Nokia MetroHopper User manual

© Nokia Networks Oy 1 (2)
Nokia MetroHopper Radio with FC RRI/
FXC RRI
User Manual B0
Binder 1/1
C33512.22

2 (2) © Nokia Networks Oy
The information in this document is subject to change without notice and describes
only the product defined in the introduction of this documentation. This document is
intended for the use of Nokia Networks' customers only for the purposes of the
agreement under which the document is submitted, and no part of it may be
reproduced or transmitted in any form or means without the prior written permission of
Nokia Networks. The document has been prepared to be used by professional and
properly trained personnel, and the customer assumes full responsibility when using it.
Nokia Networks welcomes customer comments as part of the process of continuous
development and improvement of the documentation.
The information or statements given in this document concerning the suitability,
capacity, or performance of the mentioned hardware or software products cannot be
considered binding but shall be defined in the agreement made between Nokia
Networks and the customer. However, Nokia Networks has made all reasonable
efforts to ensure that the instructions contained in the document are adequate and free
of material errors and omissions. Nokia Networks will, if necessary, explain issues
which may not be covered by the document.
Nokia Networks' liability for any errors in the document is limited to the documentary
correction of errors. Nokia Networks WILL NOT BE RESPONSIBLE IN ANY EVENT
FOR ERRORS IN THIS DOCUMENT OR FOR ANY DAMAGES, INCIDENTAL OR
CONSEQUENTIAL (INCLUDING MONETARY LOSSES), that might arise from the
use of this document or the information in it.
This document and the product it describes are considered protected by copyright
according to the applicable laws.
NOKIA logo is a registered trademark of Nokia Corporation.
Other product names mentioned in this document may be trademarks of their
respective companies, and they are mentioned for identification purposes only.
Copyright © Nokia Networks Oy 2000. All rights reserved.

User Manual B0
NOKIA / C33512.22 © Nokia Networks Oy 1 (2)
M = Missing Document
P = Preliminary
Contents
Binder 1/1
Title Document Identifier Div. Rem
1
Document Note DN99617961 Issue 2-0 en 1.0
2
Guide to Documentation DN99611449 Issue 2-0 en 2.0
3
Installation Overview DN99611437 Issue 2-0 en 3.0
4
Installation DN99592289 Issue 2-1 en 4.0
5
Commissioning and Maintenance DN99611394 Issue 2-0 en 5.0
6
Product Description DN99592717 Issue 2-2 en 6.0
7
Glossary DN99593058 Issue 2-1 en 7.0

2 (2) © Nokia Networks Oy NOKIA / C33512.22
M = Missing Document
P = Preliminary

C33512.20 D0
Nokia MetroHopper Radio
User Manual
DN99592241 © Nokia Networks Oy Draft 1 (11)
Issue 3-0 en Nokia Proprietary and Confidential
Document Note

Document Note
2 (11) © Nokia Networks Oy Draft DN99592241
Nokia Proprietary and Confidential Issue 3-0 en
The information in this document is subject to change without notice and describes only the
product defined in the introduction of this documentation. This document is intended for the
use of Nokia Networks' customers only for the purposes of the agreement under which the
document is submitted, and no part of it may be reproduced or transmitted in any form or
means without the prior written permission of Nokia Networks. The document has been
prepared to be used by professional and properly trained personnel, and the customer
assumes full responsibility when using it. Nokia Networks welcomes customer comments as
part of the process of continuous development and improvement of the documentation.
The information or statements given in this document concerning the suitability, capacity, or
performance of the mentioned hardware or software products cannot be considered binding
but shall be defined in the agreement made between Nokia Networks and the customer.
However, Nokia Networks has made all reasonable efforts to ensure that the instructions
contained in the document are adequate and free of material errors and omissions. Nokia
Networks will, if necessary, explain issues which may not be covered by the document.
Nokia Networks' liability for any errors in the document is limited to the documentary correction
of errors. Nokia Networks WILL NOT BE RESPONSIBLE IN ANY EVENT FOR ERRORS IN
THIS DOCUMENT OR FOR ANY DAMAGES, INCIDENTAL OR CONSEQUENTIAL
(INCLUDING MONETARY LOSSES), that might arise from the use of this document or the
information in it.
This document and the product it describes are considered protected by copyright according to
the applicable laws.
NOKIA logo is a registered trademark of Nokia Corporation.
Other product names mentioned in this document may be trademarks of their respective
companies, and they are mentioned for identification purposes only.
Copyright © Nokia Networks Oy 2001. All rights reserved.
Nokia Citytalk, Nokia Extratalk, Nokia FlexiHopper, Nokia Flexitalk, Nokia Hopper Manager,
Nokia Intratalk, Nokia MetroHopper, Nokia MetroHub, and Nokia MetroSite are trademarks of
Nokia Networks Oy.
Hereby, Nokia Corporation, declares that this Nokia MetroHopper radio is in compliance with the
essential requirements and other relevant provisions of Directive: 1999/5/EC.
FCC ID:PM5T55800–01
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
The product is marked with the CE marking and Notified Body number according to the
Directive 1999/5/EC
0889

