Norden Mfg EB-72US User manual

Read, Understand, and Follow this manual which provides information
and procedures to safely operate and maintain the attachment.
Euro Loader Buckets
Owner Manual
MADE IN THE USA
EB-82US
EB-82SL
EB-72US
EB-94SL

Euro Loader Buckets 3 Norden Mfg. LLC [phone]
CONTENTS
1. INTRODUCTION ..........................4
1.1 Intended Usage .......................4
1.2 Operator Orientation....................4
1.3 Specications .........................4
1.3.1 EB-72USSpecications ..........4
1.3.2 EB-82USSpecications ..........4
1.3.3 EB-82SLSpecications...........5
1.3.4 EB-94SLSpecications...........5
1.4 Serial Number Location .................5
1.5 Product Improvements ..................5
1.6 Disposal of Equipment at End of Useful Life . 5
1.7 Unanswered Questions .................5
2. SAFETY .................................6
2.1 General..............................6
2.2 Safety Alert Symbol ....................6
2.3 Safety Icons Nomenclature ..............7
2.3.1 Personal Protection /
Important Information ............7
2.3.2 Prohibited Actions ...............7
2.3.3 Hazard Avoidance ...............7
2.4 General Safety ........................8
2.5 Machine Related Safety .................8
2.6 Safety Decals .........................8
2.7 Operation Safety ......................8
2.8 Transporting Safety ....................8
2.9 Storage Safety . . . . . . . . . . . . . . . . . . . . . . . . 8
2.10 Maintenance Safety . . . . . . . . . . . . . . . . . . . . 8
2.11 Training .............................8
2.12 Authorization/TrainingSign-O󰀨Form .....9
3. SAFETY DECALS AND LABELS ...........11
3.1 General Information . . . . . . . . . . . . . . . . . . . 11
3.2 How to Install Replacement Safety Decals . 11
3.3 Safety Sign Locations..................12
3.4 Safety Decals ........................12
4. NOMENCLATURE .......................13
5. ASSEMBLY AND SETUP ..................14
5.1 Assembly Process ....................14
6. USAGE .................................15
6.1 User Safety..........................15
6.1.1 Machine Operation Recommendations
15
6.1.2 Machine Requirements ..........15
6.2 MachineSpecications.................15
6.3 Attaching to Machine ..................16
6.4 Pre-Operation Checklist ...............17
6.5 Usage..............................17
6.5.1 Picking Up a Load ..............18
6.5.2 Traveling with a Load ...........19
6.5.3 Dumping the Load ..............19
6.6 Detaching from Machine ...............20
7. TRANSPORTING.........................21
7.1 Highway and Transport Safety ...........21
7.2 Pre-transport Checklist.................21
8. STORAGE...............................22
8.1 Placing in Storage ....................22
8.2 Removing from Storage ................22
9. MAINTENANCE ..........................23
9.1 Maintenance Safety . . . . . . . . . . . . . . . . . . . 23
9.2 Practice Safe Service Procedures . . . . . . . . 23
9.3 Welding Repairs ......................24
9.4 Service Record ......................24
10. PARTS SECTION.........................25
10.1 Ordering Parts .......................25
10.2 Contact Information ...................25
10.3 Safety Decals and Instructional Labels ....25
10.4 EB Parts Detail.......................26

