OPERATIONMANUALANDPARTSLIST
HARDSURFACETOOL
NSSPART#4091341


 NSS®Enterprises,Inc.
3115FrenchmensRoad
Toledo,OH43607
Phone:(419)531‐2121
Fax:(419)531‐3761
www.nss.com

ImportantSafetyInstructions
IntendedUse
ThisproductisintendedtobeusedwiththeRally1200hardsurfacecleaningmachineforcleaningfloors.Thistool
maybeusedwithotherequipment.Seeinstructionsinthisdocumentforusewithotherequipment.
ForSafety
Alwaysreadandunderstandallinstructionsbeforeoperatingorservicingthistool.
Alwaysusethismachineonlyasdescribedinthismanual.Incorrectuseofthistoolmayresultinfloor
damageorpersonalinjury.
Neverattempttooperatethistoolunlessyouhavebeentrainedinitsoperation.
Neverallowanuntrainedpersontooperatethistool.
Neverattempttooperatethistoolifitisnotworkingproperlyorhasbeendamagedinanymanner.
Alwayswearcleantennisshoesor“non‐slip”shoes.Leathersoledshoeswillbeextremelyslippery.
Neverallowthistooltofreeze.



SaveTheseInstructions

Specifications
Model4091341HardSurfaceTool:
CleaningHead:Width:15inches
CleaningHead:Height:3.13”w/HardBoot&3.50”w/BrushRing
TotalHeightwithHandle:51inches
Weight:15.5lbs.
ShellConstruction:Polycarbonate
HardBoot:HDPE
BrushBristles:Nylon
HandleConstruction:StainlessSteel
MaximumSolutionPressure:1500psi
MinimumSolutionPressure:700psi

Maintenance
Tokeepthistoollookingandworkingitsbestforthelongestperiodofuse:
AftereachuserinsetheInnerShellofthetooltoremoveaccumulateddirtanddebris.TheInnerShellcan
beseparatedfromtheOuterShelltocleantheairflowchannelbetweenthetwoshells.
Rinseandwipedowntopofheadassemblyandhandle.
RinseandwipecleantheHardBootortheBrushRing.
ExamineHardBoot‐ReplacetheHardBootifworndownordeepgougesandembeddeddebrisare
found.
ExaminetheBrushRing‐ReplaceBrushringifbristlesareexcessivelybent,wornoriftoomanybristles
aremissing.
Checkandcleanthestainlesssteelmeshfilterbetweenthequickconnectandvalvetopreventa
reductioninwaterflowandtoolefficiency.
Checkthespraypatternofthejetsandcleanorreplacethejetsasneededtoassureevenspraypattern.
Checkvacuumhoseforholesorcracks.
Replacevacuumhoseasneeded.

VacuumReliefVentAdjustment
Thistoolhasvacuumreliefventsontopoftheheadassembly.Toincreasethewaterrecovery,movethevacuum
reliefslidetothelefttoclosethethreevents.Topreventthistoolfromstickingtothefloorandtomakethetool
easiertomove,pushthevacuumreliefslidetotherighttoopenthevents.Trydifferentslidepositionsettingsto
getthebestmovementandrecoveryforyourequipmentandthetypeoffloorbeingcleaned.











Usingthistoolwithextractorswithhigherairflowwillgenerallyrequirethevacuumreliefventstobeopened
more.Usingthistoolwithsmallerportableextractorsmayrequirethevacuumreliefventstobeclosedforthe
bestwaterrecovery.WhenusingtheHardBootthevacuumreliefventswillusuallybeopenedmorethanitis
whenusingtheBrushRingwiththesameextractor.
VacuumReliefVentsClosedVacuumReliefVentsOpen
Vacuum
ReliefSlide
Vacuum
ReliefSlide

HardBootandBrushRingUse
Thistoolcomeswithahardbootandabrushring.Youhavetheoptiontochoosetoinstalleithertypeforthe
floorbeingcleanedandtheequipmentused.

BrushRing
(Part#4091811)
HardBoot
(Part#4091761)

UseoftheHardBootshouldbelimitedtodurablesurfacessuchasceramictile.
DonotusetheHardBootonsoftsurfacessuchasmarble.TheHardBootmayscratchsoftsurfaces.
UseoftheBrushRingwillhelppreventscratchingofsoftsurfaces.

