AF4 Hay Accumulator
Owner’s Manual
MADE IN THE USA

AF4 Hay Accumulator 3 Norden Mfg (877-296-5851)
CONTENTS
1. INTRODUCTION ..........................4
1.1 Intended Usage .......................4
1.2 Operator Orientation....................4
1.3 Specifications .........................4
1.4 Serial Number Location .................4
1.5 Owner/Operator Manual Storage ..........5
1.6 Product Improvements ..................5
1.7 Disposal of Equipment at End of Useful Life . 5
1.8 Unanswered Questions .................5
2. SAFETY .................................6
2.1 General..............................6
2.2 Safety Alert Symbol ....................6
2.3 Safety Icons Nomenclature ..............7
2.3.1 Personal Protection/Important
Information .....................7
2.3.2 Prohibited Actions ................7
2.3.3 Hazard Avoidance................7
2.4 General Operating Safety................8
2.5 Safety Signs ..........................8
2.6 Practice Safe Maintenance...............8
2.7 Training..............................8
2.8 Sign-Off Form ........................9
2.9 Operation Safety......................10
2.10 Transporting Safety ...................10
2.11 Storage Safety .......................10
2.12 Maintenance Safety ...................10
3. SAFETY SIGNS AND LABELS .............11
3.1 General Information ...................11
3.2 Contact Information ...................11
3.3 How to Install Replacement Safety Signs...11
3.4 Safety Sign Locations..................12
3.5 Hay Accumulator Safety Signs ...........13
4. NOMENCLATURE .......................14
4.1 Undercarriage........................15
4.2 Accumulator Bed .....................15
4.3 Linkage System ......................15
4.4 Belted Base Chute ....................15
4.5 Linkage System Operation ..............16
5. ASSEMBLY..............................17
6. OPERATION.............................22
6.1 User Safety Training ...................22
6.2 Tractor Requirements ..................22
6.2.1 Equipment and Capabilities .......23
6.2.2 Tractor Safety Devices ...........23
6.2.3 ROPS and Seat Belt .............23
6.3 Baler Hitch Setup .....................23
6.4 Baler Chamber Settings ................25
6.5 Baler Hitch Special Requirements ........25
6.5.1 Older New Holland® (NH) Balers ...25
6.5.2 Newer New Holland® Balers ......25
6.5.3 John Deere® (JD) Balers
(1988 and newer) ...............26
6.5.4 Inline Balers ...................26
6.6 Pre-Operation Checklist ...............26
6.7 Attaching to Baler .....................26
6.8 Operation ...........................27
6.8.1 Break In ......................27
6.8.2 Stuck Bale Removal .............27
6.9 Troubleshooting ......................27
6.9.1 Cornering .....................27
6.9.2 Hillsides ......................27
6.9.3 High Moisture Hay ..............27
6.10 Detaching From Baler .................28
7. TRANSPORTING.........................29
7.1 General Safety .......................29
7.2 Safety Chain .........................29
7.3 Highway and Transport Operations .......30
7.4 Pre-towing Checklist...................30
8. STORAGE...............................31
8.1 Placing in Storage ....................31
8.2 Removing from Storage ................31
9. MAINTENANCE ..........................32
9.1 Maintenance Safety ...................32
9.2 Lubrication ..........................33
9.3 Wheel Bearings ......................33
9.4 Tire Safety ..........................34
9.5 Tire Inflation .........................34
9.6 Bolt Torque Requirements ..............34
9.7 Standard Torque Values ................34
9.8 Welding Repairs ......................34
9.9 Service Record ......................35
10. PARTS SECTION.........................36
10.1 Ordering Parts .......................36
10.2 Contact Information ...................36
10.3 Decals..............................36
10.4 Hay Accumulator Undercarriage..........37
10.5 Hub Assembly........................38
10.6 Accumulator Bed and Chute.............39
10.7 Linkage System ......................40
10.8 Belt and Tensioner ....................41
10.9 Bale Chamber Extension ...............42

