Numeris Versa User manual

Mini RFID
Shared & Assigned Use Functionality
Product Guide
1
Lock Orientation
Keys
Key Insertion
1 Up to 6 Manager Keys may be programmed to each lock. If managed with the optional Mobile App, up to 250 Manager Keys may be programmed to each lock.
2 1 Programming Key allowed per lock system.
3 Up to 20 user credentials may be assigned to each lock. If managed with the optional Mobile App, up to 250 user credentials may be assigned to each lock.
User Key Manager Key1Programming Key2
Operates the lock •••
Overrides user access ••
Allows management inspection ••
Provides external power ••
Programs Manager Keys to the lock •
Assigns user credentials3(in assigned use functionality)
•
Sets lock functionality •
RFID
CARD
RFID Card
RFID Credentials
RFID Adhesive
Label
RFID Keyfob
RFID Wristband
Versa locks with a touch RFID interface are operated by an RFID credential or by an ADA compliant User Key. Manager credentials (Manager
Key or RFID) provide management access and/or external power. Programming is accomplished via a Programming Key unique to the lock
system. An optional mobile application tool simplifies lock system management and provides audit trail.
Numeris logo must face up
on vertical up body.
Numeris logo must face
down on vertical down body.
Numeris logo must face right
on horizontal left body.
Numeris logo must face left
on horizontal right body.
Vertical Up Vertical Down
Front Unit
Vertical
Horizontal Right
Horizontal Left
Key Button
Key Slot
Reader
LED Usage Indicator
Shared Use
Assigned Use
Knob
Horizontal Left Horizontal Right

Mini RFID
Shared & Assigned Use Functionality
Product Guide
2
RFID
CARD
Manager
Knob Positions
Setup
Locks are shipped with factory default settings (only operates by pressing `). Each lock must be set up to operate with a Programming
Key and manager credentials (Manager Key or RFID).
Insert the Programming Key.
A two-tone beep will be heard and
the LED and Reader will turn on.
Insert one Manager Key or present
one Manager RFID at a time.
A two-tone beep will be heard for each
manager credential programmed.
Insert the Programming Key.
A two-tone beep will be heard and
the LED and Reader will turn off.
Repeat above steps for each lock
or follow instructions to Express
Register Manager Credentials to
setup all the locks.
90º
180º
1324
Locked
Locked
Locked
Locked
180º CCW to unlock
90º CCW to unlock
180º CW to unlock
90º CW to unlock

Mini RFID
Shared & Assigned Use Functionality
Product Guide
3
Express Register Manager Credentials
The Programming Key can quickly program multiple locks to operate with the same manager credentials.
Go to a lock already programmed to operate with the manager credentials.
Touch and hold ` for 10 seconds (a two-tone beep will be heard after
5 seconds followed by 2 sets of two-tone beeps after 10 seconds) then
release. The LED will flash.
Insert the Programming Key.
Two sets of two-tone beeps will be heard and the LED will turn off.
Insert the Programming Key to program each lock to operate with the same
manager credentials.
Two sets of two-tone beeps will be heard and the LED will flash once
to indicate successful programming.
End express registration mode.*
Go to any programmed lock.
Touch `then insert the Programming Key.
Touch `then insert the Programming Key again to return the bolt to the
original position.
Programming Instructions
12 43
Add Manager Credentials
Manager credentials can be programmed to the locks at any time.
1
3
2
4a 4b
Go to a lock requiring additional
manager credentials.
Touch and hold ` for 5 seconds
(a two-tone beep will be heard after
5 seconds) then release.
The LED will flash and the Reader
will turn on .
Insert the Programming Key.
A two-tone beep will be heard.
Insert each additional Manager Key
or present each Manager RFID one
at a time.
A two-tone beep will be heard for each
manager credential programmed.
Insert the Programming Key.
A two-tone beep will be heard and
the LED and Reader will turn off.
Repeat above steps for each lock
or follow instructions to Express
Register Manager Credentials to
quickly program the same manager
credentials to operate multiple locks.
*The Programming Key will continue to function in express registration mode until it is used to operate a lock.
RFID
CARD
Manager

Mini RFID
Shared & Assigned Use Functionality
Product Guide
4
Programming Instructions
1
1a 1b
2
2a 2b
Replace Programming Key or Manager Credentials
The locks must be reprogrammed to prevent the lost/stolen Programming Key or manager credentials from operating a lock.
To replace the Programming Key:
Note the order or serial number (found on the lock’s rear unit). Contact Digilock Support to purchase a replacement Programming Key.
To replace Manager Credentials:
Collect all remaining and replacement manager credentials.
Go to any lock operated by the lost/stolen manager credentials.
Touch and hold ` for 5 seconds (a two-tone beep will be heard after 5
seconds) then release.
The LED will flash and the Reader will turn on.
Insert the Programming Key.
A two-tone beep will be heard.
Insert the Programming Key again.
Three sets of two-tone beeps will be heard and the LED and Reader will
turn off. All previously programmed manager credentials will be erased.
Follow instructions to Add Manager Credentials to program the remaining
and replacement manager credentials to the locks.

