NRI HENRI User manual

National Rejectors, Inc. GmbH • Zum Fruchthof 6 • D-21614 Buxtehude
Phone: [phone] • Fax: [phone] • E-mail: [email protected] • Internet: www.nri24.com
Technical Documentation
Service tool
HENRI
Short reference guide
for proceeding internal HENRI functions
06.10 JMo/Roe
Version 2.0
KA.HENRI-EN

3
Ta b l e o f c o n T e n T s
National Rejectors, Inc. GmbH, Buxtehude
SRG – Internal HENRI functions
Tabel of contents
1 About this short reference guide 5
Text conventions 5
Additional technical documentationen 6
2 About HENRI 7
HENRI features 7
Scope of delivery 7
Accessories 8
3 Safety instructions 9
Proper use 9
Protecting yourself and equipment 10
4 Design 11
Operating elements 11
Functions of the operating keys 12
Multifunction keys A to F 12
c2 menu key MENU 12
General menu key HENRI 12
Navigating in the menus 13
Main menu currenza c² 13
General main menu HENRI 13
Switching between the main menus 14
From the general HENRI main menu to the c2 main menu 14
From the c2 main menu to the general HENRI main menu 14
Display help texts 14

4
Ta b l e o f c o n T e n T s
National Rejectors, Inc. GmbH, Buxtehude
SRG – Internal HENRI functions
5 Connection 15
Connecting HENRI on site 15
Connecting HENRI in the workshop 16
Start screens when connecting a ... 17
... currenza c2 17
... E-66/A-66 17
... G-46 17
6 Basic settings 18
Setting menu language 18
Setting date and time 19
Altering display contrast 20
Setting baud rate 21
7 Service work 22
Function tests 22
Testing keys, system time, memory 22
Testing keys, system time, memory and HENRI/c2interfaces 23
Firmware update 25
Calling up current rmware version 25
Updating rmware 25
Downloading the new rmware and FW updating PC application from
the internet 26
Installing HenriFlash 26
Installing new rmware in HENRI tool/Uploading new c2 rmware in
HENRI tool 26
8 G-46/E-66/A-66Conguration 29
The basics 29
Key functions in the G-46/E-66/A-66 mode 29
Accessing Dis menu 30
How to return to the G-46/E-66/A-66 mode, if I had pressed the
HENRI key by mistake? 31
9 Technical data 32
Device data 32
CE certication 33

5
National Rejectors, Inc. GmbH, Buxtehude
ab o u T T h i s s h o r T r e f e r e n c e g u i d eSRG – Internal HENRI functions
About this short reference guide1
This short reference guide provides all information about
operating elements and menu structure of the HENRI service tool.•
connection and start-up of the HENRI service tool on an NRI coin •
payment system.
basic settings and service work on the HENRI service tool.•
the basic operation of the HENRI service tool in the G-46 and E-66/•
A-66 conguration mode.
This short reference guide does not describe the entire func-
tional range of the service tool, but rather the internal HENRI
functions. In order to be able to use the service tool’s entire
functional range safely and to adjust all possible settings, all
short reference guides for the HENRI service tool, the NRI coin
changer currenza c2andforaG-46orE-66/A-66congurationthe
G-55.0460 manual for the old service tool must be read carefully
(PDF download at www.nri24.com).
Text conventions
To make it easier for you to navigate within these instructions and to operate
the devices, the following accentuations were made in the text:
Safety instructions, which you must observe in order to protect
operators and equipment.
Notes, which you must observe in order to protect the environ-
ment.
Special notes, which are to facilitate the use of the devices.
At the beginning of a chapter you will nd a short "guide", which
summarises the content of the chapter.
1 2 3 ... Requests to perform an action are numbered in another typeface.
di s p l a y T e x T s are set in small capitals.
BUTTONS and MENU ITEMS are shown in bold capitals.
[1/2] Reference to a gure. The number before the slash refers to the gure
number, the number behind the slash to the item number within the
gure.

6
ab o u T T h i s s h o r T r e f e r e n c e g u i d e
National Rejectors, Inc. GmbH, Buxtehude
SRG – Internal HENRI functions
Additional technical documentationen
Apart from the short reference guide you already have there is further
documentation for the service tool and the NRI coin changers. All product
descriptions are available in a compressed PDF format at www.nri24.com
(→ Download).