Norden Mfg (877-296-5851) 4 AF4 Hay Accumulator
1. Introduction
Using no hydraulics or electronics, the Norden Hay
Accumulator automatically arranges bales into
groups that can then be picked up with a Grabber
mounted on a loader. Handling multiple bales of
hay at one time allows wagons to be loaded more
quickly, as well as quicker stacking in the barn.
Please read the manual carefully to become
familiar with your new Norden Hay Accumulator.
This manual has been developed through our
experience with the equipment and feedback from
our customers. Ultimately it is our desire that you will
be operating your Hay Accumulator as a seasoned
professional in no time!
1.1 Intended Usage
Do not use this Hay Accumulator for any other
purpose than its intended use of arranging bales into
groups that can then be picked up with Grabbers.
1.2 Operator Orientation
The directions left, right, front, and rear, as
mentioned throughout this manual, are as seen from
the tractor operator’s seat and facing in the direction
of travel.
1.3 Specifications
Overall Width 88"
Overall Length 155"
Overall Height 84”
Overall Weight 1300 lb.
Bale Capacity 4
Bale Size 14 x 18” or 16 x 18”,
32 to 40” long
Tires ST 225/75R15
Specifications subject to change without notice.
1.4 Serial Number Location
The Hay Accumulator’s serial number is located
near the front of the Hay Accumulator Bed. Please
use this number when requesting service, seeking
information, or ordering parts. Record the serial
number in the space provided for easy reference
when contacting Norden Mfg LLC with questions.
Serial Number ______________________________
Date of Purchase ___________________________

AF4 Hay Accumulator 5 Norden Mfg (877-296-5851)
1.5 Owner/Operator Manual Storage
Store the Owner/Operator manual and other
operating materials in the document storage tube,
located on the left axle frame.
KN-00056
1.6 Product Improvements
Because Norden Mfg LLC maintains an ongoing
program of product improvement, we reserve the
right to make improvements in design or changes
in specifications without incurring any obligation to
install them on units previously sold.
1.7 Disposal of Equipment at End of Useful
Life
The Norden Mfg LLC Hay Accumulator has been
designed for the specific purpose of arranging bales
into groups. When this unit is no longer capable of
performing its intended use, it should be dismantled
and scrapped. Do not use any materials or
components from this unit for any other purpose.
1.8 Unanswered Questions
If you have any questions not answered in this
manual, require additional copies, or the manual is
damaged, please contact your dealer or:
Norden Mfg LLC
4210 Kinsman Road NW
North Bloomfield, OH 44450
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
The manual is also available for download at:
www.Nordenmfg.com

Norden Mfg (877-296-5851) 6 AF4 Hay Accumulator
2. Safety
2.1 General
Most work related accidents are caused by failure
to observe basic safety rules or precautions. An
accident can often be avoided by recognizing
potentially hazardous situations before an accident
occurs. As you operate and maintain the Hay
Accumulator, you must be alert to potential hazards.
You should also have the necessary training, skills,
and tools to perform any assembly procedure.
Improper operation and/or maintenance of this
unit could cause a dangerous situation that
results in injury or death.
Do not use this unit until you read and
understand the information contained in this
manual. Do not use the Hay Accumulator for
anything other than its intended purpose.
WARNING
Do not use the unit until you read and
understand the information contained in
this manual and all related equipment
manuals.
Safety precautions and warnings are
provided in this manual and on the unit. If
these hazard warnings are not heeded,
bodily injury or death could occur to you or
to other persons.
Norden Mfg LLC cannot anticipate every
possible circumstance that might involve
a potential hazard. The warnings in this
manual and on the product are, therefore,
not all-inclusive. If a method of operation not
specically recommended by us is used, you
must satisfy yourself that it is safe for you and
for others. You should also ensure that the unit
will not be damaged or be made unsafe by the
methods that you choose.
The information, specifications, and illustrations in
this manual are based on the information that was
available at the time this material was written and
can change at any time.
2.2 Safety Alert Symbol
This is the safety alert symbol. It is used to
alert you to potential personal injury
hazards. Obey all safety messages that
follow this symbol to avoid possible injury
or death.
This manual contains WARNINGS, CAUTIONS,
NOTICES, SAFETY INSTRUCTIONS, and NOTES
which must be followed to prevent the possibility
of improper service, damage to the equipment,
personal injury, or death. The following key words
call the reader’s attention to potential hazards.
Hazards are identified by the “Safety Alert Symbol”
and followed by a signal word such as “WARNING”
or “CAUTION”.
WARNING
Indicates a potentially hazardous situation which,
if not avoided, could result in death or serious
injury.
CAUTION
Indicates a potentially hazardous situation which,
if not avoided, may result in minor or moderate
injury.
NOTICE
Indicates that equipment or property damage can
result if instructions are not followed.
SAFETY
INSTRUCTIONS
Safety instructions (or equivalent) signs indicate
specific safety-related instructions or
procedures.
Note: Contains additional information important to a
procedure.