Norden Mfg. LLC [phone] 4 Euro Loader Buckets
1. Introduction
The Norden Euro loader bucket is an attachment
that mounts to a tractor equipped with a front end
loader having Euro mounting capabilities. It is
designed specically to move loose material.
Note: Thespecicterm“loaderbucketattachment”
willbereferredtosimplyas“loaderbucket”
or“attachment”throughouttherestofthis
manual and may refer to any of the models
covered by this manual. The term utility
tractorwillbereferredtoas“machine”
throughout this manual.
Read, understand, and follow the manual carefully
to become familiar with your new Norden loader
bucket. Ultimately it is our desire that you will
be operating your loader bucket as a seasoned
professional in very little time!
This manual is intended for all models, but will show
specicpicturesanddiagramsoftheEB-72US
loaderbucket.Ifanyspecicationsaredi󰀨erentthan
the model shown, it will be noted.
1.1 Intended Usage
Do not use this loader bucket for any other purpose
than its intended use of moving loads of loose
material.
Note: Do not use an oversized machine; the loader
buckets are intended to be used on machines
rated up to 140 HP or a 3500 pound operating
capacity.
1.2 Operator Orientation
The directions left, right, front, and rear, as
mentioned throughout this manual, are as seen from
the operator’s seat, facing in the direction of travel.
1.3 Specifications
Specifications subject to change without notice.
1.3.1 EB-72US Specifications
Overall Width 73"
Overall Length 34.5"
Overall Height 25.5”
Overall Approximate Weight 462.4 lb.
Approx. Struck Capacity 18.7Cu.Ft.
1.3.2 EB-82US Specifications
Overall Width 83"
Overall Length 34.5"
Overall Height 25.5”
Overall Approximate Weight 505.1 lb.
Approx. Struck Capacity 21.4Cu.Ft.

Euro Loader Buckets 5 Norden Mfg. LLC [phone]
1.3.3 EB-82SL Specifications
Overall Width 83"
Overall Length 37"
Overall Height 30.5”
Overall Approximate Weight 578 lb.
Approx. Struck Capacity 29.0Cu.Ft.
1.3.4 EB-94SL Specifications
Overall Width 95"
Overall Length 37"
Overall Height 30.5”
Overall Approximate Weight 651.9 lb.
Approx. Struck Capacity 34.0Cu.Ft.
1.4 Serial Number Location
The loader bucket’s serial number and model
number are on the data plate which is located on the
rear of the bucket. Please use these numbers when
requesting service, seeking information, or ordering
parts.
1.
4210 Kinsman Rd NW, North Bloomeld, OH 44450
www.nordenmfg.com - [phone]
Made in USA
Serial Number
Mfg Date
Model Number/Rev
Max Hyd. Pressure
Load Rating
Approx. Weight
Part Number
1027460
Record the serial and model numbers as well as
the date of purchase in the space provided for easy
reference when contacting Norden Mfg LLC with
questions.
Model Number _____________________________
Serial Number ______________________________
Date of Purchase ___________________________
1.5 Product Improvements
Because Norden Mfg LLC maintains an ongoing
program of product improvement, we reserve the
right to make improvements in design or changes
inspecicationswithoutincurringanyobligationto
install them on attachments previously sold.
1.6 Disposal of Equipment at End of Useful
Life
The Norden Mfg LLC loader buckets are designed
forthespecicpurposeofmovinggraveland
dirt. When this attachment is no longer capable
of performing its intended use, it should be
dismantled and scrapped. Do not use any materials
or components from this attachment for any other
purpose.
1.7 Unanswered Questions
If you have any questions not answered in this
manual, require additional copies, or the manual is
damaged, please contact your dealer or:
Norden Mfg LLC
4210 Kinsman Road NW
North Bloomfield, OH 44450
Phone: [phone]
Fax:(440)693-4336
E-mail: [email protected]
The manual is also available for download at:
www.nordenmfg.com