7
National Rejectors, Inc. GmbH, Buxtehude
ab o u T henriSRG – Internal HENRI functions
About HENRI2
The HENRI service tool is used to operate, diagnose and congure the
NRI coin changers currenza c2, G-46.F4xxx, and E-66/A-66 on site at the
machine. It reads out the programmed device data of the connected changer
and displays them on its display for control or conguration purposes.
Using HENRI you can:
operate, congure NRI coin changers•
inspect optional audit data of NRI coin changers•
perform error diagnostics on NRI coin changers•
update rmware of NRI coin changers•
read out statistical data of the coin changer currenza c• 2
This short reference guide only describes the general operation and
proceeding of internal HENRI functions (cp. further manuals).
HENRI features
One conguration tool for the NRI changers currenza c• 2, G-46.F4xxx
and E-66/A-66 with different vending machine interfaces
Simple connection on site at the machine using 8-pole RJ-45 inter-•
face
Can be used immediately as a plug-and-play solution•
Diagnostics options by means of status and error messages being •
displayed
Display of all audit data (optional) in service cases•
Useful service functions•
Scope of delivery
In addition to the HENRI service tool you are supplied with a USB cable.

8
ab o u T henri
National Rejectors, Inc. GmbH, Buxtehude
SRG – Internal HENRI functions
Accessories
The following accessories can be ordered for the HENRI service tool:
WinSPT basic kit (MDB)•
with EURO plug (ordering code 24688)–
with USA plug (ordering code 24854)–
WinSPT accessory kit•
BDV/Executive (ordering code 26218)–
JVI/VCCS (ordering code 26215)–
SIM card (ordering code 32845)•
for automatic c– 2 data block & rmware updates
as licence for currenza heartbeat PC conguration software–

9
National Rejectors, Inc. GmbH, Buxtehude
sa f e T y i n s T r u c T i o n sSRG – Internal HENRI functions
Safety instructions3
Before operating the device for the rst time, please read through these
short reference guide carefully at least once, and most importantly the
safety instructions.This is to ensure you have understood the contents of
these instructions as well as how to operate the device.
Proper use
The HENRI service tool is used for operation, diagnostics, conguration
and general service work on the NRI coin changers currenza c2, G-46.
F4xxx and E-66/A-66. Only use the service tool for this purpose. Under
no circumstances can the manufacturer be held liable for any damage or
loss resulting from improper use of the device.
The service tool has been constructed in compliance with the state of the
art and the recognised safety regulations. Nevertheless this equipment
can be a source of danger. Therefore please observe the following safety
regulations.

10
National Rejectors, Inc. GmbH, Buxtehude
SRG – Internal HENRI functions
sa f e T y i n s T r u c T i o n s
Protecting yourself and equipment
The service tool may only be used, if the device and connecting
cable are not damaged.
Only use the service tool according to proper use. Under no cir-
cumstances can the manufacturer be held liable for any damage
or loss resulting from improper use of the device.
PleasemakesurethataftereachcongurationofanNRIchanger
the label of the changer has been adapted to the new settings
or the new settings are written down in another way for the
workshop and the installation place.
The coin validator, changer and HENRI PCBs are tted with
components which may be damaged beyond repair by electro-
static discharge. Please observe the handling instructions for
components exposed to the risk of electrostatic discharge.
Do not alter the construction of the device.
Keep water and other liquids away from the device.
If the device is no longer required, please dispose of it cor-
rectly.
Wereservetherighttomaketechnicalmodicationstothedevice
which are not covered by these instructions!

11
National Rejectors, Inc. GmbH, Buxtehude
de s i g nSRG – Internal HENRI functions
Design4
This chapter describes:
design and operating elements of the HENRI service tool•
the functions of the operating keys of the HENRI service tool•
the menu structure of the HENRI service tool•
Operating elements
General menu key HENRI1
(for general functions)
c2 2 menu key MENU
(for internal c2 functions)
Slot – SIM card3
Operating elementsFig. 1:
1
3 2
7
6
4
5
USB port – PC4
Multifunction keys A–F5
Display6
Connecting cable (RJ-45 plug (8-pole)) – 7
payment system
To operate and service the coin changer connected, the service tool is
equipped with a display [1/6], six multifunction keys [1/5] and two menu
keys [1/1, 2]. It can be connected to an NRI payment system (e.g. coin
changer) using the connecting cable installed with RJ-45 plug [1/7]. For,
e.g., rmware updates the service tool can be connected to a PC using
the USB port [1/4].

