USER'S MANUAL
CAUT ON
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
Serial Number
Decal
Model No. NTL01308.0
Serial No.
Write the serial number in the space
above for reference.
www.nordictrack.com
QUEST ONS?
If you have questions, or if parts are
damaged or missing, DO NOT
CONTACT THE STORE; please
contact Customer Care.
MPORTANT: You must note the
product model number and serial
number (see the drawing above)
before contacting us:
CALL TOLL-FREE:
1-888-825-2588
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–4 p.m. MT
ON THE WEB:
www.nordictrackservice.com

TABLE OF CONTENTS
WARNIN DECALPLACEMENT ..............................................................2
IMPORTANTPRECAUTIONS .................................................................3
BEFOREYOUBE IN .......................................................................6
ASSEMBLY ...............................................................................7
OPERATIONANDADJUSTMENT ............................................................14
HOWTOFOLDANDMOVETHETREADMILL ..................................................27
TROUBLESHOOTIN ......................................................................29
EXERCISE UIDELINES ...................................................................32
PARTLIST ...............................................................................34
EXPLODEDDRAWIN .....................................................................36
ORDERIN REPLACEMENTPARTS ..................................................BackCover
LIMITEDWARRANTY...............................................................BackCover
NordicTrack is a registered trademark of ICON IP, Inc.
2
This drawing shows the locations of the
warning decals. f a decal is missing or il-
legible, call the telephone number on the
front cover of this manual and request a
free replacement decal. Apply the decal
in the location shown. Note: The decals
may not be shown at actual size.
WARN NG DECAL PLACEMENT

3
1. Before beginning this or any exercise pro-
gram, consult your physician. This is espe-
cially important for persons over age 35 or
persons with pre-existing health problems.
2. t is the responsibility of the owner to ensure
that all users of this treadmill are adequately
informed of all warnings and precautions.
3. Use the treadmill only as described.
4. Place the treadmill on a level surface, with at
least 8 ft. (2.4 m) of clearance behind it and 2
ft. (0.6 m) on each side. Do not place the
treadmill on any surface that blocks air open-
ings. To protect the floor or carpet from dam-
age, place a mat under the treadmill.
5. Keep the treadmill indoors, away from mois-
ture and dust. Do not put the treadmill in a
garage or covered patio, or near water.
6. Do not operate the treadmill where aerosol
products are used or where oxygen is being
administered.
7. Keep children under age 12 and pets away
from the treadmill at all times.
8. The treadmill should be used only by per-
sons weighing 350 lbs. (159 kg) or less.
9. Never allow more than one person on the
treadmill at a time.
10. Wear appropriate exercise clothes when
using the treadmill. Do not wear loose
clothes that could become caught in the
treadmill. Athletic support clothes are recom-
mended for both men and women. Always
wear athletic shoes. Never use the treadmill
with bare feet, wearing only stockings, or in
sandals.
11. When connecting the power cord (see page
14), plug the power cord into a surge suppres-
sor (not included) and plug the surge sup-
pressor into a grounded circuit capable of
carrying 15 or more amps. No other appliance
should be on the same circuit. Do not use an
extension cord.
12. Use only a single-outlet surge suppressor that
meets all of the specifications described on
page 14. To purchase a surge suppressor, see
your local NordicTrack dealer or call the tele-
phone number on the front cover of this man-
ual and order part number 146148, or see your
local electronics store.
13. Failure to use a properly functioning surge
suppressor could result in damage to the con-
trol system of the treadmill. f the control sys-
tem is damaged, the walking belt may slow,
accelerate, or stop unexpectedly, which may
result in a fall and serious injury.
14. Keep the power cord and the surge suppres-
sor away from heated surfaces.
15. Never move the walking belt while the power
is turned off. Do not operate the treadmill if
the power cord or plug is damaged, or if the
treadmill is not working properly. (See
TROUBLESHOOT NG on page 29 if the tread-
mill is not working properly.)
16. Read, understand, and test the emergency
stop procedure before using the treadmill (see
HOW TO TURN ON THE POWER on page 16).
17. Never start the treadmill while you are stand-
ing on the walking belt. Always hold the
handrails while using the treadmill.
WARN NG: To reduce the risk of serious injury, read all important precautions and in-
structions in this manual and all warnings on your treadmill before using your treadmill. CON as-
sumes no responsibility for personal injury or property damage sustained by or through the use of
this product.
MPORTANT PRECAUT ONS