Norden Mfg. LLC [phone] 6 Euro Loader Buckets
2. Safety
2.1 General
Most work-related accidents are caused by failure
to observe basic safety rules or precautions. An
accident can often be avoided by recognizing
potentially hazardous situations before an accident
occurs. As you use and maintain the attachment you
must be alert to potential hazards.
Improper use and/or maintenance of this attachment
could cause a dangerous situation that results in
property damage, personal injury, or death.
WARNING
Do not use the attachment until you read,
understand, and follow the information
contained in this manual and all related
equipment manuals. Do not use the attachment
for anything other than its intended purpose of
loose gravel or dirt.
Safety precautions and warnings are
provided in this manual and on the
attachment. If these precautions and warnings
are not followed, bodily injury or death could
occur to you or to other persons.
Norden Mfg LLC cannot anticipate every possible
circumstance that might involve a potential hazard.
The warnings in this manual and on the product are,
therefore, not all-inclusive. If a method of operation
notspecicallyrecommendedbyusisused,you
must satisfy yourself that it is safe for you and for
others. You should also ensure that the attachment
will not be damaged or be made unsafe by the use
or maintenance methods that you choose.
Theinformation,specications,andillustrationsin
this manual are based on the information that was
available at the time this material was written and
can change at any time.
2.2 Safety Alert Symbol
This is the safety alert symbol. It is used to
alert you to potential personal injury
hazards. The symbol is followed by a
signalwordsuchas“WARNING”or
“CAUTION”dependingontheseverityofthe
potential hazard. Obey all safety messages that
follow this symbol to avoid possible injury or death.
This manual contains WARNINGS, CAUTIONS,
NOTICES,SAFETYINSTRUCTIONS,andNOTES.
Warnings, Cautions, and Safety Instructions must be
followed to prevent the possibility of personal injury
or death due to improper operation. Notices and
Notes help prevent attachment or property damage.
WARNING
Indicates a potentially hazardous situation
which, if not avoided, COULD result in death or
serious injury.
CAUTION
Indicates a potentially hazardous situation
which, if not avoided, MAY result in minor or
moderate injury.
NOTICE
Indicates that attachment or property damage
can result if instructions are not followed.
SAFETY
INSTRUCTIONS
Indicates specific safety-related instructions or
procedures.
Note: Contains additional information important to
operation or a procedure.

Euro Loader Buckets 7 Norden Mfg. LLC [phone]
2.3 Safety Icons Nomenclature
This manual and the attachment has numerous
safety icons. These safety icons provide important
operating instructions which alert you to potential
personal injury hazards
2.3.1 Personal Protection /
Important Information
Read the manual
Maintenance procedure
Eye protection
Hearing protection
Hand protection
Foot protection
First aid kit
Use proper tools
OEMOEM
Use OEM parts
Use ROPS and seat belt
Maintain safety decals
Place in park
Remove key
STOP
Stop engine
Visibility - slow moving vehicle (SMV)
Set parking brake
2.3.2 Prohibited Actions
Do not alter or modify
Do not leave out tools
Do not weld
No riders
No children
No alcohol
No drugs
2.3.3 Hazard Avoidance
Crushing hazard
Crushing hazard
Slipping hazard
Tripping hazard
Falling hazard
Safety alert symbol
Defective or broken part
Falling hazard
Maintain safe distance
Pinch point hazard
Crush hazard
Rollover hazard
Not a lifting device
Electrocution hazard
Entanglement hazard

Norden Mfg. LLC [phone] 8 Euro Loader Buckets
2.4 General Safety
WARNING
Read, Understand, and Follow
Manual
To prevent personal injury or even death, be
sure you read, understand, and follow all of the
instructions in this manual and other related
OEM equipment manuals! This attachment
was designed for a specific application; DO
NOT modify or use this attachment for any
application other than that for which it was
designed. Attachments used improperly or
by untrained personnel can be dangerous!
Inexperienced operators should receive
instruction from someone familiar with the
attachment and the machine before being
allowed to use the attachment.
Do Not Operate
Do not use the attachment if it is in
need of repair. If you believe the attachment has
a defect which could cause injury or death, you
should immediately stop using the attachment.
Fall Hazard
Do not use the attachment as a platform
for standing. Do not stand on top of the
attachment at any time. Do not hang on the
attachment or allow others to hang on it.
Pinch Point Hazard
Keep hands and feet away from
the attachment to prevent them from getting
pinched or crushed.
2.5 Machine Related Safety
Impaired User Hazard
Do not attempt to use or maintain
the attachment under the influence of drugs
or alcohol. Consult your doctor before using
the attachment while taking prescription
medications.
Falling Hazard
Do not allow riders on the machine
or attachment at any time. Falling can result in
severe injuries or death.
Not A Lifting Device
Do not use the attachment to lift other
objects.
WARNING
Stay Clear
Clear the area of people, especially
small children, before using the attachment.
Under no circumstances should young
children be allowed to work with or around the
attachment.
2.6 Safety Decals
Refertosection“3.SafetyDecalsandLabels”on
page 11 for safety recommendations related to
using the attachment.
2.7 Operation Safety
Refertosection“6.1UserSafety”onpage15
for safety recommendations related to using the
attachment. All applicable safety recommendations
in other sections should also be followed.
2.8 Transporting Safety
Referto“7.Transporting”onpage21forsafety
recommendations related to traveling with a
machine and attachment on a public roadway. All
applicable safety recommendations in other sections
should also be followed.
2.9 Storage Safety
Refertosection“8.Storage”onpage22forsafety
recommendations related to storing the attachment.
All applicable safety recommendations in other
sections should also be followed.
2.10 Maintenance Safety
Refertosection“9.Maintenance”onpage23for
safety recommendations related to maintaining the
attachment. All applicable safety recommendations
in other sections should also be followed.
2.11 Training
Norden Mfg LLC follows the general Safety
StandardsspeciedbytheFarmEquipment
ManufacturersAssociation(F.E.M.A.),andthe
American National Standards Institute (ANSI).
Anyone who will be using and/or maintaining the
attachment must read and clearly understand ALL
safety, operation, and maintenance information
presented in this manual, other related OEM
machine manuals, and the safety decals.

