Numatic TEM 390A-11 User manual

TEM390A-11
620W (Kit AS10)
Original Instructions
numatic.com
CAUTION, Read instructions before using the machine.
This machine is suitable for DRY use
only.
Make sure that the ltration system
tted to the machine is suitable for the
material being collected.
PLEASE READ
BEFORE COMMENCING
OPERATION
M-Class
GB

Kit AS10
601102 2.9m NuFlexFlex Hose 900918 MultiFlo 300 mm Dry Floor Tool
601008 Stainless Steel Extension Tube x2 601430 FreeFlo 290 Floor Tool
601052 Stainless Steel Bend Tube 601999 5 Piece Accessory Kit
601176 Multi Size Power Adaptor
Handle Assembly
2
1

Air Di󰀨user
Hose and Wands
3 54

Machine Function
2
1
On / O󰀨
If your appliance fails to operate, ensure that the Auto/Manual
switch (2) is in the o󰀨 position prior to switching the On/O󰀨
switch (1) to the On position.
Auto / Manual Switch
Auto Mode - If an external appliance fails to operate when
connected to the vacuum auxiliary socket (3) please check
and ensure that switch (1) & (2) are in the On position prior to
operating the external appliance.
1
2
TEM 390-A 2200W Maximum Load (min. 100W).
If the auxiliary socket is overloaded, the machine will cut out.
To reset switch o󰀨 the machine, then wait for
5 seconds before switching on.
110 Volt industrial models
TEM 390-A 1100W Maximum Load (min. 100W).
3

Using your Machine
Low Flow Warning Light
Low ow monitoring
Slow Repeated Flash.
The vacuum cleaner is tted with a warning lamp
that will illuminate and ash when the air speed in
the suction hose falls below 20m/s.
If problem persists...
Causes Solution
Suction hose blocked
or kinked.
Remove blockage or
kink.
Dust collection bag
full.
Replace dust bag
Filter clogged or
blocked.
Replace lter
cartridge.

Cleaning your Machine

901649
H13 Filter Cartridge
Replacing the Cartridge Filter

3
21
6
5
4
987
10 11
Changing / Replacing Cable
In the event of a breakdown
contact your Numatic dealer
or the Numatic Technical help
line [phone]

Moving your Machine

H05VV-F
10m x 3 x 1.5mm²
(110V) H05VV-F
10m x 3 x 1.5mm²
Failure to rectify the problem or in the event of a breakdown contact your Numatic dealer or the
Numatic Technical helpline [phone]
(GB) About your machine
PPE (personal protective equipment). That may be required for certain operations.
Ear Protection Safety Footwear Head Protection Safety Gloves
Eye Protection Protective Clothing Dust / Allergens
Protection Hi Viz Jacket Caution Floor Sign
NOTE: A risk assessment should be conducted to determine which PPE should be worn.
Maintenance
Daily
Keep the machine clean, including hoses and tubes.
Ensure the bag and  lter are  tted.
Regularly examine the power cord.
Check dust bag frequently.
Check  lters are clean.
Weekly - as daily and:-
Check for any worn or damaged parts and replace immediately.
WEEE (Waste, Electrical and Electronic Equipment)
Vacuum Cleaner Accessories and packaging should be sorted for environmentally-friendly recycling.
Only for UK/EU countries.
Do not dispose of Vacuum Cleaner into household waste.
According to the European Directive 2012/19/EU on waste electrical electronic equipment and its
incorporation into national law, vacuum cleaners that are no longer suitable for use must be separated,
collected and sent for recovery in an environmentally-friendly manner.
Rating Label
1 Company Name & Address
2 Machine Description
3 Voltage Frequency
4 Power rating
5 Machine yr/wk Serial number
6 Weight (ready to use)
7 WEEE Logo
8 Approvals Mark
9 Max Auxiliary load (if applicable)
10 Switch Identi cation
Safety Critical
Component:
Mains Lead
8
1
2
3
4
5
6
7
9
10
