Nokia 1616 User manual

Nokia 1616/1800 User Guide
Issue .0
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
9220214
2

Contents
Safety 3
Get started 5
Insert the SIM card
and battery 5
Remove the SIM
card 6
Charge the battery 6
Switch on and off 7
Your phone 9
Keys and parts 9
Main features 10
Calls 11
Write text 11
Message 13
Contacts 14
Multi-phonebook 15
FM Radio 16
Flashlight shortcuts
in standby mode 17
Product and safety
information 17
2Contents
English
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.

Safety
Read these simple guidelines. Not following them
may be dangerous or illegal. Read the complete user
guide for further information.
SWITCH ON SAFELY
Do not switch the device on when
wireless phone use is prohibited or when
it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your
hands free to operate the vehicle while
driving. Your first consideration while
driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to
interference, which could affect
performance.
Safety 3
English
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.

SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device
off in aircraft, near medical equipment,
fuel, chemicals, or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may install or
repair this product.
ACCESSORIES AND BATTERIES
Use only approved accessories and
batteries. Do not connect incompatible
products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it
dry.
4Safety
English
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.

Get started
Insert the SIM card and battery
This phone is intended for use with the BL-5CB
battery.
Safe removal. Always switch the device off and
disconnect the charger before removing the battery.
1 Place your finger in the recess at the bottom of
the device, and carefully lift and open the back
cover (1).
2 Lift the battery, and remove it (2).
3 Insert the SIM card (3). Ensure the contact
surface area is facing down and the bevelled
Get started 5
English
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.

corner of the SIM card is facing the bottom of the
device.
4 Replace the battery (4) and back cover (5, 6, 7).
Remove the SIM card
Press the release spring (1), and slide out the SIM
card (2).
Charge the battery
Your battery has been partially charged at the
factory. If the device indicates a low charge, do the
following:
6Getstarted
English
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.

1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
3 When the device indicates a full charge,
disconnect the charger from the device, then
from the wall outlet.
Tip: To save energy, unplug the charger when the
battery is fully charged.
You do not need to charge the battery for a specific
length of time, and you can use the device while it
is charging. If the battery is completely discharged,
it may take several minutes before the charging
indicator appears on the display or before any calls
can be made.
Switch on and off
Press and hold the end key.
Get started 7
English
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010Nokia. All rights reserved.

Use the phone only in its normal operating position.
Your device may have internal and external
antennas. Avoid touching the antenna area
unnecessarily while the antenna is transmitting or
receiving. Contact with antennas affects the
communication quality and may cause a higher
power level during operation and may reduce the
battery life.
8Getstarted
English
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.

Your phone
Keys and parts
1Earpiece
2Display
3Selection keys
4Navi™ key (scroll
key)
5Call key
6End/Power key
7Keypad
8Microphone
9Flashlight
10 Headset connector (3.5mm)
11 Wrist strap eyelet
Your phone 9
English
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010Nokia. All rights reserved.

12 Charger connector
To activate the speaking clock (Nokia 1616) or FM
radio (Nokia 1800), press and hold *.
Main features
Select Menu and from the following:
Messages Create, send, and manage messages.
Contacts Save names and phone numbers.
Call
register
Access missed, received, and dialled
calls.
Settings Set up various features of your
device.
Clock Set the time for the alarm.
Radio Manage radio features.
Reminders Manage reminders.
Games Play or set up the games in your
device.
10 Your phone
English
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.

Extras Access various applications. Chinese
lunar calendar is also available.
SIM
services
Use supported SIM card services.
Calls
To make a call, enter the phone number, including
the country code and area code, if necessary, and
press the call key. To answer a call, press the call key.
To end or reject a call, press the end key.
To use a loudspeaker or earpiece during a call, select
Loudsp. or Hands.. To adjust the volume during a
call, scroll left or right.
When the volume is high, do not hold the device
near your ear.
Write text
To enter text, you can use traditional or predictive
text input. Not all languages are supported by
predictive text input.
Your phone 11
English
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010Nokia. All rights reserved.

Use traditional text input
Press a key repeatedly until the desired letter is
displayed.
Activate predictive text input
Select Options > Dictionary and the desired
language.
Deactivate predictive text input
Select Options > Dictionary > Dictionary off.
When using predictive text input, press each key
once for a single letter. If the desired word is
displayed, press 0, and start writing the next word.
If ? is displayed after the word, the word is not in
the dictionary.
Change a word
Press *repeatedly until the desired word is
displayed.
Add a word
Select Spell, enter the word using traditional text
input, and select OK.
12 Your phone
English
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.

Add a space
Press 0.
Change text input method
Press #repeatedly, and check the indicator at the
top of the display.
Add a number
Press and hold the desired number key.
Add a special character
Press *when using traditional text input; press and
hold *when using predictive text input.
Undo clearing of a message
Select Options > Undo clear.
Message
The message services can only be used if they are
supported by your service provider.
Your device supports text messages beyond the limit
for a single message. Longer messages are sent as
two or more messages. Your service provider may
Your phone 13
English
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010Nokia. All rights reserved.

charge accordingly. Characters with accents, other
marks, or some language options take more space,
and limit the number of characters that can be sent
in a single message.
Write and send a message
1 Select Menu > Messages > Create message.
2 Write the message. The message length
indicator shows how many characters you can
enter in the message.
3 Select Options > Send, enter the recipient's
phone number or select it from the contacts list,
and select OK.
Delete messages
Select Menu > Messages > Delete messages > All
read or the desired folder.
Contacts
You can save names and phone numbers in the
phone and SIM card memory. The contacts list can
contain up to 500 contacts, stored in the phone
memory.
14 Your phone
English
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.

