NTI XTENDEX Series User manual

Man014 Rev. 6/26/09
600 FOOT EXTENDERS
Installation and Operation Manual
XTENDEX®Series
ST-C5KVM-600
PS/2 KVM Extender
ST-C5KVM-600M
PS/2 KVM Extender
VMCTINT-3-MM
(sold separately)

i
TRADEMARK
XTENDEX is a registered trademark of Network Technologies Inc in the U.S. and other countries.
COPYRIGHT
Copyright © 2003, 2009 by Network Technologies Inc. All rights reserved. No part of this publication may be reproduced, stored
in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written consent of Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202.
CHANGES
The material in this guide is for information only and is subject to change without notice. Network Technologies Inc reserves the
right to make changes in the product design without reservation and without notification to its users.
Note: Shielded CAT 5,5e, or 6 cable must be used to connect to LOCAL and REMOTE units in order to meet CE emission
and immunity requirements.
Note: CAT5 connection cable used between NTI XTENDEX Series Local and Remote or any XTENDEX Series products
should not be run underground, outdoors or between buildings.
WARNING: Outdoor or underground runs of CAT5 cable could be dangerous and will void the warranty.
CE Statement
We, Network Technologies Inc, declare under our sole responsibility that the ST-C5KVM-600(M), STC5KVMRS-600(M),
STC5VMA-600(M), ST-C5V-600(M), STC5VRS-600(M), ST-C5VA-600(M), ST-C5SV-600, and ST-C5SVA-600 is in conformity
with European Standard EN55022.
Federal Communications Commission Radio Frequency Interference Statement
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference and
(2) this device must accept any interference received, including interference that might cause undesired operation.
This device complies with Part 15 of the FCC rules. This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment.
Warning: This equipment generates, uses and can radiate radio frequency energy, and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.

ii
TABLE OF CONTENTS
Introduction...................................................................................................................................................................... 1
Materials .......................................................................................................................................................................... 2
Features and Functions................................................................................................................................................... 4
Limitations ....................................................................................................................................................................... 6
Preparation for Installation .............................................................................................................................................. 6
Installation ....................................................................................................................................................................... 7
Installing The Local Unit (models with VGA video connectors).................................................................................. 7
Installing The Local Unit (models with S-Video connectors) ...................................................................................... 9
Installing the Local Unit (models with only KM connectors) ...................................................................................... 10
Connect The CAT5 Cable.......................................................................................................................................... 11
Installing The Remote Unit (models with VGA video connectors)............................................................................. 11
Installing The Remote Unit (models with S-Video connectors) ................................................................................. 13
Installing The Remote Unit (models with only KM connectors) ................................................................................. 14
Connect the CAT5 cable............................................................................................................................................ 14
Plug-in and Boot Up................................................................................................................................................... 15
Rackmount Modules (optional)................................................................................................................................. 16
Mount the ST-C5RCK-12 Rackmount Extender Module Tray................................................................................ 16
Connect the CPU .................................................................................................................................................... 18
Connect the Devices............................................................................................................................................... 19
Connect the CAT5 cable......................................................................................................................................... 20
Plug-in and Boot Up................................................................................................................................................... 21
Video Quality ................................................................................................................................................................. 22
Technical Specifications................................................................................................................................................ 23
Interconnection Cable Wiring Method ........................................................................................................................... 24
Troubleshooting............................................................................................................................................................. 24
Index.............................................................................................................................................................................. 25
Warranty Information..................................................................................................................................................... 25
TABLE OF FIGURES
Figure 1- Connect the Local Unit with VGA video and RS232 support to the CPU............................................................................7
Figure 2- Connect the Local Unit with Audio support to the CPU ...................................................................................................... 8
Figure 3- Connect the local user to the XTENDEX Local Unit ...........................................................................................................8
Figure 4- Connect stereo speakers to XTENDEX Local Unit with audio support ...............................................................................9
Figure 5- Connect the S-Video Local Unit to the s-video/audio source..............................................................................................9
Figure 6- Connect S-Video display and speakers to Local Unit with s-video support ...................................................................... 10
Figure 7- Connect Local Unit with only keyboard and mouse support ............................................................................................. 10
Figure 8- Connect CAT5 cable to Local Unit.................................................................................................................................... 11
Figure 9- Connect the Extended Components to the Remote Unit .................................................................................................. 12
Figure 10- Connect speakers to the Remote Unit ............................................................................................................................ 12
Figure 11- Connect components to an S-Video Remote Unit .......................................................................................................... 13
Figure 12- Connect keyboard and mouse to Remote Unit ............................................................................................................... 14
Figure 13- Connect the CAT5 cable to the Remote Unit.................................................................................................................. 14
Figure 14- Connect the AC adapter to the Remote Unit .................................................................................................................. 15
Figure 15- Mount ST-C5RCK-12 Extender Module Tray in a rack................................................................................................... 16
Figure 16- Secure each module to the tray...................................................................................................................................... 16
Figure 17- Secure each power supply to the tray ............................................................................................................................ 17
Figure 18- Connect cable between CPU and module...................................................................................................................... 18
Figure 19- Connect cable between user and module ...................................................................................................................... 19
Figure 20- Connect the CAT5 cable between the Local and Remote Units ..................................................................................... 20
Figure 21- Connect AC adapters ..................................................................................................................................................... 21
Figure 22- Buttons for video quality adjustment ............................................................................................................................... 22
Figure 23- View looking into RJ45 female........................................................................................................................................ 24