12
de s i g n
National Rejectors, Inc. GmbH, Buxtehude
SRG – Internal HENRI functions
Functions of the operating keys
The HENRI keypad [1/1, 2, 5] can be divided in three groups:
Multifunction keys • Ato F[1/5]
c• 2 menu key MENU [1/2]
General menu key • HENRI [1/1]
Multifunction keys A to F
The multifunction keys Ato F[1/5] are arranged around the display [1/6].
The functions which can proceed using the keys depend on the:
payment system connected•
(currenza c2 or other NRI payment systems)
active menu•
(for internal c2 or general functions)
c2menu key MENU
Pressing the MENU key [1/2] you enter the main menu for operation, con-
guration and service work on the coin changer currenza c². Using this
main menu you are able to select the internal c2 functions.
The menu is only available if HENRI is connected to a currenza c².
If not, the key has no function.
This short reference guide only describes the general operation and
proceeding of internal HENRI functions (cp. further manuals).
General menu key HENRI
Pressing the HENRI key [1/1] you enter the main menu for
work on the NRI coin changer currenza c• 2 which require an external
data media (e.g. reading out statistical data, updating rmware).
basic settings and service work on the HENRI service tool.•
service work and conguration of the NRI coin changers G-46.F4xxx •
and E-66/A-66.

13
National Rejectors, Inc. GmbH, Buxtehude
de s i g nSRG – Internal HENRI functions
Navigating in the menus
HENRI distinguishes between functions that are proceeded in the coin
changer currenza c² and functions that are proceeded either in other NRI
payment systems or in the HENRI itself. Accordingly there are two inde-
pendent menus.
This short reference guide only describes the general operation and
proceeding of internal HENRI functions (cp. further manuals).
Main menu currenza c²
In the main menu for the coin changer currenza c² you select the submenu
required by pressing the multifunction key with the character A, B, C, D, E
or F on the left-hand side of the menu.
In the submenu you navigate with the
down-arrow • or up-arrow keys to select a certain menu item.
OK key • to enter the menu selected.
Exit key • to return to the superordinate menu.
MENU• key to switch over to the c² main menu.
General main menu HENRI
In the general main menu HENRI you navigate with the
m• ultifunction keys A, B, C, D, Eor Fto select a menu, submenu and
menu item.
OK key • to enter the (sub)menu selected.
Exit key • to return to the superordinate menu.

14
de s i g n
National Rejectors, Inc. GmbH, Buxtehude
SRG – Internal HENRI functions
Switching between the main menus
While you are in one of the both main menus you cannot switch over to the
other main menu direct by pressing the appropriate menu key.
If you try to switch over direct to the other menu, the connec-
tion between changer and service tool will be interrupted.
In this case pull the HENRI plug out of the c² socket and wait for ap-
prox. 30 sec. until a new connection has been set up.
From the general HENRI main menu to the c2main menu
With the• Exit key back to the HENRI main menu
With the menu key• MENU to the c2 start screen rst and then
With the menu key• MENU to the c2 main menu
From the c2main menu to the general HENRI main menu
With the • Exit key back to the c2 main menu
With the menu key• MENU to the c2start screen
With the menu key• HENRI to the HENRI main menu
Display help texts
The bottom display line is intended for help texts and offers you key instruc-
tions for possible courses of action, e.g. leaving a (sub)menu.

