NSI 804CP Operating instructions

LUMA-NET
804CP / 808CP
REMOTE CONTROL PANEL
INSTALLATION AND OPERATION GUIDE
Software Revision 3.00, Version C
INTRODUCTION
The NSI 804CP and 808CP represents a key part of a state of the art, total lighting control system. Combined
with NSI dimmers and optionally, an NSI memory control console, a totally integrated system is achieved.
The 804CP and 808CP can automatically take control and preset the lighting level of up to 100 dimmer channels.
Control is automatically passed between control panels and the memory control console as desired. The 804CP
features 4 zone slide controls while the 808CP features 8 zone slide control. Both units are exceptionally easy to
operate. Remote lockout capability is also included. Installation is a snap with the simple 4 wire digital connection
required.
IMPORTANT
•Programming differs from other Luma-net panels, please read instructions.
•Programming of dimmer channels beyond factory defaults requires computer and software interface
package
•Luma-net control panels with software release 3.00 and higher are not directly compatible and will
not operate with older 400CP panels with software prior to release 3.00. Contact dealer or factory
for modifications if necessary.
•NSI dimming systems used with these release 3.00 panels require the following software releases:
2408CD, 2408CR, 2404CD release 2.30 and above.
DDS 8600/8800/9600/9800 release 1.30 and above. *
DDS 6000 release 1.30 and above. *
DDS 5300/5500/5600 release 1.30 and above. *
*Optional interface kit required for these units.

WIRING
The 804CP and 808CP will only operate with NSI dimming and control systems explicitly designed for interfacing
with it. Communication between the panels and the dimming system is via a 4 wire interface. Three wires carry
the RS 422/485 bi-directional data. A fourth wire carries the DC voltage necessary for powering the unit.
Wiring cable between the panels and the dimming system is class 2 and should be at least 22 AWG, 4 conductor
shielded, twisted pairs. (BELDEN 8302, 8723; 22 AWG.) Use 20 AWG for runs over 500ft.
The 804CP and 808CP may be connected to the dimming system via parallel or daisy-chained wiring. Due to
power supply current demands, panels must be limited to 5 units per daisy chain run with 22 awg wire, or 10
units with 20 AWG wire.
The Luma-net panels feature plug on wiring terminals. The terminals may be unplugged from the panel to facilitate
ease of wiring and testing. Connect the terminals marked remote+, remote-, common, and +15 VDC to the same
respective terminals on the dimming system and other Luma-net panels. Use one twisted pair for remote+ and
remote- and the other pair for common and +15 VDC.
The wiring to the remote lockout switch, if used, can be simple 2 conductor 22 AWG. Connect the wires from
the switch to the lockout+ and lockout- terminals. Any panel or group of panels may be locked-out remotely by
interrupting the +15V supply to the panels. This should not affect any other panels still powered, or affect lighting
levels currently set.
IMPORTANT: Verify wiring is correct before powering system! Make sure nothing conductive may touch
pc board or components!
MOUNTING
The 804CP and will mount in any standard double-gang electrical box, while the 808CP will mount in a large
three-gang box with the 4 screws provided. See below paragraph on system turn-on before final mounting of
panels.
SYSTEM TURN-ON
It is very important that the system operation be verified one panel at a time. Else, an improper connection at
one panel would cause the entire system to not operate properly and may be difficult to diagnose.
After all terminal plugs have been wired and the dimmer system has been installed and tested, the installer is ready
to connect each panel to the system. Panels may be plugged-in while system is live, but the installer must take
care not to touch PC board or connections with fingers or metal objects. On daisy-chain runs, the panels closest
to the dimming system should be connected first.
804CP and 808CP panels have dip switches to set network ID number and must have their ID programmed before
the system power is connected. It is recommended that the installer review the programming procedures for
network ID before proceding. A duplicate network ID number will cause the entire network to malfunction.
Connect the first panel and immediately notice whether the POWER LED comes on, indicating power to the
panel. The BUSY LED should come on momentarily and then go out and stay out. This indicates a successful
reconfiguration of the network. If the BUSY LED flashes slowly, this indicates a duplicate ID number or wiring
problem. Program the ID number, if not already, and observe the BUSY LED. (Note, the busy LED also flashes
quickly when the program jumper is removed).
Now test the dimmer function by operating the panel. If the dimmer responds, then mount the panel and procede
to the next panel in the system and follow the same procedure.
REMOTE CONTROL PANEL
Software Revision 3.00, Version C
NSI CORPORATION 2