Euro Loader Buckets 9 Norden Mfg. LLC [phone]
If you do not understand any information in this
manual, see your dealer or contact Norden Mfg LLC
before proceeding.
Do not use or allow anyone else to use this
attachment until all information has been reviewed.
Annually review this manual before the season start-
up.
MakeperiodicreviewsofSAFETYandOPERATION
a standard practice. An untrained operator is not
qualiedtousethisattachment.
2.12 Authorization / Training Sign-Off Form
Theauthorizationandtrainingsign-o󰀨formis
provided for your records to show that all personnel
who will be working with the attachment have read
and understand the information in this Operator
Manual and have been trained in the operation of
the machine the attachment is connected to. The
user and the owner should both sign and date the
form to indicate acceptance of the risk of using the
attachment.

Norden Mfg. LLC [phone] 10 Euro Loader Buckets
Authorization / Training Sign-O󰀨 Form
Date User’s Signature Owner’s Signature

Euro Loader Buckets 11 Norden Mfg. LLC [phone]
3. Safety Decals and Labels
3.1 General Information
The types of safety decals (hazard labels) and
instructional labels, along with their locations on the
attachment are shown in the following illustrations.
Good safety practices require that you familiarize
yourself with the various safety decals, the type
of warning, and the area or particular operation
relatedtothatareathatrequiresyourSAFETY
AWARENESS.
THINK
SAFETY!
Think SAFETY!
Work SAFELY!
Pay close attention to the safety decals and
instructional labels attached to the machine and
attachment.Thesafetydecalsa󰀩xedonthe
attachment are reproduced in this section. If the
attachment is missing a label or one is unreadable,
replace the label before using the attachment.
SAFETY
INSTRUCTIONS
Safety Decals and Instructional Labels
1. Keep safety decals or instructional labels
clean and legible at all times. Use a clean,
damp cloth to clean safety decals.
2. Replace any missing or hard-to-read safety
decals or instructional labels.
3. Use care when washing or cleaning the
attachment not to remove or damage the
decals. When using a pressure washer to
clean the attachment, avoid spraying too
close to decals; high-pressure water can
enter through very small scratches or under
edges of decals causing them to peel or
come off.
4. Locations for the decals and replacement
part numbers are shown in this section.
5. Replacement parts must have replacement
decals attached before the attachment is
used.
6. Decals are available from your authorized
dealer or from Norden Mfg LLC at no charge.
Contact Information
Forreplacementdecals,contact:
Norden Mfg LLC
4210 Kinsman Road NW
North Bloomfield, OH 44450
Phone: [phone]
Fax:440-693-4336
E-mail: [email protected]
3.2 How to Install Replacement Safety
Decals
1. Clean and dry the installation area.
Note: Do not install the decals if the temperature is
below50°F.
2. Determinetheexactpositionbeforeyouremove
the backing paper.
3. Remove the backing paper.
4. Alignthedecalorlabeloverthespeciedarea
and carefully press the sign to the part/frame.
Note: Small air pockets can be pierced with a pin
and smoothed out using the piece of backing
paper or plastic card.

