SAFETY PRECAUTION
IMPORTANT: PLEASE READ BEFORE INSTALLATION
 Installation must be carried out by a qualified wiring installer
 Turn off the electrical mains at the circuit breaker fuse box
 Use power supply 220-240V/50Hz.
 The ceiling mounting must be able to with hold a min of 24.8kg.
 Install ceiling fan blade more than 2.3 M above floor.
 Do not place any objects in the path of the blades.
 When all electrical connection is done, store all wire neatly.
 Make sure that all screws and connection are tightly screwed and secured.
 This appliance is not intended for use by persons (including children) with Seduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety. Children should be supervised to ensure that they do not play with the appliance.
 This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made bychildren without supervision.
 An all pole disconnection must be incorporated in the fixed wiring in accordance with the
wiring rules, aOall pole disconnection incorporated in the fixed wiring is to be provided.
 The replacement of parts of the safety suspension system device shall be performedby the
manufacturer, its service agent or suitably qualified persons
 The fixing means for attachment to the ceiling such as hooks or other devices shall be fiYFE
with a sufficient strength to withstand 4 times the weight of the ceiling fan.
 The mounting of the suspension system shall be performed by the manufacturer, its service
agent or suitably qualified persons.
 Disconnection must be incorporated in the fixed wiring in accordance with the wiring rules
WARNING: If unusual oscillating movement is observed, immediately stop using the ceiling
fan and contact the manufacturer, its service agent or suitably qualified persons.
-0564The weight of the appliance in kilograms: .kg
Anise: The weight of the appliance in kilograms: 6.6kg

2
PARTS & ACCESSORIES
2
8
9
10
3
4
5
6
7
Fig.2
Fig.1
2
3
4
5
7
8
9
10
11
11
6
Remote control x 1set
10
11
'BO hook
'BO hook
1
1Models with lights(LED)
Models without lights
2
PARTS & ACCESSORIES
2
8
9
10
3
4
5
6
7
Fig.2
Fig.1
2
3
4
5
7
8
9
10
11
11
6
Remote control x 1set
10
11
'BO hook
'BO hook
1
1Models with lights(LED)
Models without lights
ling cover

3
INSTAKK THE DOWNROD ASSEMBLY
Coupling cover
Canopy
IMPORTANT: SWITCH OFF THE ELECTRICAL MAINS THE CIRCUIT BREAKER FUSE BOX.
Follow the steps below to hang your fan properly.
Fig.3
Fig.3
Fig.5
Fig.4
Downrod
Bolt
 Insert the downrod through the canopy and Doupling cover (Fig.4) . Align the holes at the bottom of
the downrod with the holes in the NPUPSCSBDLFU on top of the fan motor assembly.(Fig.5)

Carefully insert the bolt through the holes in the motor shaft and downrod. Be careful not to
jam against the wires inside the downrod. Insert DMFWJT pin to ensure security.
 Tighten the two screws on top of the fan motor CSBDLFU firmly, Slide down the DPVQMJOH
cover.
(Fig.5)
down rod
Parts screws(C)
Parts screws(C)
Pin (B)

4
7
INSTALLATION OF THE MOUNTING HOOK
Bolt
Nut
$MFWJT1in
Spring Washer
Ceiling
Hook
a
WARNING
!
Screw Screw
Safety
Cable
1 2 3
1).Remove the safety Cable Screw from the downrod bracket.
2).Arrange and tie the Safety Cable as above image
labelled with 2.
Safety Cable must be fixed correctly.
May cause injury if ceiling fan drops.
Install Safety Cable
rubber
wheel
3).Firmly screw the Safety Cable onto the downrod.
 “J” Hook mounted When mounting the fan, ensure that the safety cable is loop across the “J” hook

“U” Hook mounted Remove the bolt, DMFWJT pin, nut, washer and rubber pulley from the
downrod. Place the rubber pulley onto “U” hook and fix back the bolt, DMFWJT pin, nut and washer.
Fig.6 Fig.7
Fig.8

