Nokia D211 User manual

User’s Guide
Issue 2

2
© Nokia Corporation 2004. All rights reserved.
DECLARATION OF CONFORMITY
We, NOKIA CORPORATION declare under our sole responsibility that the product DTE-1 is in conformity with the provisions
of the following Council Directive: 1999/5/EC. A copy of the Declaration of Conformity can be found from
http://www.nokia.com/phones/declaration_of_conformity/
Copyright © Nokia Corporation 2002-2004. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form without the prior
written permission of Nokia is prohibited.
Nokia and Nokia Connecting People are registered trademarks of Nokia Corporation. Other product and company names
mentioned herein may be trademarks or tradenames of their respective owners.
Includes RSA BSAFE cryptographic or security protocol software from RSA Security.
Nokia operates a policy of continuous development. Nokia reserves the right to make changes and improvements to any of the
products described in this document without prior notice.
Under no circumstances shall Nokia be responsible for any loss of data or income or any special, incidental, consequential or
indirect damages howsoever caused.
The contents of this document are provided "as is". Except as required by applicable law, no warranties of any kind, either
express or implied, including, but not limited to, the implied warranties of merchantability and fitness for a particular
purpose, are made in relation to the accuracy, reliability or contents of this document. Nokia reserves the right to revise this
document or withdraw it at any time without prior notice.
The availability of particular products may vary by region. Please check with the Nokia dealer nearest to you.
Issue 2

For your safety
3
© Nokia Corporation 2004. All rights reserved.
For your safety
Read these simple guidelines. Breaking the rules may be dangerous or illegal.
Further detailed information is given in this manual.
Do not switch the radio card on when wireless equipment use is prohibited
or when it may cause interference or danger.
Road safety comes first
Don’t use the radio card while driving.
Interference
All radio cards may get interference, which could affect performance.
Switch off in hospitals
Follow any regulations or rules. Switch the radio card off near medical
equipment.
Switch off in aircraft
Wireless devices can cause interference in aircraft.
Switch off when refuelling
Don’t use the radio card at a refuelling point. Do not use near fuel or
chemicals.
Switch off near blasting
Don’t use the radio card where blasting is in progress. Observe restrictions,
and follow any regulations or rules.
Use sensibly
Use only in the normal position. Don’t touch the antenna unnecessarily.
Qualified service
Only qualified personnel may repair radio card equipment.
Accessories
Use only approved accessories. Do not connect incompatible products.
Water-resistance
Your radio card is not water-resistant. Keep it dry.
Backup copies
Remember to make backup copies of all important data.
Connecting to other devices
When connecting to any other device, read its user's guide for detailed
safety instructions. Do not connect incompatible products.

For your safety
4
© Nokia Corporation 2004. All rights reserved.
Network Services
The radio card described in this guide is approved for use on the EGSM 900 and
GSM 1800 networks.
Dualband is a network dependant feature. Check with your local service provider
if you can subscribe to and use this feature.
A number of features included in this guide are called Network Services. These are
special services that you arrange through your wireless service provider. Before
you can take advantage of any of these Network Services, you must subscribe to
them through your service provider and obtain instructions for their use from your
service provider.
Note: Some GSM networks may not support all language-dependent
characters and/or services.

Table of contents
5
© Nokia Corporation 2004. All rights reserved.
Table of contents
For your safety 3
Network Services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Introduction 7
Data and fax communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
About data transmission. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
General Packet Radio Service (GPRS). . . . . . . . . . . . . . . . . . . . . . . . . 9
High Speed Circuit Switched Data (HSCSD) . . . . . . . . . . . . . . . . . . 10
Wireless Local Area Network (WLAN) . . . . . . . . . . . . . . . . . . . . . . . 10
Antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Installation 15
Installing the Nokia D211 software . . . . . . . . . . . . . . . . . . . . . . . . . 15
Uninstalling the Nokia D211 software . . . . . . . . . . . . . . . . . . . . . . . 17
Getting started 19
Connecting to a network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Ending network connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Removing the radio card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Nokia D211 features 24
Manager and Monitor window. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Profiles page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Settings page. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Tools page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Administrator page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
WEP security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Nokia Short Messaging 46
Text messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Picture messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Contacts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Chat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Troubleshooting 53
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Table of contents
6
© Nokia Corporation 2004. All rights reserved.
Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Resources. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Care and maintenance 56
Important safety information 57
Glossary 60
Index 63