NTI XTENDEX 600 Foot Extenders
1
INTRODUCTION
The XTENDEX Series CAT5 Extender (XTENDEX) is designed to enable one CPU to be controlled by two users, one local and
one remote. The remote user can be located as much as 600 feet away from a PS/2 CPU via Category 5 unshielded twisted-
pair cable. The local user will be located near the CPU.
Option:
Rackmount Modules- The XTENDEX Series CAT5 Extenders can be ordered as rackmount modules (Remote and/or Local
Units)- add “M” to the model number (i.e. ST-C5KVM-600M). When ordering rackmount modules, also order the ST-C5RCK-12
Rackmount Extender Module Tray (see page 16).
The XTENDEX Series Extender is extremely simple to install and has been thoroughly tested to insure reliable performance.
Through the use of Category 5 cable it is possible to economically increase the flexibility of a computer system. Here are some of
the features and ways this can benefit any workplace:
•Allows the placement of computer peripherals (monitor, keyboard, and mouse) in a location where
only these parts are needed without having the CPU there too, taking up valuable space
•Allows a PS/2 CPU to be accessed by both a local and remote user (up to 600 feet away)
•Compatible with XGA, VGA, and SVGA systems
•Provides crisp and clear resolution up to 1024 x 768 @ 600 feet (see page 21 for more details)
•Compatible with all NTI switches and splitters, enabling the joining of products to create a system that
satisfies all networking needs
•Video quality adjustment, for varying lengths of cable, is automatic (most models, see below and
page 20) providing optimum image quality
•Audio frequency response is 20Hz to 20Khz, + 1Db (models with audio support only)
•Digital transmission of audio signals reduces any loss in quality (models with audio support only)
This manual covers each of the XTENDEX Series CAT5-600 Extender models offered. Some features described in this manual
are available in some models and not in others. The chart below shows the features supported in each:
Model Video Keyboard Mouse
Support
Audio
Support
RS232
Support
Video Quality
Adjustment
ST-C5KVM-600 VGA Yes No No Automatic
ST-C5KVMA-600 VGA Yes Yes No Automatic
ST-C5KVMRS-600 VGA Yes No Yes Automatic
ST-C5V-600 VGA No No No Manual
ST-C5VA-600 VGA No Yes No Automatic
ST-C5VRS-600 VGA No No Yes Automatic
ST-C5SV-600 S-Video No No No Manual
ST-C5SVA-600 S-Video No Yes (RCA) No Automatic
ST-C5KVMRS-600-SCI VGA Yes No Yes Manual
ST-C5KM-600 NO Remote only No No Not Applicable
Note: Rackmount modules are not available with S-Video support