Mini RFID
Shared & Assigned Use Functionality
Product Guide
5
Programming Instructions - In Assigned Use Functionality
or
RFID
CARD
Manager
RFID
CARD
Assign User Credentials
Up to 20 user credentials (User Key or RFID) may be assigned to each lock.
Touch and hold `for 5 seconds
(a two-tone beep will be heard after
5 seconds) then release.
The LED will flash and the Reader
will turn on.
Insert a valid Manager Key or present
a valid Manager RFID.
A two-tone beep will be heard.
Insert each User Key or present
each User RFID one at a time.
Two sets of two-tone beeps will
be heard for each user credential
assigned to the lock.
Insert a valid Manager Key or present
a valid Manager RFID.
A two-tone beep will be heard and
the LED and Reader will turn off.
or
1324
Express Register User and Manager Credentials
The Programming Key can quickly program multiple locks to operate with the same user and manager credentials.
Go to a lock already programmed to operate with the user and
manager credentials.
Touch and hold `for 15 seconds (a two-tone beep will be heard after 5 seconds
followed by 2 sets of two-tone beeps after 10 seconds followed by 3 sets of two-
tone beeps after 15 seconds) then release.
The LED will flash.
Insert the Programming Key.
Two sets of two-tone beeps will be heard and the LED will turn off.
Insert the Programming Key to program each lock to operate with the same user
and manager credentials.
Two sets of two-tone beeps will be heard and the LED will flash once to indicate
successful programming.
End express registration.*
Go to any programmed lock
Touch ` then insert the Programming Key.
1
3
2
4a 4b
*The Programming Key will continue to function in express registration mode until it is used to operate a lock.
RFID
CARD
Manager

Mini RFID
Shared & Assigned Use Functionality
Product Guide
6
RFID
CARD
Manager
RFID
CARD
Manager
or or
Operating Instructions - In Shared Use Functionality
RFID
CARD
RFID
CARD
1a 1b
1a 1b
In shared use functionality, the user presents an RFID credential to lock and the same RFID credential to unlock. Once unlocked, the lock is
available for a different user.
Operate with a User RFID
To lock: Touch `, present an RFID then turn the handle to the
locked position. To unlock: Touch `, present the same RFID then turn the handle to the unlocked position. Open the door.*
Operate with a Manager Credential
To lock: Close the door. Insert a registered Manager Key or touch `,
present a valid Manager RFID then turn the handle to the
locked position.
To unlock: Insert a registered Manager Key or touch `, present a valid
Manager RFID then turn the handle to the unlocked position.
Open the door.*
*If a manager credential is used to relock, the previous user credential will continue to operate the lock.

Mini RFID
Shared & Assigned Use Functionality
Product Guide
Phone: [phone]
www.digilock.com | [email protected]
092817
PG-NMVM-RF-DEN
7
RFID
CARD
Manager
or
RFID
CARD
Operating Instructions - In Assigned Use Functionality
1a 1b
1a 1b
In assigned use functionality, users operate the lock with their assigned user credential.
Operate with a User RFID
To unlock: Touch `, present an assigned User RFID then turn the
handle to the unlocked position.
To relock: Close the door then turn the handle to the locked position.
Operate with a Manager Credential
To unlock: Insert a valid Manager Key or touch `, present a valid
Manager RFID then turn the handle to the unlocked position.
To relock: Close the door then turn the handle to the locked position.

Mini RFID
Shared & Assigned Use Functionality
Product Guide
Phone: [phone]
www.digilock.com | [email protected]
092817
PG-NMVM-RF-DEN
8
Regulatory Information
The user is cautioned that changes or modifications not expressly approved by CompX, Timberline could
void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undersired operation.
This equipment has been tested and found to comply with the lim its for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residen tial installation. This equipment generates, uses and can radiate radio
frequency energ y and, if not installed and used in accordance with the instructions,may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuitdifferent from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV tech nician for help.
