evaporator coils,
the compressor will cycle off and the fan will
continue to run until the frost disappears.
Auto-Restart
If the unit turns off unexpectedly due to a
power outage, it will restart with the previous-
ly set functions automatically when the power
resumes.
Identication of parts
➊Control panel
➋Air intake grille
➌Water bucket
➍Air lter (behind the air intake grille)
➎Handle
➏Air Outlet grille
➐Power cord band (Used only when storing
the unit.)
➑Drain hose outlet (see page 7)
➒Power Cord
➓Power Plug
NOTE: All the pictures in the manual are for
explanation purposes only.Your unit may be
slightly different. The actual shape of the unit
you purchased may be slightly different, but
the operations and functions are the same.
Front
Rear
Fig. 1
Fig. 2

17
Air outlet grille
Air intake
grille
20cm or more
20cm or more 20cm or more
20cm or more
40cm or
more
Positioning the unit
A dehumidier operating in a basement will have
little or no effect in drying an adjacent enclosed
storage area, such as a closet, unless there is ade-
quate circulation of air in and out of the area.
• Do not use outdoors.
• This dehumidifer is intended for indoor residential
applications only. This dehumidier should not be
used for commercial or industrial applications.
• Place the dehumidier on a smooth, level oor
strong enough to support the unit with a full bucket
of water.
• Allow at least 20cm of air space on all sides of the
unit for good air circulation.
• Place the unit in an area where the temperature
will not fall below 5°C(41°F). The coils can be-
come covered with frost at temperatures below
5<t(41°F), which may reduce performance.
• Place the unit away from the clothes dryer, heater
or radiator.
• Use the unit to prevent moisture damage any-
where books or valuables are stored.
• Use the dehumidier in a basement to help pre-
vent moisture damage.
• The dehumidier must be operated in an enclosed
area to be most effective.
• Close all doors, windows and other outside open-
ings to the room.
When using the unit
• When rst using the dehumidier, operate the unit continuously 24 hours.
• This unit is designed to operate with a working environment between 5°C/41°F and 32°C/90°F
and between 30%(RH) and 80%(RH).
• If the unit has been switched off and needs to be switched on again quickly, allow approximately
three minutes for the correct operation to resume.
• Do not connect the dehumidier to a multiple socket outlet, which is also being used for other
electrical appliances.
• Select a suitable location, making sure you have easy access to an electrical outlet.
• Plug the unit into a 115V~ 60Hz/220~240V 50Hz (Refer to the nameplate located on the side/
rear of the unit) electrical socket-outlet with earth connection.
• Make sure the Water bucket is correctly tted otherwise the unit will not operate properly.
NOTE:When the water in the bucket reaches to a certain level,please be careful to move the
machine to avoid it falling down.
OPERATING THE UNIT
Casters (Install at four points on the
bottom of unit)
• Casters can move freely.
• Do not force casters to move over
carpet, nor move the unit with water
in the bucket. (The unit may tip over
and spill water)
NOTE:Casters is optional,some
models without.
Fig. 4

18
OPERATING THE UNIT
Removing the collected water
There are two ways to remove collected water.
1. Use the bucket
• When the bucket is full, the unit will automatically
stop running, and the Full indicator light will ash.
• Slowly pull out the bucket. Grip the left and right
handles securely, and carefully pull out straight so
the water does not spill. Do not put the bucket on
the oor because the bottomof the bucket is uneven.
Doing so will cause the bucket to fall and the water to
spill.
• Throw away the water from the water outlet (See
Fig.7) and replace the bucket. The bucket must be
in place and securely seated for the dehumidier to
operate.
• The machine will re-start when the bucket is re-
stored in its correct position.
NOTES: When you remove the bucket, do not touch
any parts inside of the unit. Doing so may damage
the product. Be sure to push the bucket gently all the
way into the unit. Banging the bucket against any-
thing or failing to push it in securely may cause the
unit not to operate. When you remove the bucket,if
there is some water in the unit you must dry it .
1. Pull out the bucket a little.
Cut the cover down
2. Hold both sides of the bucket with even
strength, and pull it out fromthe unit.
Fig. 5
Fig. 6
3. Pour the water out.
Fig. 7