NTI XTENDEX 600 Foot Extenders
2
MATERIALS
Materials Included with this kit:
9NTI XTENDEX Local Unit
9NTI XTENDEX Remote Unit
92- 120VAC or 240VAC at 50 or 60Hz-9VDC/1.0A AC Adapters (only 1 ST-C5KM-600)
9CD with a pdf file of this owner's manual
Additional materials may need to be ordered, depending upon the configuration:
¾CAT5/5e/6 unshielded twisted-pair cable(s) terminated with RJ45 connectors wired straight thru- pin 1 to pin 1, etc. (see pg.
8 for proper EIA/TIA 568 B wiring method)
Note: Shielded CAT 5,5e, or 6 cable must be used to connect to LOCAL and REMOTE units in order to meet CE emission
requirements.
¾Cable(s) needed if Local Unit will be located further than 15" from the CPU
Model Cable(s) needed
ST-C5KVM-600 VKMEXT-xx (xx= 3/6/10/15/25/35/50/75/100 feet)
ST-C5KVMRS-600 VKMEXT-xx and DINT-xx
ST-C5KVMA-600 VKMEXT-xx and SA-xx-MF
ST-C5V-600 VEXT-xx
ST-C5VRS-600 VEXT-xx and DINT-xx
ST-C5VA-600 VEXT-xx and SA-xx-MF
ST-C5SV-600 SVEXT-xx
ST-C5SVA-600 SVEXT-xx and SA-xx-MF
ST-C5KM-600 VVKINT-xx or VVKEXT-xx
Cables Lengths Available
Cable xx= Length in feet
VKMEXT-xx 3/6/10/15/25/35/50/75/100
VEXT-xx 3/6/10/15/25/35/50/75/100
DINT-xx 6/10/15
SA-xx-MF 6/12/25/50
SVEXT-xx 1/3/6/10/15/25/35/50/75/100
VVKINT-xx 3/6/10/15/25
VVKEXT-xx 35/50/75/100
For Rackmount Modules the following materials are required- not supplied:
Model Cables needed
ST-C5KVM-600M VMCTINT-xx-MM and VMCTINT-xx
ST-C5KVMRS-600M VMRSTINT-xx-MM and VMRSTINT-xx
ST-C5KVMA-600M VMATINT-xx-MM and VMATINT-xx
ST-C5V-600M VTINT-xx-MM and VTINT-xx
ST-C5VRS-600M VRSTINT-xx-MM and VRSTINT-xx
ST-C5VA-600M VATINT-xx-MM and VATINT-xx
Legend:
xx= 3, 6, 10, 15 or 25 foot length
MM= cables have male connectors on both ends (except for the DB9) and are only used with Local Units
Note: If two users will be connected (one local and one remote), two of the cables without the “MM”
(i.e. VMCTINT-xx) will be needed.
Contact your nearest NTI distributor or NTI directly for all of your KVM needs at 800-RGB-TECH (800-742-8324) in US & Canada
or 330-562-7070 (Worldwide) or at our website at http://www.networktechinc.com and we will be happy to be of assistance.

NTI XTENDEX 600 Foot Extenders
3
FEATURES AND FUNCTIONS
8b 11c
3
ST-C5SVA-600 Local Unit
4b
5b
-+
XTENDEX
NTI R
Net work Te ch nolo gies Inc
-+
15
(Front View) (Rear View)
11d
NTI R
Net work Te ch nolo gies Inc
XTENDEX
8a 9 10
1
3
ST-C5KVMRS-600 Local Unit
11a
2
4a
5a
6
7
-+
XTENDEX
NTI R
Network Tech nologies Inc
-+
15
(Front View) (Rear View)
NTI R
Net work Te ch nolo gies Inc
XTENDEX
8a 9 10
ST-C5KVMA-600 Local Unit
11b
4a
5b
-+
XTENDEX
NTI R
Network Tech nologies Inc
-+
15
(Front View) (Rear View)
3
6
7
NTI R
Network Tech nologies Inc
XTENDEX
910
ST-C5KM-600 Local Unit
6
7
XTENDEX
NTI R
Netw ork Tech nologies Inc
(Front View) (Rear View)
NTI R
Netw ork Tech nologies Inc
XTENDEX
3