5
Ceiling
Black(AC IN N)
Red(AC IN L)
ELECTRICAL CONNECTION
Warning : To avoid possible electric shock, turn off the electricity at the main fuse
box or circuit panel before the fan electrical connection. For safety and best
installation result please consult a qualified electrician.
7. Connect wires: As shown in the below (Fig.9)
 Connect the Black wire from motor to the Black "For Light L" wire from Receiver
with a wire nut.
 Connect the Blue wire from motor to the Blue "For Light N" wire from Receiver
with a quick connector.
 Connect the Pink wire from motor to the Pink "TO MOTOR V " wire from Receiver
with a quick connector.
 Connect the Red wire from motor to the Red "TO MOTOR U " wire from Receiver
with a quick connector.
 Connect the Grey wire from motor to the Grey "TO MOTOR W " wire from
Receiver with a quick connector.
 The electric wire(MJWF) the Red "AC in L" wire from Receiver with a wire nut.
 The electric wire (neutral) the Black "AC in N" wire from Receiver with a wire nut
 The ground wire from the Hanger Ball and the green ground wire from the
Hanger Bracket with a wire nut. (Make sure all of wire nuts are connected firmly.)
8. When the connection is completed, raise the top canopy and tighten it with the
screw attached, Tighten the Set Screw of the Coupling cover.(Fig.10)
quick connector
Fig.9
Fig.10
Screw

6
BLADE INSTALLTION
8. Insert the screws through the motor blade holder then secure the blade to the
motor by tightening the 2 screws.
9Repeat this process to install the other blades to the motor.
Fig.11
Blade
Screw
4
7
INSTALLATION OF THE MOUNTING HOOK
Bolt
Nut
$MFWJT1in
Spring Washer
Ceiling
Hook
a
WARNING
!
Screw Screw
Safety
Cable
1 2 3
1).Remove the safety Cable Screw from the downrod bracket.
2).Arrange and tie the Safety Cable as above image
labelled with 2.
Safety Cable must be fixed correctly.
May cause injury if ceiling fan drops.
Install Safety Cable
rubber
wheel
3).Firmly screw the Safety Cable onto the downrod.
 “J” Hook mounted When mounting the fan, ensure that the safety cable is loop across the “J” hook

“U” Hook mounted Remove the bolt, DMFWJT pin, nut, washer and rubber pulley from the
downrod. Place the rubber pulley onto “U” hook and fix back the bolt, DMFWJT pin, nut and washer.
Fig.6 Fig.7
Fig.8

7
INSTALL THE LIGHT KIT & BOTTOM COVER
11. Install the lamp on the fan assembly then secure it by turning clockwise.
Note: Compatible voltage 220-240V 50Hz max 12W GX53 LED Lamp are included
Fig.11
Fig.12
bottom cover
GX53 LED
10. Take off 1 screw from the connection base, and loPsen the other two screws
(do not remove).
Attach the fan light plate onto the lamp base, and slide through the two key holes
on plate by turning clockwise, then
4
7
INSTALLATION OF THE MOUNTING HOOK
Bolt
Nut
$MFWJT1in
Spring Washer
Ceiling
Hook
a
WARNING
!
Screw Screw
Safety
Cable
1 2 3
1).Remove the safety Cable Screw from the downrod bracket.
2).Arrange and tie the Safety Cable as above image
labelled with 2.
Safety Cable must be fixed correctly.
May cause injury if ceiling fan drops.
Install Safety Cable
rubber
wheel
3).Firmly screw the Safety Cable onto the downrod.
 “J” Hook mounted When mounting the fan, ensure that the safety cable is loop across the “J” hook

“U” Hook mounted Remove the bolt, DMFWJT pin, nut, washer and rubber pulley from the
downrod. Place the rubber pulley onto “U” hook and fix back the bolt, DMFWJT pin, nut and washer.
Fig.6 Fig.7
Fig.8

