Norbec Intelligence I3 User manual

1
1. Panic Alarm Buzzer
2. Battery (9 Volt) Holder
3. Display
4. High Temp alarm Button
5. Light Switch Button
6. Set Button
7. Low Temp Alarm Button
8. Up Button (and Mute)
9. Down Button
10. Mute Button (only mute the loud Buzzer)
DESCRIPTION FOR EACH FEATURE
Activation & disabling the module
Before being delivered to the customer, the module is disabled.
The ''OFF'' message is displayed on the screen. When the
module is disabled, only the alarms and temperature displays
are deactivated. It is always possible to control the lighting
manually or automatically, with the door (See ''lighting
Control''). Note that all the initial parameters and those
modified by the customer are stored in memory when the
module is disabled.
Refer to ''keypad Operation'' section on how to enable and
disable the module.
Temperature monitoring and display
The unit displays the temperature in degrees Celsius. Should
one or more alarms be present, the display will show the
temperature and the alarm message(s) alternatively.
Lighting control
The lighting is controlled two different ways;
1. By pressing the button on the keypad, which will switch
alternatively ON and OFF.
2. By detecting the opening of the door, which will turn the
lights ON and the closing door will initiate a 5-minute
countdown. The light will then go OFF after this delay.
Temperature Alarms
These alarms are activated 45 minutes (adjustable, see
«parameter descriptions» after reaching the
temperature alarm settings. An audible alarm (about 55
dB) from the keypad will then occur. The display will
show the message HA (High Temp Alarm) Or LA *Low
Temp Alarm), alternatively with the actual temperature.
The 115 Volt alarm signal will turn ON.
The High and Low temperature alarm setting and the
activation delay can be modified in the parameters menu.
Door Open Alarm
If the door remains open for more than 15 minutes
(adjustable, see « parameter descriptions»), this alarm is
triggered and an audible alarm from the keypad will
occur. The display will show the message dA (Door Open
Alarm), alternatively with the actual temperature. The
115 Volt alarm signal will turn ON.
OPERATING AND CONFIGURING INSTRUCTIONS
OPTION

Panic Alarm
This alarm is triggered by an interior backlit button, besides the
door opening. When pressing this button, an audible alarm
(about 80 dB) from the keypad and from the external grey buzzer
will occur. The display will also show the message EA (External
Alarm) alternatively with the actual temperature. The 115 Volt
alarm signal will turn ON. This alarm will be active as long as the
panic button is pressed.
Note that the gray external buzzer connected to the emergency
alarm is powered only by the battery backup power. It is
important to periodically check the condition of the battery and
the backup power. It is important to periodically check the
condition of the battery and the backup power because once the
battery dies, no external sound signal will be triggered with the
activation of the emergency alarm push button.
Muting an alarm
Pressing the ''Silent'' button on the keyboard (top left), during
an alarm, will mute the audible signal but the associated alarm
message and the 115 Volt signal will remain until the alarm
condition disappears.
Alarm Annunciator
This additional buzzer (about 90dB) is ideally suited for hearing
any of the I3 alarms in a noisy environment. It is muted
independently from the keyboard Buzzer, by its own Mute
button. This annunciator is not supported by the back-up battery.
Note that at the request of the client on site, this additional
audible warning can be surface mounted to the desired location
(see I3 wiring diagrams for details). Without special request, it will
be installed near the I3 Intelligence module.
Fan failure alarm
When a ventilation system circulates air in concealed spaces
around the exterior of walk-in cold rooms, optional sensors can
be supplied to monitor the presence of air flow on each blower.
If air flow stops, the system triggers an audible alarm and
displays a message on the keypad. The display will also show the
message EA (External Alarm) alternatively with the actual
temperature. Without grey external alarm (Different from Panic
Alarm).
The 115 Volt alarm signal will be active as long as the failure
exists. When this alarm is ON, the Alarm LED on the left of the
display will ON.
OPTIONS
Battery back-up
The 9 Volt battery holder is located just above the controller. In
normal condition, an alkaline battery should maintain the
temperature display and the alarm messages in operation during
power outages for 24 hours, depending on the battery condition.
As this battery is not rechargeable, it shall be replaced yearly or
every time there is a power outage lasting more than one hour.
The battery only supports the controller display and the local
Panic Alarm, via the grey buzzer. This battery's condition must be
checked periodically.
The external 115 Volt alarm signal is not supported by this battery
back-up. If it is a requirement to have an external alarm signal on
power outages, the Dry Contact signal option, with proper
parameter settings, is required to achieve this functionality.
Three-way Switch for Lighting
This option allows to control lighting through two different door.
The three-way switch for lighting can be in automatic of manual
mode. For each lighting mode, cable configurations and,
positioning of hardware and distinct metrication is required. You
must refer to the I3 wiring diagrams for the proper electrical
connection according to the lighting mode selected. By default,
the three-way switch is in automatic mode. The configuration in
three ways manual mode is only on demand.
Note that the open door alarm will be disabled with the three-
way switch for manual lighting.
Dry Contact for External Alarm signal
The standard external alarm is a 115 Volt signal. As an option, it
can be converted to a dry contact (Normally Closed) that opens
an alarm signal (see I2 wiring diagrams for more details). This
option also includes a normally open contact if it needs to be.
Glycerine Immersion
Having the temperature probe immersed in glycerine prevents
rising temperature readings and false temperature alarms due to
the opening of the door.
DESCRIPTION FOR EACH FEATURE (Cont'd.)
(SUITE)
2