15
National Rejectors, Inc. GmbH, Buxtehude
co n n e c T i o nSRG – Internal HENRI functions
Connection5
The HENRI service tool can either be connected to the payment system
on site in the vending machine or in the workshop by using a tester.
Connecting HENRI on site
In order to connect HENRI to a coin changer, plug the RJ-45 connector
(western plug) of the connecting cable into the socket on the top right of
the coin changer (see Fig. 2).
 AsHENRI identiestheconnected paymentsystemautomatically
thedisplayshowsdevicespecicdataaftertheconnectionwiththe
payment system has been established.
Connecting HENRI on siteFig. 2:

16
Co n n e C t i o n
National Rejectors, Inc. GmbH, Buxtehude
SRG – Internal HENRI functions
Connecting HENRI in the workshop
If the NRI payment system has been removed from the vending machine
for, e.g., update purposes, it has to be powered by a tester. The tester of
the WinSPT PC test station along with the appropriate power pack and
cable are used to supply the payment system with voltage (see Fig. 3):
Using the complete WinSPT PC test station all of the vending ma-
chine functions can be simulated in order to test a serial NRI payment
system. For further information regarding the WinSPT PC test station
and all ordering codes please refer to our product accessory pages
on the internet (www.nri24.com).
If necessary, connect 24V-power pack to appropriate power cable.1
Connect WinSPT tester to power pack using the DC interface.2
Connect WinSPT tester to, e.g., coin changer using the MDB inter-3
face and the machine connecting cable (if necessary, by means of
the adapter cables which are part of the accessory kits for other ma-
chine interfaces).
Connect the power pack to the power supply using the power cable.
4
The display of the WinSPT tester shows "SPT (C)NRI vx.x_".
Plug the HENRI connector into the socket on the top right of the coin
5
changer (see Fig. 2).
 AsHENRI identiestheconnected paymentsystemautomatically
thedisplayshowsdevicespecicdataaftertheconnectionwiththe
payment system has been established.
Connecting HENRI in the workshopFig. 3:

17
National Rejectors, Inc. GmbH, Buxtehude
co n n e c T i o nSRG – Internal HENRI functions
Start screens when connecting a ...
HENRI identies the payment system connected automatically. Thus the
start screen is device-dependent.
... currenza c2
If HENRI is connected to a currenza c², HENRI displays two start
screens:
and switches then over to the c² mode automatically in order to display the
selected status message, if there is no error, e.g.:
... E-66/A-66
If HENRI is connected to an E-66/A-66, HENRI displays two start
screens:
E-66 / A-66
... G-46
If HENRI is connected to a G-46, HENRI displays two start screens:
G-46

18
ba s i c s e T T i n g s
National Rejectors, Inc. GmbH, Buxtehude
SRG – Internal HENRI functions
Basic settings6
This chapter describes how to adjust basic settings, which HENRI saves
as presettings for all further applications:
Menu language•
System time•
Display contrast•
Baud rate•
Setting menu language
HENRI supports the following languages:
English•
French•
German•
Italian•
Dutch (option)•
Spanish (option)•
Default language is English when HENRI is delivered. If another language
is to be set:
Press
1 HENRI key.
You enter the main menu:
Press2 C key to open the se T T i n g s menu:
Press3 A key to open submenu la n g u a g e .
Press
4 Aor B key to select the language.
Use
5 EXIT key to return to the main menu.

19
National Rejectors, Inc. GmbH, Buxtehude
ba s i c s e T T i n g sSRG – Internal HENRI functions
Setting date and time
To set time and date for HENRI:
 IfHENRIhasalreadybeenconnectedtoaPC,e.g.,forarmware
update, HENRI has already saved the PC system time. In this case
time setting is not necessary.
Press1 HENRI key.
You enter the main menu:
Press2 C key to open the se T T i n g s menu:
Press3 C key again to open submenu da T e /Ti m e .
Set date (format: day/month/year) and time
4
(format: hour:mi nute:second):
use • Dor C key (reight arrow/left arrow) to mark data to be changed
use • A key (up-arrow) to increase data selected.
use • B key (down-arrow) to decrease data selected.
Use
5 EXIT key to return to the main menu.

20
ba s i c s e T T i n g s
National Rejectors, Inc. GmbH, Buxtehude
SRG – Internal HENRI functions
Altering display contrast
The default setting of the display contrast is "46". To alter the contrast:
Press
1 HENRI key.
You enter the main menu:
Press2 C key to open the se T T i n g s menu:
Press3 B key to open submenu co n T r a s T .
• Use
4 A key (up-arrow) to increase the contrast.
Use • B key (down-arrow) to decrease the contrast.
Use
5 EXIT key to return to the main menu.