8
USING YOUR REMOTE CONTROL
 *OTFSU 2 units of 1.5V AAA battery into the remote control.
 Turn on the main switch power of the ceiling fan, then press
and hold the " " button within 3 seconds, wait until the
receiver makes a "beep" sound, and then let go of the button,
the pairing process is complete.
 If pairing multiple fans (ceiling fans using the same RF and
DC motors). Turn on the power to the first ceiling fan, then turn
off the power to the other ceiling fans and follow steps 1 and 2
above to complete the ceiling fan pairing. Repeat for the
second and other ceiling fans.
Switch OFF the fan
Switch ON/OFF the light.(Each time the button is
pressed quickly, the LED color changes in sequence:
warm white > natural white > cool white > off, repeat
the above steps.)
Fan speed-1 (lowest)
Fan speed-2
Fan speed-3
Fan speed-4
Fan speed-5
Fan speed-6
Fan speed-7 (highest)
Fan Forward/Reverse (the SBUBUJOH direction of ceiling fan)
Natural wind mode(fan speed repeat cycle from speed-1 to
speed-6,and then from speed-6 to speed-1, changes are
made within every 8 seconds.)
Sleep mode(fan speed auto-reduce to speed-2 after 1 hour
of initial speed and stay at speed-2.)
TIMING 1H (fan turn off after 1 hour)
TIMING 4H (fan turn off after 4 hours)
TIMING 8H (fan turn off after 8 hours)
- Correct battery type: AAA 1. 5V battery X 2PCS.
- Batteries should be inserted in the correct polarity.
- Do not charge non-rechargeable batteries.
- Do not mix different types of batteries or old and new batteries.
- Used batteries must be removed from the device and disposed
of safely.
- If the device is left unused for a long period of time, the batteries
should be removed.
1
2
3
4
5
6
RF Transmitter /Receiver pairing procedure
Installation:
 *nstall the RF Transmitter holder on wall with the 2
screws provided.
 Install provided battery into the RF Transmitter.
Note:
 RF Taransmitter pack included 2 pieces of 1.5 (AAA)
battery.
 All RF transmitter had been pre-paired during production
from factory.PlFBTF follow the RFparing procedure as
below if the ceiling fan could not operate.
In order to reduce damage to the RF transmitter,if you don’t use for a long time,please take out the battery
Buttons function description:
Maintenance and Precautions:
Fig.14
o
e”

9
Due to fan’s natural movement, connections may get loose after a period of usage. To
ensure a proper and safety usage,*UJThighly recommended to inspect and tighten
all connections every 6 months.
CLEANING
Clean your fan periodically to prolong its new appearance. Basic cleaning procedures are as
follows:
 Use only lukewarm water. Do not use detergent, corrosive or acidic solution.
 Damp the cloth lightly. Use only soft or lint-free cloth to clean the fan. Rough fabric will
scratches the surface.
 To cover small scratches, apply a light coat of shoe polish over it.
 There is no need to lubricant the fan.
MAINTENANCE
TROUBLESHOOTING
C
h
e
c
k
o
n
t
h
e
f
o
l
l
o
w
i
n
g
b
e
f
o
r
e
l
o
d
g
i
n
g
a
s
e
r
v
i
c
e
r
e
p
o
r
t
.

SYMPTOM PROBLEM SOLUTION
Fan not moving • Main cables not connected
• Wire connection loose
Fan noisy
Remote control
Not working
• Housing screws are loose
• Wire and nut connections rattles
against each other.
• Canopy touches the ceiling
• Tighten all screws
• Separate and store neatly the
wire connections from the nut.
• Check to ensure the canopy is
not touching or too close to the
Ceiling.
• Check main and branch
circuit breakers or fuse.
• Check the line wires connec-
tions to the fan and switch
housing.
• Remote and receiver code different
• Battery not installed
• Weak battery
• Check that the codes to ensure
exactly the same.
• Install the remote control
battery
The official website : https://www.nsb.com.my
The maintenance cycle and method of maintenance.