4
18. The treadmill is capable of high speeds.
Adjust the speed in small increments to
avoid sudden jumps in speed.
19. The pulse sensor is not a medical device.
Various factors, including the user's move-
ment, may affect the accuracy of heart rate
readings. The pulse sensor is intended only
as an exercise aid in determining heart rate
trends in general.
20. Never leave the treadmill unattended while it
is running. Always remove the key, unplug
the power cord, and switch the reset/off cir-
cuit breaker to the “off” position when the
treadmill is not in use. (See the drawing on
page 6 for the location of the reset/off circuit
breaker.)
21. Do not attempt to raise, lower, or move the
treadmill until it is properly assembled. (See
ASSEMBLY on page 7, and HOW TO FOLD
AND MOVE THE TREADM LL on page 27.) You
must be able to safely lift 45 lbs. (20 kg) to
raise, lower, or move the treadmill.
22. Do not change the incline of the treadmill by
placing objects under the treadmill.
23. When folding or moving the treadmill, make
sure that the storage latch is holding the
frame securely in the storage position.
24. nspect and properly tighten all parts of the
treadmill regularly.
25. Never insert or drop any object into any
opening on the treadmill.
26. DANGER: Always unplug the power
cord immediately after use, before cleaning
the treadmill, and before performing the main-
tenance and adjustment procedures de-
scribed in this manual. Never remove the
motor hood unless instructed to do so by an
authorized service representative. Servicing
other than the procedures in this manual
should be performed by an authorized service
representative only.
27. The treadmill is intended for in-home use
only. Do not use the treadmill in any commer-
cial, rental, or institutional setting.
28. To protect the treadmill and television during
lightning storms, unplug the power cord from
the wall outlet and disconnect the cable sys-
tem. This will prevent damage due to light-
ning and power line surges.
29. f an outside antenna or cable system is con-
nected, be sure that the antenna or cable sys-
tem is grounded to provide some protection
against voltage surges and built-up static
charges. Section 810 of the National
Electrical Code, ANS /NFPA No. 70-1984, pro-
vides information with respect to proper
grounding of the mast and supporting struc-
ture, grounding of the lead-in wire to an an-
tenna discharge unit, size of grounding con-
ductors, location of antenna discharge unit,
connection to grounding electrodes, and re-
quirements for the grounding electrode.
30. An outside antenna system should not be lo-
cated in the vicinity of overhead power lines
or other electric light or power circuits, or
where it can fall into such power lines or cir-
cuits. When installing an outside antenna sys-
tem, extreme care should be taken to keep
from touching such power lines or circuits, as
contact with them might be fatal.