NTI XTENDEX 600 Foot Extenders
4
FEATURES AND FUNCTIONS
1. Green LED- traffic indicator- illuminates when there is communication between the local and remote units.
2. Yellow LED- power indicator- illuminates when power has been supplied to the unit
3. Cat 5- RJ45 female- for connecting the CAT 5 cable
4a. Video Connector- 15HD female- for connecting the local user's VGA monitor
4b. S-Video Connector- 4 pin miniDIN female- for connecting the local user's S-video display (S-Video models
only)
5a. RS232 Connector- 9D male- for connecting the local user's touchscreen monitor (models with RS232
support only)
5b. Audio Jack- 3.5mm stereo audio jack- for connecting to local speakers (models with audio support only)
6. Mouse Connector- green female 6 miniDIN- for connecting the local user's mouse
7. Keyboard Connector- purple female 6 miniDIN- for connecting the local user's keyboard
8a. Video Connector- blue 15HD male- for connecting to the video port on the CPU or KVM switch
8b. S-Video Connector- black 4 pin miniDIN male- for connecting to the s-video port on the video source
(S-Video models only)
9. Mouse Connector- green male 6 miniDIN- for connecting to the mouse port on the CPU or KVM switch
10. Keyboard Connector- purple male 6 miniDIN- for connecting to the keyboard port on the CPU or KVM switch
11a. RS232 Connector- light gray 9D female- for connecting to the RS232 port on the CPU or KVM switch
(models with RS232 support only)
11b. Audio Plug- 3.5mm stereo audio plug- for connecting to CPU audio line out (models with audio support
only)
11c. Audio Plug- red RCA plug- for connecting to the right channel audio (model ST-C5SVA-600 only)
11d. Audio Plug- white RCA plug- for connecting to the left channel audio (model ST-C5SVA-600 only)
12. Keyboard Connector- purple female 6 miniDIN- for connecting the remote user's keyboard
13. Mouse Connector- green female 6 miniDIN- for connecting the remote user's mouse
14a. RS232 Connector- 9D male- for connecting the remote user's touchscreen monitor (models with RS232
support only)
14b. Audio Jack- 3.5mm stereo audio jack- for connecting to remote speakers (models with audio support only)
15. 9VDC- 1.0A- connection jack for the AC adapter
16a. Video Connector- 15HD female- for connecting the remote user's monitor
16b. S-Video Connector- 4 pin miniDIN female- for connecting the remote user's S-video display (S-Video
models only)
17. Buttons- for manually adjusting video quality (models ST-C5V-600, ST-C5SV-600, and ST-C5KVMRS-600-SCI only)
ST-C5KVMA-600 Remote Unit
16a
1213
14b 15
-+
-+
(Front View) (Rear View)
3
NTI R
Netw ork Tec hnolo gies Inc
XTENDEX
NTI R
Network Technologies Inc
XTENDEX

NTI XTENDEX 600 Foot Extenders
5
18. USER- .05 SCSI II Female- for connecting cable between module and the user devices
19. CPU- .05 SCSI II Female- for connecting cable between the module and the CPU
15
ST-C5SVA-600 Remote Unit
14b
3
16b
-+
-+
(Front View) (Rear View)
NTI R
Network Tec hnolo gies Inc
XTENDEX
NTI R
Network Te chnolo gies Inc
XTENDEX
CAT5
REMOTE UNIT
NTI R
ST-C5KVM-600M
XTENDEX RKVM
CAT5
LOCAL UNIT
NTI R
ST-C5KVM-600M
XTENDEX RKVM
9V
1.0 A
USER CPU
L
0
C
A
L
U
N
I
T
ST-C5KVM-600M
NTI R
www.networktechin c.com
USER
9V
1.0 A
R
E
M
O
T
E
U
N
I
T
ST-C5KVM-600M
NTI R
www.networktechin c.com
3
319
18
18
15
15
ST-C5KVM-600M
Local Module
Front and Rear Views
ST-C5KVM-600M
Remote Module
Front and Rear Views
(All XTENDEX 600 foot extender modules have the same connections)
16a
ST-C5KVMRS-600-SCI Remote Unit
12
13
14a 15
-+
-+
(Front View) (Rear View)
1
3
2
17
NTI R
Netw ork Tec hnolo gies Inc
XTENDEX
NTI R
Netw ork Tec hnolo gies Inc
XTENDEX
ST-C5KM-600 Remote Unit
1213
(Front View) (Rear View)
3
NTI R
Netw ork Tech nologies Inc
XTENDEX
NTI R
Netw ork Tech nologies Inc
XTENDEX
-+
-+
15

