BRDR24 Mounting Template
1:1 A4 version
BR24 Mounting Template
A4 1:1 version
LA000667A
TO FRONT
OF BOAT

Drill 9.5mm (3/8”) holes
141.5 mm (5-9/16”)
Check scale:-Measure before drilling
233 mm (9-5/32”)
BR24 base
Surface Min 5 mm (0.3”)
M8 x 30 mm bolt
Min 8 mm (0.3”)
Max 18 mm (0.7”)
Max 18 mm (0.7”)
Check scale:-Measure before drilling