5
SAVE THESE NSTRUCT ONS
Power Lines
round
Clamps
round
Clamps
round
Clamp
Bonding
Jumper
Standoff
Insulators
Antenna
Lead-in Wire
round Wire
round
Wire Antenna
Discharge Unit
To External 75 Ohm
Terminal of Treadmill
Mast
Service
Entrance
Equipment
Power Service rounding
Electrode System (e.g.
Interior Metal Water Pipe)
Service
Entrance
Conductors
Optional Antenna rounding Electrode Driven 8
Feet (2.44 m) Into The Earth (If Required By Local
Codes). See NEC Section 810–21 (f).
31. Upon completion of any service or repairs to
the treadmill or the television, ask the service
technician to perform safety checks to con-
firm that the unit is in proper operating condi-
tion.
• Use No. 10 AWG (5.3 mm2) copper, No. 8
AWG (8.4 mm2)aluminum, No. 17 AWG (1.0
mm2) copper-clad steel or bronze wire, or
larger as a ground wire.
• Secure an antenna lead-in and ground
wires to the house with stand-off insulators
spaced from 4 to 6 feet (1.22 to 1.83 m)
apart.
• Mount an antenna discharge unit as close
as possible to where the lead-in enters the
house.
• Use a jumper wire not smaller than No. 6
AWG (13. 3mm2) copper, or the equivalent
when a separate antenna-grounding elec-
trode is used. See NEC Section 810-21 (j).
Note to CATV system installer: This reminder is
provided to call the CATV system installerʼs at-
tention to Article 820-40 of the NEC that provides
guidelines for proper grounding and, in particu-
lar, specifies that the cable ground shall be con-
nected to the grounding system of the building,
as close to the point of cable entry as practical.

6
Thank you for selecting the revolutionary NordicTrack®
VIEWPOINT 3200 treadmill. The VIEWPOINT 3200
treadmill offers a selection of features designed to
make your workouts at home more enjoyable and ef-
fective. And when youʼre not exercising, the unique
treadmill can be folded up, requiring less than half the
floor space of other treadmills.
For your benefit, read this manual carefully before
using the treadmill. If you have questions after read-
ing this manual, please see the front cover of this man-
ual. To help us assist you, note the product model
number and serial number before contacting us. The
model number and the location of the serial number
decal are shown on the front cover of this manual.
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
BEFORE YOU BEG N
Handrail
Console/Television
Fan
Key/Clip
Reset/Off
Circuit Breaker
Walking Belt
Foot Rail
Power Cord
Platform Cushion
Idler Roller
Adjustment Bolts
Accessory Tray
Pulse Sensor

ASSEMBLY
Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not
dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking
belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to
the top of the walking belt or the shipping carton. This is a normal condition and does not affect treadmill perfor-
mance. If there is lubricant on top of the walking belt, simply wipe off the lubricant with a soft cloth and a mild,
non-abrasive cleaner.
Assembly requires the included hex key and your own Phillips screwdriver , rubber
mallet , and adjustable wrench .
Use the drawings below to identify the assembly hardware. The number in parentheses below each drawing is
the key number of the part, from the PART LIST near the end of this manual. The number after the parentheses
is the quantity needed for assembly. Note: f a part is not in the hardware kit, check to see if it is preattached
to one of the parts to be assembled. To avoid damaging plastic parts, do not use power tools for assem-
bly. Extra hardware may be included.
1. Make sure that the power cord is unplugged.
With the help of a second person, carefully tip
the treadmill onto its side as shown. Partially fold
the Frame (55) so that the treadmill is more sta-
ble. Do not fully fold the Frame until the
treadmill is completely assembled.
Insert a Base Extension (97) into the indicated
bracket on the base of the Uprights (85). Make
sure that the Base Extension is turned so the
Base Foot (81) is on the side shown. If neces-
sary, use a rubber mallet to align the holes in the
Base Extension with the holes in the bracket.
Attach the Base Extension (97) with two 5/16" x
2" Bolts (87), two 5/16" Star Washers (110), and
two 5/16" Base Extension Nuts (91) as shown.
Firmly tighten the Bolts.
#8 x 3/4" Screw
(7)–6
5/16" Star
Washer (110)–4
5/16" Base Extension
Nut (91)–4
3/8" Star
Washer (67)–4
3/8" Nut (20)–2
#8 x 2 1/4" Screw (63)–4
#8 x 1" Tek Screw
(82)–8
5/16" x 2" Bolt (87)–4
3/8" x 1 1/4" Bolt
(72)–4
3/8" x 1 3/4" Bolt
(109)–2
85
Bracket
81
55
87
91
1
110
97
7

