Noirot Spot Plus 7358-3T Product guide
Safety Read the Installation and User Guide(*), especially the
safety instructions below.
WARNING - Certain parts of
this product may become very
hot and may cause burns.
Pay extra attention to small
children and vulnerable people
when they are around the heater.
-
This heater may be used by children aged 8 and over and
by persons with reduced physical, sensory or mental capacity
or without any experience or knowledge providing they are
correctly supervised or they have been given instructions
on how to use the heater safely and they clearly understand
the potential hazards. Children must not play with the heater.
Unless supervised, children must not perform user cleaning
and maintenance.
-
Ensure children aged under 3 are kept at a safe distance
unless they are under constant supervision.
-
Children aged between 3 and 8 may only turn the heater on or
off providing it has been placed or installed in the normal position
for its operation and providing they are under supervision or
they have been given instructions on how to use the heater
safely and clearly understand the potential hazards.
-
Children aged between 3 and 8 must not plug in, change the
heater settings, clean or perform any user maintenance on the
heater.
-
Do not insert anything into the heater.
-
The heater may only be connected by a qualified person after
the power has been switched off.
2 www.noirot.com.au
Attention surface
tres chaude.
Caution, very hot
surface
-
The heater risks
overheating if it is
covered. The following
logo reminds users of this risk.
-
It is therefore strictly forbidden to cover or block the air intakes
or outlets at the risk of causing an accident or damaging the
heater.
-
All service operations must be performed by a qualified and
authorised person after the power has been switched off.
-
The installation must include an omni polar circuit breaker
with a contact opening gap of at least 3 mm.
-
The heater must not be installed underneath a power socket.
-
Comply with the minimum installation distances from floors,
walls, furniture, etc.
-
The power supply must be protected by a residual current
device of at least 30 mA, especially when installed in a room
with a bath or shower.
-
When installing the heater in bathrooms, it must comply
with local regulations.
-
If the power supply cable is damaged, it must be replaced by
the manufacturer, its after-sales service or a person with similar
qualifications in order to prevent any potential hazards.
-
Avoid installing the heater in a draught which may otherwise
affect its thermostat control.
-
This direct electric heater is designed for ambient heating of
residential type rooms, or similar, in new or existing, single and
multi-unit dwellings.
-
Do not use this heater in the immediate surroundings of a
bath, a shower or a swimming pool.
(*) These instructions were correct at the time of the heater's manufacture
and comply with the standards applicable as at that date.
The company reserves the right to modify the Installation and User Guide
at any time in order to take into account any new standards or changes to
existing standards.
www.noirot.com.au 3
IMPORTANT : NE PAS COUVRIR
IMPORTANT : DO NOT COVER
Press to turn the heater ON or return it
to STANDBYMode
The MODEbutton enables the heater to operate in the following 3 modes
(shown by the different symbols along the bottom of the display:
THE MR190 DIGITAL CONTROLLER
On/Standby: Press to turn the heater ON or return it to STANDBY Mode
Mode Selector: The MODE button enables the heater to operate in the following 3 modes
(shown by the different symbols along the bottom of the display:
Mode
Display
Description
TIMER
Heater operates only during heating
periods
COMFORT
Heater operates continuously at the set
temperature
FROST-PROTECTION
Heater operates continuously at 7°C
(frost-protection)
MANUAL HEATER OPERATION
Ensure your heater is correctly installed or mounted on castors, plugged in and turned on
at the power point on.
Press
to turn the heater ON and ensure the mode is set to COMFORT.
Use the + and - buttons to set the required room temperature. The temperature is
increased or decreased in 0.5°C increments and ranges from 7°C to a maximum of 27°C.
The symbol on the display indicates that the element is energised. Once the room
temperature has stabilised, the heating element will cycle on and off to maintain the room
temperature.
Press to return the heater to STANDBY mode
SETTING THE TIME
Press the button.
Prog
Press the OK button for 3 seconds to enter the programming mode
The Day will now be blinking
Prog
Press the OK button again, this time for 3 seconds to enter the time setting mode
The Hour will now be flashing
www.noirot.com.au
Program
Decrease
Mode Selector
Increase
On/Standby
7
Use the + and - buttons to set the current hour, then press
The Minutes will now be flashing .
Use the + and - buttons to set the current hour, then press
Prog
OK to confirm.
Prog
OK to confirm.
The Day will now be flashing.
Set the current day (i.e. 1 for Monday, 2 for Tuesday, etc.), then press
The time and day are now set.
Prog
OK
Prog
to confirm.
To display the current time during normal operation, briefly press the
will be displayed for 3 seconds.
PROGRAMMING THE TIMER
OK button. The time
It is possible to set up to 3 On/Standby periods per day using the timer mode. Each day can
be programmed individually or all days can be programmed at once.
Prog
Press the OK button for 3 seconds to enter the programming mode
The Day will now be blinking
Use the + and - buttons scroll to the required day. Note that after Day 7, ‘ALL’ will be
displayed. Use this setting to program every day.
Prog
Press OK the button to confirm
Period 1 settings are now displayed
Use the + and - buttons to select the time that
you would like the heater to turn ON.