AF4 Hay Accumulator 7 Norden Mfg (877-296-5851)
2.3 Safety Icons Nomenclature
This manual and the equipment has numerous
safety icons. These safety icons provide important
operating instructions which alert you to potential
personal injury hazards
2.3.1 Personal Protection/Important Information
Read the manual
Eye protection
Hearing protection
Hand protection
Foot protection
First aid kit
Fire extinguisher
Inspect equipment
Use proper tools
Use support stands
Weight rating
OEMOEM
Use OEM parts
Use ROPS and seat belt
N
I
NG
AR
Maintain safety signs
Place in park
Remove key
STOP
Stop engine
Visibility
Set parking brake
2.3.2 Prohibited Actions
Do not alter or modify
Do not weld
No riders
No children
No alcohol
No drugs
2.3.3 Hazard Avoidance
Crushing hazard
Crushing hazard
Slipping hazard
Tripping hazard
Falling hazard
Fire hazard
Safety alert symbol
Maintain tire pressure
Defective or broken part
Chock wheels
Maintain safe distance
Pinch point hazard
Overturn hazard
Negative tongue weight hazard
Rollover hazard

Norden Mfg (877-296-5851) 8 AF4 Hay Accumulator
2.4 General Operating Safety
WARNING
Read And Understand Manual
To prevent personal injury or even death,
be sure you read and understand all of the
instructions in this manual and other related
OEM equipment manuals! This Hay Accumulator
(unit) was designed for a specific application;
DO NOT modify or use this unit for any
application other than that for which it was
designed. Units operated improperly or by
untrained personnel can be dangerous!
Inexperienced operators should receive
instruction from someone familiar with the
equipment before being allowed to operate the
unit.
Do Not Operate
Do not use the unit if it is in need
of repair. If you believe the unit
has a defect which could cause injury or
death, you should immediately stop using the
unit.
Fall Hazard
Do not use the unit as a platform. Do not
climb on the unit. Do not stand on the unit
at any time. Do not ride on the unit or allow
others to ride on it.
Pinch Point Hazard
Keep hands and feet away from any
moving parts to prevent them from getting
pinched.
Impaired User Hazard
Do not attempt to assemble,
operate, or maintain the Hay
Accumulator under the influence of drugs or
alcohol. Consult your doctor before using the
Hay Accumulator while taking prescription
medications.
Falling Hazard
Do not allow riders on the tractor,
or Hay Accumulator at any time.
Falling can result in severe injuries or death.
Stay Clear
Clear the area of people, especially
small children, before using the Hay
Accumulator. Under no circumstances should
young children be allowed to work with or
around the Hay Accumulator.
2.5 Safety Signs
CAUTION
N
I
NG
AR Legible Safety Signs
Keep safety signs clean and legible at all
times. Replace any safety sign or
instruction sign that is missing or not legible.
Refer to the Safety Sign Location section for
additional information.
Replacement parts that displayed a safety sign
should also display the current sign.
Replacement safety signs (labels) are available
from your authorized Dealer Parts Department
or the factory at no cost.
2.6 Practice Safe Maintenance
SAFETY
INSTRUCTIONS
Understand service procedures before
doing any work. Keep the work area clean
and dry.
Keep all parts in good working
condition and properly installed.
Replace worn or broken parts
immediately.
Do not modify the unit or its safety
devices. Do not weld on the unit.
Unauthorized modifications may impair its
function and safety.
2.7 Training
Anyone who will be using and/or maintaining the
Hay Accumulator must read, clearly understand,
and follow ALL safety, operation, and maintenance
information presented in this manual, other related
OEM manuals, and the safety signs.
If you do not understand any information in this
manual, see your dealer or contact Norden Mfg LLC
before proceeding.
Do not use or allow anyone else to use this Hay
Accumulator until all information has been reviewed.
Annually review this manual before the season start-
up.
Make periodic reviews of SAFETY and OPERATION
a standard practice. An untrained operator is not
qualified to use this Hay Accumulator.