Introduction
7
© Nokia Corporation 2004. All rights reserved.
Introduction
The Nokia D211 is a multimode radio card that combines General Packet Radio
Service (GPRS), GSM high-speed data (HSCSD), and Wireless Local Area
Network (WLAN).
With the Nokia D211 you can send and receive e-mail, text messages, data and fax
files, and access the Internet. Note that with the Nokia D211 you cannot make or
receive voice calls.
The Nokia D211 operates on the GSM 900/1800 networks and IEEE 802.11b-
compliant WLANs. It plugs into compatible portable computers or other devices
with a type II or III PC card slot. The Nokia D211 is equipped with an integrated
smart card reader: Wired Equivalent Privacy (WEP) keys and personal network
profiles that make moving between networks easy, can be stored on a SIM card.
Supported operating systems are: Windows 98 Second Edition, Windows Me,
Windows 2000, and Windows XP. For other supported operating systems and
software updates, please check the Nokia Web site at www.club.nokia.com.
Important!
Warning: Do not use the radio card when the use of a wireless device is
prohibited or when it may cause interference or danger. Note that the radio
card may cause similar interference as any cellular device (e. g. mobile phone)
and must not be used in areas where the use of any such device is prohibited.
Warning: Be careful when moving your computer so that you do not cause
damage to the protruding end of the inserted radio card.
Warning: Using the Nokia D211 in some countries or regions may be illegal.
Consult local authorities on the regulations concerning the use of the
Nokia D211.
Note: Transmitted data is not encrypted by the radio card by default.
Warning: Use only accessories approved by the radio card manufacturer for
use with this particular radio card model. The use of any other types may
invalidate any approval or warranty applying to the radio card, and may be
dangerous.
For availability of approved accessories, please check with your dealer.

Introduction
8
© Nokia Corporation 2004. All rights reserved.
Data and fax communication
The Nokia D211 provides the functionality of a wireless modem. In order to be able
to connect to a remote computer, to send and receive files, e-mail and faxes, and
to access the Internet, you need to take the following points into account:
•You need the appropriate data and fax communications software installed on
your computer. You can use the Nokia D211 with a variety of commercially
available Windows 98 Second Edition, Windows Me, Windows 2000, and
Windows XP compatible data and fax communications applications, such as
Dial-Up Networking and HyperTerminal.
•The data and fax communications applications must be correctly configured
for use with the Nokia D211, according to the instructions given in the
documentation of these applications and your compatible computer.
Remember to select the Nokia D211 as the modem for each application.
•The data transfer and fax functions depend on the applications you have
chosen, and not only on the computer or the Nokia D211. For information on
how to use an application, please refer to that application’s documentation.
•You need to subscribe to the corresponding data and fax services from your
service provider or network operator. Contact your service provider for
information about the availability and details of the services in your home
network. Internet access requires that you have subscribed to the data service
and obtained an Internet access point from your service provider.
The Nokia D211 can also be controlled with AT commands. For more information,
please refer to the Developer Manual for Nokia D211,which can be found at
www.forum.nokia.com.
About data transmission
The Nokia D211 employs the data transmission capabilities of the WLAN and GSM
network in order to send and receive data, to browse the Internet, to send
short messages and e-mail, and to establish connections with other computers,
for example.
Data connections may be made from most locations where your radio card
operates. However, it is recommended that you move the radio card to a location
where the strongest possible network signal can be obtained. When the signal is
strong, data transmission is more efficient.
The following factors may impair wireless connections:
Noise – Electronic appliances and equipment can cause radio interference. Also in
areas where radio cards are prevalent, other radio cards can impair the wireless
connection.

