OPERATOR’S & PARTS
MANUAL OLXE
For Generator Model:
LX-E 34E
Read this manual thoroughly before starting your equipment.
This manual contains information needed to operate your set correctly and safely.
Introduction......................................................................4
Safety Rules .....................................................................4
Models and Serial Numbers ...........................................5
Mechanical Construction .................................................6
INITIAL INSPECTION AND COUPLING
Initial Inspection..........................................................6
Coupling with Prime Mover........................................6
Grounding ...................................................................6
PERFORMANCE AND FUNCTION
Excitation System........................................................7
Automatic Voltage Regulator (AVR) ..........................7
Under Speed Protection...............................................7
Rotary Rectifier and Surge Suppressor .......................7
CHARACTERISTICS
Voltage Regulation ......................................................8
Response .....................................................................8
Voltage Stability ..........................................................8
Short Circuit................................................................8
Phase Rotation.............................................................8
STANDARD VOLTAGE SELECTION TABLE .........8
OPERATION - GENERATOR SET
Starting........................................................................9
Voltage Adjustment.....................................................9
Running.......................................................................9
Stopping......................................................................9
OPERATION - VOLTAGE REGULATOR
Safety Rules ................................................................9
Operation ....................................................................9
Adjustment..................................................................9
MAINTENANCE
Bearing Inspection ................................................... 10
Insulation Resistance Measurement Method ........... 10
Rotating Rectifier Assembly ................................... 10
Parts Replacement Method ...............................10 - 11
Automatic Voltage Regulator Maintenance..............11
SPECIFICATIONS
Generator Specifications.......................................... 12
Voltage Regulator Specifications............................. 13
TROUBLESHOOTING ............................................. 14
PARTS LIST....................................................... 15 - 16
WIRING DIAGRAM
AVR DST-100-2FAK ............................................. 17
Connection Schematic............................................. 18
Table of Contents
Proprietary Information
This publication is the property of Northern Lights, Inc.
It may not be reproduced in whole or in part without the written permission of Northern Lights, Inc.
© Northern Lights, Inc. 2010. All rights reserved. Litho U.S.A. Publication number OLXE 03/10

OLXE 03/10
4
Introduction
This manual describes procedures for operation,
maintenance, inspection and adjustment. It will help the
operator realize peak performance through effective,
economical and safe operation.
• Read this manual carefully BEFORE operating the
generator.
• Study this manual until proper operation becomes
personal habit.
• Operation, inspection, and maintenance should be
carried out carefully. Safety must be given the first .
priority.
Safety Rules
• To insure years of trouble-free operation, the
specified maintenance is important and should be
performed.
• Electrical equipment should always be kept
clean. Oil, dust, moisture and salt are all harmful
to generators.
• Be careful with electricity. Do not touch rotating
parts.
• Ambient Environmental Conditions
a) Gas: Do not use in an environment of corrosive
or flammable gas (gasoline, hydrogen sulfide,
methane gas, etc.)
b) Sandy Dust: Do not use equipment in places
with excessive sand and dust.
c) Humidity: Do not use in very humid
environments for long periods of time.
d) Salt/Seawater: Protect your generator from
exposure to salt, water, and water vapor.
• Insulation Resistance and Dielectric: When
measuring insulation resistance and dielectric, be
sure to disconnect the AVR and rectifier.
• Be sure that the regulator is shut off by switching the
CPR (circuit breaker) on the AVR to the off position
when the unit is running at less than rated speed, or
when the unit is to be run but no power generation is
required.
• Before starting your generator, be sure operating
conditions are safe.
• Ventilation: When selecting the installation site, be
sure that the area is well ventilated and that ambient
temperature does not exceed 40°C.
• Be sure to provide generator with cover and
protection when operating outside.
LX-E Series AC generators are based on
BS 4999 part 20 and IEC34-5, IP22.

OLXE 03/10
5
Model and Serial Numbers
GENERATOR END MODEL NUMBER
Generator Set Model No ....................... Generator Model
M944T ...........................................................LX-E 34E
SERIAL NUMBERS
• When referencing Northern Lights equipment by serial
number, it is important to differentiate between the engine,
generator end, and generator set serial numbers.
• The engine serial number is either on a metal tag or stamped
directly into the engine block.
• The generator END serial number is on a metal tag attached
to the generator end.
• The generator SET serial number is on a separate metal tag
attached to the generator end. It may be a five by one inch tag
installed directly below the generator end tag. Or, it may look
like the illustrations below. Please use the generator SET number
in correspondence or when ordering parts.
Figure 1: Generator Set Serial Number Plate
AC Generator Data
Generator Set Data
Northern Lights, Inc., WA USA
www.northern-lights.com
Model No.
Serial No.
DUTY
KW
KVA
RPM
HERTZ
PHASE
°C RISE
RULE
WIRE
INSUL
AMB°C
PF
VOLTS
VOLTS
AMPS
AMPS
Set Serial
Set Model