AF4 Hay Accumulator 9 Norden Mfg (877-296-5851)
2.8 Sign-Off Form
Norden Mfg LLC follows the general Safety
Standards specified by the Farm Equipment
Manufacturers Association (FEMA), and the
American National Standards Institute (ANSI).
Anyone who will be using and/or maintaining the
Hay Accumulator must read and clearly understand
ALL safety, operation and maintenance information
presented in this manual.
Do not use or allow anyone else to use this
equipment until all information has been reviewed.
Annually review this manual before the season start-
up.
Sign-O󰀨 Form
Date User’s Signature Owner’s Signature
Make periodic reviews of SAFETY and OPERATION
of the Hay Accumulator a standard practice. An
untrained operator is not qualified to use this Hay
Accumulator.
This sign-off sheet is provided for your records to
show that all personnel who will be working with
the equipment have read and understand the
information in this Operation and Parts Manual
and have been instructed in the operation of the
equipment.

Norden Mfg (877-296-5851) 10 AF4 Hay Accumulator
2.9 Operation Safety
Refer to “2.4 General Operating Safety” on page
8 for safety recommendations related to
using the Hay Accumulator. All applicable safety
recommendations in other sections should also be
followed.
2.10 Transporting Safety
Refer to “7. Transporting” on page 29 for safety
recommendations related to transporting the Hay
Accumulator. All applicable safety recommendations
in other sections should also be followed.
2.11 Storage Safety
Refer to “8. Storage” on page 31 for safety
recommendations related to storing the Hay
Accumulator. All applicable safety recommendations
in other sections should also be followed.
2.12 Maintenance Safety
Refer to “9. Maintenance” on page 32 for safety
recommendations related to maintaining the Hay
Accumulator. All applicable safety recommendations
in other sections should also be followed.

AF4 Hay Accumulator 11 Norden Mfg (877-296-5851)
3. SAFETY SIGNS AND LABELS
3.1 General Information
The types of safety signs (hazard labels) and
instructional labels, along with their locations on the
equipment, are shown in the following illustrations.
Good safety practices require that you familiarize
yourself with the various safety signs, the type
of warning, and the area or particular operation
related to that area that requires your SAFETY
AWARENESS.
THINK
SAFETY!
Think SAFETY!
Work SAFELY!
Pay close attention to the safety signs and
instructional labels attached to the tractor, baler, and
Hay Accumulator. The safety signs attached to the
Hay Accumulator are reproduced in this section. If
the Hay Accumulator is missing a label or one is
unreadable, replace the label before using the Hay
Accumulator.
SAFETY
INSTRUCTIONS
N
I
NG
AR Safety Signs and Instructional
Labels
Keep safety signs or instructional labels clean
and legible at all times. Use a clean, damp cloth
to clean safety decals.
1. Replace any missing or hard-to-read safety
signs or instructional labels.
2. Use care when washing or cleaning the
equipment. Make sure not to remove or
damage the labels. When using a pressure
washer to clean the Hay Accumulator, avoid
spraying too close to decals; high-pressure
water can enter through very small scratches
or under edges of decals causing them to peel
or come o󰀨.
3. Locations for the labels and replacement part
numbers are shown in this section.
4. Replacement parts must have replacement
labels attached before the Hay Accumulator is
used.
5. Labels are available from your authorized
dealer or from Norden Mfg LLC at no charge.
3.2 Contact Information
For replacement decals, contact:
Norden Mfg
4210 Kinsman Road NW
North Bloomfield, OH 44450
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
3.3 How to Install Replacement Safety
Signs
1. Clean and dry the installation area.
Note: Do not install the signs if the temperature is
below 50°F.
2. Determine the exact position before you remove
the backing paper.
3. Remove the backing paper.
4. Align the sign over the specified area and
carefully press the sign to the part/frame.
Note: Small air pockets can be pierced with a pin
and smoothed out using the piece of backing
paper.

