Northern Industrial 109085 User manual

1
For technical questionsand replacement parts,please call 1-800-556-7885.
Thank you verymuch for choosinga Northern IndustrialProduct! For futurereference,
please complete theowner's record below:
Model: _______________ PurchaseDate: _______________
Save the receipt, warranty and these instructions. It is important that you read the
entire instruction sheetto become familiarwith this productbefore you beginusing it.
This machine is designed for certain applications only. It is strongly recommended
that this machine is not modified and/or used for any application other than that for
which it wasdesigned. If youhave any questionsrelative to aparticular application,
DO NOT use the machine until you have first contacted yourdealer to determineif it
can or shouldbe performed onthe product.
Before using thisproduct, please readthe following instructionscarefully.
"
Important
Read the safety warnings andinstructions in this manual carefully, before installation and
start-up of the control handle.It is the responsibility ofthe purchaser to retain thismanual
for future reference. Failure tocomply with the recommendations statedin this manual
may damage the control handleand void factory warranty.
Wear ear and eyeprotection to guard against airborneparticles and noise hazards.
Before doing any maintenance onthe control handle, be certainall pressure is completely
vented from the pump, suction,discharge, piping, and all otheropenings and connections.
Be certain the air supplyis locked out or madenon-operational, so that it cannotbe
started while work is beingdone on the control handle.Be certain that approved eye
protection and protective clothing areworn at all times inthe vicinity of the controlhandle.
Failure to follow these recommendationsmay result in serious injuryor death.
OO
DANGER: Not for use withfluids that have a flashpoint below 100 F(38 C).
Examples: gasoline, alcohol. Sparking couldresult in a explosion causingdeath.
CAUTION
Maximum fluid pressure 1500 PSI.Under no circumstances should thecontrol handle be
aimed at any person. Personalinjury may occur.
PRODUCT DESCRIPTION
The control handles are usedfor dispensing automotive lubricants.
The control handle is balancedand light weight for reducingoperator fatigue. The gripis
shaped to fit the handcomfortably. Itis equipped with a fourfinger trigger and an inlet
screen is included.
All models have a manualtip.
OPERATION
1. Connect the control handleto the lubricant supply line(1/2 NPT male thread required).
2. Open the manual tip.
3. Squeeze control handle trigger. When the required amountof product has been