19
OPERATING THE UNIT
Remove the
rubber plug
Insert the
water hose
from the
drain outlet
Do not block water ow by a rise.
Do not block water ow by a retortion.
Fig. 8
Fig. 9a
Fig. 9b
2. Continuous draining
• Water can be automatically emptied into a oor drain by
attaching the unit with a water hose
(Φ16.5*13.5mm) (not included).
• Remove the rubber plug fromthe back of the unit and
store it in a safe location.
• Insert the water hose into the unit from the drain outlet in
the back of the unit as shown in Fig.8. Attach the water
hose to the drain hose outlet of the unit. Make sure the
connection of the water hose and the drain hose outlet
of the unit is tight and does not let the water leak.
• Then lead the water hose to the oor drain or a suitable
drainage facility.The drainage facilify should be lower
than the drain outlet of the unit.
• Be sure to run the water hose sloping downward al-
lowing the water to ow out smoothly. Do not install the
water hose as shown in Fig.9a and Fig.9b.
• When you remove the bucket,if there is some water
inthe unit you must dry it.
NOTE: When the continuous drain feature is not being
used, remove the drain hose fromthe outlet and attach
the rubber plug back into the drain outlet.

20
CARE AND MAINTENANCE
Care and cleaning of the dehumidier
Turn the dehumidier off and remove the plug from
the wall outlet before cleaning.
1. Clean the Grille and Case
• Use water and a mild detergent. Do not use bleach or
abrasives.
• Do not splash water directly onto the main unit. Doing
so may cause an electrical shock, cause the insulation
to deteriorate, or cause the unit to rust.
• The air intake and outlet grilles get soiled easily, so use
a vacuum attachment or brush to clean.
2. Clean the bucket
Every few weeks, clean the bucket to prevent growth
of mold, mildew and bacteria. Partially ll the bucket
with clean water and add a little mild detergent. Swish
it around in the bucket, empty and rinse.
NOTE: Do not use a dishwasher to clean the bucket.
After clean, the bucket must be in place and securely
seated for the dehumidier to operate.
3. Clean the air lter
The air lter behind the front grille should be checked
and cleaned at least every 30 days or more often if
necessary.
NOTE: DO NOT RINSE OR PUT THE FILTER IN AN
AUTOMATIC DISHWASHER.
To remove:
• Pull the water bucket out as shown in Fig.10.
• Grip the tab on the lter and press them in slightly
• to take them out fromthe lter holder, then pull out
• the lter downward.(see Fig.11~13).
• Clean the lter with warm, soapy water. Rinse and
• let the lter dry before replacing it. Do not clean the
• lter in a dishwasher.
To attach:
• Insert the lter into the unit,then press the tab in on
• the lter slightly and push the lter upward.(See
• Fig.14 and Fig.15).
CAUTION:
DO NOT operate the dehumidier without a lter
because dirt and lint will clog it and reduce performance.
Grip the tab
on the lter
and press
them in.
Pull out the lter
downward.
Press the tab
in and push
the lter upward.
Tab
Insert the lter.
Fig. 10
Fig. 12
Fig. 14
Fig. 11
Fig. 13
Fig. 15
Table of contents
Languages:
Other Nobu Dehumidifier manuals
Popular Dehumidifier manuals by other brands

REMKO
REMKO SLE 45 Operating and installation instructions

Daitsu
Daitsu ADD-10 operating instructions

Aerial
Aerial ASE 200 user manual

CUOGHI
CUOGHI Nader Yard Pro Series manual

Quest Engineering
Quest Engineering 506 Installation, operation and maintenance instructions

Seaira Global
Seaira Global WatchDog NXT120 Installation and operation manual