OLXE 03/10
6
Mechanical Construction
STATOR
The stator frame is fabricated from rolled steel. The
round construction provides rigidity and strength to
resist excessive mechanical shocks. The stator core is
made of high quality silicon steel plates coated with
insulating film for prevention of eddy currents. The
core is positioned along the internal surface of the
frame. The exciter field core is made of special steel
plates capable of retaining a high degree of residual
magnetism.
BEARINGS
The long-life ball bearings are sealed to prevent grease
from escaping and to keep dirt out.
ROTOR
The rotor shaft is made of high quality carbon steel,
and is designed and manufactured to be mechanically
durable. The rotor is a salient revolving field type
with the main field core made from special steel plates
having superior magnetic characteristics. The field
core elements, exciter rotor, rotary rectifier and
cooling fan are integral parts of the same shaft.
VENTILATION
Cooling is provided by the cooling fan of the rotor
through suction ports and exhausted through outlet
ports. Every machine conforms to the cooling code
ICO1 of BS.
Initial Inspection and Coupling
INITIAL INSPECTION
If the generator is stored for long periods of time, store
in a clean, dry, ventilated area. After extensive storage
time, check the resistance of the coil insulation in accor-
dance with this manual (see MAINTENANCE, page
11) before operation. Be sure there are no abnormal
sounds or any overheating during operation.
COUPLING WITH PRIME MOVER
LX-E series single bearing generators make centering and
direct coupling easy. Coupling bolt torque is 35 ft.-lb.
GROUNDING
The neutral is not grounded to the frame unless
specified.

OLXE 03/10
7
Performance and Function
EXCITATION SYSTEM
The excitation system of the LX-E Series generator uses an
Automatic Voltage Regulator (AVR) which uses a portion
of the output power to supply controlled DC power to the
exciter field (EX) as show in Figure 2. When DC power is
supplied to the exciter field, output from the exciter armature
is rectified by a 3-phase bridge rotary rectifier (Si) and
supplied to the main field coils. See Figure 2.
AUTOMATIC VOLTAGE REGULATOR (AVR)
The LX-E generators use a DST-100-2FAK AVR. This is a
compact voltage regulator for generators with an output up
to 50kW. The AVR can be used in 120V single phase
applications and is installed inside the generator junction
box.
The AVR obtains sensing input from the main stator coils
and compares the rectified value of the sensing voltage with
the reference voltage produced inside the AVR. Input power
is obtained from the main stator.
Rectified output power to the exciter field is controlled by
switching a transistor on and off. This AVR will control
terminal voltage even if the input sine wave is distorted.
Figure 2: LX-E Block Diagram
AVR: Automatic Voltage
Regulator
EX: Exciter
Si: Rotating Rectifier
Figure 4: For 60 Hz
Figure 3: For 50 Hz
UNDER SPEED PROTECTION
A frequency sensing circuit is built into the AVR.
When the generator speed drops to 90% of rated
speed this circuit protects the AVR by reducing
the voltage in proportion to the decrease in engine
speed. In addition, when the generator is hit with a
rapid overload, this circuit will lower the voltage to
protect the engine. See Figures 3 & 4.
ROTARY RECTIFIER AND SURGE
SUPPRESSOR
The rotary rectifier assembly, consisting of six
diodes, functions as a 3-phase full wave rectifier for
the output of the exciter armature and supplies this
to the main field. To protect the diodes from large,
instantaneous voltage surges, surge absorbers are
provided as part of the rotating rectifier assembly.

OLXE 03/10
8
Characteristics
VOLTAGE REGULATION
Generator terminal voltage regulation is within ±1% of the
rated voltage in lagging power factor. 1.0 to 0.8, when the
load is varied gradually from no load to full load. This value
includes the temperature drift and rotating variation.
RESPONSE
After supplying a load instantaneously, the generator voltage
should be restored to the steady condition in accordance with
BS4999 Part 40, grade VR2.11 to VR2.23.
VOLTAGE STABILITY
In constant load and engine speed, voltage stability remains
0.25% of the rated voltage.
Winding Connection Frequency Voltages
3 Phase Series Star 60 Hz 480/277 460/266 440/254 416/240
(High Wye) 50 Hz 415/240 400/231 380/219
3 Phase Parallel Star 60 Hz 240/139 230/133 220/127 208/120
(Low Wye) 50 Hz 208/120 200/115 190/110
1 Phase 60 Hz 120/240
50 Hz 100/200 110/220 115/230 120/240
SHORT CIRCUIT
LX-E Series AC generators can provide over 300% of the
rated current for a short period of time, with an excitation
support system.
PHASE ROTATION
Phase sequence is T1-T2-T3 (U-V-W, A-B-C) with a
counterclockwise rotation of generator viewed from the
anti-coupling side.
Figure 5: Standard Voltage Table
Standard Voltage Tables and Connection Diagrams
Standard voltage selection table and connection diagram for LX-E Series 3-phase 12-wire AC
generators. See AC wiring schematic page 19.