8
2. Attach two Base Feet (81) to the base of the
Uprights (85) in the indicated locations with two
#8 x 1" Tek Screws (82). Note: One replacement
Base Foot may be included. Use the Base Foot to
replace any Base Foot that becomes worn. 85
81
82
82
2
3. With the help of a second person, carefully tip
the treadmill onto its other side as shown.
Partially fold the Frame (55) so that the treadmill
is more stable. Do not fully fold the Frame
until the treadmill is completely assembled.
Insert the other Base Extension (97) into the in-
dicated bracket on the base of the Uprights (85).
Attach the Base Extension (97) with two 5/16" x
2" Bolts (87), two 5/16" Star Washers (110), and
two 5/16" Base Extension Nuts (91) as shown.
Firmly tighten the Bolts.
87
110
85
91
97
55
3
4. Attach two Base Feet (81) to the base of the
Uprights (85) in the indicated locations with two
#8 x 1" Tek Screws (82).
With the help of a second person, carefully tip
the treadmill so that all the Base Feet (81) are
resting on the floor and the Uprights (85) are in
the vertical position.
81
82
82
85
4
81
81
Bracket

9
6. Identify the Left Base Cover (88), which has
cutouts in the locations shown. Slide the Left
Base Cover onto the left Upright (85). Then, slide
the Right Base Cover (86) onto the right Upright.
Identify the Left Upright Sleeve (77) and the Right
Upright Sleeve (9). Slide the Upright Sleeves onto
the Uprights (85) as shown. 88
77
86
9
85
Left
Right
Cutouts
6
5. Raise the Frame (55) to the position shown.
Have a second person hold the Frame until
this step is completed.
Orient the Storage Latch (76) so that the large
barrel and the Latch Knob (50) are in the posi-
tions shown.
Remove the tie from the upper end of the
Storage Latch (76). Attach the upper end of the
Storage Latch to the bracket on the Frame (55)
with a 3/8" x 1 3/4" Bolt (109) and a 3/8" Nut
(20).
Remove the tie from the lower end of the
Storage Latch (76). Keep the holes in the Latch
Cap (53) aligned with the holes in the Storage
Latch. Make sure to keep the Latch Cap in-
side the Storage Latch. Attach the Storage
Latch to the bracket on the Uprights (85) with a
3/8" x 1 3/4" Bolt (109) and a 3/8" Nut (20).
Note: It may be necessary to move the Frame
(55) back and forth to align the Storage Latch
with the bracket on the Upright.
Lower the Frame (55) (see HOW TO LOWER
THE TREADMILL FOR USE on page 28).
76
20
20
Large
Barrel
85
109
55
5
109
50
53

10
9. Attach the console assembly to the Uprights
(85) with four 3/8" x 1 1/4" Bolts (72) and four
3/8" Star Washers (67) (only one side is shown).
Start all four Bolts before tightening any of
them.
67
72
85
Console
Assembly
9
8. Remove the band securing the TV Cable (112) to
the left Upright (85). Connect the TV Cable to
the cable extending from the console assembly.
Then, insert the cables into the left Upright.
Next, insert the brackets on the Handrails (70)
into the Uprights (85). Make sure that no wires
are pinched.
70
Bracket
112
85
Console
Assembly
8
7. Remove the band securing the Upright Wire (73)
to the right Upright (85). Have a second person
hold the console assembly near the right Upright.
Connect the Upright Wire (73) to the wire harness
on the console assembly. See the inset draw-
ing. The connectors should slide together
easily and snap into place. If they do not, turn
one connector and try again. F THE CONNEC-
TORS ARE NOT CONNECTED PROPERLY,
THE CONSOLE MAY BE DAMAGED WHEN
THE POWER S TURNED ON. Then, insert the
connectors into the right Upright (85).
73
85
Console
Assembly
73
7
Wire
Harness
Cable
