Nouveau NHFE320 User manual

FLAME EFFECT HEATER
OPERATING INSTRUCTIONS
For Model: NHFE320

This page is intentionally left blank.

CAUTION: In order to avoid a hazard due to inadvertent resetting of the
thermal cut-out, this appliance must not be supplied through an external
switching device, such as a timer, or connected to a circuit that is regularly
switched on and off by the utility.
•This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities or lack of experience and
knowledge, unless they are supervised or have been given instruction
concerning the use of the appliance by a person responsible for their safety.
•Children should be supervised to ensure that they do not play with the
appliance.
•If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
WARNING: You must not cover this heater. Covering this heater presents
fire risk and will activate the safety fuse; permanently disabling the unit.
WARNING: Do not use this heater in small rooms when they are occupied
by persons not capable of leaving the room on their own, unless constant
supervision is provided.
WARNING: To reduce the risk of fire, keep textiles, curtains, or any
flammable material a minimum distance of 1 metre from the air outlet.
General Care and Safety Guide
•Use only the voltage specified on the rating label of the appliance.
•The heater must not be located immediately below a socket outlet.
•Keep all objects at least 1 metre from the front, sides and rear of the appliance.
•This appliance is intended for household use only and not for commercial or industrial use.
•Indoor use only.
•Use this appliance only as described in this manual. Any other use is not recommended by
the manufacturer and may cause fire, electric shock or injury.
•Do not use the heater if it has been dropped or damaged.
•The common cause of overheating is deposits of dust or fluff in the appliance. Ensure these
deposits are removed regularly by unplugging the appliance and vacuum cleaning the air
vents and grills.
•Always unplug appliance when not in use.
•When the appliance has been unpacked, check it for transport damage and ensure all parts
have been delivered. If parts are missing or the appliance has been damaged, contact the
Customer Services Team.
•Do not use if there are visible signs of damage to the heater.
YOUR SAFETY IS IMPORTANT TO US. PLEASE ENSURE YOU TAKE NOTE OF THE
INSTRUCTIONS AND WARNINGS OUTLINED IN THIS MANUAL.

•Never use the appliance to dry clothes.
•Do not connect the appliance to mains supply until completely assembled and adjusted.
•Ensure hands are dry before handling the plug or main unit.
•Ensure heater is on a flat, stable, heat-resistant surface.
•Do not operate with cord set coiled up as a heat build up is likely, which could be sufficient to
become a hazard.
•Carry out regular checks of the supply cord to ensure no damage is evident
•Do not operate this appliance with a damaged cord, plug or after the appliance malfunctions
or has been dropped or damaged in any manner. Return to a qualified electrical person for
examination, electrical service or repair.
•Do not twist, kink or wrap the cord around the appliance, as this may cause the insulation to
weaken and split. Always ensure that all cord has been removed from any cord storage area
and is unrolled before use.
•It is recommended that this heater is plugged directly into the wall socket. Power boards are
not rated to supply power to high wattage appliances.
•A correctly specified, undamaged extension cord may be used with this heater provided it is
used in a safe manner.
•Do not remove plug from power socket until the appliance has been switched off.
•Do not remove plug from power socket by pulling cord; always grip plug.
•Do not place cord under carpet or cover with rugs or furniture. Arrange the cord so it cannot
be tripped over.
•Don’t place appliance on bedding or on thick & long carpet where the openings may get
blocked.
•Switch off and use handle provided when moving
•Do not place appliance close to radiant heat source.
•Do not insert or allow foreign objects to enter any ventilation or exhaust opening, as this may
cause an electric shock, fire or damage to the appliance.
•Do not sit on the appliance.
•Do not use abrasive cleaning products on this appliance. Clean with a damp cloth (not wet)
rinsed in hot soapy water only. Always remove plug from the mains supply before cleaning.
•Do not operate in areas where petrol, paint or other flammable liquids are used or stored.
•Do not use this appliance in the immediate surrounds of a bath, a shower, or a swimming
pool or other liquids.
•The appliance must not be immersed in any liquids.
•There are no user serviceable parts installed in the unit.
•Do not place the unit in wardrobes or other enclosed spaces as this may cause fire hazards.
•This unit is not supposed to be used in or around locations where foodstuffs, works of art or
delicate articles of science, etc. are stored.
•If your appliance does not work, or is not working properly, contact the place of purchase or
the Customer Services Team.
General Care and Safety Guide