DN99592241 © Nokia Networks Oy Draft 3 (11)
Issue 3-0 en Nokia Proprietary and Confidential
Summary of changes
Document Date Comment
C33512002PE_00 24 Jun 1999
C33512002PE_A0 06 Sep 1999
C33512002PE_B0 26 Oct 1999
C33512009XE_A0 29 Oct 1999
DN99592241 Issue 1-0 en 01 Nov 1999 New document numbering scheme adopted.
DN99592241 Issue 2-0 en 11 Feb 2000
DN99592241 Issue 2-1 en 16 Mar 2000
DN99592241 Issue 2-2 en 11 May 2000
DN99592241 Issue 3-0 en 31 Aug 2001

Document Note
4 (11) © Nokia Networks Oy Draft DN99592241
Nokia Proprietary and Confidential Issue 3-0 en

User Manual / Product version compatibility
DN99592241 © Nokia Networks Oy Draft 5 (11)
Issue 3-0 en Nokia Proprietary and Confidential
1User Manual / Product version
compatibility
C33512.20 Nokia MetroHopper with FIU 19 / RRIC User Manual
Version D0
This user manual provides the instructions for the installation and operation of the
products listed below.
All units are labelled with a sticker stating the product code and version.
Table 1. Outdoor unit
Product code Product name Product
version
T55800.01 Nokia MetroHopper OU 58 GHz B
Table 2. Alignment unit pole clamp
Product code Product name Product
version
T55851.01 Nokia MetroHopper Mounting Adapter Plate A
Table 3. Optical alignment unit
Product code Product name Product
version
T55875.01 MetroHopper Optical Alignment Tool A

Document Note
6 (11) © Nokia Networks Oy Draft DN99592241
Nokia Proprietary and Confidential Issue 3-0 en
Note
Note
The ordering practice will change so that the product codes, comprimising of both
a main unit and plug-in units, are not used any longer. Now the main unit
(T55240.01) and the needed number of plug-in units are ordered with seperate
codes. For example, to get a 12 x 2M 1+0 configuration, place an order for one
main unit and three 4 x 2M plug-in units. For 16 x 2M 1+0 you have to order a
main unit a suitable upgrade kit (T55246.4x).
The capacity of Nokia MetroHopper is fixed to 4 x 2 Mbit/s.
Table 4. FIU 19 indoor units
Product code Product name Product
version
T55240.01 FIU 19 0x2M 1+0 C
T55240.80 FIU 19 16x2M 1+1 120 C
55240.81 FIU 19 16x2M 1+1 75 C
55240.82 FIU 19 16x2M 1+1 120 RJ-45 C
Table 5. FIU 19 upgrades
Product code Product name Product
version
P55044.01 Hopper SW upgrade kit CD-ROM
T55220.01 FIU 19 4x2M 120 Plug-in Unit TQ C
T55220.02 FIU 19 4x2M 75 Plug-in Unit C
T55220.03 FIU 19 4x2M Plug-in Units 120 RJ-45 C
T55221.01 FIU 19 Flexbus Plug-in Unit A
T55223.01 FIU 19 Aux Data plug-in Unit A
T55241.04 FIU 19 Mounting Kit for TM4 rack A
T55241.05 FIU 19 Mounting Kit for ETSI rack A
T55246.40 FIU 19 UPG for 4-12x2M 1+0 120 TQ C

User Manual / Product version compatibility
DN99592241 © Nokia Networks Oy Draft 7 (11)
Issue 3-0 en Nokia Proprietary and Confidential
T55246.41 FIU 19 UPG for 4-12x2M 1+0 75 C
T55246.42 FIU 19 UPG for 4–12x2M 1+0 120 RJ-45 C
T55246.51 FIU 19 UPG FOR 16 X 2M TO 1+1 C
T55246.80 FIU 19 UPG to 16x2M 1+1 120 C
T55246.81 FIU 19 UPG to 16x2M 1+1 75 C
T55246.82 FIU 19 UPG to 16x2M 1+1 120 RJ-45 C
Table 6. FIU 19 spare parts
Product code Product name Product
version
T55210.01 FIU 19 Backplane 1+0 A
T52210.02 FIU 19 Backplane 1+1 B
T55211.01 FIU 19 EXU 16x2M 120 Ohms TQ B
T55211.02 FIU 19 EXU 16x2M 75 Ohms B
T55211.03 FIU 19 EXU 16x2M 120 Ohms TQ RJ-45 B
T55212.01 FIU 19 16x2M IC Plug-In Unit C
T55240.01 FIU 19 0x2M 1+0 C
T55241.01 FIU 19 Mounting Kit for 4-12x2M 1+0 A
T55241.02 FIU 19 Mounting Kit for 16x2M 1+0 A
T55241.03 FIU 19 Mounting Kit for 16x2M 1+1 A
Table 7. RRIC indoor unit
Product code Product name Product
version
T55290.01 RRIC Radio Relay Interface C
T55291.01 RRIC Power Supply for AC Intratalk BTS A
Table 5. FIU 19 upgrades (Continued)
Product code Product name Product
version

