Nokia 6265 Installation instructions

Nokia Customer Care
6265/6265i/6268 (RM-66)
Mobile Terminals
Issue 1 11/2005 Company Confidential ©2005 Nokia Corporation
Reassembly

6265/6265i/6268 (RM-66)
Reassembly
Page 2 ©2005 Nokia Corporation Company Confidential Issue 1 11/2005
Contents Page
Safety Information ......................................................................................................................................... 3
ESD Protection .............................................................................................................................................3
Reassembly Instructions............................................................................................................................... 4
1. Insert the DC Jack ...................................................................................................................................4
2. Insert the Camera Flash ........................................................................................................................4
3. Insert the BT Antenna ............................................................................................................................4
4. Insert the IHF Assembly ........................................................................................................................5
5. Insert the Camera Key and the Volume Key ...................................................................................5
6. Insert the LCD Flex Cable and Assembly ..........................................................................................6
7. Insert the Main Flex Assembly ............................................................................................................7
8. Add the Screws ........................................................................................................................................8
9. Camera Installation ................................................................................................................................8
10. Attach the PWB and B/C Slide Assembly ......................................................................................9
11. Add the Screws ...................................................................................................................................10
12. Connect the A-cover and the B-cover .........................................................................................10
13. Add the Camera Gasket ....................................................................................................................11
14. Attach the Antenna/E-cover ...........................................................................................................12
15. Attach the Main Keymat ..................................................................................................................12
16. Insert the Battery and Attach the Battery Cover ......................................................................13

Nokia Customer Care Reassembly
6265/6265i/6268 (RM-66)
Issue 1 11/2005 ©2005 Nokia Corporation Company Confidential Page 3
Safety Information
Adhere to the following guidelines when assembling and disassembling the phone.
•QUALIFIEDSERVICE
Only qualified personnel may install or repair phone equipment.
• ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do not connect incompatible
products.
• CONNECTING TO OTHER DEVICES
When connecting to any other device, read its user’s guide for detailed safety
instructions. Do not connect incompatible products.
ESD Protection
Nokia requires that phone repair centers have sufficient ESD protection against static
electricity when servicing cellular phones. Use the following guidelines:
• A cellular phone that is ready for use can be handled normally without ESD
protection. The battery can be replaced in normal conditions of use.
• Use ESD protection when replacing a color cover, except for the phone covers
which can be replaced by the customer.
• All electronic parts of the phone, including the display, are susceptible to ESD.
Resistors also can be damaged by static electricity discharge.
• All ESD-sensitive parts must be packed in metallized protective bags during
shipping and handling outside any ESD Protected Area (EPA).
• Every repair action involving opening the phone or handling the phone
components must be done under ESD protection.
• ESD-protected spare part packages MUST NOT be opened/closed outside an EPA.
For more detailed information about ESD protection and EPAs, contact your local Nokia
Customer Care representative.

6265/6265i/6268 (RM-66)
Reassembly
Page 4 ©2005 Nokia Corporation Company Confidential Issue 1 11/2005
Reassembly Instructions
1. Insert the DC Jack
Using a CA-44 adapter, gently press the DC-Jack into the D-cover assembly. Make sure
the adapter is not plugged into an electric source.
2. Insert the Camera Flash
Gently place the camera flash into its retainers and snap it into place using your fingers.
Make sure not to damage snap in the process.
3. Insert the BT Antenna
Using tweezers, gently place the BT antenna into the D-cover making certain the
assembly snaps into place. Note the snap located just above the vertical tab.
Caution: Do not damage the metal antenna springs.
CA-44 adaptor
Snap above vertical tab

Nokia Customer Care Reassembly
6265/6265i/6268 (RM-66)
Issue 1 11/2005 ©2005 Nokia Corporation Company Confidential Page 5
4. Insert the IHF Assembly
Grasp the IHF assembly with the inside facing you. Insert it, pushing toward the bottom
of the D-cover. Rotate and snap it into position within the D-cover assembly. Make
certain not to damage the IHF speaker gasket during assembly.
5. Insert the Camera Key and the Volume Key
a. Using tweezers, position the camera key into its mount and press it into
place.
Note: To correctly place volume key, orient the central tab closest to the UIM lid.
b. Using tweezers, gently place the volume key on its retaining pins and press
into place, with the retention tabs closest to the GPS antenna module. Be
careful not to damage the retaining pins.
Note: Notice the semi-circular indention on the top of the key.
Retaining
pin holes