Installing Your Heater
Before using the heater, The unit must be either wall-mounted or fitted to
its’ stand. First, Unpack the appliance and remove all the packaging. Check
that the appliance shows no signs of damage.
WALL MOUNTING
Wall bracket and fixing pack. Consisting of:
1 x Wall mount plate
1 x Small angled plate
6 x Mounting screws and wall plugs
2 x Small black screws to secure the angled plate
The wall bracket must be fitted horizontally and the cable routed to the bottom right of the heater.
A distance of 600mm from bottom of heater to floor is recommended for optimum viewing of fuel bed.
Mark the top four screws fixing positions on wall in accordance with the pre-drilled holes in the wall bracket.
Ensure that the bracket is level by using a spirit level whilst marking out the hole positions. Drill holes with a
correct size drill bit for the wall plugs.
Fix the wall bracket using 4 of the wall plugs and screws provided.
Attach the lower fixing bracket to the base of the fire using the two small black screws supplied.

Installing Your Heater
WALL MOUNTING CONTINUED
Bracket shown above in located in position.
Carefully lift the heater up ensuring that the top rear ledge of heater engages with the wall bracket and is
sitting centrally. This process should be carried out by two people to avoid injury or damage to property or
the appliance. Gently bring the heater down against the wall. Mark the lower fixing bracket two fixing hole
positions on the wall. Remove the heater and drill the wall and insert the wall plugs. Refit the heater to the
wall and fasten the bottom fixing bracket to the wall using the screws provided to permanently fix the
heater in place.
SET UP
Unpack the pebbles from the bag and place them along the light unit in the desired position.
Place the front surround over the front of the fire aligning the slots in the brackets at each side of the front
panel with the lugs on the sides of the fire. Two people will be required for this operation.
Then fit the one-way screw into the hole on the bottom of the right lateral hook to stop the front surround
from being removed.
FIREPLACE STAND
It is possible to install the electric fireplace on a stand, instead mounting it on the wall.
Remove the tempered glass panel from the metal body and place the heater face up on a suitable surface.
In the lower part of the body there are some screws. Which need to be aligned to the holes on the stand.
This will then mean the screw holes on the base and the bottom of the unit will then line up correctly.
Use the 4 screws that are supplied, secure the base to the lower side of the main body.
Replace the front surround over the front of the fire aligning the slots in the brackets at each side of the
front panel with the lugs on the sides of the fire. Two people will be required for this operation.
Then fit the one-way screw into the hole on the bottom of the right lateral hook to stop the front surround
from being removed.
Place the unit on a flat and stable surface.
This side goes to front of heater

Operating Your Heater
Always choose a safe location for the heater, keeping in mind the safety precautions outlined.
Ensure all packaging has been removed from the unit before use. This heater needs minimal
assembly before first use. Please follow the below instructions.
WARNING: In order to avoid overheating or fire, do not cover the heater.
WARNING: Keep all objects at least 1 metre from the front and 150mm
from the sides of the appliance.
WARNING:Do not use this heater with a programmer, separate timer,
remote-control system or any other device that switches the heater on
automatically, since a fire risk exists if the heater is covered or positioned
incorrectly.
WARNING:Never leave this heater unattended while in use.
Ensure heater is mounted on a heat-resistant surface.
Once the heater is in a safe operating position and all switches are in the off
position, insert the power plug into the mains outlet.
CAUTION: Ensure the power cord is not tight because if pulled it may
partially pull the plug from the socket. A partially inserted plug will overheat
the plug and socket and could result in fire.
HEATER CONTROL SWITCH
The control switch positions are:
O/I On/Off switch + dimmer switch
900W Low Heat Mode
1800W High Heat Mode
Press the O/I button once to turn on the appliance and fire effect. A red indicator light will show to
indicate that the fire is ON.
Press the O/I button for 3 seconds this will operate the dimmer mode, hold the button down until
the desired brightness is obtained.
Press the 900W button once for the low heat setting; press twice to switch off the heat setting.
Press the 1800W button once for the high heat setting; press twice to switch off the heat setting.