Norden Mfg. LLC [phone] 12 Euro Loader Buckets
3.3 Safety Sign Locations
1
2
4
3
Item Type Description Qty.
1INFORMATIONAL Read the Manual 1
2 WARNING No Riders 1
3 WARNING FallingHazard 1
4INFORMATIONAL Mfg Placard 1
3.4 Safety Decals
1.
INFORMATIONAL — Read the Manual
2.
WARNING — No Riders
3.
1028640
WARNING —FallingHazard
4.
INFORMATIONAL — Manufacturer Placard
5.

To avoid injury or death
caused by falling attachment:
Lockpins must completely
engage attachment plate slots.
Coupler Handles - Locked
Handle
Locked
Lockpin Extended 1027140
WARNING —Pin Engagement

Euro Loader Buckets 13 Norden Mfg. LLC [phone]
4. Nomenclature
1
2
4
3
Item Description
1 Loader Bucket
2 Cutting Edge
3 Attachment Eyes
4 Attachment Hooks

Norden Mfg. LLC [phone] 14 Euro Loader Buckets
5. Assembly and Setup
5.1 Assembly Process
The loader bucket comes fully assembled from the
factory.
NOTICE
Confirm Proper Ballast
For light weight utility tractors, consult the Tractor
Operator’s Manual to determine if rear ballast is required
for heavy loads to maintain steering control.

Euro Loader Buckets 15 Norden Mfg. LLC [phone]
6. Usage
6.1 User Safety
Referto“2.4GeneralSafety”onpage8for
additional safety information.
6.1.1 Machine Operation Recommendations
WARNING
STOP
Roll Away Hazard
Before leaving the
operator’s seat, make
sure the engine is stopped, the transmission
is placed in park, the key is removed, and the
parking brake is set.
Crush Hazard
The weight of the machine, plus the
attachment, if it rolls onto a person, could
cause serious crushing injury or death.
Entanglement Hazard
If using a small compact or utility
tractor, keep hands and clothing
clear of any rotating parts. Stay clear of the
attachment while the machine is moving.
SAFETY
INSTRUCTIONS
The following safety instructions are provided to
help prevent injury or limit attachment damage.
SI
It is the owner’s responsibility to make
sure any person using a machine with the
attachment, especially if it is loaned or rented,
has been thoroughly trained on its proper and
safe use.
SI
Be certain only physically-able persons will
use the attachment.
SI
Users who have not read and understood
all operating and safety instructions are not
qualified to use the attachment.
SI
If the elderly are assisting with the work,
their physical limitations need to be
recognized and accommodated.
SI
Never allow children to use the attachment.
SI
Be especially observant of the operating
area and terrain – watch for loose fill,
holes, rocks or other hidden hazards. Always
inspect the area prior to operation.
SI
Be careful at the edge of ditches or gullies.
Be careful when working on inclines.
SI
Do not use excessive speed when moving
loads.
SI
Allow for attachment length when making
turns.
6.1.2 Machine Requirements
WARNING
Machine Operator Manual
Always refer to the machine’s
operator manual to ensure
compatibility and maximum safety.
The machine must be equipped with a front-end
loader with Euro attachment mounting style rated
to lift the attachment which can weigh up to 653
pounds plus the weight of the load.
SAFETY
INSTRUCTIONS
SI
Do not use an oversized machine; the
loader buckets are intended to be used on
machines rated up to 140 HP or a 3500 pound
operating capacity.
SI
Using the attachment with a machine that
exceeds the specified requirements may
cause machine or attachment damage, be a
potential danger to the operator or bystanders,
and will void any warranty.
SI
Always review the “controls” section of the
machine’s Operator Manual to be familiar
with the location, settings, and function of the
controls. Be familiar with all controls before
using this attachment.
6.2 Machine Specifications
This section is provided to give the operator general
safety information for the machine. Always follow the
OEM instructions given in the operator’s manual for
the machine.