OLXE 03/10
9
Operation – Generator Set
STARTING
Before starting generator, check the following:
1. Make sure that the wiring is correct.
2. Be sure that nothing is blocking the air inlet/ outlet.
3. Make sure that the inside of the generator is clean.
4. Be sure the main line circuit breaker is switched
OFF.
After checking each of the above, start the generator in the
following procedure:
1. Start engine in accordance with instructions in the
Operator’s Manual. Be sure there is no abnormal
sound or vibration.
2. The voltage will rise due to the increase in generator
speed. After making sure that each interphase voltage
is balanced, set the voltage and frequency to the rated
level. Be sure the CPR switch is “ON”. The voltage
will not rise with CPR “OFF”.
3. After running the generator without load, switch the
circuit breaker ON to start the load operation.
VOLTAGE ADJUSTMENT
The generator has been adjusted to obtain optimum
voltage at the factory. If the voltage is different, adjust
the voltage with the Voltage Adjust provided on the
AVR.
RUNNING
Check the following while operating the generator:
1. Abnormal vibration and/or sound
2. Load
3. Environment:
Keep the air inlet/outlet clean and clear for optimum
cooling. Insufficient cooling causes overheating of the
generator.
Note: When a 3-phase generator is used at single phase
load, each phase current should be balanced and should
not exceed 50% of the rated current.
STOPPING
After putting the running generator in a no-load condition
by removing the generator load, stop the engine in
accordance with the Engine Manual.
Operation – Automatic Voltage
Regulator
SAFETY RULES
• Do not leave AVR connected when testing generator
with high-pot or megger.
• Adjust the engine only when the CPR is in “OFF”
position.
OPERATION
1. Make sure the wiring is correct.
2. Make sure the frequency selection switch is set to
the rated frequency (60 or 50 Hz).
3. To adjust the voltage turn the Voltage Adjust
(VR1) counter-clock wise. Make sure the CPR is
“ON”.
a. Start the engine with no load and increase the
engine speed slowly to the rated level.
The voltage will automatically build up (residual
voltage: more than 10V).
b. Adjust to the rated voltage using the Voltage
Adjust (VR1).
c. Make sure of the proper Volt/Frequency
characteristic by reducing the generator speed.
d. Make sure of voltage stability by switching the
load “ON” or “OFF”. Use the Stability Adjust
(VR2).
e. If you find no problem with the AVR, start the
normal operation.
ADJUSTMENT
Each component of the AVR is adjusted at the factory to
obtain optimum voltage. If readjustment is
necessary, make sure the voltage, frequency, load, etc.
are functioning properly after readjustment.
1. Initial Excitation: For initial excitation use a
DC12V or DC24V battery.
a. Stop the generator.
b. Remove the AVR connectors.
c. Connect the field terminal F(+) with the
polarity (+) of battery and the terminal F (-)
with the polarity (-) and excite AVR field for 2
or 3 seconds.
2. Voltage Adjustment:
If the voltage output is low, increase the voltage by
turning the Voltage Adjust (VR1) slowly clockwise.
3. Stability:
If the voltage output is unstable, increase the voltage
by turning the Stability Adjust (VR2) clockwise.
4. Voltage and Frequency:
Voltage and Frequency (Hz) have been preset at the
factory.

