nubeca EL-1001 User manual

TABLE OF CONTENTS
*SAFETY INSTRUCTION
*INTRODUCTION
*SPECIAL FEATURES
*DESCRIPTION OF THE APPLIANCE
AND THE SUPPLIED ACCESSORIES
*INSTALLATION OF THE BATTERIES
*OPERATION
*CLEANING AND MAINTENACE
*SPECIFICATIONS
*WARRANTY
SAFETY INSTRUCTION
For your safety, it is recommended that you read this User Guide
very carefully, and comply with the following instruction.
*Using the appliance only as intended in accordance with the
instructions provided in this guide.
*This electric device is not a toy, avoid the reach of child
*Children under the age of 3, are not suited for this
appliance
*Children should be supervised by an adult while using this
electric device.
*Consult the physician before using this unit, if you have a pace
maker, artificial limbs or any electronic implant.
*Do not operate this unit close to a mobile telephone, a micro
wave oven, or a television set ( away more than 1 meter)
*Any persons who suffer from epilepsy or heart disease are not
recommended to use this appliance.
*Do not use this unit on moisture hair or any undo knots or braids.
*Avoid cracked or dry skin, or direct contact with your ears, eyes
and mouth.
*Avoid the direct exposure of sunlight, and upon any hot surface.
*Keep the unit away from moisture, or any liquid.
*Do not use the unit, if the housing or comb is damaged, if the unit
does not function properly or if it has been emerged by liquid.
*Prevent accident or damage to the unit by keeping the unit away
from clothing, bristles, wires, strings, shoelaces, threads ect.
*Always switch off the unit when not in use
*Remove the battery if the appliance is not to be used for
extended period.
INTRODUCTION
Head lice are tiny, wingless insects. When fully grown, they’re
similar in size to a sesame seed. Because they can’t survive the
cold, they cling to our hair, keeping close to the warmth of our
heads.
Head lice are harmless – though they can cause your child’s head
to itch. Head lice have been making a nuisance of themselves for
thousands of years. Fortunately, getting rid of them nowadays
need only take a ten minute treatment time!
The nu-beca electric lice comb is one viable option to consider in
the quest of eradicating head lice so they will stop spreading
through your family member's hair and scalp. It is certainly no
secret that an infestation of lice can make life difficult for everyone
in the household, but thanks to modern technology -- an electric
lice comb, the process of getting rid of these pests can be just a
lot easier.
SPECIAL FEATURES
nu-beca lice comb uniquely can not only dispel but also efficiently
kill head lice and nits by quickly, increasing electrical voltage of
130-180 Volts, which is harmless to human.
Comb activity is indicated by an audible signal, which provides
different sounds : one sound per three seconds indicates the
functional unit (60-90V) ; the short, sharp buzzer 1 second sound
per 0.5 second indicates the contact with the intruder (130-180V).
LED setting in the On/Off switch button : different level of scintilla-
tions to distinguish the functions and low battery.
Automatic switch off function
After 5 minutes not in use, the unit will switch off automatically for
extending the battery life..
Low battery indication, the unit will detect the battery if the voltage
is lower than normal working voltage, LED indicator will glitter
twice shorter, once longer quickly; the buzzer will sound continu-
ously for 30 sec. till switching off automatically.
Impeccable design for containing the accessories inside the main
appliance, portable and suitable for travel.

OPERATION
1.Press the On/Off switch button “1“, maintain two sec. to operate
the appliance.
LED indicator on, buzzer will hum three seconds to indicate
operation.
2.Use the appliance as normal comb. Please use the unit on
dry hair. Undo the knots or braids before using the unit.
3.While operating the unit, LED lights will be on and also the
buzzer will sound once every three sec.
4.The buzzer will have a short and quick humming sound, LED
indicator flashes quickly when the teeth come in contact a louse
or egg.
4-1.The voltage will kill the louse and eggs.
4-2.Be sure to clean the comb with the cleaning brush thoroughly
after every usage.
5.After use, remember to switch off the unit and clean the comb
with the cleaning brush thoroughly, put the protective cap “2”
back on the unit while the storage.
DESCRIPTION OF THE APPLIANCE AND THE
SUPPLIED ACCESSORIES
1.On/Off switch (press button)
2.Protective cover
3.Electric comb
4.Lid of the battery compartment
5.Cleaning brush
6.Battery compartment
INSTALLATION OF THE BATTERIES
Open the lid protecting the battery
by lifting the point “4“, the lid
connects the housing with one
part avoid the concern of missing.
Insert two AAA batteries, observe
the proper polarity (+/-)of the
batteries as indicated on the
batteries and on the battery
compartment. A polarity error
can damage your appliance
and compromise the guarantee.
CLEANING AND MAINTENACE
1.Remove the batteries before cleaning the appliance
2.Avoid using any liquid, strong detergents to scrub the unit.
3.For the housing, use a dry, soft paper or fabric cloth to clean.
For the teethes, use the accessory of cleaning brush.
4.Make sure no water gets into the unit while cleaning, and never
immerse the unit in water.
5.The storage should be in a clean, dry and cool, ventilative
location.
6.Direct exposure to sunlight will damage the unit
SPECIFICATIONS
WARRANTY
Please contact your dealer or the service center in case of a claim
under the warranty.
The following warranty terms apply:
1.The warranty period for nu-beca products is 1 Year from the
date of producing. In case of a warranty claim, make sure the
production date before the usage, if the production date is
expired or closed to expired, please contact your dealer or
service center.
2.Defect in material or workmanship will be removed free of
charge within the warranty period.
3.Repairs under the warranty do not extend the warranty period
either for the unit or for the replacement parts.
4.The following is excluded under the warranty:
a.Damages caused by improper use, not follows the user
instructions.
b.Damages caused by the repairs or tampering by the
consumer or unauthorized third parties.
c.Accessories which are damaged by wear and tear
2
1
3
4
1
2
-
+
4
5
6
3 4
Model name
Power supply
Stay by Current
Full Current
Export Voltage
Consumption
Battery life
Auto switch off
Dimension
Weight
Certificate
EL-1001
AAA battery x 2
30µA
30mA
30~180 V
35mA during use
Eight hour in continuous use
Yes
177 x 34 x 39 mm
200g
CE, RoHS