LEDS
The PWR LED indicates the presence of +15VDC to the panel.
The CONTROL ACTIVE green LED’s indicate that the panel has control over any dimmers assigned
to the repective zone and the dimmer levels have not been altered by any other panel. The LED will
go out as soon as another panel changes the levels of any dimmer assigned to that particular zone.
The BUSY LED indicates the following:
Off Normal state when there is no activity.
Short Blinks A message is being sent on the network.
Steady on or Slow flashing Network trying to reconfigure (bad ID?)
While programming, the following actions are normal.
Quickly flashing Programming mode.
LOCKOUT
Any 804CP and 808CP may be disabled from operation with a remote key switch or other contact closure. Several
Luma-net panels of the same version may be connected to the same contacts in parallel as long as polarity is
maintained.
Closing the contact will prevent connected panels from operating, regardless of button presses.
Luma-net panels may also be locked out by causing a switch to disconnect the +15V supply to the panels.
REMOTE CONTROL PANEL
Software Revision 3.00, Version C LEDS
NSI CORPORATION 3

PROGRAMMING
The 804CP and the 808CP come from the factory programmed for the following, unless special factory programming
was requested:
Dimmer channels for each zone: Zone 1-4 (1-8) = Ch 1-4 (1-8) respectively
Fade time for each zone and presets: 1 second
PRESET button levels: Zone 1-4 (1-8) full
ALL OFF button levels: Zone 1-4 (1-8) off
The installer may reprogram the PRESET and ALL OFF buttons easily without additional equipment. Other
features such as dimmer channel assignment and fade time require a computer and software.
Details on programming other features are supplied with the Luma-net Software Package.
Optionally, the unit may be ordered preprogrammed from the factory.
REMOTE CONTROL PANEL PROGRAMMING
Software Revision 3.00, Version C LOCKOUT
NSI CORPORATION 4

Programming the PRESET and ALL OFF buttons:
In order to program panels, a jumper block must be removed from the program jumper pins. This will allow data
to be stored in the eeprom memory. At this point the BUSY LED will start flashing, indicating that you are in
the program select mode.
IMPORTANT: After programming it is important to replace the programming jumper block so memory
will be protected. DO NOT press all three buttons down simultanously while the jumber is removed, this
will erase programming.
To program:
1. Make sure that the 804CP or 808CP is in the program select mode as discussed. The BUSY LED should
be flashing.
2. Set the zone levels as desired using the slide controls.
3. Press the PRESET or ALL OFF button to store the new zone levels.
4. Replace the programming jumper. Test the button operation.
Network ID number
Network ID number must be set to a uniqe number (IMPORTANT).
Since the Luma-net System is a digital network, all panels and devices attached (except dimmers) must have a
unique network ID number.
If two panels have the same network ID number, the entire network will stop functioning.
Panels need not be in program mode to change network ID number, since a dipwitch is used.
To set Network ID number:
1. Locate dipswitch on rear of unit as illustrated below.
2. Set the switches as per the chart on the following page.
Factory Default Setting:
The 804CP and 808CP are programmed at the factory for zone 1-4 (1-8) to be set for dimmer channel 1-4 (1-8)
respectively. PRESET is programmed for dimmers 1-4 (1-8) full on. ALL OFF is programmed for dimmers 1-4
(1-8) off. The fade rate and other parameters are also set to factory defaults. This may be acceptable for initial
testing. If it is necessary to return the panel to it’s factory default settings (except network ID), follow this procedure:
Caution: Special factory programming will be lost.
1. Remove program jumper block and disconnect plug-in terminal block.
2. Hold down all pushbuttons while connecting terminal block.
3. Setting is complete when busy light begins to flash after several seconds.
REMOTE CONTROL PANEL PROGRAMMING
Software Revision 3.00, Version C Programming the PRESET and ALL OFF buttons:
NSI CORPORATION 5