NTI XTENDEX 600 Foot Extenders
6
LIMITATIONS
•Hot-plugging of devices is supported provided devices were originally connected at power-up.
•In order for two users to share a PS/2 CPU, the user in control must pause for at least 3 seconds before another user can
take control. After the 3 second pause, either user can take control of the CPU.
For models with RS232 support:
•The RS232 ports on the Local and Remote Units will support serial devices other than touchscreen monitors as follows:
•2 simple devices (i.e. mice) connected to each unit, or
•1 complex device (i.e. serial modem, RS232 command port on an NTI switch) connected to
either the Remote or Local Unit.
•In order for two users to share a PS/2 CPU, the user in control must pause for at least 3 seconds before another user can
take control. After the 3 second pause, either user can take control of the CPU.
•The RS232 port supports all baud rates up to 56K bits per second and the attached CPU must be configured accordingly.
For models with audio support:
•The audio input of the XTENDEX with audio support is compatible with the following standard CPU audio outputs:
•Line out - typically lime green in color
•Speaker out- typically orange in color
•Headphone out- typically located on the CD-ROM
•To connect the ST-C5SVA-600 to a CPU, it may be necessary to use an RCA phono-to-3.5mm stereo jack adapter
•The audio output of the XTENDEX with audio support is compatible with self-powered stereo speakers.
PREPARATION FOR INSTALLATION
•Locations should be chosen for the monitors, mice, and keyboards that also have space to connect the Remote and Local
Units within the distance provided by the cables. If extension cables are needed, contact NTI for the cables required.
•The CAT5 cables must be run to the locations where the Remote and Local Units will be connected. Be careful to route the
cables away from any sources of magnetic fields or electrical interference that might reduce the quality of the video signal
(i.e. AC motors, welding equipment, etc.).
•All cables should be installed in such a way that they do not cause stress on their connections to the equipment. Extended
lengths of cable hanging from a connection may interfere with the quality of that connection. Secure cables as needed to
minimize this.
•Properly shut down and disconnect the power from the CPU and monitors to be separated. If other equipment is involved
whose connections are being interrupted, be sure to refer to the instruction manuals for that equipment for proper
disconnection and re-connection procedures before proceeding.
Note: CAT5 connection cable used between NTI XTENDEX Series Local and Remote or any XTENDEX Series products
should not be run underground, outdoors or between buildings.
WARNING: Outdoor or underground runs of CAT5 cable could be dangerous and will void the warranty.

NTI XTENDEX 600 Foot Extenders
7
INSTALLATION
Installing The Local Unit (models with VGA video connectors)
1. Plug the cables of the Local Unit into the back of the CPU. (See Figure 1.)
a) Connect the blue 15HD cable end to the VGA port on the back of the CPU.
b) Connect the purple 6 pin miniDIN cable end with the keyboard symbol
on it to the keyboard port on the back of the CPU. (KVM models only)
c) Connect the green 6 pin miniDIN cable end with the mouse symbol
on it to the mouse port on the back of the CPU. (KVM models only)
Figure 1- Connect the Local Unit with VGA video and RS232 support to the CPU
d) If the Local Unit has RS232 support, connect the light gray 9D cable end to the RS232 port on
the back of the CPU.
e) If the Local Unit has Audio support, connect the black 3.5mm stereo plug into the "line out",
"spkr", or "headphones" jack on the back of the CPU. (See Figure 2)
Notes:
If all 3 jacks are available, use the jack marked "line out".
The "line out" jack is typically lime green and may be marked with this symbol
The "spkr" jack is typically orange, and may be marked with this symbol
The "headphones" jack may be marked with this symbol
(Mouse)
(Keyboard)
ST-C5KVMRS-600 Local Unit
(Front View)
15HD Female
Video Connector
6 pin miniDIN
Male Connector
(GREEN-MOUSE)
(PURPLE-KEYBOARD)
(BLUE- VIDEO)
PS/2 CPU
6 pin miniDIN
Female
Connector
DEVICE
CONNECTORS
VIDEO
CONNECTOR
15HD Male
Video Connector
(LIGHT GRAY- RS232)
9D Female Connector
9D Male
RS232 Connector
SERIAL
CONNECTOR
-+
NTI R
Netw ork Tech nologies Inc
XTENDEX