Search for a contact
Scroll down in the standby mode, enter the first
characters or letters of the name, and scroll to the
desired contact.
Save contacts to the contacts list
Select Menu > Contacts > Add contact.
Copy contacts between the phone and SIM card
memory
Select Menu > Contacts > Copy.
Multi-phonebook
Your phone supports up to five separate
phonebooks for multiple users. When the multi-
phonebook is activated, only the contacts in the
active phonebook are visible.
A contact can belong to one or several phonebooks.
The contacts in Shared contacts are accessible from
all phonebooks.
Your phone 15
English
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010Nokia. All rights reserved.

Select Menu > Contacts > Settings > Multi-
Phonebook and the appropriate options.
Activate the multi-phonebook
Select Phonebook style > Multi-Phonebook.
Activate a phonebook
Select Current phonebook and the desired
phonebook or Shared contacts.
Assign a contact to one or more phonebooks
Select Manage contacts and the desired contact.
Rename a phonebook
Select Rename phonebooks and the desired
phonebook.
FM Radio
The FM radio depends on an antenna other than the
wireless device antenna. A compatible headset
needs to be attached to the device for the FM radio
to function properly. You may need to purchase a
compatible headset separately.
16 Your phone
English
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.

To open the radio, select Menu > Radio. To adjust
the volume of the radio, scroll left or right.
You need at least one saved channel for the clock
radio to function properly.
Warning:
Continuous exposure to high volume may damage
your hearing. Listen to music at a moderate level,
and do not hold the device near your ear when the
loudspeaker is in use.
Flashlight shortcuts in standby mode
To switch on, scroll up twice. To switch off, scroll up
once.
Do not shine the flashlight in anyone's eyes.
Product and safety information
General information
About your device
The wireless device described in this guide is approved for use on the EGSM
900 and 1800 MHz networks. Contact your service provider for more
information about networks.
Product and safety information 17
English
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010Nokia. All rights reserved.

Warning:
To use any features in this device, other than the alarm clock, the device
must be switched on. Do not switch the device on when wireless device use
may cause interference or danger.
When using this device, obey all laws and respect local customs, privacy and
legitimate rights of others, including copyrights. Copyright protection may
prevent some images, music, and other content from being copied,
modified, or transferred.
Make back-up copies or keep a written record of all important information
stored in your device.
When connecting to any other device, read its user guide for detailed safety
instructions. Do not connect incompatible products.
The images in this guide may differ from your device display.
Network services
To use the device you must have service from a wireless service provider.
Some features are not available on all networks; other features may require
that you make specific arrangements with your service provider to use
them. Network services involve transmission of data. Check with your
service provider for details about fees in your home network and when
roaming on other networks. Your service provider can explain what charges
will apply.
Your service provider may have requested that certain features be disabled
or not activated in your device. If so, these features will not appear on your
device menu. Your device may also have customized items such as menu
names, menu order, and icons.
18 Product and safety information
English
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.

Support
When you want to learn more about how to use your product or you are
unsure how your device should function, see the user guide or see the
support pages at www.nokia.com/support or your local Nokia website, or
with a mobile device, www.nokia.mobi/support.
If this does not resolve your issue, do the following:
•Restart the device: switch off the device, and remove the battery. After
about a minute, replace the battery, and switch on the device.
•Restore the original factory settings as explained in the user guide.
If the issue remains unsolved, contact Nokia for repair options. See
www.nokia.com.hk/repair. Before sending your device for repair, always
back up the data in your device.
Accessories
Nokia original accessories
Warning:
Use only batteries, chargers, and accessories approved by Nokia for use with
this particular model. The use of any other types may invalidate any
approval or warranty, and may be dangerous. In particular, use of
unapproved chargers or batteries may present a risk of fire, explosion,
leakage, or other hazard.
For availability of approved accessories, check with your dealer.
Product and safety information 19
English
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010Nokia. All rights reserved.

An extensive range of accessories is available for your device. For more
details, see www.nokia.com.hk.
Practical rules about accessories
•Keep all accessories out of the reach of small children.
•When you disconnect the power cord of any accessory, grasp and pull
the plug, not the cord.
•Check regularly that accessories installed in a vehicle are mountedand
are operating properly.
•Installation of any complex car accessories must be made by qualified
personnel only.
Battery
Type Talk time Standby
BL-5CB Up to
Important: Battery talk and stand-by times are estimates and only possible
under optimal network conditions. Actual battery talk and standby times
depend on SIM cards, features used, battery age and condition,
temperatures to which battery is exposed, network conditions, and many
20 Product and safety information
English
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
4 hours 10 minutes 750 hours
Up to
time
© 2010 Nokia. All rights reserved.
