NovaFlex RIBBON Series User manual

1. VERIFY PRODUCT IS CORRECT
Pre-light using the wiring diagrams in this guide to power your
ribbon/neon to ensure color/Kelvin temperature is correct.
Note: Do NOT connect max runs.
2. TURN POWER OFF AT CIRCUIT BREAKER
SHOCK HAZARD! Turn power OFF at circuit breaker prior to
installation, to avoid serious injury or death.
3. DETERMINE LOCATION TO INSTALL
Dry-t the lights to the desired location BEFORE removing the
adhesive backing. Refer to the CONFIGURATION GUIDE for a list
of products and zone locations.
Skip to step 6 to mount the ribbon without a channel.
Skip to step 10 to mount neon.
4. CUTTING THE CHANNEL FOR RIBBON
To determine the cut length, place the LED ribbon beside the
channel, add 1” to account for the Lead Lock Heat Shrink around
the lead. Snap the lens and end cap into place and secure with
masking tape at the cut mark to protect the lens from cracking.
Cut using metal rated saw blade. If cut is rough, use a metal le to
smooth the edges. Clean any remaining slivers of metal or plastic
to insure a clean install.
If installing Surface 1707 or Surface 1919: After cutting, remove
lens and measure 0.39” from end and cut just the lens to
account for the end cap.
5. MOUNTING THE RIBBON IN CHANNEL
a. Channel, directly to the Surface
Install channel directly to the surface with the provided screws.
You will need to pre-drill the holes before installation or use
self- tapping screws when installing onto metal.
b. Channel with Clips
Screw clips to the surface at the beginning and end of
each section and then about every 1.5 ft in between. For
certain channels, you can utilize the clips to connect channel
(see diagram).
c. Universal Clips
Attach the provided channel clips to the Universal
Clips. Then install at least four clips for every 2M
of channel, to the surface with screws. Snap your channel into
the channel clips and secure the channel by pinching the clips
around the channel.
d. Mud-In
Prep the wall for the channel base by measuring the
channel width and cutting into the drywall. Then, slide the
channel in the wall, with the wings resting on the drywall.
(Optional: Secure the channel in place by using screws in the
mud-in holes.)Then, mud over the wings to secure the channel.
6. PREP SURFACE PRIOR TO INSTALLING RIBBON
To ensure lasting bond, use the provided alcohol wipe to prep the
surface. For slippery surfaces, pre-sand the area before installing
the lights or use the 3M Primer 94.
7. INSTALL END CAP WITH HOLE (OPTIONAL)
Slide the lead through the hole of the end cap and snap it into the
channel and conrm the t. If lead is to the back, drill hole through
the channel for the lead to go through.
8. MOUNT THE RIBBON
Once t is conrmed, begin peeling the backing and gently
pressing the ribbon into place, slowly working your way towards
the end of the ribbon. This process will make it easier to handle
the ribbon, especially in longer runs. In channel, center the ribbon
starting 1/8” away from the end cap with the hole.
Note: Adhesive MUST BE REMOVED for proper heat dissipation.
Do not let the LEDs hang when installing, as this could add
stress to the solder connections.
9. INSTALL LENS (OPTIONAL)
Once the ribbon is in place, install the lens by pressing it into
place, starting from one end and working your way to the other,
then snap the solid end cap onto the open end.
10. CUTTING THE CHANNEL FOR NEON
Measure the length of the neon and subtract 3.62” to allow room
for the end caps. Then measure the length of the channel and
mark on the channel where you plan to cut.
Example: 35” run of neon would need to have a 31.38” channel.
Cut using a metal rated saw blade. If cut is rough, use a metal
le to smooth the edges. Clean any remaining slivers of metal to
insure a clean install.
11. MOUNTING THE NEON WITH CHANNEL OR CLIPS
Install channel or clips directly to the surface with screws. You will
need to pre-drill the holes before installation or use self-tapping
screws when installing onto metal.
Then gently press neon into the channel/clip, where it will lock
into place with the locking clamps. If you need to remove the
neon, use a pliers to gently pinch the clamps to pull the neon out.
12. TURN POWER ON AT CIRCUIT BREAKER
Once your ribbon or neon is connected, turn the power on at the
circuit breaker.
INSTALLATION GUIDE RIBBON, NEON & CHANNEL
ATTENTION: This product should be installed by a professional, licensed electrician.
Do not attempt to make sharp bends. Excessive or exaggerated bending and twisting can damage the circuit.
NOTE: IP65 is water resistant & IP68 is protected against water; power supply is NOT.
Cutting Ribbon or Neon in the eld may void the UL Certication and Warranty.
Continued on next page
novaexled.com | 1

