NTI VOPEX-C5HD-4LC User manual

3
Panel View:
Local Unit (Transmitter)
No. Interface Description
1 Green LED Green LED indicates “ON” status.
2 Blue LED Blue LED indicates “HDMI IN” is connected to an HDMI source.
3 Blue LED Blue LED indicates “LOOPOUT” is connected to an HDMI display.
4 Rotary Switch Select EDID by rotating the switch from 0 to F. (please refer to EDID settings)
5 SET Button Press for 1 second to copy the selected EDID.
6 Output 1~4 Connects to Remote Units with CAT5e cables. (please refer to Notes2-4)
7 HDMI Input Connects to an HDMI source with an HDMI cable.
8 Loop Out Connects to an HDMI display or another Local Unit with an
HDMI cable. (please refer to Note 1)
9 Console Connects to RS232 control device with DB9(F) cable for controlling the
Local Unit or updating firmware. (please refer to RS232 settings)
10 Power Input Connects to DC12V 1A adapter.
Remote Unit (Receiver) (End Views)
No. Interface Description
1 Green LED Green LED indicates receiving power and video signals.
2 Yellow LED Yellow LED indicates no signal input or receiving an unsupported format.

4
Notes:
1. When connecting an HDMI display to the Loop Out port, make sure the HDMI cable connects to
"Input 1"of the HDMI display.
2. It is recommended to use unshielded CATx cable.
3. When using shielded cable, the transmission distance might be shorter. (i.e. CAT6a: 25-30M,
CAT7:25- 40M)
4. The cable must be straight, avoid rolling the cable to avoid crosstalk interference.
RJ45 Pinout
(Wiring to TIA/EIA-568B)
RS232 Wiring
HyperTerminal settings:〔57600bps (8-N-1)〕
Note: Pins not shown in table have no connection
RS232 Command Table
Command Description
OFF 1(Enter) OUTPUT 1 OFF
OFF 2(Enter) OUTPUT 2 OFF
OFF 3(Enter) OUTPUT 3 OFF
OFF 4(Enter) OUTPUT 4 OFF
OFF 5(Enter) HDMI LOOPOUT OFF
ON 1(Enter) OUTPUT 1 ON
ON 2(Enter) OUTPUT 2 ON
ON 3(Enter) OUTPUT 3 ON
ON 4(Enter) OUTPUT 4 ON
ON 5(Enter) HDMI LOOPOUT ON
TIA/EIA-568B Pinout
PIN Wire Color
1 Orange-white
2 Orange
3 Green-white
4 Blue
5 Blue-white
6 Green
7 Brown-white
8 Brown
RS232
Pin Signal
2 TX
3 RX
5 GND
By default, all Outputs and the HDMI Loopout are ON.
Note: After a reboot/power cycle,
the VOPEX-C5HD-4LC will
return to default settings.

5
EDID Table
Number EDID Number EDID
0 CustomizedEDID #1 81920x1080
1 CustomizedEDID #2 91920x1200
2 1024x768 A720p 50Hz LPCM 2CH
3 1280x720 B720p 60Hz LPCM 2CH
4 1280x1024 C1080p 50Hz LPCM 2CH
5 1366x768 D1080p 60Hz LPCM 2CH
6 1600x900 E1080p 50Hz MULTI
7 1680x1050 F1080p 60Hz MULTI
EDID Settings
Step1: Refer to EDID list above and find the number of which EDID is needed. (0~F)
Step2: Rotate the rotary dip switch arrow to the selected number.
Step3: Press the “SET” button for 1 second and the two blue LEDs will flash quickly.
Step4: Wait for the Local Unit to restart. Upon restart the process of EDID setting is complete.
Customize EDID Settings
Step1: Connect the display and "Loop Out"port through an HDMI cable.
Step2: Press and Hold the “SET” button for approximately 3 seconds, and the two blue LEDs will flash,
first slowly,then quickly.
Step3: Wait for the Local Unit to restart. Upon restart the process of copying EDID is complete.
Caution:
1. The wiring must be away from any equipment with electromagnetic waves, i.e.: microwave,
radio equipment, fluorescent lamps, high voltage power lines.
2. The VOPEX-C5HD-4LC is not a networking device. Do not connect it to an Ethernet
device (i.e. router, hub or switch)

MAN366 REV 1/14/20
6