Introduction
9
© Nokia Corporation 2004. All rights reserved.
Roaming – As the radio card user moves from one WLAN access point coverage
area or GSM network cell to another, the signal strength of the channel drops. As
a consequence, the network may hand the user over to a coverage area and
frequency where the signal is stronger. Due to varying network traffic loads,
roaming may also occur when the user is stationary. Such roaming may cause
slight delays in transmission.
Electrostatic discharge – A discharge of static electricity from a finger or a
conductor may cause erroneous functions in electrical devices. The discharge may
result in unstable software operation. Network connections may become
unreliable, data may become corrupted, and transmission halted. In those cases,
end the existing connection (if any), stop the radio card, and remove it from
the PC card slot. Then re-insert the radio card into the PC card slot and try
connecting again.
Dead spots and dropouts – Dead spots are areas where radio signals cannot be
received. Dropouts occur when the radio card user passes through an area where
the radio signal is blocked or reduced by geographical or structural obstructions,
such as concrete walls.
Signal impairment – Distance and obstacles can cause signals to become out-of-
phase. They can also cause reflected signals. Both situations result in a loss of
signal strength.
Low signal strength – Due to either distance or obstacles, the radio signal
strength from a WLAN access point or GSM cell site may not be strong or stable
enough to provide a reliable connection for communication. Therefore, to ensure
the best possible communication, remember to consider the following points:
•Data connection works best when the radio card is in a stationary position.
Attempting wireless data communication while in a moving vehicle is not
recommended. Fax transmission is more easily impaired than data or text
message transmission.
•Do not place the radio card on a metal surface.
General Packet Radio Service (GPRS)
GPRS is a packet data technology where information is sent in short bursts of data
over the mobile network. The benefit of sending data in packets is that the
network is occupied only when sending or receiving data. GPRS as such is a data
bearer that enables wireless access to data networks like the Internet. The
applications that use GPRS are SMS messaging and GPRS dial-up (for example,
the Internet and e-mail).
Before you can use GPRS technology:
•You need to subscribe to GPRS service.
For availability and subscription to GPRS service, contact your service provider
or network operator.

Introduction
10
© Nokia Corporation 2004. All rights reserved.
•You need to save the GPRS settings for the applications used over GPRS.
See “Messages” on page 36 for configuring text message settings.
See also “Creating new profiles” on page 26 and “Data and fax
communication” on page 8.
Please refer to the Data Security document found on the Nokia D211 CD-ROM for
information on security issues.
Pricing for GPRS and applications
Both the active GPRS connection and the applications used over GPRS, for
example sending and receiving data and text messages, are priced. For more
detailed information on fees, contact your service provider or network operator.
High Speed Circuit Switched Data (HSCSD)
The Nokia D211 enables you to use GSM high-speed data services (HSCSD). The
standard GSM data transmission rate is 9.6 kbit/s, but HSCSD technology allows
for higher data transmission rates, making, for example, the downloading of large
files faster and more convenient.
HSCSD technology is based on the use of multiple timeslots at the same time.
Depending on the network, the data transmission speed in a single timeslot is 9.6
or 14.4 kbit/s. When sending and receiving e-mail, the 14.4 kbit/s data
transmission speed can be doubled up to 28.8 kbit/s, and in Internet connections
a download speed of up to 43.2 kbit/s can be achieved if supported by the
equipment of the network operator and the Internet service provider.
The use of GSM high-speed data services requires that your network supports
HSCSD technology and that you have subscribed to this service. For more
information, contact your service provider or network operator.
See also “Data and fax communication” on page 8.
Please refer to the Data Security document found on the Nokia D211 CD-ROM for
information on security issues.
Wireless Local Area Network (WLAN)
The radio card described in this document is approved for use in a Wireless Local
Area Network (WLAN).
Warning: This equipment operates at 2.4 - 2.4835 GHz. Note that in France
the use of this equipment is only allowed at the frequency band of 2.445 -
2.4835 GHz (channels 10, 11, 12, and 13).