NOVA FLEX LED, INC. WARNINGS AND WAIVER
• Any installation of this product should be completed by a professional licensed electrician pursuant to all applicable governing laws,
ordinances, regulations, national and local electrical and building codes.
• This is an electronic product which is susceptible to damage if handled incorrectly. Improper soldering or modication may result in a voided
warranty. Warranty cases will be made at Nova Flex’s discretion based on multiple factors.
• Do not allow product to be punctured or penetrated by foreign objects; this can result in a short circuit.
• Do not connect product directly to a 120 volt AC power source.
• For best performance, do not load the DC power source more than 80% of its labeled rating.
• Any use of this product is entirely at your own risk. Failure to utilize and install this product in its proper manner could result in severe injury and/
or property damage.
• Keep out of reach of children.
This product is provided by the manufacturer “as is” “with all faults” without any warranties or representations, express or implied, including,
but not limited to the warranties of merchantability or tness for a particular purpose. In no event shall manufacturer be liable for any special,
incidental, punitive indirect or consequential damages of any kind. Manufacturer offers this product and the user accepts it subject to the foregoing
conditions, which may only be modied in a writing signed by the manufacturer.
See complete Terms & Conditions at novaexled.com
LIGHTS ARE FLICKERING OR WILL NOT LIGHT?
l
Conrm polarity of wiring (make sure + and - are connected properly).
l
Check all connections to make sure they are secure and tight.
l
Ensure you are using a compatible dimmer and correct power supply.
Contact your distributer for technical support.
INSTALLATION GUIDE RIBBON, NEON & CHANNEL
2 | novaexled.com

novaexled.com | 3
WIRING DIAGRAM FOR POWER SUPPLIES Ribbon: 14 - 20 Gauge Wire | Neon: 12 - 18 Gauge Wire
E-Series Hardwire
OUTPU T
INPU T
AC POWER
N (White)
L (Black) V+ (Red to Red)
V- (Blue to Black)
L
N
Ground
Ground Static Ribbon or Neon
EZJ Multi-Channel
OUTPU T
INPU T
AC POWER
N (White)
L (Black)
L
N
Ground
Ground
Dimmable with standard MLV
Dimmable with 0 - 10V Dimmers
Dimmable with standard MLV
Non-Dimming
Non-Dimming
Static Ribbon or Neon
Static Ribbon or Neon
Static Ribbon or Neon
Electronic Hardwire
AC POWER
120 VAC Switch (Non-Dimming)
*Only NF-PS-HLG100W2V-HW will have a ground wire.
Ground
LBrown
Blue CN (Blue)
ACL (Brown)
V+ (Red)
V- (Black)
INPUT
OUTPUT
*Ground
NStatic Ribbon or Neon
Plug & Play
AC POWER
NF-C-Y
NF-C-MF Static Ribbon or Neon
Static Ribbon or Neon
Static Ribbon or Neon
0 - 10 VOLT
AC POWER
Ground
LED Driver
Red (+)
White (N)
Black (L) Black (-)
Gray
Violet
0-10V
Dimmer
Static Ribbon or Neon
OUTPUT
OUTPUT
Ground
~
N
OUTPUT
+
+
+
-
-
-
Continued on next page
OUTPUTINPUT
INPUT

WIRING DIAGRAM S3i Series
Ribbon: 14 - 20 Gauge Wire | Neon: 12-18 GaugeWire
S3i Wireless Receiver - RGBW
Run #1
Run #2
RGBW Ribbon or Neon
RGBW Ribbon or Neon
NF-A-UNV
INPUT
W- B- G- R- + v+ v-
OUTPUT
W- B- G- R- V+ V+ V-
Red Wire = R- | Green Wire = G- | Blue Wire = B- | White Wire (Gray) = W- | Black Wire = V+
S3i Wireless Receiver - RGB
NF-S3i-WR-1009
NF-PS-HLG100W-24V-HW
NF-PS-HLG100W-24V-HW
Run #1
Run #2
120V AC (Line)
120V AC (Line)
INPUT
OUTPUT
RGB Ribbon or Neon
RGB Ribbon or Neon
- +- +
NF-A-UNV
INPUT
W- B- G- R- + v+ v-
OUTPUT
W- B- G- R- V+
W- B- G- R- V+
NF-S3i-WR-1009
NF-PS-HLG100W-24V-HW
NF-PS-HLG100W-24V-HW
120V AC (Line)
120V AC (Line)
INPUT
OUTPUT
- +- +
W- B- G- R- V+
NF-S3i-WR-1009
NF-PS-HLG100W-24V-HW
NF-PS-HLG100W-24V-HW
120V AC (Line)
120V AC (Line)
INPUT
OUTPUT
- +- +
W- B- G- R- V+
V+ V-
Red Wire = R- | Green Wire = G- | Blue Wire = B- | Black Wire = V+
S3i Wireless Receiver - Adjustable Run #1
Run #2
Adjustable Ribbon or Neon
Adjustable Ribbon or Neon
NF-A-UNV
INPUT
W- B- G- R- + v+ v-
OUTPUT
W- B- G- R- V+ V+ V-
Black Wire = V+ | Yellow Wire (Orange) = V- | White Wire (Gray) = V-
NF-S3i-WR-1009
NF-PS-HLG100W-24V-HW
NF-PS-HLG100W-24V-HW
120V AC (Line)
120V AC (Line)
INPUT
OUTPUT
- +- +
W- B- G- R- V+
S3i Wireless Receiver - Static Run #1
Run #2
Static Ribbon or Neon
Static Ribbon or Neon
NF-A-UNV
INPUT
B- G- R- + V- V+ V-
OUTPUT
W- B- G- R- V+ V+ V-
Black Wire = V- | Red Wire = V+
4 | novaexled.com
Note: Gray Wire = White Wire
Note: Gray Wire = White Wire