Norden Mfg (877-296-5851) 12 AF4 Hay Accumulator
3.4 Safety Sign Locations
Item Type Description Qty.
1 WARNING Read the Manual 1
2 WARNING No Riders 4
3 INFORMATIONAL Serial Number 1
4 WARNING Pinch Point 6
5 WARNING Do Not Transport at Speeds Over 20 MPH 1
6 WARNING Fall Hazard 4

AF4 Hay Accumulator 13 Norden Mfg (877-296-5851)
3.5 Hay Accumulator Safety Signs
1.
READ THE
MANUAL
Do not operate or perform
service on unit without
reading and understanding
Owner’s manual.
Avoid unsafe operating
methods or maintenance
procedures.
If manual is lost, go to
www.kuhnsmfg.com to
download a manual.
KN-00045
To avoid serious injury or death:
2. KN-00047
WARNING
NO RIDERS
3.
4.
PINCH POINT
CAUTION
KN-00046
• Pinch points may cause
injuries such as cutting or
crushing.
• Do not place hand or fingers
between stationary and
moving parts.
• Stay clear of moving parts.
5. KN-00048
DO NOT transport at speeds above 20 mph.
Exceeding 20 mph may cause loss of control
and serious personal injury.
ONLY transport behind a properly sized and
equipped tow vehicle. ALWAYS properly
fasten the implement to the tow vehicle.
REDUCE speed on inclines, while turning, and
when towing in adverse conditions.
ENSURE an SMV emblem can be clearly seen
from behind the unit. Turn ON the tow vehicle
flashing warning lights when transporting.
1.
2.
3.
4.
WARNING
6.
FALLING HAZARD
Do not climb or stand on the unit at
any time.
Do not use the unit as a platform.
Falling can result in serious injury
or death.
KN-00053
7.

Norden Mfg (877-296-5851) 14 AF4 Hay Accumulator
4. Nomenclature
KN-00000
5
14
9
13
16
12
11
10
15
8
6
7
3
4
2
1
17
Item Description
1 Main Chute
2 Belted Base Chute
3Belt Tensioner
4 Hitch
5 Hexagon Plate
6 Jack
7 Reach Pole
8 Tires, ST225/75R15
9 Accumulator Bed
Item Description
10 Back Gate
11 Back Gate Paddle
12 Slow Moving Vehicle Sign
13 Gate #1
14 Gate #2
15 Gate #3
16 Gate Flipper
17 Side Panels

AF4 Hay Accumulator 15 Norden Mfg (877-296-5851)
4.1 Undercarriage
The Hay Accumulator’s undercarriage supports the
overall unit and includes the axle frames, wheel
assemblies, reach poles, base chute bottom, and
the hitch.
KN-00001
4.2 Accumulator Bed
The accumulator bed guides and positions the bales
on the accumulator.
KN-00002
4.3 Linkage System
The linkage system directs the bales through the
accumulator bed. The system consists of three
gates, one gate flipper, a back gate, and six springs.
KN-00003
4.4 Belted Base Chute
The belted base chute is standard equipment on the
AF4 Hay Accumulator and will eliminate cornering
issues.
KN-00004

Norden Mfg (877-296-5851) 16 AF4 Hay Accumulator
4.5 Linkage System Operation
1. Bale #1 enters the Hay Accumulator and slides
downward and into position, rotating the left gate
to open row #2.
KN-00005
2. Bale #2 enters the Hay Accumulator and slides
downward and into position, rotating the gate
flipper and shifting the center gate to open row
#3.
KN-00006
3. Bale #3 enters the Hay Accumulator and slides
downward and into position, rotating the right
gate to open row #4.
KN-00007
4. Bale #4 enters the Hay Accumulator and slides
downward. As it slides into position, it depresses
the back gate paddle, releasing the gate.
KN-00008
5. Once the back gate is open, the bales drop to
the ground. When all bales are clear, the back
gate returns to its original position and latches. All
gates return to their original position.
KN-00009

AF4 Hay Accumulator 17 Norden Mfg (877-296-5851)
5. Assembly
1. If the AF4 Hay Accumulator and EGF8 Grabber
are palletized together for shipment. Begin
assembly by removing all components from the
shipping pallet.
WARNING
Read the Manual
The EGF8 Grabber has a separate Owner’s
Manual, contained in the document storage
canister located on the Grabber frame. Do
not use the Grabber until you read and
understand the information contained in its
manual and all related equipment manuals.
2. Attach a suitable lifting device to the front lifting
eye, and lift the accumulator bed assembly. It will
tip backwards as shown. The accumulator bed
assembly weighs approximately 600 pounds.
KN-00010
WARNING
Crush Hazard
The accumulator bed weighs
approximately 600 pounds and can cause
serious injury or death if it falls on a person.
Use a lifting device with adequate capacity to
support the accumulator bed. Use extreme
caution when working under the accumulator
bed when it is supported by a lifting device.
3. With the bed tipped up as shown, attach the axle
frames using eight 1/2 x 3” bolts and serrated
ange nuts provided. Make sure the axle frames
are installed on the correct side, as shown.
Tighten to the proper torque value.
Note: Refer to “9.7 Standard Torque Values” on
page 34 for the proper torque value for all
fasteners.
KN-00011
4. Insert the spindles into the axle sleeves, and
retain them with two 3/8 x 2-3/4” bolts and nylon
lock nuts. Tighten to the proper torque value.
KN-00012