NTI XTENDEX 600 Foot Extenders
8
Figure 2- Connect the Local Unit with Audio support to the CPU
2. Make connections for a local user (see Figure 3)
a) Connect the cable from the local user's VGA monitor to the female 15HD port on the Local Unit.
b) Connect the local user's keyboard to the purple 6 pin miniDIN female port on the Local Unit.
c) Connect the local user's mouse to the green 6 pin miniDIN female port on the Local Unit.
Figure 3- Connect the local user to the XTENDEX Local Unit
VGA
Multi-Scan
Touch-screen
Monitor
PS/2 KEYBOARD PS/2 MOUSE
15HD Female
Video Connector
Front View of
Local Unit
ST-C5KVMRS-600 Local Unit (Front and Rear View)
9D Male
RS232 Connector
Rear View of Local Unit
Local User's Keyboard, Monitor, and Mouse
6 pin miniDIN
Female Connector
NTI R
Network Technologies Inc
XTENDEX
-+
ST-C5KVMA-600 Local Unit
(Front View)
(GREEN-MOUSE)
(PURPLE-KEYBOARD)
(BLUE- VIDEO)
PS/2 CPU
-+
NTI R
Netw ork Tech nologies Inc
XTENDEX
(BLACK- AUDIO)
3.5mm Stereo Plug
AUDIO CONNECTOR
line
out
ONE WILL BE MARKED "line
out" ,"spkr", "headphones"
OR WITH THIS SYMBOL

NTI XTENDEX 600 Foot Extenders
9
d) If the Local Unit has RS232 support, connect the local user's RS232 cable from a touch screen
monitor to the 9D male port on the Local Unit.
e) If the Local Unit has audio support, connect the cable from the local speakers to the 3.5mm
stereo audio jack on the Local Unit. (See Figure 4)
Figure 4- Connect stereo speakers to XTENDEX Local Unit with audio support
Installing The Local Unit (models with S-Video connectors)
1. Plug the cables of the Local Unit into the back of the s-video source. (See Figure 5.)
a) Connect the 4 pin miniDIN male cable end to the s-video port on the video source.
b) If the Local Unit has audio support, connect the red RCA plug to the "right" speaker jack on the
audio source and connect the white RCA plug to the "left" speaker jack on the audio source.
Note: Refer to the owner's manual of the s-video/audio source to determine how the left and right audio channels are
labeled.
Figure 5- Connect the S-Video Local Unit to the s-video/audio source
ST-C5SVA-600 Local Unit
(Front View)
DVD Player
4 pin miniDIN Male
S-Video Connector
-+
Red RCA Plug
Right Channel
White RCA Plug
Left Channel
NTI R
Netw ork Tech nologies Inc
XTENDEX
Front View
ST-C5KVMA-600 Local Unit
NTI R
Netw ork Tech nologies Inc
XTENDEX
-+
3.5mm Stereo
Audio Jack
Stereo
Speakers

NTI XTENDEX 600 Foot Extenders
10
2. Make connections for a Local User (see Figure 6)
a) Connect one end of an SVEXT-xx-MM cable to the s-video port on the display.
b) Connect the other end of the same SVEXT-xx-MM cable to the s-video port on the Local Unit.
c) If the Local Unit has audio support, connect the cable from the local speakers into the 3.5mm
jack on the local unit.
Figure 6- Connect S-Video display and speakers to Local Unit with s-video support
Installing the Local Unit (models with only KM connectors)
1. Plug the cables of the Local Unit into the back of the CPU. (See Figure 7)
a) Connect the green 6 pin miniDIN cable end with the mouse symbol on it to the mouse port on the back of the CPU.
b) Connect the purple 6 pin miniDIN cable end with the keyboard symbol on it to the keyboard port on the back of the
CPU.
Figure 7- Connect Local Unit with only keyboard and mouse support
Front View
ST-CSVA-600 Local Unit
NTI R
Netw ork Te chnol ogie s Inc
XTENDEX
-+
3.5mm Stereo
Audio Jack
Stereo
Speakers
Rear View
Local User's Display
S-Video
Display
SVEXT-xx-MM
ST-C5KM-600 Local Unit
(Front View)
(GREEN-MOUSE)
(PURPLE-KEYBOARD)
PS/2 CPU
NTI R
Netw ork Tech nologies Inc
XTENDEX
6 pin miniDIN
Female Connector
DEVICE
CONNECTORS
6 pin miniDIN
Male Connector