Introduction
11
© Nokia Corporation 2004. All rights reserved.
The Nokia D211 supports the following WLAN features:
•IEEE 802.11b standard
•Data rates of 1, 2, 5.5, and 11 Mbit/s
•Operation at a frequency of 2.4 GHz using Direct Sequence Spread Spectrum
(DSSS) radio technology
•Wired Equivalent Privacy (WEP) data encryption with keys up to 152 bits.
The Nokia D211 enables you to wirelessly connect compatible laptop computers,
hand-held devices, desktop PCs, and other devices with a type II or III PC card slot
to a wired local area network through a WLAN access point. Instead of cables,
radio waves are used to transmit and receive data over the air.
If you move the computer to another location within the WLAN and out of range
of a WLAN access point, the roaming functionality can automatically connect
your computer to another access point that belongs to the same network. As long
as you remain within range of access points that belong to the same network, your
computer can stay connected to the network.
The Nokia D211 enables different types of communication in a WLAN. There are
two operating modes to choose from: infrastructure and ad hoc.
Infrastructure
The infrastructure operating mode allows two kinds of communication:
•Wireless stations communicate with each other through a WLAN access point.
•Wireless stations communicate with a wired LAN station through a WLAN
access point.
The advantage of the infrastructure operating mode is that you can have more
control over network connections because they pass through an access point. A
wireless station can access the services that are available in a regular wired LAN:
company database, e-mail, the Internet, and other network resources, for example.
Figure 1 - Infrastructure network
WLAN access point

Introduction
12
© Nokia Corporation 2004. All rights reserved.
Ad hoc
In the ad hoc operating mode, wirelessstations send and receive data directly with
each other; no access point is required. Simply insert the radio cards into the
stations, make the necessary configurations, and start communicating. Ad hoc
networking is easy to set up, but communication is limited to stations that are
within range. As long as the stations are within range, you can, for example, share
and exchange files.
See “Setting up and joining ad hoc networks” on page 22 for how to set up an ad
hoc network.
SIM services
SIM services refers to a service which enables you to access the Internet via your
service provider’s or network operator’s own public network. Your service provider
may, for example, offer you the possibility to check data from your company
intranet, send and receive e-mail, and save documents. SIM services are usually
available in public places such as hotels, airports, railway stations, business
centres, and corporate buildings.
Note: Before you can take advantage of the SIM services, you must subscribe
to these services from your service provider or network operator and obtain
instructions for use.
A SIM card is used as a means for user identification: the data stored on the SIM
card is read, and if valid, you are allowed to connect to the Internet and intranets.
The SIM card is provided by the service provider or network operator.
Accounting data, such as used access time and/or transferred data, is passed from
the network on to the service provider for billing purposes. Accounting begins
when the wireless station is authenticated and ends when the wireless station
logs off.
Note: The actual invoice for services from your service provider may vary,
depending upon network features, rounding-off for billing, taxes and
so forth.
Figure 2 - Ad hoc network

Introduction
13
© Nokia Corporation 2004. All rights reserved.
Security in WLAN
Security issues should always be carefully considered to ensure the secure
transmission of data in both wired and wireless LANs. In current wireless systems,
for example, WLAN access points need to authenticate wireless stations to
prevent unauthorised access to the network. Authentication is a service that
confirms the identity of an entity, such as a user or a computer, or confirms the
origin of a transmitted message.
The Nokia D211 supports the Wired Equivalent Privacy (WEP) protocol, which
offers basic protection in WLAN. The WEP protocol utilises the RC4 algorithm with
an up to 152-bi t s ecret key, which enc rypts dat a b efore it is transm itted ov er radio
waves. When the wireless stations in a WLAN wish to communicate using WEP,
they must have the same WEP key in possession.
The Nokia D211 is also compatible with leading Virtual Private Network (VPN)
clients over GPRS and WLAN. VPN is recommended for more secure network
access.
The Nokia D211 is equipped with an integrated smart card reader. SIM cards and
smart card readers provide a tool for managing secure user authentication in a
WLAN. SIM cards also provide an easy way for users to carry an authentication
device with them. On a SIM card users can store important information, such as
WEP keys and network profiles.
The smart card reader reads the data stored on the computer chip and sends it to
the network for processing. The SIM card is protected by a PIN code; to access the
contents of the SIM card, you need to enter the correct PIN code.
Caution: Keep all miniature SIM cards out of small children’s reach.
Please refer to the Data Security document found on the product CD-ROM for
more information on security issues.
Antennas
The Nokia D211 has built-in antennas inside an extension box. In this document
antenna refers to the extension box and the antennas inside it.
Figure 3 - Extension box of the Nokia D211

Introduction
14
© Nokia Corporation 2004. All rights reserved.
When connecting to a WLAN, make sure that the antenna is pointing towards the
WLAN access point and placed in an open area. Do not cover the antenna.
Use only the supplied antenna. Unauthorised antennas, modifications, or
attachments could damage the radio card and may violate regulations governing
radio devices.