Norden Mfg. LLC [phone] 16 Euro Loader Buckets
WARNING
Rollover Hazard
To avoid serious injury or death
from falling, runover, rollover, or
crushing, the machine must have an approved
Roll-Over Protective Structure (ROPS) or ROPS
cab and seat belt.
1. The machine must be equipped with an approved
Roll-Over Protective Structure (ROPS) or ROPS
cab and seat belt.
a. If equipped with a folding ROPS structure,
keep it locked in the UP position.
b. Only operate the machine when seated in the
operator seat.
c. Always fasten seat belt whenever the machine
is moving.
2. If working around dry grass or vegetation, to
reducetheriskofre,donotuseamachinewith
anunder-frameexhaust.
3. If the machine must travel on a public roadway,
followguidancegivenin“7.Transporting”on
page 21.
4. Maintain all manufacturer’s safety shields and
guards
6.3 Attaching to Machine
WARNING
Pinch Point Hazard
Use caution when connecting the
attachment to the machine. Keep
hands and feet from under the attachment
and clear of pinch points between bucket
and machine. Do not allow anyone to stand
between the machine and loader bucket during
attachment process.
1. Ensure there are no potential unintended collisions
between the attachment and the loader before
connectingthemforthersttime.
2. Tilt the tool carrier forward completely to angle the
carrier arms downward toward the attachment.
Position the tool carrier an inch below the
attachment hooks.
3. Drive the machine forwards slowly, centering
the carrier arms between the hooks on the
attachment.
4. When the tool carrier makes contact with the
attachment, raise the loader arms to engage both
hooks of the attachment on the tool carrier.
5. Roll the tool carrier back toward the machine.
6. If equipped, the hydraulic or electronic powered
locking pins can be engaged. In this case; skip
Steps 7, 8, and 9.
7. If your loader requires manual locking, perform a
full roll back to automatically lock the attachment
onto the tool carrier.
8. If your loader requires a fully manual locking
process:
WARNING
STOP
Roll Away Hazard
Before leaving the
operator’s seat, make
sure the engine is stopped, the transmission
is placed in park, the key is removed, and the
parking brake is set.
a. Raise the back of the attachment slightly off
the ground and angle it back to apply pressure
against the stops.
b. Shut off the machine.
c. Apply the parking brake.
d. Manually lock the attachment to the carrier
assembly.
WARNING
Injury Hazard
To avoid serious injury or death
caused from falling attachment: lock
pins must completely engage attachment eyes.
Crush Hazard
Do not stand under raised
attachment.
9. If equipped, the attachment’s locking lug will
impact/push aside the Click-on system on the
tool carrier, automatically locking the attachment
in position. The lock lever is released and moves
tothe“lockedattachment”position.
10. Raise the loader arms until the tool carrier is
clearly visible from the driver’s cab. Inspect
alignment and verify positioning.

Euro Loader Buckets 17 Norden Mfg. LLC [phone]
11. Pay attention to the tool carrier lock indicators,
whichmaydi󰀨erdependingonthetypeoftool
carrier installed on the loader. Carefully observe
howyourspecictoolcarrierindicatesalocked
attachment.
12. Before starting work with the loader/attachment,
readthe“6.4Pre-OperationChecklist”onpage
17 to ensure the attachment is correctly
locked onto the loader’s tool carrier:
• Visually check that the locking lever indicates a
locked attachment.
• Visually check that the tool carrier locking pins
are in the locked position.
13. Verify that the attachment is locked in place
on the tool carrier by pressing the front of the
attachment against the ground.
14. Before using the attachment, the operator must
operate it through its full range of motion and
conrmthattheattachmentissecureandsafe
6.4 Pre-Operation Checklist
Before each use of the attachment, the following
areas should be checked.
Checklist Before Each Use
þTask
Make sure the attachment is positively attached to the machine.
Referto“6.3AttachingtoMachine”onpage16.
If the machine uses tires, make sure they are inflated properly
and the lug nuts are tight.
Inspect the tires of the machine for full operational reliability.
Failureofthetirescouldresultindamagetothemachine,load,
or attachment.
Visually inspect the attachment for any worn parts or cracked
welds. Make necessary repairs before using the loader bucket
attachment.
Make sure the loader bucket is not bent or cracked.
Make sure the operating area is clear, especially of children and
animals.
6.5 Usage
Before using the attachment, the operator must
have a complete understanding of how to operate
the machine including all controls, and how to use
the attachment.
The operator should read and understand the Safety
and Operation Sections of the machine operator’s
manual. It is important to note that these manuals
mustbereadandexplainedtoanyoperatorwho
cannot read. It is crucial to never allow anyone to
operate the machine or use the attachment without
complete operating instructions.
To ensure safety to the operator, bystanders, and
equipment, the operator must become familiar
with the surrounding work area and any obstacles
and hazards contained within before starting any
operation. Special attention should be paid to foreign
debris, rough terrain, steep slopes, bystanders, or
animals in the area.
If the operator is not already familiar with the
process, it is recommended to practice lifting,
lowering, maneuvering, and placing a load on a level
siteuntilthecondenceandskillneededtosafely
move loads is achieved. It is important to follow the
safety operating procedures that are spelled out in
this Operator’s Manual.
WARNING
Crush Hazard
When handling loads, improper use
of the machine can result in serious
injury or death to the machine operator. This
could be caused by the contents of the load
falling or rolling backwards into the operator’s
station. Therefore, it is important to handle
loads safely.
CAUTION
Tip Over Hazard
It is important not to exceed 3,500 lbs. or
83% of the lift capacity of the machine.
The operator should not lift the load too high,
creating an unstable and unsafe situation. The
operator should also avoid tilting the load too
far forward, setting up a situation that could
cause the load to empty from the bucket
The operator must travel at a safe speed for
ground conditions. Travel slowly over rough
ground or when making turns. Working on or
around slippery or sloped areas could cause the
operator to lose control of the machine.
The operator must not allow bystanders, pets,
or livestock to approach the danger zone of the
working area.
The operator must not leave the machine with
the attachment raised off the ground.