Norden Mfg (877-296-5851) 18 AF4 Hay Accumulator
5. Attach both wheels using the lug nuts provided.
Lower the Hay Accumulator until both wheels and
the back end are on the ground, as shown. Block
both sides of each wheel. Remove the lifting
device.
KN-00013
6. Insert the reach poles into the sleeves on the axle
frames, as shown. Bolt the reach poles in place
using four 1/2 x 3” bolts and serrated ange nuts
provided. Do not fully tighten the bolts.
KN-00014
Note: The reach poles can be inserted in either
direction.
7. Using two people, rotate the Hay Accumulator
forward until the reach poles are approximately
level to the ground. The assembly will still be
heavy to the back. Place blocks under the back of
the accumulator bed to keep it from tipping back
during the next step.
KN-00015
WARNING
Negative Tongue Weight Hazard
To prevent serious injury from upending,
do not allow anyone to stand over the
reach poles or base chute during assembly.
8. Bolt the base chute bottom to the front of the
reach poles using four 1/2 x 3” bolts and serrated
ange nuts. Do not fully tighten the bolts.
KN-00016
Note: After the base chute bottom is attached, the
accumulator will be heavy to the front, and will tip
forward.

AF4 Hay Accumulator 19 Norden Mfg (877-296-5851)
9. Bolt the roller assembly into position using three
5/8 x 1-1/2” bolts (1) and nylon lock nuts on each
side. Use 5/8” at washers (2) on the positioning
bolts. Do not use washers on the pivot bolts.
Leave the pivot bolts loose enough that the
roller assembly can still pivot. Rotate the roller
assembly to make the roller shafts vertical, then
tighten the four positioning bolts to lock it into
position.
KN-00017
1
2
ROLLER SHAFT VERTICAL
WITH GROUND
10. Attach the base chute sides using ve 3/8 x 1”
serrated ange bolts and nuts on each side.
Make sure the anges are to the outside, as
shown. Do not fully tighten the bolts.
KN-00018
11. Attach the base chute top using two 3/8 x 1”
serrated ange bolts and nuts on each side. Do
not fully tighten the bolts.
KN-00019
12. If the hay dog is not already bolted to the base
top, bolt it on using two 3/8 x 1” serrated ange
bolts and nuts.
KN-00020
13. Bolt the hexagon plate into position using two
3/8 x 2-3/4” bolts and nuts. This part is not
symmetrical and will only t one way. Make
sure the top surface of the hexagon is ush and
parallel with the accumulator bed. Do not fully
tighten the bolts.
KN-00021

Norden Mfg (877-296-5851) 20 AF4 Hay Accumulator
14. Bolt the jack mount onto the left reach pole 24”
from the front end using four 7/16 x 3” bolts and
nylon lock nuts. Tighten the bolts to the proper
torque value.
KN-00022
24”
15. Attach the jack to the mount with the retaining
pin, and adjust the height, as needed, to make
the reach poles parallel to the ground.
KN-00023
REACH POLES LEVEL
WITH THE GROUND
16. Attach the main chute using six 3/8 x 1” serrated
ange bolts (1) and nuts at the bottom and two
3/8 x 1” carriage bolts (2) with serrated ange
nuts at the top. Do not fully tighten the bolts.
KN-00024
2
1
17. Bolt the side panels to the hexagon plate and
the accumulator bed using six 3/8 x 3/4” serrated
ange bolts (1) and nuts on each side. Bolt the
side panels to the main chute using two 3/8 x
3/4” carriage bolts (2) with serrated ange nuts
on each side. Do not fully tighten the bolts.
KN-00025
1
2
18. Bolt the chute tops into position using three 3/8
x 3/4” carriage bolts with serrated ange nuts on
each side. Tighten the bolts to the proper torque
value.
KN-00026