3
KEYPAD OPERATION
Press 1 second to activate the module. Press 5 seconds to disable the mode. The message OFF is displayed on
the screen when the module is disabled.
Switch ON and OFF the light fixture.
Press to see the HIGH Temp ALARM setting (ALU parameter).
Press for 3 seconds to enter a new value for the HIGH Temp ALARM (ALU displayed), then press the Up-Down
Buttons for proper setting and then press the Set button to confirm and exit.
Press to see the LOW Temp ALARM setting (ALL parameter).
Press for 3 seconds to enter a new value for the LOW Temp ALARM (ALL displayed), then press the Up-Down
Buttons for proper setting and then press the Set button to confirm and exit.
Press to increase the displayed value, in programming mode.
Press to mute the local buzzer when an ALARM occurs.
Press to decrease the displayed value, in programming mode.
Press for 3 seconds to lock the keyboard (The ''POF'' message will be displayed).
Press for 3 seconds again to unlock.
Silencingbuzzer
Once the alarm signal is detected, the buzzer can be muted by pressing the key.
The alarm message and the 120V message will be displayed until the alarm condition is reset.
PARAMETERS SETTING
1. Enter the Programming Mode by pressing the keys for 3 seconds and the LED will start blinking.
2. Select the required parameter by using the keys.
3. Press the key to display its value (now only the LED is blinking).
4. Use to change its value
5. Press to store the new value and move to the next parameter.
To exit: Press or wait 15 seconds without pressing a key.
NOTE: The set value is stored upon its recording, even when the procedure is not completed by exiting the configuration menu.

4
The factory settings are as follows:
PARAMETER
DESCRIPTION
PRESET VALUE (By default)
RANGE
ALU
High temperature alarm setting
C : 6°C F : -12°C
« ALL » value to 150°C
ALL
Low temperature alarm setting
C : 0°C F : -25°C
-50°C to « AL U » value
Ald
Temperature alarm delay
45
0 — 255 (min)
LHt
Light timer, start after door closing
5
0 — 255 (min)
doA
Door open alarm delay (timer start after
door opening)
15
0 — 255 (min)
Ot
Temperature probe calibration
0
-12 °C à 12°C
ALARM MESSAGE DESCRIPTIONS
MESSAGE
MODE
CAUSE
P1
Flashing
Probe failure
PoF
Flashing (3s)
Keyboard locked
Pon
Flashing (3s)
Keyboard unlocked
HA
Alternated with temperature
High Temperature Alarm
LA
Alternated with temperature
Low Temperature Alarm
dA
Alternated with temperature
Door open Alarm
EA
Alternated with temperature
Panic Alarm (Message and gray signal alarm ) Or
Fan failure alarm (message only)
Pan
Alternate with temperature
Serious external Alarm
