SUPPORT GUIDE FOR
HOW TO USE NOKIA 9210I COMMUNICATOR
AS A MODEM OVER IR CONNECTION IN
WINDOWS 2000
Copyright
©
Nokia Mobile Phones 2000. All rights reserved | Date: 04.04.02, ver. 1.0

Contents
1. INTRODUCTION ............................................................................................................1
2. SETTING UP A DIAL-UP CONNECTION FOR USE WITH THE NOKIA 9210I
COMMUNICATOR VIA CABLE IN WINDOWS 2000 ......................................................1
3. TROUBLESHOOTING....................................................................................................6
Legal Notice
Copyright © Nokia Mobile Phones 2000. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form without the
prior written permission of Nokia is prohibited.
Nokia and Nokia Connecting People are registered trademarks of Nokia Corporation. Other product and company
names mentioned herein may be trademarks or tradenames of their respective owners.
Nokia operates a policy of continuous development. Nokia reserves the right to make changes and improvements
to any of the products described in this document without prior notice.
Under no circumstances shall Nokia be responsible for any loss of data or income or any special, incidental,
consequential or indirect damages howsoever caused.
The contents of this document are provided "as is". Except as required by applicable law, no warranties of any
kind, either express or implied, including, but not limited to, the implied warranties of merchantability and fitness
for a particular purpose, are made in relation to the accuracy, reliability or contents of this document. Nokia
reserves the right to revise this document or withdraw it at any time without prior notice.

1/1
1. INTRODUCTION
The purpose of this document is help to use Nokia 9210i Communicator as a modem over IR
connection.
2. SETTING UP A DIAL-UP CONNECTION FOR USE WITH THE
NOKIA 9210I COMMUNICATOR VIA CABLE IN WINDOWS 2000
In the communicator's Fax modem settings, select Infrared.
Select Windows 2000 in Operating system. And then select Done.

2/2
Press Activate in the Fax modem main view.
Select Make New Connection in Network and Dial-up connections. Click Next in
Network Connection Wizard of Windows 2000.

3/3
Choose either Dial-up to private network or Dial-up to the Internet and click Next.
Choose Infrared Modem Port and click Next.

4/4
Type in the ISP's phone number and click Next.
Choose either For all users or Only for myself and click Next.

5/5
Name the connection and click Finnish.
Now you should be able to establish a Dial-Up connection to your ISP.

6/6
3. TROUBLESHOOTING
Note: If you have already checked all the settings and a data call is not
established, try to reboot your PC. It is also recommended that your restart your
Nokia 9210i Communicator by removing battery.
If you get an error message (Error :769) before Dial Up starts dialling.
-Check that you have activated Fax modem in Nokia 9210i Communicator
-Check that IrDA port in PC and in Nokia 9210i Communicator are face to face and there
is nothing between them.
If you get an error message (Error :651) before Dial Up starts dialling.
-Check from Device manager in PC that IrDA port is enabled
-Check from Bios settings in PC that IrDA port is enabled
If you get an error message (Error :770) after Nokia 9210i Communicator has started to dial
-If you have installed PC Suite for Nokia 9210i on you PC close the PC Suite Icon on the
taskbar. Also close the Copy Anywhere icon.
-If there is another piece of software using same Com port, close it and try again.
If you get an error message (Error: 737) after Nokia 9210i Communicator has started to dial
Data call dropped by server you were dialling or network signal is weak. Try later again.
Copyright
©
Nokia Mobile Phones 2000. All rights reserved | Date: 04.04.02, ver. 1.0
PC Suite icon Copy Anywhere icon