Document Note
8 (11) © Nokia Networks Oy Draft DN99592241
Nokia Proprietary and Confidential Issue 3-0 en
Table 8. Node manager programs and accessories
Product code Product name Product
version
P38206.01 Hopper Manager C4.2 CD-ROM + Cable (2.5 m) C
CS72451.01 LMP Cable (5.0 m)
P31711.01 TruMan C8.0 K
E62717.01 V.11/V.28 converter cable set (PC-TRUx)
E62717.03 V.11/V.28 converter cable set (PC-TRUx)
26287.01 Chassis 20T/14U
T55270.01 Nokia Q1 LMP cable C

User Manual / Product version compatibility
DN99592241 © Nokia Networks Oy Draft 9 (11)
Issue 3-0 en Nokia Proprietary and Confidential
Note
Jumper cables for connecting the RRIC indoor unit to the connector board on top
of the base station cabinet are included with the base station.
Table 9. Flexbus cables, connectors and accessories
Product code Product name Product
version
T36625.01 TNC-M/0–TNC-M/0, 1.5 m
T36625.02 Cable TNC-M/0–TNC-M/0, 4 m
T36625.03 Cable TNC-M/0–TNC-M/0, 8 m
T36625.04 Cable TNC-M/0–TNC-M/0, 15 m
T36626.01 Cable Reel Flexbus, RG223, 500 m
T36629.01 Cable Reel Flexbus, RG214, 500 m
T55255.01 Flexbus TNC-TNC (RG-223) Connector Kit B
T55255.02 Flexbus TNC-TNC (RG-214) Connector Kit B
T55255.11 Flexbus N-TNC (RG-223) Connector Kit B
T55255.12 Flexbus N-TNC (RG-214) Connector Kit B
T55257.01 Flexbus TNC-TNC Jumper Cable B
T55257.02 Flexbus TNC-TNC Cable (500 mm) B
T38094.01 Jumper Cables DMR 18-38CE BBU1 A
T55271.01 TNC-N Adapter for Jumper Cable 0
CS72749.60 Grounding kit KTM P 1/4” for RG-213/214
CS72749.61 Grounding kit for RG-223 – RG-58 (61 1540
0006)
CS72746.20 Clamp RF A4 2 x 1/4” for L-profile 40 x 40

Document Note
10 (11) © Nokia Networks Oy Draft DN99592241
Nokia Proprietary and Confidential Issue 3-0 en
Table 10. FIU 19 2M and Q1 cables and connectors
Product code Product name Product
version
T55250.01 FIU 19 D9M-TQ Q1 Jumper Cable F
T55250.02 FIU 19 D9F-TQ Q1 Jumper Cable F
T55250.03 FIU 19 D9F-TQ 2x2M Jumper Cables F
T55250.20 FIU 19 TQ-TQ Q1 or 2M Cable (500 mm) F
T55250.21 FIU 19 TQ-TQ 2M Cable (30 m) G
T55250.31 FIU 19 4xTQ Cable 5m open G
T55250.32 FIU 19 4xTQ Cable 15m open G
T55251.01 FIU 19 4xTQ 2M Connector Kit A
T55252.01 FIU 19 4xRJ 45 2M Connector Kit A
T55252.02 FIU 19 4xRJ 45 Aux Card Connector Kit A
T55253.01 FIU 19 2M Cable 500 m A
T55260.01 FIU 19 2xTQ-DB9 Q1 Adapter D
T55265.01 Cable sets 1/4–Euro; TQ + Converter D9 A
T38122.02 Q1 Interconnection Cable B
T38122.04 Q1 Chaining Cable 2, CE, (6xIU/SSS) B
T38122.10 Q1 Coupling Connector, CE B
T38127.01 Interconn. Cable, 2M, 75, C/CE (SSS/BTS) B
T38127.02 Jumper Cable, 2x2M, 75, C/CE (SSS) B
T38127.04 Cross-Conn. Cable, 2M, 75, CE (SSS) B
T38128.01 Interconn. Cable, 2M, 120, C/CE (SSS/BTS) C
T38081 4x2 Connector set DMR 18–38CE SMB A
Table 11. Power supplies and cables
Product code Product name Product
version
T55254.01 TALK FIU 19 Power Connector Kit 0
T55258.02 FIU 19 Power Cable 15m 0
T55259.02 FB Plug-In Power Cable 15m 0