ChangingtheHardBootandBrushRing
ChangingbetweentheHardBootandtheBrushRing
canbedonequicklyandeasilywithouttools.
1.Disconnectthesolutionhosefromtheswivel.
2.Liftthethreeretainerleversontopofthetoolto
releasetheretainers.

SolutionHose
RetainingLever(1)
RetainingLever(2)
RetainingLever(3)
Swivel


3.Turnthedeckoverandturnthethreerectangularretainingnutsontheretainerstoalignwiththeholesinthe
bottomoftheInnerShell,sotheycanpassthroughtheholes.

Threerectangularretainingnuts Retainingnutalignedforinnershellremoval
4.Pullandseparatetheinnershellfromtheoutershell

5.LiftupandremovetheHardBootorBrushRingfromthebottom
lipoftheoutershell.

6.PlaceeithertheBrushRingortheHardBootontothebottomlip
oftheOuterShell.
7.PlacetheInnerShellbackontotheOuterShellwiththe
rectangularretainingnutsgoingthroughtheopeningsintheInner
Shell.TheflangesontheInnerShellsetontheedgeoftheHard
BootorBrushRingtoholditinplace.

8.Turntherectangularretainingnutsperpendiculartotheslotsin
thebottomoftheInnerShell.Retainingnutsmayneedtobe
tightenedsothattheyeachcontacttheplasticsurfaceoftheinner
shellwhentheretainingleversarepushedbackdowntoassurethat
theassemblyissecuredproperly.

9.Turntheheadassemblybackoverandsnapthethreeretaining
leversbackdowntosecuretheOuterandInnerShells.Checkthe
retainingnutstobesureallthreeareincontactwiththeplastic
InnerShell.Opentheretainingleversandtightenretainingnutsas
neededtoassurethattheInnerShellisproperlysecuredwhenthe
leversarepusheddown.
10.Reconnectthesolutionhosetotheswivel.


Usingthistoolwithotherequipment
Thistoolwillworkwithportableortruckmountedextractors,butthewaterrecoverymaybebetterwithhigher
poweredextractorswithmoreairflow.Theextractorsolutionpumpmustprovideaminimumof700psiofwater
pressurewithaflowrateofatleast1.5gpm(GallonPerMinute).At1000psitheflowratemustexceed2.0gpm
andat1500psitheflowratemustexceed3.0gpm.
Therecommendedpressurefortooloperationis700to1200psi.
Set‐upProcedure
1. InstalltheHardBootorBrushringonthetool.
2. Connectthevacuumhosefromyourextractortothevacuumpipeonthetoolhandle.A2”cuffwillfit
overthepipe,a1‐1/2”cuffwillfitinsidethepipe.
3. Connectthesolutionhosefromtheextractortothequickconnectonthevalveassembly.
4. Turntheextractoron.Adjustthewaterpressuretothedesiredvalue.Minimumpressure:700psi.
Maximumpressure:1500psi.
5. Adjustthevacuumreliefslideforbestrecoveryandeaseofmovement.
BasicCleaningProcedure
Removeallfurniturefromtheareayouaregoingtoclean.Sweeporvacuumthefloortoremovedustandgrit,
piecesofglass,sand,etc.