ID number codes / dipswitch settings
ID number 12345678 ID number 12345678 ID number 12345678
000000000 110000000 201000000
311000000 400100000 510100000
601100000 711100000 800010000
910010000 10 01010000 11 11010000
12 00110000 13 10110000 14 01110000
15 11110000 16 00001000 17 10001000
18 01001000 19 11001000 20 00101000
21 10101000 22 01101000 23 11101000
24 00011000 25 10011000 26 01011000
27 11011000 28 00111000 29 10111000
30 01111000 31 11111000 32 00000100
33 10000100 34 01000100 35 11000100
36 00100100 37 10100100 38 01100100
39 11100100 40 00010100 41 10010100
42 01010100 43 11010100 44 00110100
45 10110100 46 01110100 47 11110100
48 00001100 49 10001100 50 01001100
51 11001100 52 00101100 53 10101100
54 01101100 55 11101100 56 00011100
57 10011100 58 01011100 59 11011100
60 00111100 61 10111100 62 01111100
63 11111100 64 00000010 65 10000010
66 01000010 67 11000010 68 00100010
69 10100010 70 01100010 71 11100010
72 00010010 73 10010010 74 01010010
75 11010010 76 00110010 77 10110010
78 01110010 79 11110010 80 00001010
81 10001010 82 01001010 83 11001010
84 00101010 85 10101010 86 01101010
87 11101010 88 00011010 89 10011010
90 01011010 91 11011010 92 00111010
93 10111010 94 01111010 95 11111010
96 00000110 97 10000110 98 01000110
99 11000110 100 00100110 101 10100110
102 01100110 103 11100110 104 00010110
105 10010110 106 01010110 107 11010110
108 00110110 109 10110110 110 01110110
111 11110110 112 00001110 113 10001110
114 01001110 115 11001110 116 00101110
117 10101110 118 01101110 119 11101110
120 00011110 121 10011110 122 01011110
123 11011110 124 00111110 125 10111110
126 01111110 127 11111110
For channels 129 - 256 Set dipswitch 1-7 as above and set dipswitch #8 on.
REMOTE CONTROL PANEL PROGRAMMING
Software Revision 3.00, Version C ID number codes / dipswitch settings
NSI CORPORATION 6

OPERATION
Slide controls:
Moving a slide control will cause an immediate takecontrol of all dimmers assigned to that zone. The lighting
levels will fade up or down quickly to match the slide control level, and the LED of the zone will illuminate
indicating that the slider has full control. (This feature may be modified through computer software wheras the
MANUAL button must first be pressed to gain control.)
The LED of the zone will go out when either the PRESET or ALL OFF button is pressed, or if another panel
gains control of the dimmer channel assigned. (A control console will not affect the LEDs.)
Default dimmer assignment are : Zone 1-4 (1-8) = Dimmer Channel 1-4 (1-8).
MANUAL button:
When pressed, this button will cause all dimmer channels assigned to all zones of this panel to fade to the current
settings of the slide controls. All zone LEDs will come on and the slide controls will have full control.
PRESET button:
This button will cause all dimmer channels assigned to all zones of this panel to fade to the zone setting previously
programmed. (Default is all full on.) All zone LEDs will go out.
ALL OFF button:
This button will cause all dimmer channels assigned to all zones of this panel to fade to the zone setting previously
programmed. (Default is all full off.) All zone LEDs will go out.
To restore control from a console:
Simply perform a change in the channel level from the console. The lighting channel will then fade back to the
new console level at the factory default fade rate. Once the console level matches or is moved past the lighting
level, full console control will be resumed for that channel.
REMOTE CONTROL PANEL OPERATION
Software Revision 3.00, Version C Slide controls:
NSI CORPORATION 7

WARRANTY
NSI Corporation Limited Warranty
NSI Corporation warrants new electronics products to be free from defective materials and workmanship for a
period of one (1) year from the date of purchase to the original owner when purchased from an authorized NSI
dealer.
The purchaser is responsible for completing and mailing to NSI, within 15 days of purchase, the warranty registration
card enclosed with each product. NSI products that have been subject to accident, alteration, abuse, or defacing
of the serial number are not covered by this warranty. The normal wear and tear of items such as knobs, jacks,
and switches are not covered under this warranty.
If your NSI product requires service during the warranty period, NSI will repair or replace, at its option, defective
materials provided you have identified yourself as the original owner of the product to NSI or any authorized NSI
dealer. Transportation charges to and from an authorized dealer or the NSI factory for repair shall be the responsibility
of the owner. All products returned to NSI must have factory authorization for return prior to shipping.
NSI Corporation is not liable for any incidental or consequential damages resulting from defect or failure other
than repairs of the NSI product subject to the terms of this warranty. This warranty gives you specific legal rights,
and you may have other rights which vary from state to state. This warranty is expressly in lieu of all other
agreements and warranties expressed or implied except as may be otherwise required by law.
REMOTE CONTROL PANEL OPERATION
Software Revision 3.00, Version C NSI Corporation Limited Warranty
NSI CORPORATION 8