User Manual / Product version compatibility
DN99592241 © Nokia Networks Oy Draft 11 (11)
Issue 3-0 en Nokia Proprietary and Confidential
T30839.01 Power AC/DC 1x100W 19/ETS 1.5U B
T30839.02 Power AC/DC 2x100W 19/ETS 1.5U B
T30839.03 Power DC/DC 1x100W 19/ETS 1.5U B
T30839.04 Power DC/DC 2x100W 19/ETS 1.5U B
Table 11. Power supplies and cables (Continued)
Product code Product name Product
version

DN99611394 © Nokia Networks Oy 1 (42)
Issue 2-0 en
Nokia MetroHopper Radio with FC RRI/FXC RRI
User Manual B0
C33512.22
Commissioning and Maintenance

Commissioning and Maintenance
2 (42) © Nokia Networks Oy DN99611394
Issue2-0en
The information in this document is subject to change without notice and describes only the
product defined in the introduction of this documentation. This document is intended for the
use of Nokia Networks' customers only for the purposes of the agreement under which the
document is submitted, and no part of it may be reproduced or transmitted in any form or
means without the prior written permission of Nokia Networks. The document has been
prepared to be used by professional and properly trained personnel, and the customer
assumes full responsibility when using it. Nokia Networks welcomes customer comments as
part of the process of continuous development and improvement of the documentation.
The information or statements given in this document concerning the suitability, capacity, or
performance of the mentioned hardware or software products cannot be considered binding
but shall be defined in the agreement made between Nokia Networks and the customer.
However, Nokia Networks has made all reasonable efforts to ensure that the instructions
contained in the document are adequate and free of material errors and omissions. Nokia
Networks will, if necessary, explain issues which may not be covered by the document.
Nokia Networks' liability for any errors in the document is limited to the documentary correction
of errors. Nokia Networks WILL NOT BE RESPONSIBLE IN ANY EVENT FOR ERRORS IN
THIS DOCUMENT OR FOR ANY DAMAGES, INCIDENTAL OR CONSEQUENTIAL
(INCLUDING MONETARY LOSSES), that might arise from the use of this document or the
information in it.
This document and the product it describes are considered protected by copyright according to
the applicable laws.
NOKIA logo is a registered trademark of Nokia Corporation.
Other product names mentioned in this document may be trademarks of their respective
companies, and they are mentioned for identification purposes only.
Copyright © Nokia Networks Oy 2000. All rights reserved.
Nokia FlexiHopper, Nokia MetroHopper, Nokia MetroSite, and Nokia MetroHub are trademarks
of Nokia Networks Oy. Any other trademarks mentioned in the documents are the property of
their respective owners.

DN99611394 © Nokia Networks Oy 3 (42)
Issue 2-0 en
Contents
Contents 3
1 About this document 7
2 Commissioning Nokia MetroHopper 9
2.1 Precautions 9
2.2 Commissioning with Nokia BTS Manager 10
2.3 Commissioning with Nokia MetroHub Manager 13
2.4 Configuring identifications and settings 13
2.4.1 Identifications 14
2.4.2 Unit settings 14
2.4.3 Outdoor unit settings 14
2.5 Verifying commissioning 16
3 Maintaining Nokia MetroHopper 17
3.1 Preventive maintenance 17
3.2 Performance monitoring 17
3.2.1 Measurements 18
3.2.2 Error counters 18
3.2.3 Reading statistics 18
3.3 Using loopbacks 19
3.4 Replacing or removing outdoor unit 21
Appendix A. Alarm descriptions 23
A.1 FC RRI unit alarms 23
A.2 FXC RRI unit alarms 36
A.3 MetroHopper unit alarms 40

Commissioning and Maintenance
4 (42) © Nokia Networks Oy DN99611394
Issue2-0en

DN99611394 © Nokia Networks Oy 5 (42)
Issue 2-0 en
Summary of changes
Document Date Comment
C33512012SE_00 29 Oct 1999 Prerelease version
DN99611394 Issue 1-0 en 28 Dec 1999 New document numbering scheme adopted
DN99611394 Issue 2-0 en 30 May 2000 Valid for Nokia SiteWizard C1.0
