Nuovo Egg-Jet23 Setup guide

Quick Start User Guide
Egg-Jet23 R6
1
It’s important to clean your ink cartridges daily before use to maintain good print quality and proper
functioning of the cartridges. Dust and dried up ink will start to build up on the nozzle and clog up the tiny
holes where the ink has to come out of. The cartridge will get blocked if not properly cleaned!
1. Use a CLEAN tissue or paper towel
to clean the nozzle of the ink cartridge.
2. Clean the nozzle by pulling it in a line
 overthetissueusingyourindexnger
on the other side of the tissue.
3. You may need to repeat this a couple of
times to get the cartridge to work
properly again.
4. Make sure to clean the gold contact
points to ensure good connection with
the printhead.
Clean the ink cartridges daily before use
Insert the ink cartridges into the Egg-Jet23 R6
Cartridge cleaning procedure
Lift up the locker [1] completely and place the ink
cartridge carefully into the bottom positioning points [2]
of the printhead cartridge plate from above.
Press the ink cartridge carefully into the printhead
(against the back of the cartridge plate) with
one hand and apply a light counter pressure on the back
of te cartridge plate with the other hand.
Bring down the locker to keep the ink cartridge in place.
The locker should fall over the little latch on the ink
cartridge, so it “clicks” into the printhead.
Check before use if each cartridge is placed correctly!
If the cartridge is not placed correctly all the way against
the back of the printhead, some contact points with not
have a good connection and cause a bad imprint.
2
2
1

Adjust the height of the printheads
The height of the printheads can be adjusted by turning the
“height adjustment bolt” [1].
The height position has to be set depending on the size of the
eggs being printed, with larger eggs the printheads have to be
heigher, with smaller eggs lower.
The height position has to be set so the bottom of the printhead
is gently touching the avarage sized eggs.
This way the larger eggs with lift up the printheads slightly and
the smaller eggs will not be touched by the printheads but also
not be too far away to get a clear imprint on them.
3
1
Select the print text and ink consumption mode on MMI panel
Nozzle mode selection Printing text selection
Nozzle
mode
Printing text
Nozzle cleaning:
Select printing text CL
and switch on Printing
on/off button.
Printing On/Off
(LED Spot lights = Printing)
On/Off Dots:
The dots in the bottom of the
display represent if printing
is on or off.
Don’t use any of the other options, these are for testing only!!
Standard ink consumption
(For brown eggs) - 100%
Ink saving mode
(For white eggs) - 50%
Medium ink consumption
(For brown eggs) - 75%
Nozzle modes
for users:
4