Installation
15
© Nokia Corporation 2004. All rights reserved.
Installation
There are some slight differences in the installation process between the different
Windows operating systems. If the installation differs from the steps described
below, follow the instructions on the screen.
The Nokia D211 software requires 20 MB of free disk space.
Installing the Nokia D211 software
Note: Do not insert the radio card into your computer until the installation
program instructs you to do so.
1Exit all Windows programs. Insert the CD-ROM into the CD-ROM drive of
your computer.
If the CD-ROM is not launched automatically, go to your CD-ROM drive (e.g.
drive D) and double-click on Start.exe.
2Select the language for the CD-ROM and installation program and read
through and accept the Nokia license agreement. If you do not accept the
license agreement, you cannot use the CD-ROM.
3The main screen of the CD-ROM opens. Click Install to start the installation.
4The Welcome page of the installation wizard opens. Click Next to continue.
5Read through and accept the Nokia license agreement. If you do not accept the
license agreement, you cannot use the software and the installation procedure
stops. Click I Accept to accept the license agreement.
6Select the destination folder for the software. The default folder is C:\Program
Files\Nokia\Nokia D211. If you want to install the software in another drive or
folder, click Browse. When you have selected the correct destination folder,
click Next.
Note: You cannot install the Nokia D211 software on a network drive.
7Select the type of installation you want. The Administrator option is for system
administrators only. Custom allows you to choose the individual software
components to be installed, and is recommended for advanced users. Typical
installs the most common software components. This option is recommended
for most users. When you have selected the desired type of installation,
click Next.
8Check the installation settings. To accept them, click Next. To change the
settings, click Back, make the changes, and then click Next. The installation
program starts copying the files.
9When the installation program prompts you to insert the radio card, insert it
into the PC card slot of y o u r c om pu t e r a s sho w n i n F igur e 4. No te t h a t the r a d io

Installation
16
© Nokia Corporation 2004. All rights reserved.
card is not inserted all the way into the PC card slot and there is a gap between
the protruding extension box and the computer. Do not use excess force when
inserting the card.
In the Windows 2000 operating system you are informed that no digital
signature was found. Click Yes in each dialog box to continue with the
installation.
In Windows XP, the operating system opens Found New Hardware wizards. For
each of these wizards, first select the option Install the software
automatically, and then select Continue Anyway to continue with the
installation.
10 The Completion page informs you when the installation is completed. Remove
the CD-ROM from the CD-ROM drive and click Finish. You may need to restart
your computer.
11 A dialog box asks if you want to create a network profile now. Remember that
you can create and edit your own network profiles at any time. If you do
not want to create a profile, click No and the installation procedure is
completed. If you want to create a profile, click Yes and the Welcome window
of the profile wizard opens. See “Creating new profiles” on page 26 for more
information.
Note: If you want other applications to be able to use the smart card reader
of the Nokia D211, you need to install separately a PC/SC (Personal Computer
Smart Card) compliant smart card driver on your computer. Install the smart
card driver only if you want to use other applications or special types of
smart cards with the smart card reader of the Nokia D211. To install the
driver, select Custom as the installation type (see step 7 above) and select the
PC/SC smart card driver component. In the Windows 98 and Me operating
systems you must have the Microsoft Smart Card Base Components 1.0 or
later installed.
Figure 4 - Inserting the radio card