OLXE 03/10
10
Maintenance
BEARING INSPECTION
For bearing inspection, make sure that there is no
abnormal sound during normal running and no over-
heating. Greasing is not necessary for generators using the
double seal type ball bearings, but these will need to be
replaced after every 10,000 hours of operation (see PARTS
REPLACEMENT METHOD).
INSULATION RESISTANCE MEASUREMENT
If the generator has not been used for a long time, check
the insulation resistance of each lead wire at 500V with a
megger.
It is usually enough to check only the stator winding. In
order to prevent damage to the AVR, disconnect it. If the
measured insulation resistance value is above 2 M ohms,
there is no problem, but if it is lower than that, check to
see if the inside of the generator is wet or dirty. If dust has
accumulated, blow it out with dry compressed air. Wipe
off oil stains with a cloth. If the generator is damp, dry it
and re-check.
ROTATING RECTIFIER ASSEMBLY
The rotating rectifier assembly needs little attention.
Clean off dust and oil stains periodically. In the unlikely
event that it becomes necessary to replace the diode ele-
ments and surge absorber elements. Refer to PARTS
REPLACEMENT METHOD.
PARTS REPLACEMENT METHOD
1. Bearing Replacement:
a. In order to replace the bearing, first remove the
bearing holder housing on the end of the
generator. Loosen and remove the four housing
bolts. Remove the bearing holder gently since
there is a risk that the rotor could fall and damage
the exciter rotor or the exciter stator.
Figure 6. Pilot Length
b. Using a bearing puller, extract bearing from
shaft.
c. When installing a new bearing, place a steel pipe
on the inner race surface, and fit the bearing by
tapping it lightly with a hammer.
Figure 7. Bearing Puller
Note: Absolutely do not apply pressure to outer race
of the bearing during insertion.
2. Replacement of Rotary Rectifier Parts:
a. Rotary rectifier parts are all located at the rear
of Exciter rotor. For parts replacement, remove
the bearing shield.
b. To test the rotating rectifier diodes, disconnect
the lead to the diode element and measure the
resistance between the anode and cathode on
each diode (see Figure 8).
Caution: Do not overheat the diodes. If the resist-
ance value of the diode in the forward direction is
low and the reverse direction resistance value shows
infinity, it is good. If this is not the case, the diode
element is defective and must be replaced. The diode
elements can be damaged if overtightened.
c. “J” type diode elements are fastened to the J(+)
side of the rotating rectifier assembly, and “K”
type diode elements to the K(-) side.

OLXE 03/10
11
Maintenance, continued
Figure 8. Testing Diode Elements
d. The Diode Torque Specifications for LX-E
models is 5 mm = 48 in. lb.
e. In order to test whether the rotating rectifier
assembly surge absorber elements are good or
not, first disconnect all lead wires as described
in PARTS REPLACEMENT METHOD, Point 2,
(above) and measure the resistance across surge
absorber elements with a tester.
• Good surge absorber elements have about 10-30 K
ohms, but if the resistance reading is near 0 ohms,
the surge absorber elements is defective and must
be replaced.
• Also, inspect outside of surge absorber and replace
if it is cracked.
• In addition, when installing surge absorber
elements, apply Loctite to the bolts.
3. Bearing Housing Replacement:
Inspect the O-Ring. If cracked, replace.
Reassemble carefully, aligning housing with
bearing. Tighten housing bolts to 2.5 kpm (18
ft/lbs.).
4. Rotating Rectifier Assembly Detailed
Structure:
Figure 9. Rotating Rectifier.
Maintenance – Automatic Voltage
Regulator
1. Keep the AVR clean at all times. Make
sure no dust or moisture accumulates
on the AVR.
2. Inspect periodically making sure that
wiring connections are not loose.

OLXE 03/10
12
Generator Specifications: Taiyo Winding Resistances for LX-E 34E
All ratings in Ohms @ 20° C
1 or 3 Phase
MAIN
STATOR: 0.0580 Ω
1 or 3 Phase
MAIN
ROTOR: 3.3 Ω
1 or 3 Phase
EXCITER
STATOR: 16.4 Ω
1 or 3 Phase
EXCITER
ROTOR: 0.629 Ω
1 or 3 Phase
AUXILIARY WINDING: 1.34 Ω
1 Phase 3 Phase
FULL LOAD 50 Hz/ 220 volts 21.2 volts
EXCITATION 60 Hz/ 240 volts 19.0 volts
VOLTAGE: 50 Hz/ 220 volts 31.3 volts
50 Hz/ 400 volts 29.0 volts
60 Hz/ 208 volts 24.6 volts
60 Hz/ 480 volts 27.0 volts

