Nokia X1-00 User manual

Nokia X1-00 User Guide
5555555
Issue 1
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Contents
Safety 3
Get started 5
Insert the SIM card and
battery 5
Insert or remove a
memory card 7
Charge the battery 9
Switch on or off 10
Your phone 11
Keys and parts 11
Make and answer a
call 13
Text input 14
Message 15
Contacts 16
Multi-phonebook 17
Listen to music 18
FM Radio 19
Flashlight 21
Support 21
Protect the
environment 22
Save energy 22
Recycle 23
Product and safety
information 23
Index 33
2 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Safety
Read these simple guidelines. Not following them may be
dangerous or illegal. Read the complete user guide for
further information.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when mobile phone use is
not allowed or when it may cause interference
or danger, for example, in aircraft, near medical
equipment, fuel, chemicals, or blasting areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free
to operate the vehicle while driving. Your first
consideration while driving should be road
safety.
INTERFERENCE
All wireless devices may be susceptible to
interference, which could affect performance.
QUALIFIED SERVICE
Only qualified personnel may install or repair
this product.
3
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

BATTERIES AND OTHER ACCESSORIES
Use only batteries, chargers and other
accessories approved by Nokia for use with this
device. Do not connect incompatible products.
KEEP YOUR DEVICE DRY
Your device is not water-resistant. Keep it dry.
PROTECT YOUR HEARING
Listen to a headset at a moderate level, and do
not hold the device near your ear when the
loudspeaker is in use.
4
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Get started
Insert the SIM card and battery
Important: Do not use a mini-UICC SIM card, also
known as a micro-SIM card, a micro-SIM card with an
adapter, or a SIM card that has a mini-UICC cutout (see
figure) in this device. A micro SIM card is smaller than the
standard SIM card. This device does not support the use of
micro-SIM cards and use of incompatible SIM cards may
damage the card or the device, and may corrupt data
stored on the card.
The SIM card and its contacts can be easily damaged by
scratches or bending, so be careful when handling,
inserting, or removing the card.
1 Place your finger in the recess at the bottom of the
device, and carefully lift and remove the back cover (1).
2 If the battery is inserted, lift the battery out (2).
5
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

3 Open the SIM card holder (3). Make sure the contact
area is facing down, and insert the SIM card (4). Close
the holder.
4 Line up the contacts of the battery and the battery
compartment, and insert the battery (5). To replace the
back cover, direct the top locking catches toward their
slots (6), and press down until the cover locks into
place (7).
6
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

This phone is intended for use with the BL-5J battery.
Insert or remove a memory card
Use only compatible memory cards approved by Nokia for
use with this device. Incompatible cards may damage the
card and the device and corrupt data stored on the card.
Your device supports microSD cards with a capacity of up
to 16 GB.
7
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Insert a memory card
1 Open the cover of the memory card slot.
2 Insert the memory card. Push the card in, until it locks
into place. Make sure the contact area is facing up.
3 Close the slot cover.
You can remove or replace the memory card without
switching the device off.
Remove the memory card
Important: Do not remove the memory card when
an application is using it. Doing so may damage the
memory card and the device, and corrupt data stored on
the card.
1 Open the cover of the memory card slot.
8
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

2 Push the card in gently, until it is released, and pull the
card out.
3 Close the slot cover.
Charge the battery
Your battery has been partially charged at the factory, but
you may need to recharge it before you can switch on your
device for the first time.
If the device indicates a low charge, do the following:
1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
3 When the device indicates a full charge, disconnect the
charger from the device, then from the wall outlet.
Tip: To save energy, unplug the charger when the battery
is fully charged.
9
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

You do not need to charge the battery for a specific length
of time, and you can use the device while it is charging.
If the battery is completely discharged, it may take several
minutes before the charging indicator appears on the
display or before any calls can be made.
If the battery has not been used for a long time, to begin
charging, you may need to connect the charger, then
disconnect and reconnect it.
It may take longer than expected before the device is fully
charged, due to the large capacity of the BL-5J battery.
Switch on or off
Press and hold the end key.
Use the phone only in its normal operating position.
Avoid touching the antenna area unnecessarily while the
antenna is transmitting or receiving. Contact with
10
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

antennas affects the communication quality and may
cause a higher power level during operation and may
reduce the battery life.
Your phone
Keys and parts
1End/Power key
2Earpiece
3Display
4Selection keys
5Navi™ key (scroll key)
6Call key
11
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

7Keypad
8Microphone
9Wrist strap hole
10 Music keys
12
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