When a time is displayed a triangle appears on the
display below FROM.
Prog
Press OK the button to confirm.
Use the + button to select the time that you would like
the heater to return to STANDBY
The triangle is now displayed below TO, indicating the
time the heater is set to revert to STANDBY mode.
Prog
Press the OK button to confirm
Period 2 settings are now displayed. Repeat the above steps for Period 3 to set the times
that the heater is to turn ON and return to STANDBY.
If no more On/Standby periods are required for the day, continue to press
is again displayed.
Repeat the above steps for each day heating periods are required.
Prog
Prog
OK until the Day
To exit to programming mode press
until EXIT is displayed on the display.
Prog
OK until the DAY is displayed. Press the button +
Press the OK button to confirm to exit programming
Briefly pressing the
Prog
OK button when the heater is in AUTO Mode will display the time left
in a heating period or the lapsed time until the next heating period starts. No Pr is displayed
if no more heating periods are programmed for that day.
www.noirot.com.au
8
No. of the
period
Note: The temperature can be adjusted at any time during a heating period. Simply
press the + or - buttons to adjust the roomtemperature.
PROGRAMMING RESET
The programming can be reset to the original status Press
the button to turn the heater to STANDBY Mode.
Press once again the button for at last 15 seconds until «RST» appears on the
screen. The programming is now :
-from Day 1 to Day 5 heater ON from 06 am to 09 am and from 05 pm to 11pm.
-Day 6 and Day 7 heater ON from 08 am to 11pm.
Press the button to turn the heater ON.
CHILD LOCK
Press both the + and -buttons together until the is displayed
on the screen.
This indicates that the child lock is activated, disabling the buttons on the
keypad.
To re-activate the keypad, press both the + and - buttons together until the key
disappears
MAINTENANCE
Your Noirot Electric Panel Heater requires very little maintenance. To remove surface dust
use a soft cloth; to remove marks use a damp cloth. Never use abrasives or metal scourers
which could damage the polyester coating. It is recommended to periodically clean the
front and under carriage air vents using the soft brush on your vacuum cleaner, as dense
accumulation of dust will cause the heater to over-heat and trigger the safety thermal cut-
out switch.
SPECIFICATIONS:
Model
Power (W)
Current (A)
Height
A
B
C
7358-3T
1000
4.2
440
420
208
106
7358-5T
1500
6.3
440
580
178
201
7358-7T
2000
8.3
440
745
320
210
7358-8T
2400
10.0
440
900
405
248
Please note: Heater temperature settings will vary from house to house according
to the building type and its level of insulation. They will also vary from room to room,
depending on factors such as room orientation (facing north or south) and window sizes.
Items such as computers and lights (which generate heat) and people will also affect a
room’s temperature.
Running costs are not wholly governed by the temperature setting on the panel heater. The
same maximum power is used to reach 7° or 27°. Where the energy efficiency and economy
is obtained is in the sizing of the heater to the particular room where it is to be used. If the
heater is sized correctly, then the thermostat will cycle on & off as required to maintain your
comfort level, no matter where on the scale your comfort setting is.
www.noirot.com.au
9
-
-
-
-
-
WAR:
www.noirot.com.au
WARRANTY REGISTRATION:
IMPORTANT: To validate your product warranty, you are required to do the following:
1. Register your product online at www.noirot.com.au, click on “Product Registration”
and fill out the required fields.
2. You must also retain your receipt of purchase
WARRANTY CONDITIONS
Your Noirot Spot Plus electric panel heaters comes with a LIFETIME WARRANTY, therefore
any replacement of faulty parts or repairs of any kind must be carried out by a qualified
person and authorised by Noirot Australia Pty Ltd or their approved representative. Failure to
do so will VOID the WARRANTY.
Noirot Australia Pty. Ltd. reserve the right to reject any warranty claim deemed to be false.
Retailers must have warranty claims authorised by a representative of Noirot Australia.
If you believe your product to be faulty and under warranty you are required to do the
following:
1. Return the product, at your expense, to the place of purchase for assessment by an
authorised representative of Noirot Australia.
2. This may require leaving the product at the place of purchase.
3. If the product is deemed faulty and under warranty, the place of purchase of the
product will order a replacement heater to which Noirot Australia, at our cost, will
deliver the heater to the place of purchase.
4. The consumer will then be required, at their cost, to pick up the replacement heater
from the place of purchase.
5. If the heater is faulty but not deemed to be under warranty, an explanation will be
provided to the consumer and that the faulty heater can be picked up by the
customer from the place of purchase.
6. Castors are a bonus item and have a 6-month warranty.
Our goods come with guarantees that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and for compensation for
any other reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure does not
amount to a major failure.
If you have any queries regarding your product or its warranty please contact:
ddurd
P:
E:
1 300 664 768
oddou
421AA4278-A01
1www.noirot.com.au
Olimpia Splendid New Zealand Pty Ltd
C /
Key Service Ltd
34A Cryers Road.
East Tamaki. Manukau City Auckland.
New Zealand
P: (09) -
E: sales@limpiaplendid.co.nz
uro
ur
This manual suits for next models
3
Table of contents
Other Noirot Heater manuals