6265/6265i/6268 (RM-66)
Reassembly
Page 6 ©2005 Nokia Corporation Company Confidential Issue 1 11/2005
6. Insert the LCD Flex Cable and Assembly
a. Fit the LCD display into the LCD frame, carefully aligning the mounting tabs.
Gently press into place from the back to secure.
b. Place the UI PWB into the B/C slide assembly making sure the alignment pin
is visible.
c. Hook the LCD frame over the B/C slide assembly. Snap it into place on the
bottom, making sure the alignment pin is visible.
Alignment pin
Alignment pin

Nokia Customer Care Reassembly
6265/6265i/6268 (RM-66)
Issue 1 11/2005 ©2005 Nokia Corporation Company Confidential Page 7
d. Connect the LCD to the UI PWB by pressing together.
7. Insert the Main Flex Assembly
a. With the slide assembly open, align both UI flex slots. Insert the flex through
the two slots. Place the keymat on the frame. Align and connect the flex
cable.
b. Tuck the keymat assembly under the mounting tab located just under the LCD
display and rotate it downward into position. Snap it into place.
Mounting tabs

6265/6265i/6268 (RM-66)
Reassembly
Page 8 ©2005 Nokia Corporation Company Confidential Issue 1 11/2005
8. Add the Screws
With the main flex assembly secured, fasten the four IP-4 Torx 4 Plus screws. Use torque
driver set to 11Ncm.
9. Camera Installation
Using the SS-45 camera removal tool, place the camera module into position in the
camera mount using the alignment tab. Secure the camera module into place.

Nokia Customer Care Reassembly
6265/6265i/6268 (RM-66)
Issue 1 11/2005 ©2005 Nokia Corporation Company Confidential Page 9
10. Attach the PWB and B/C Slide Assembly
a. Place the PWB into the D-cover using the alignment pins.
b. With the mobile terminal slide assembly open, align and connect the main
flex cable through the keymat hole.
c. Close the mobile terminal slide, align the assemblies and snap together.

6265/6265i/6268 (RM-66)
Reassembly
Page 10 ©2005 Nokia Corporation Company Confidential Issue 1 11/2005
11. Add the Screws
With the slide assembly open, fasten the four IP-4 Torx 4 Plus screws in the order shown
below. Use torque driver set to 15 Ncm.
12. Connect the A-cover and the B-cover
a. With the mobile terminal slide assembly open, rotate the
A-cover into position on the slide assembly and snap it into place.
b. Fasten the two IP-4 Torx 4 Plus screws using torque driver set to 11 Ncm.
1
3
2
4

Nokia Customer Care Reassembly
6265/6265i/6268 (RM-66)
Issue 1 11/2005 ©2005 Nokia Corporation Company Confidential Page 11
c. Complete the step by affixing the screw caps.
Caution: Make sure the mini-SD door is open before placement. Do not close SD
door until A-cover is screwed down.
13. Add the Camera Gasket
Gently place the camera gasket onto the camera lens barrel and press it into place.

6265/6265i/6268 (RM-66)
Reassembly
Page 12 ©2005 Nokia Corporation Company Confidential Issue 1 11/2005
14. Attach the Antenna/E-cover
Carefully align the E-cover to the D-cover assembly. Press the E-cover into place by
gently squeezing all sides to ensure a tight fit.
15. Attach the Main Keymat
a. Gently insert the left side of the keymat into the C-cover assembly, tucking it
between the cover and the keydome sheet.
b. Bend the keymat to tuck the in the other side.
c. Press down on both the upper and lower edges to secure the keymat in place.

Nokia Customer Care Reassembly
6265/6265i/6268 (RM-66)
Issue 1 11/2005 ©2005 Nokia Corporation Company Confidential Page 13
16. Insert the Battery and Attach the Battery Cover
a. Insert the battery.
a. Slide the battery cover into position and press to snap it into place.