Operating Your Heater
REMOTE CONTROL
If the appliance is new, or the batteries in the remote control are flat, 2 new AAA batteries must
be installed.
Slide off the battery compartment cover on the underside of the remote control.
Remove old batteries, if present
Insert new batteries, ensuring the correct polarity (+/-), as shown on the bottom of the battery
compartment.
Slide the battery compartment cover back into place.
The mains switch located at the top right hand side of the fire must first be switched on; the fire
will beep to indicate that it is powered up.
Once the main power switch is set to ON; the remote control performs all the same functions as
the main control panel.
It takes a little time for the receiver to respond to the transmitter. Do not press the buttons
more than once within two seconds for the fire to operate normally.
Press the ON/OFF button once to turn on the appliance and fire effect.
Press the 900W button once for the low heat setting; press twice to switch off the heat setting.
Press the 1800W button once for the high heat setting; press twice to switch off the heat
setting.
Press the DIMMER button to operate the dimmer mode, repeat pressing will raise and lower the
brightness.

TECHNICAL SPECIFICATION
Model No: NHFE320
Supply: 220-240VAC 50Hz
Wattage: 1800W
Operating Your Heater
SAFETY DEVICES
This appliance has three protection devices:
•Tilt Switch - this will automatically turn the appliance off if the appliance is not in the
correct operating position.
•Resettable Thermal Link - this will automatically disconnect the power to the
appliance at a pre-set overheat temperature. After cooling down it will reset and
power on again. If this occurs, investigate what is causing the appliance to overheat.
•Thermal Fuse - this disconnects the appliance permanently in case of overheating. (It
is non resettable).
CAUTION: The heater generates heat during use. Proper precautions must
be taken to prevent the risk of burns, scalds, fires or other damage to persons.
CARE AND CLEANING
•The heater requires regular cleaning to ensure trouble free operation:
•Unplug the heater from the mains supply before cleaning.
•Ensure that the heater has been allowed to cool down completely before cleaning.
•The common cause of overheating is deposits of dust or fluff in the appliance. Ensure
these deposits are removed regularly by unplugging the appliance and vacuum
cleaning the air vents and grills.
•Use a damp cloth (not wet) to wipe the exterior of the heater to remove dust and
dirt.
•Never use solutions such as petrol, thinners or polishing agents.
•Ensure the heater is dry before plugging back into the mains supply.
PROOF OF PURCHASE
To receive warranty retain receipt as proof of purchase.
SUPPORT AND TECHNICAL ADVICE
North Shore City, Auckland, New Zealand
Monday –Friday 8am-5pm
Phone: [phone]

This page is intentionally left blank.

This page is intentionally left blank.

Thank you for purchasing this Nouveau product. Your product is warranted against factory faults when used in a
normal domestic setting for a period of two years from the date of purchase. Valid proof of purchase will be
required. As the product is intended for home use only, commercial usage of this product for professional or
industrial purposes will VOID this warranty.
Should your product be faulty, it may be replaced, repaired or refunded during the warranty period, as deemed
appropriate by the retailer.
This warranty excludes damage caused by misuse, neglect, shipping accident, incorrect installation, or work
carried out by anyone other than a qualified electrical service technician.
PLEASE KEEP YOUR RECEIPT AS THIS WILL HELP VERIFY YOUR WARRANTY.
This warranty is additional to the conditions and guarantees of the Consumers Guarantee Act (1993).
TWO YEAR WARRANTY
Nouveau Two Year Warranty (IMPORTANT: Please complete and retain this warranty card)
Name
Address
Place Of Purchase
Date of Purchase
Name Of Product
Model Number
Attach a copy of the purchase receipt to this warranty card
Due to continual design improvements, the product illustrated in this User Manual may differ slightly from the
actual product.
Nouveau –New Zealand
67 Corinthian Drive
Albany
Auckland 0632
New Zealand
Phone [phone]
