ViewSonic VPC14-WP User manual

Slot in PC module
VPC14-WP
(for IFP50 series)
Quick Start Guide
Model No. VS16933

i
Compliance Information
NOTE: This section addresses all connected requirements and statements regarding
regulations. Confirmed corresponding applications shall refer to nameplate labels
and relevant markings on unit.
FCC Compliance Statement
This device complies with part 15 of FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy, and if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Warning: You are cautioned that changes or modifications not expressly approved
by the party responsible for compliance could void your authority to operate the
equipment.
Industry Canada Statement
CAN ICES-3 (B)/NMB-3(B)
Contains FCC ID: PD93165NG
IC ID: 1000M-3165NG
CE Conformity for European Countries
The device complies with the EMC Directive 2014/30/EU and Low Voltage
Directive 2014/35/EU and Radio Equipment Directive (RED) 2014/53/EU.

ii
Following information is only for EU-member states:
The mark shown to the right is in compliance with the Waste Electrical and
Electronic Equipment Directive 2012/19/EU (WEEE).The mark indicates
the requirement NOT to dispose the equipment as unsorted municipal
waste, but use the return and collection systems according to local law.
In all EU member states, operation of 5150-5350MHz is restricted to indoor
use only. This device should be installed and operated with a minimum distance of
20cm between the radiator and your body.
Indian Restriction of Hazardous Substances
Restriction on Hazardous Substances statement (India) This product complies
with the “India E-waste Rule 2011” and prohibits use of lead, mercury, hexavalent
chromium, polybrominated biphenyls or polybrominated diphenyl ethers in
concentrations exceeding 0.1 weight % and 0.01 weight % for cadmium, except for
the exemptions set in Schedule 2 of the Rule.

iii
Declaration of RoHS2 Compliance
This product has been designed and manufactured in compliance with Directive
2011/65/EU of the European Parliament and the Council on restriction of the use
of certain hazardous substances in electrical and electronic equipment (RoHS2
Directive) and is deemed to comply with the maximum concentration values issued
by the European Technical Adaptation Committee (TAC) as shown below:
Substance
Proposed Maximum
Concentration
Actual Concentration
Lead (Pb) 0.1% < 0.1%
Mercury (Hg) 0.1% < 0.1%
Cadmium (Cd) 0.01% < 0.01%
Hexavalent Chromium (Cr6+) 0.1% < 0.1%
Polybrominated biphenyls (PBB) 0.1% < 0.1%
Polybrominated diphenyl ethers (PBDE) 0.1% < 0.1%
**Certain components of products as stated above are exempted under the Annex III
of the RoHS2 Directives as noted below:
Examples of exempted components are:
1. Lead in glass of cathode ray tubes
2. Leadinglassofuorescenttubesnotexceeding0.2%byweight
3. Lead as an alloying element in aluminium containing up to 0.4% lead by weight
4. Copper alloy containing up to 4% lead by weight
5. Lead in high melting temperature type solders (i.e. lead-based alloys containing
85% by weight or more lead)
6. Electrical and electronic components containing lead in a glass or ceramic other
than dielectric ceramic in capacitors, e.g. piezoelectronic devices, or in a glass or
ceramic matrix compound.
7. Lead as an alloying element in steel for machining purposes and in galvanized
steel containing up to 0.35% lead by weight.
8. Lead in dielectric ceramic in capacitors for a rated voltage of 125V AC or 250V DC
or higher.
9. Cadmium and its compounds in electrical contacts.

1
1. Interface
Item Description
WIFI antenna interface
Anti-theft lock
Connect the display to a DisplayPort connector
USB 3.0 interface , connects USB peripherals such as HDDs USB
keyboards and mice
Connects the display to a VGA-IN connector
Standard RJ45 (10M/100M/1G) Internet connection interface (This network
port is only used for PC)
Recovery the system. User needs to press and hold the button then power
on the device, device will recovery the system automatically, then user can
release the button.
Note: All settings will return to default and all data will be deleted.
Working indicator light
9Connects the device to headphones or speakers
10 Connects to a microphone
11 Connected to device with HDMI input function

2
2. Installation
2-1
2-2

3
2-3
3. Internet Connection

4
4. Input Selection
1. Press INPUT button on remote control to display the input setting menu, then
press DOWN to enter the input source menu.
2. Press DOWN / UP / LEFT/ RIGHT to select PC.
3. Press Enter button on remote control or click with touch pen to select the input
source.
4. Press EXIT key on remote control or click blank area outside menu with touch
pen to quit the on-screen menu.

5
5. USB Connection

6
Using the Intel Unite®Solution
Launch, Connect and Present with the Intel Unite Solution in 3 steps
Launch
Present
•Your Screen
•An Application
•Virtual Display
(If applicable)
3
Enter PIN
288-532
2
1
Enter PIN Present/ View Share display
on screen
View Presentation on your Device
Lock a Meeting
Unlocked by default
Lock
Non-participants trying to
join meeting/session
Not alldevices are supported on the Small Business version of the Intel Unite®app
Devices supported: Windows*, macOS*, iOS*,Chromebook*, & Android*

7
Play a Video with Audio Support Take Over a Presentation
Annotate on Presentations
Windows* OS users
macOS* users
Share Files with other Participants
Moderated Presentations
Be the
moderator
Assign roles
to others
Or request
Moderator role
Select Files
Receive Files
The Moderated sessions feature must be enabled by your system administrator. The “Self Promote mode”is shown above.
Review & Send

8
Disconnect other Participants Disconnect from a Meeting/Session
Copyright © Intel Corporation, 2017. All rights reserved.
*Other names and brands may be claimed as the property of others.
Or close lid
Select Participant

9
6. Specifications
IO ports 1 x Display Port
1 x HDMI
1 x VGA
1 x LAN
6 x USB 3.0
1 x Earphone
1 x Microphone
Power 100V-240V AC 50/60HZ
Operation
Conditions
Temperature
Humidity
Altitude
32°F to 113°F (0°C to 45°C)
10% ~ 90% non-condensing
0 meter to +5000 meters above sea level
Storage
Conditions
Temperature
Humidity
Altitude
-4°F to 140°F (-20°C to 60°C)
10% ~ 90% non-condensing
0 meter to +5000 meters above sea level
Dimensions Physical(mm) 246.2 x 265.4 x 32.2
Weight Physical(kg) 1.9
Power consumption 95W
Frequency Range and Output Power
(Max.)
2402 to 2480 MHz(BT) 2.0 dBm
2402 to 2480 MHz(LE) 3.73 dBm
2412 to 2472 MHz 17.41 dBm
5150 to 5250 MHz 18.94 dBm
5250 to 5350 MHz 18.94 dBm
5470 to 5725 MHz 18.94 dBm

10