NTI XTENDEX 600 Foot Extenders
11
Rear View of Local Unit
Green Traffic LED
Yellow Power LED
XTENDEX
NTI R
Netw ork Tech nologies Inc
-+
CAT5 Cable to
Remote Unit
Connect The CAT5 Cable
Connect the CAT5 cable to the “Cat 5” port on the Local Unit.
(See Figure 8.) When properly inserted the cable end should
snap into place.
Note: If an RJ45 wall outlet is being used, connect the other
end of the extension cable to the RJ45 wall outlet.
WARNING: Never connect the XTENDEX to an Ethernet
card, Ethernet router, hub or switch or other Ethernet RJ45 connector
of an Ethernet device. Damage to devices connected to the
Ethernet may result.
Figure 8- Connect CAT5 cable to Local Unit
Installing The Remote Unit (models with VGA video connectors)
1. Position the Remote Unit such that the CAT5 cable, the monitor cable, device cables, and the AC
adapter power connector can each reach the Remote Unit without putting strain on the cables.
2. Connect the monitor cable to the female 15HD video connector on the Remote Unit.
3. Connect the device(s) to the Remote Unit (see Figure 9)(KVM models only).
a) Connect the keyboard to the purple female 6 pin miniDIN connector on the Remote Unit.
b) Connect the mouse to the green female 6 pin miniDIN connector on the Remote Unit.
4. If the Remote Unit has RS232 support, connect the remote user's RS232 cable from a touch
screen monitor to the 9D male port on the Remote Unit.
5. If the Remote Unit has audio support, connect the cable from the remote speakers to the 3.5mm
stereo audio jack on the Remote Unit. (See Figure 9)
!

NTI XTENDEX 600 Foot Extenders
12
Figure 9- Connect the Extended Components to the Remote Unit
Figure 10- Connect speakers to the Remote Unit
9D Male
RS232 Connector
Front View of
Remote Unit Rear View of Remote Unit
VGA
Multi-Scan
Monitor
PS/2 KEYBOARD PS/2 MOUSE
15HD Female
Video Connector
Remote User's Keyboard, Monitor, and Mouse
6 pin miniDIN
Female Connector
NTI R
Net work T ec hnol ogi es Inc
XTENDEX
-+
ST-C5KVMRS-600 Remote Unit (Front and Rear View)
Front View
ST-C5KVMA-600 Remote Unit
NTI R
Netw ork Tech nologies Inc
XTENDEX
-+
3.5mm Stereo
Audio Jack
Stereo
Speakers

NTI XTENDEX 600 Foot Extenders
13
Installing The Remote Unit (models with S-Video connectors)
1. Position the Remote Unit such that the CAT5 cable, the s-video cable, speaker cable, and the AC
adapter power connector can each reach the Remote Unit without putting strain on the cables.
2. Connect one 4 pin miniDIN end of another SVEXT-xx-MM cable to the Remote Unit.
3. Connect the other 4 pin miniDIN end of the SVEXT-xx-MM cable to the s-video port on the display.
4. If the Remote Unit has audio support, connect the speakers to the 3.5mm jack on the Remote Unit
(see Figure 11).
Figure 11- Connect components to an S-Video Remote Unit
Rear View
Remote User's Display
S-Video
Display
SVEXT-xx-MM
Front View
ST-C5SVA-600 Remote Unit
-+
NTI R
Network Technolo gies Inc
XTENDEX
3.5mm Stereo
Audio Jack
Stereo
Speakers

NTI XTENDEX 600 Foot Extenders
14
Rear View of Remote Unit
XTENDEX
NTI R
Network Tech nologies Inc
-+
CAT5 Cable to
Local Unit
Installing The Remote Unit (models with only KM connectors)
1. Position the Remote Unit such that the CAT5 cable, the keyboard cable, mouse cable and power supply cable can each
reach the Remote Unit without putting strain on the cables.
2. Connect the keyboard to the purple female 6 pin miniDIN connector on the Remote Unit.
3. Connect the mouse to the green female 6 pin miniDIN connector on the Remote Unit.
Figure 12- Connect keyboard and mouse to Remote Unit
Connect the CAT5 cable
Make sure the CAT5 cable has been installed in accordance with the “Preparation for Installation”
instructions on page 3. Connect the CAT5 cable to the “Cat 5” port on the Remote Unit. (See Figure 13.)
When properly inserted the CAT5 cable end should snap into place.
Note: If an RJ45 wall outlet is being used, connect
the other end of the extension cable to the RJ45 wall
outlet.
WARNING: Never connect the XTENDEX to
an Ethernet card, Ethernet router, hub or switch or other
Ethernet RJ45 connector of an Ethernet device. Damage
to devices connected to the Ethernet may result.
Figure 13- Connect the CAT5 cable to the Remote Unit
!
Front View
PS/2 KEYBOARDPS/2 MOUSE
Remote User's Keyboard and Mouse
6 pin miniDIN
Female Connector
NTI R
Netw ork Tech nologies Inc
XTENDEX
ST-C5KM-600 Remote Unit
-+