Norden Mfg. LLC [phone] 18 Euro Loader Buckets
6.5.1 Picking Up a Load
1. Before raising loader, for overhead obstructions
and wires.
WARNING
Risk of Electric Shock,
Crushing, and Ramming.
Be sure to keep a safe distance
between the loader and power lines or barn
roofs when driving with the raised loader. Do
not touch the machine or attachment if they
come into contact with a live electric cable.
Back the tractor away from the cable or wait
until it is de-energized.
NOTICE
Care must be taken to ensure there is enough overhead
clearance and no potential hazards or obstructions that
could interfere with the lifting and placing of the loads.
2. Verifythattheloaddoesnotexceedthesmaller
of the two lift capacities:
• Rated lift capacity of the attachment.
• 83% of the rated lift capacity of the machine.
Note: Using 83% of the rated lift capacity accounts
for increased loader stresses caused by the
extendedattachmentandensurespropertire
rating.
NOTICE
Prying with the bucket’s edge or using the bucket with
excessive horsepower can damage the bucket and void its
warranty.
3. Center the bucket on the material to be picked
up.
WARNING
Before digging
Check for hidden live electrical
cables. Do not leave the driver’s
seat if any part of the tractor, loader, or tool
contacts a live electric cable. Avoid touching
the machine or attachment and the ground
simultaneously. Back the tractor away from the
cable or wait until it is de-energized.
Carefully approach the loading area,
ensuring no objects will come back into
the operator’s space, causing serious
injury or death.
If working on an uphill slope, drive
straight upwards, fill the bucket, and
reverse downhill while lowering the loader
as far as possible. Avoid driving along the
side of a slope to prevent overturning.
SAFETY
INSTRUCTIONS
Transport loads at a height that maintains a
clear line of sight and keep the load low to the
ground when possible to enhance stability.
4. Slowly drive into the pile without ramming the
bucket.
WARNING
Bystander Hazard
Keep all bystanders at a safe
distance when entering and picking
up a load. Objects can shift or be thrown
suddenly as the bucket makes contact with the
load, causing serious injury or death. Avoid
ramming the bucket into a pile as it can damage
the attachment.
5. Lift the load of material a short distance and tilt
the bucket back before traveling.
6. Conrmthattheloadisbalancedandsecurely
positioned.
Note: Ensure the material is properly secured before
traveling. Have good control of the load,
releasing and recapturing it if it’s not secure.
7. Verify that no animals or bystanders are behind
you and that it is safe to reverse.
8. Back the load out of the pile slowly, ensuring it
clears all other obstacles.
9. Position the load at a safe, low traveling height
before transferring it to the unloading site. It
is recommended to keep it two to four inches
above the ground
Note: To minimize jerking, stop and start the loader
gradually when lowering or lifting loads.
WARNING
Risk of falling.
Do not use the loader or the
attachment as a working platform.
Do not lift or transport people using the loader
or attachment.