11 Charger connector
12 Flashlight
13 Headset connector/Nokia AV Connector (3.5 mm)
14 Memory card slot
15 Loudspeaker
Make and answer a call
Make a call
Enter the phone number, including the country code and
area code, if necessary, and press the call key.
Answer a call
Press the call key.
End or reject a call
Press the end key.
Use the loudspeaker or earpiece
During a call, select Loudsp. or Hands..
Adjust the volume
During a call, scroll left or right to adjust the volume of the
earpiece or headset.
13
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Text input
Write text
To enter text, you can use traditional or predictive text
input. Not all languages are supported by predictive text
input.
Use traditional text input
Press a key repeatedly until the desired letter is displayed.
Activate predictive text input
Select Options > Dictionary and the desired language.
Deactivate predictive text input
Select Options > Dictionary > Dictionary off.
When using predictive text input, press each key once for
a single letter. If the desired word is displayed, press 0, and
start writing the next word. If ? is displayed after the word,
the word is not in the dictionary.
Change a word
Press *repeatedly until the desired word is displayed.
Add a word
Select Spell, enter the word using traditional text input,
and select OK.
14
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Add a space
Press 0.
Change text input method
Press #repeatedly, and check the indicator at the top of
the display.
Add a number
Press and hold the desired number key.
Add a special character
Press *when using traditional text input; press and hold
*when using predictive text input.
Clear a whole message
Select Options > Clear text.
You can undo the clearing of a whole message, but only
right after you have selected Clear text.
Undo clearing of a whole message
Select Options > Undo clear.
Message
The message services can only be used if they are
supported by your service provider.
15
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

You can send text messages that are longer than the
character limit for a single message. Longer messages are
sent as two or more messages. Your service provider may
charge accordingly.
Characters with accents, other marks, or some language
options, take more space, and limit the number of
characters that can be sent in a single message.
Write and send a message
1 Select Menu > Messages > Create message.
2 Write the message. The message length indicator
shows how many characters you can enter in the
message.
3 Select Options > Send, enter the recipient's phone
number or select it from the contacts list, and select
OK.
Delete messages
Select Menu > Messages > Delete messages > All
read or the desired folder.
Contacts
You can save names and phone numbers in the phone and
SIM card memory. The contacts list can contain up to 500
contacts, stored in the phone memory.
16
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Search for a contact
Scroll down in the standby mode, enter the first characters
or letters of the name, and scroll to the desired contact.
Save contacts to the contacts list
Select Menu > Contacts > Add contact.
Copy contacts between the phone and SIM card
memory
Select Menu > Contacts > Copy.
Multi-phonebook
Your phone supports up to five separate phonebooks for
multiple users. When the multi-phonebook is activated,
only the contacts in the active phonebook are visible.
A contact can belong to one or several phonebooks. The
contacts in Shared contacts are accessible from all
phonebooks.
Select Menu > Contacts > Settings > Multi-
Phonebook and the appropriate options.
Activate the multi-phonebook
Select Phonebook style > Multi-Phonebook.
17
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Activate a phonebook
Select Current phonebook and the desired phonebook or
Shared contacts.
Assign a contact to one or more phonebooks
Select Manage contacts and the desired contact.
Rename a phonebook
Select Rename phonebooks and the desired phonebook.
Listen to music
You can listen to your MP3 music files with the music player.
Select Menu > Music > Mp3 Music player.
To play music, you need to store the music files on a
memory card.
Start or pause playback
Press .
Skip to the previous song
Press .
Skip to the next song
Press .
18
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Change the volume
Scroll left or right.
Set the music player to play in the background
Press the end key.
Close the music player when it is playing in the
background
Press and hold the end key.
FM Radio
Listen to the radio
Enjoy your favourite FM radio stations on the go!
1 Attach a compatible headset to the device.
2 Select Menu > Music > Radio.
Change the volume
Scroll left or right.
Listen using the headset or the loudspeaker
Select Options > Loudspeaker or Options > Headset.
Close the radio
Select Options > Switch off.
19
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Set the radio to play in the background
Press the end key.
Close the radio when it is playing in the background
Press and hold the end key.
Find and save a radio station
Search for your favourite radio stations, and save them, so
you can easily listen to them later.
Select Menu > Music > Radio.
1 Select Options > Auto tuning, and scroll up or down.
2 To enter a frequency manually, select Options > Set
frequency.
3 To save the found station, select Options > Save
channel.
Rename a station
Go to the station, and select Options > Rename.
Delete a station
Go to the station, and select Options > Delete channel.
20
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