Itisimportantforyoutoshowutmostcareforyourclient’shomeandfurnishings.PlaceCornerGuardswhen
movingyourhosesaboutandusefurnitureskiddersorfloorguardsformovingheavyappliances.Noteanyplaces
whereothersurfacesborderthefloor.Carpet,cabinets,delicatewallcovering,orpaintedsurfacesneedtobe
protectedfromalltypesofoverspray.Cautionandcareinsprayingisgenerallysufficient,butmaskingoruseofa
sprayshield(likethoseusedbypainters)workswellandmaybenecessaryinhigh‐riskareas.Useremovable
painter’stapetoavoiddamagetowoodfinisheswhenmaskingisremoved.Ifthepre‐spraysareoversprayedon
thecarpettheycansimplyberinsedusingyourcarpetwand.
Selectanappropriatepre‐sprayandapplytothefloor.Usually,a5minuteorlessdwelltimeisideal.Excessive
dwelltimemayactuallyretardthecleaningprocessbysoakingindeeperandrequiringmoredryingtimebefore
sealing.Youcouldinadvertentlybeginaprocessofefflorescencebyover‐wetting.Avoidlettingthepre‐spraydry
onthefloorbyextractingwithinthefiveminutetimeframe.Forgreatestefficiency,ahelpercanassistyouby
sprayingthreetofiveminutesaheadasyouextract.Beginbygoingoverlargeareaswiththetool.Recommended
pressureis700to1500psi.Itisusuallyeasiesttomoveatamoderaterateforwardandbackward.Youneedonly
overlapenoughtoassurecompletecoverage.Movingtoofastwillcreateaspiralpatterninthegroutortile.Slow
downsothispatterndoesnotoccur.Useairmoverswhereyouhavejustextractedtogetthegroutdryasquickly
aspossible,especiallyifyouplantosealthegroutthesameday.

HardSurfaceToolPartList















‐‐
Decal
(4091671)
SprayGun
(4091371)
HandleSS
(4091681)
SprayGun,BodyOnly
(4091711)
HoseClamp
(4091691)
HoseClamp
(4091691)
VacuumHose2”IDx3’Long
(
4091751
)

















‐‐
Swivelw/Flange
(4091781)
OuterShell
(4091701)
SwellLatch(Qty3)
(4091801)
BrushRing
(4091811)
SolutionHoseHP
3/16”IDx50”,1/8MPT
1/8”MPTand1/4”MPTEnds
(4091821)

















‐‐
Bushing,Bronze3/8”IDx5/8”ODx2”
(QTY2)
(
4091941
)
Screw3/8‐16x2”SSSocHead
(QTY2)
(
4091951
)
Nut3/8
–
16SSNylock
(QTY2)
(
4091961
)
Washer,Flat3/8”SS
(QTY2)
NOTSHOWN
(4091971)
Washer,Flat3/8”SS
(QTY2)
(4091971)
Swivelw/Flange
(4091781)QC1/8”Malex1/8”MPT
(4091981)
QC1/8”Femalex1/8”FPT
(4091991)
















‐‐
RetainingNut,Rectangular
QTY3
(
4094021
)
HardBoot
(4091761)
InnerShell
(4093961)
OuterShell
(4091701)
















‐‐
Swivelw/Flange
(4091781)
VacuumReliefRing
(4093971)
InnerShell,TopView
(4093961)
InnerShell,BottomView
(4093961)
Veejet 1/8”SSMEG0502
(QTY2)
(4092001)
SprayBarSS
(4094121)
Screw1/4”‐28x1/2”SSPHP
(QTY3)
(4093981)
Screw1/4”‐28x1/2”SSPHP
(QTY3)
(4093981)
SwivelW/Flange
(4091781)













‐‐
Grommet
(4094001)
EndCap
(4093991)
SprayGun,BodyOnly
(4091711)
SprayGun
(4091371)
Nut10‐32Nylock
(QTY6)
(4093931)
Nut10‐32Nylock
(QTY6)
(4093931)
SolutionHoseHP
3/16”IDx50”,1/8MPT
1/8”MPTand1/4”MPTEnds
(4091821)
SprayGun
(4091371)
SprayGun,BodyOnly
(4091711)
Screw10‐32x1‐5/8”BHSOCSS
(QTY6)
(4093941)
QC1/4”Male
(3590751)

















‐‐
SprayGun
(4091371)
QC1/4”Male
(3590751)
StrainerBody
(4093231)
Strainer50SS
(4093911)
StrainerAdapter
(4093921)
Elbow901/4”Street
(4093061)
Elbow451/4”Street
(4094221)
ReplacementValveforSprayGun
(4093081)SprayGunValveRepairKit
(4093221)
ValveRepairKitContains:
Spring
SSBall
Seat
SeatO‐Ring
Stem
StemO‐Ring
Back‐UpRings(Qty2)
CapO‐Ring
ValveCap

HardSurfaceTool,OperationManualandPartsList  RevA10‐15    9094071