NTI XTENDEX 600 Foot Extenders
15
Plug-in and Boot Up
1. Plug the power cord from the monitor into the power outlet.
2. Connect each AC adapter power connector to the 9VDC ports on the Remote and Local Units Plug each AC adapter into a
power outlet. The yellow LED on the RJ45 connector of both the Remote and Local Units should illuminate, indicating that a
proper power connection has been made to them. (See Figure 14.)
Figure 14- Connect the AC adapter to the Remote Unit
3. Turn ON the CPU and Monitor. They should each react as if they were directly connected to each other.
Note: The green LED on each RJ45 connector will illuminate anytime data traffic is passing between the Local and
Remote Units, indicating proper CAT5 cable connection and communication. (See Figure 14)
Green Traffic LED
9 VDC
Adapter
ADAPTER
Barrel
(Inside
barrel)
(Outside
barrel)
Power Connector
2.1 mm x 5.5 mm Female
9VDC @ 1.0A OUTPUT
Yellow Power LED
Rear View of Remote Unit

NTI XTENDEX 600 Foot Extenders
16
Rackmount Modules (optional)
If ST-C5-600M Series XTENDEX rackmount modules (Local and/or Remote modules) are being installed, then an ST-C5RCK-12
Rackmount Extender Module Tray must be used (sold separately) to mount the modules to a RACK. The ST-C5RCK-12
provides a convenient mounting method for up to 12 Local and /or Remote XTENDEX modules.
Note: Rackmount Local modules are compatible with rackmount Remote modules or desktop Remote units.
Mount the ST-C5RCK-12 Rackmount Extender Module Tray
1. The ST-C5RCK-12 Rackmount Extender Module Tray was designed to be directly mounted in a rack. It includes a mounting
flange to make attachment easy.
2. Install 4 cage nuts (supplied) to the rack in locations that line up with the holes in the mounting flange on the tray.
Then secure the tray to the rack using four #10-32 x 3/4” screws (supplied). Be sure to tighten all mounting screws securely.
Figure 15- Mount ST-C5RCK-12 Extender Module Tray in a rack
3. Slide each module into the tray and line up the holes in the mounting plate on the module with corresponding holes in the tray.
Secure the module(s) using the two screws provided. Blank plates and screws are provided to cover empty module spaces.
Figure 16- Secure each module to the tray
4. Secure the power supply for each module to the power supply/cable management shelf at the rear of the tray using the bracket
and screw supplied.
CAT 5
LOCAL UNIT
NTIR
ST-C 5KVM-600M
XTENDEX RKVM
CAT 5
LOCAL UNIT
NTI R
ST-C 5KVM-600M
XTENDEX RKVM
CAT5
LOCAL UNIT
NTI R
ST-C 5KVM-6 00M
XTENDEX RKV M
Secure XTENDEX module(s) to the ST-C5RCK-12
using the screws provided.
Frontview of ST-C5RCK-12 with XTENDEX Extender Modules
Cage Nuts
Rack Screws
Rack
#10-32 x 3/4"
(supplied)
(supplied)

NTI XTENDEX 600 Foot Extenders
17
Figure 17- Secure each power supply to the tray
9V
1.5 A
USER CP U
L
0
C
A
L
U
N
I
T
ST-C 5U SB VA- 30 0M
NTIR
Tel:[phone]
Fax:[phone]
1275 Danner D r
Aurora,OH 44202
www.networkt echinc.com
Secure each power supply to the tray
using the bracket and screw provided.
Rearview of ST-C5RCK-12 with XTENDEX Extender Modules
Power supply mounting bracket
(supplied with each module)
Connect power cord to
power supply here
Plug power connector
into Extender module
Power supply/cable managment shelf