Euro Loader Buckets 19 Norden Mfg. LLC [phone]
WARNING
Avoid standing, walking, or working under
or beside a raised loader. Keep everybody,
especially children and animals, away from
the work area. Always keep an eye on your
workplace.
Never carry out work with the attachment
that requires another person to be in the
work area.
NOTICE
No Chains.
Do not attach chains intended for lifting or securing loads
to the attachment, as it may cause damage.
SAFETY
INSTRUCTIONS
Always ensure the tractor is properly ballasted
before attempting to lift any load with the
attachment.
6.5.2 Traveling with a Load
1. Always yield to pedestrians.
2. Tilt the load back slightly, adjusting the tilt angle
of the attachment to prevent it from aiming at the
driver when the load is raised.
3. Keep the load low, preferably two to four inches
abovetheoor.
4. Continuously scan all sides for bystanders or
othertra󰀩c.
SI
Make sure that the work area is clear of
children, animals, and other obstacles
before using the attachment. This is particularly
important in areas with higher noise levels or
quiet cabs, as you may not hear people
shouting.
5. Maintain a safe and controlled speed, reduce
speed when turning, and avoid sudden braking.
6. Provide adequate clearance while turning to
avoid contact between the attachments, load,
and obstacles such as storage racks, buildings,
trees, or fences.
7. When traveling over ramps or inclines, keep the
loadonthe“uphill”sideofthemachine.
8. Whenever possible, travel straight on grades,
ramps, and inclines, avoiding turns.
9. Only raise or lower the load when the machine is
stopped, not during travel.
10. Reduce speed when traveling over rough or hilly
terrain.
11. Do not transport loads on public roadways.
12. If using public roadways, ensure safe
transportation to allow faster vehicles to pass.
13. Planyourroutetoavoidheavytra󰀩c.
14. Keep equipment away from electrical power
lines and place orange warning signs under
overhead electrical power lines to indicate the
danger.
6.5.3 Dumping the Load
1. Bring the machine to a stop in front of the
desired location for load placement.
2. Gradually raise the load to the required height.
3. Move the machine forward slowly with the load
raised until it is positioned squarely and directly
abovethenaldestination.
4. Tilt the front of the bucket down to release the
load. If necessary, raise the bucket up to allow
the load to fully discharge.
5. Once the load has settled onto the pile, rotate
the front of the bucket level.
6. After the load has settled, slowly back up while
watching for clearances, pedestrians, and other
tra󰀩c.
7. Leave enough clearance when turning and/or
lowering the bucket to prevent it from making
contact with obstacles such as vehicles,
buildings, trees, or fences.
8. Lower the bucket to transporting height (low to
the ground) before moving again.

Norden Mfg. LLC [phone] 20 Euro Loader Buckets
6.6 Detaching from Machine
CAUTION
Pinch / Crush Hazard
Use caution when disconnecting
the attachment from the machine.
Keep hands and feet from under the attachment
and clear of pinch points. Do not allow anyone
to stand near the machine or attachment when
disconnecting.
1. Movethemachineontoaat,level,solidsurface.
Lower the attachment slightly above the surface
with the hitch angled, front of the loader bucket
slightly higher than the rear.
2. If your machine is equipped with hydraulically
operated locking pins, retract the coupler lock at
this time. In this case; lower the attachment to
the ground and skip Steps 3, 4, and 5.
3. Shut down the machine and set the parking brake
properly without lowering the attachment.
WARNING
STOP
Unintended
Movement
Before leaving the
operator’s seat, make sure the engine is
stopped, the transmission is placed in park, the
key is removed, and the parking brake is set.
4. Move the locking lever to disengage the locking
pins.
5. Start the engine and lower the attachment to the
ground.
6. Tilt the tool carrier forward to allow the tool carrier
to clear the hooks on the attachment.
7. Make sure the area is clear of bystanders and
animals, then slowly back the machine away from
the attachment, ensuring that the tool carrier does
not interfere with the attachment.