OLXE 03/10
13
Sensing Output Frequency 50 Hz 60 Hz
Voltage 100 Volt Class 100V (86.5V~110V~120V) 120V
200 Volt Class 200V (173V~220V~240V) 240V
Phase: Single Phase Single Phase
Power Input Voltage: 100V ~ 127V ~ 139V
Frequency: 50 Hz / 60 Hz
Phase: Single Phase Single Phase
Sensing Output Max. Voltage: 87% of Power Input Voltage (DC Voltage)
(F+) – (F-) Continuous Current: Maximum 3A Current
Current Maximum Forcing: 9A forcing 1 to 5 seconds at 25°C
Field Resistance: Minimum 15 Ohms
Voltage Adjust Range Minimum ±5% of Normal Voltage
Volt/ Hertz Characteristic 57 Hz in 60 Hz operation mode, 47 Hz in 50 Hz operation mode
Voltage Build-Up Self-Building Up at over 6V Power Input Voltage
Voltage Changeable Rate Maximum ±1.5%
Temperature Drift Within ±0.02%/ degree C
Operating Temperature -4°F (-20°C) to 140°F (60°C)
Storage Temperature -4°F (-20°C) to 158°F (70°C)
Outside Dimension 5.6" x 4.0" x 1.57" (140mm x 100mm x 40 mm)
Weight 1.4 lbs. (0.65 kgs)
Automatic Voltage Regulator: DST-100-2FAK

OLXE 03/10
14
Trouble Shooting
PROBLEM POSSIBLE CAUSE RECOMMENDATION(S)
Only a FEW VOLTS Loss of residual magnetism of the exiter field • Flash field.
of output
Disconnection or short circuit of windings • Check the insulation of all windings
and check the resistance value.
Defective AVR • Check the AVR.
Defective rotating rectifier assembly • Replace diode elements.
Voltage is LOW Incorrect wiring (GEN, AVR) • Check the winding connection.
Low speed • Check the engine.
Overload • Reduce the load.
Defective AVR • Check the AVR.
Voltage DIPS Starting of big motor or spot welding machine • About 15% voltage dip is no problem.
when on load
Defective diode on rotating rectifier • Change diode.
[F(+) – F(-) terminal voltage will show a
very high value when a diode is defective]
Voltage is HIGH Incorrect wiring (GEN, AVR) • Check the AVR.
Too high speed • Check the engine.
Defective AVR • Check the AVR.
Voltage FLUCTUATES Wiring leads are loose • Tighten leads.
Irregular speed of engine • Check the engine.
Poor AVR adjustment • Check the AVR.
External noise • Check the filter.
Abnormal SOUND Foundation uneven • Check ground level.
or VIBRATION
Poor mounting • Check the mounting section.
Misaligned coupling • Check the coupling section.
Defective bearing • Replace the bearing.

OLXE 03/10
15
No Description LX-E 34E
1 Stator Assembly GW-20650-STF with frame GM304980-1
2 Rotor Assembly GM304982
3 Exciter Field Assembly WKC-0131-F
4 Rectifier Assembly 3T201-084-3 with diode element
5 Diode Element SKN 26/12
Diode Element SKR 26/12
6 Bearing 6311ZZ
7 Fan Assembly GM34865-2 with coupling boss GM405464
8 Coupling Plate 4M698-011-1
9 Bearing Shield GM34467-3
10 Rubber Cap GM403175
11 Ventilation Cover GM413645 Inlet
12 Ventilation Cover GM413639 Outlet
13 Automatic Voltage Regulator 22-42071
14 Junction Box 3T303-671
15 Top Cover, Junction Box 4T302-144
16 Side Cover, Junction Box 4T302-859
17 Bracket, Junction Box 3T303-672 Left and right
18 Rubber Mount 33-40007
19 Terminal (Output) 22-45413
20 Terminal UK150-3J
21 Circuit Breaker 3 Amp 22-42077
3T102-435
LX-E Parts List

OLXE 03/10
16
Junction Box (Single Phase Wiring Shown)
Key Description Part Number
1 Grommet NG-79-R
2 Circuit Breaker 22-40018
3 Terminal 22-45413
4 Automatic Voltage Regulator (DST-100-2FAK) 22-42071
5 Terminal UK150-3J
6 Circuit Breaker 3 Amp 22-42077
7 Rubber Mount 33-40007
8 Bracket, Junction Box Mtg. - Right and left 3T303-672
9 Junction Box 3T303-671
10 Relay Board Sub-Assembly 22-70083-1 Manual Start
Relay Board Sub-Assembly 22-70086-1 Autostart
11 Relay 12 Volt (4 ea.) 22-42047
Relay 24 Volt (4 ea.) 22-40085
12 Timer Module 12 Volt 22-40407
Timer Module 24 Volt 22-40408
3T102-430-2

OLXE 03/10
17
AC Wiring Schematic - B-9582
DST-100-2FAK, All Voltages

OLXE 03/10
18
Connection Schematic
3T103-437

NORTHERN LIGHTS
4420 14th AVE. N.W.
SEATTLE, WA 98107-5043
USA
TEL: [phone]
FAX: [phone]
http://www.northern-lights.com