Installation
17
© Nokia Corporation 2004. All rights reserved.
Modifying the installation
You can alter the installation of the Nokia D211 by adding or removing
components, for example.
1Exit all Windows programs. Insert the CD-ROM into the CD-ROM drive of
your computer.
If the CD-ROM is not launched automatically, go to your CD-ROM drive (e.g.
drive D) and double-click on Start.exe.
2Select the language for the CD-ROM and installation program and read
through and accept the Nokia license agreement. If you do not accept the
license agreement, you cannot use the CD-ROM.
3The main screen of the CD-ROM opens. Click Install to start the installation.
4When the Welcome page of the installation maintenance program opens,
choose from the following options:
Modify – You can install new components or remove existing ones.
Update – You can update the installed components and network profiles.
Uninstall – You can remove the Nokia D211 program files and drivers from your
computer.
When you have selected the option, click Next.
5The selected wizard opens. Make the changes and click Next to continue.
6Check the settings. To accept them, click Next. To change the settings, click
Back, make the changes, and then click Next.
7The modification starts. The Completion page informs you when the
modification is completed. Click Finish.
Uninstalling the Nokia D211 software
Caution: Before you start uninstalling the Nokia D211 software, you must
first stop the radio card and then remove it from the PC card slot of the
computer. See “Removing the radio card” on page 22 for more information.
Close all dialog boxes in the user interface before uninstalling the Nokia D211.
To uninstall the Nokia D211 software:
1From the Start menu, select Settings and then click Control Panel. Click Add/
Remove Programs.
2From the list of programs, select Nokia D211 and click Add/Remove.
3The Welcome page of the uninstallation wizard opens. If you do not want
profiles and settings configured on the Settings page removed, select the Keep
all profiles and other settings check box. If you want to save all data relating
to the SMS application, for example text and picture messages you have sent
or received, select the Keep all data from the SMS application check box.

Installation
18
© Nokia Corporation 2004. All rights reserved.
Click Next to continue.
4Check the uninstallation settings. To accept them, click Next. To change the
settings, click Back, make the changes, and then click Next.
5The uninstallation starts. The Completion page informs you when the
uninstallation is completed. Click Finish.

Getting started
19
© Nokia Corporation 2004. All rights reserved.
Getting started
With the Nokia D211 you can:
•establish a General Packet Radio Service (GPRS) connection where information
is sent in short bursts of data over the cellular network. The benefit of sending
data in packets is that the network is occupied only when sending or receiving
data. GPRS is ideal for applications which transmit data in short bursts, such as
Web browsers. The data rate can be up to 40.2 kbit/s. You need to subscribe to
the GPRS service.
•connect to a GSM network where you can send and receive text and picture
messages. You can also connect to the Internet or your e-mail by making a data
call, which enables data transmission rates of up to 14.4 kbit/s. You can make
GSM high-speed data calls if your network supports High Speed Circuit
Switched Data (HSCSD) technology and you have subscribed to GSM high-
speed data services. HSCSD technology is especially suited for active file
transfer, and the data rate can be up to 43.2 kbit/s.
•connect to a Wireless Local Area Network (WLAN) and send and receive data
like in a regular wired LAN. The data rate in WLAN can be up to 11 Mbit/s.
Connecting to a network
To be able to connect to a network you need a network profile. Easy connection
profile with pre-defined settings is automatically created during software
installation. This profile enables network access without your needing to
configure any settings.
If you want to create a profile yourself, see “Creating new profiles” on page 26
for more information.
You need a SIM card to be able to establish a GSM or GPRS connection.
To create a network connection:
1Slide the SIM card into the smart card slot of the
Nokia D211. Make sure that the metal contacts of the
SIM card are facing down and that the bevelled
corner is on the right. Note that the radio card does
not support 5 Volt SIM cards.

Getting started
20
© Nokia Corporation 2004. All rights reserved.
2Insert the radio card firmly into the PC card slot of
he computer.
Note that the radio card is not inserted all the way
into the PC card slot and there is a gap between the
protruding extension box and the computer. Do not
use excess force when inserting the card.
3Switch on your computer.
4If you are using a SIM card, enter the PIN code and click OK. You can enter the
PIN code before logging on to a network.
5During the log on a dialog box opens in the top left-hand corner of the screen.
To select the profile and connection type at this stage, click Select.
6The Select Connection dialog box opens. See Figure 5. From the list of profiles
open the profile and select the connection type you want to use.
WLAN – Connects you to a wireless local area network where you can send
and receive data.
GSM – Allows you to make data calls and utilise GSM high-speed data services
if your network supports HSCSD technology and you have subscribed to the
service.
GPRS – You can establish a GPRS connection and send packet data. You need
to subscribe to the GPRS service.
OFF – Disconnects the radio card from the network and turns off all radios.
7Click OK to establish a network connection.
Figure 5 - Select Connection dialog box
