NSB FAN JUMBO User manual

INSTRUCTION MANUAL
JUMBO / BIANCA
CEILING FAN

1
SAFETY PRECAUTION
IMPORTAN: PLEASE READ BEFORE INSTALLATION
1. Installation must be carried out by a qualified wiring installer
2. Turn off the electrical mains at the circuit breaker fuse box
3. Use power supply 220-240V/50Hz.
4. The ceiling mounting must be able to with hold a min of 16kg.
5. Install ceiling fan blade more than 2.3 M above floor.
6. Do not place any objects in the path of the blades.
7. When all electrical connection is done, store all wire neatly.
8. Make sure that all screws and connection are tightly screwed and secured.
9. This appliance is not intended for use by persons (including children) with Reduced physi-
cal, sensory or mental capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the appliance by a person responsi-
ble for their safety. Children should be supervised to ensure that they do not play with the
appliance.
10. his appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by
children without supervision.
11. An all‐pole disconnection must be incorporated in the fixed wiring in accordance with the
wiring rules, a all‐pole disconnection incorporated in the fixed wiring is to be provided.

2
PARTS & ACCESSORIES
1
2
6
7
8
34
5
8
9
1 Mounting bracket x 1
2 Fan motor assembly x 1
3 Fan blade bracket x 1
4 Fan bladesx 3
5 Fan blades fixing cap x 3
6 Fan blades screw x 9 (and 1 spare)
7 Wire Nut x 3
8 Expansion screws x 2
9 Remote receiver x 1 set
10 Remote transmitter x 1 set
ROTATE
TURBO
HI
MED
LOW
OFF
Fig.1

3
FAN INSTALLATION INSTRUCTION
The fan must be installed so that the lowest point of the fan blade must be 2.3m from the floor.
NOTE: The lowest point of the fan blade is when the fan head is adjusted to 45°.
The ceiling fan must be installed in a location so that the blades are a minimum 1M spacing
from the tip of the blade to the nearest objects or walls.
Fig. 2
Foor
Wall or any
other object
＞2.3M
＞1M

4
WARNING: Make sure electricity off at the main power box before commencing work.
• Install the hanging bracket to the ceiling joist or structure that is capable of carrying a load of
at least 16kg, with the two long screws(expansion screws) provided.(3)
• Remove the key pin from the side of hanging bracket.(4)
• Lift the fan assembly onto the mounting bracket, put the holes of down rod and plug aligning
the hanging bracket holes, Make sure to tighten the key pin to prevent the fan from falling .(5)
All electrical connections must be in accordance with local and national electrical code
standards. If you are unfamiliar with proper electrical wiring connections obtain the
services of a qualified electrician.
• Make the wire connection L, N, and Rotate to the remote receiver as shown the diagram
below in Fig. 6
• Carefully insert the Remote Receiver above the hanger ball in the remainder spacing in the
mounting bracket. Take care not to damage or loosen any of the wiring Fig. 7
INSTALLATION OF THE MOUNTING BRACKET
ELECTRICAL WIRING DIAGRAM
Hanging bracket
Expansion screws
Key pin Key pin
Plastic plug
Down rod
TO MOTOR N Remote
Receiver
TO MOTOR N
Quick connector for
infra red sensor
Infra red sensor
for remote control
TO MOTOR L
TO MOTOR L
FOR ROTATE
FOR ROTATE AC IN L
220-240V/50Hz
Power supply
AC IN N
Fig.3
Fig.6
Fig.7
Fig.7
Fig.4 Fig.5

5
CANOPY ASSEMBLY
• After completing electrical connection, cover the MOUNTING BRACKET with the CANOPY.
• Ensure that all electrical wiring is carefully tucked inside the canopy.
• Locate 2 screws on underside of mounting bracket.
• Attach canopy to the mounting bracket by placing screws into slotted holes in canopy.
• Twist clockwise to lock into place. Tighten screws firmly.
Fig.8
Screws

6
• Align the 3 mounting holes on the blade (3) to the 3 mounting holes of the blade bracket (2);
• Insert the fixing cap (4) into the mouting holes from the bottom of the blade (3) and secure
by tightening the 3 screws (1) from the top of the blade bracket (2).
• Once completed, repeat the same process on the remaining blades.
• Install the assembled fan-blades (7) to the motor part (5).
• Tighten the 2 set screws (6) on the side of the motor shaft.
NSTALLATION OF THE FAN BLADES
(1)
(2)
(3)
(4)
(5)
(6)
(7)
Fig.9
Fig.10

7
• Loosen the two set screws on both sides of the motor; (Fig.11)
• Rotate the fan head and aim the arm screw at the desired angle (There are only three angles
available: 0°, 45°, 90°.They are labelled on the motor part) (Fig.12)
• Retighten the set screws after adjusting to the desired angle. Ensure the set screws are
tighten and postioned well into the slot of the desired angle. (Fig.13)
ADJUSTMENT OF THE FAN HEAD
45 degree Horizontal 90 degree
Vertical 0 degree
Arm Screws
Set Screws
Arm
Screws
0
90
45
Fig.11
Fig.12
Fig.13

8
Due to fan’s natural movement, connections may get loose after a period of usage.
To ensure a proper and safety usage, We are highly recommended to inspect and
tighten all connections every 6 months.
CLEANING
Clean your fan periodically to prolong its new appearance. Basic cleaning procedures are as
follows:
1. Use only lukewarm water. Do not use detergent, corrosive or acidic solution.
2. Damp the cloth lightly. Use only soft or lint-free cloth to clean the fan. Rough fabric will
scratches the surface.
3. Apply a thin coat of furniture polish to the wooden blades will protect and enhance the
appearance.
4. To cover small scratches, apply a light coat of shoe polish over it.
5. There is no need to lubricant the fan.
MAINTENANCE
TROUBLESHOOTING
Check on the following before lodging a service report.
SYMPTOM
PROBLEM
SOLUTION
Fan not moving
• Main cables not connected
• Wire connection loose
Fan noisy
Remote control
Not working
• Housing screws are loose
• Wire and nut connections rattles
against each other.
• Canopy touches the ceiling.
• Tighten all screws
• Separate and store neatly the
wire connections from the nut.
• Check to ensure the canopy is
not touching or too close to the
Ceiling.
• Check main and branch
circuit breakers or fuse.
• Check the line wires connec-
tions to the fan and switch
housing.
• Remote and receiver code different
• Battery not installed
• Weak battery
• Check that the codes to ensure
exactly the same.
• Install the remote control
battery
