NuTone 422401 User manual

Quality construction and ease of installation make
the 42000 the popular choice in vertically-ducted
economy hoods.
FEATURES
•Rocker-type fan and light switches
•Polymeric blade and light lens (accepts up to 75W bulb)
•Washable aluminum filter
•Mitered sides and hemmed bottom for safety and good
looks
•Model BP87 double-leaf damper (available separately)
•Contemporary styling in White, Almond and Stainless
Steel
•Available in 30" and 36" widths
•Special Order Color - Black (30" and 36" only)
•Special Order Size - 24" and 42" (White, Biscuit,
Almond and Stainless Steel only)
SPECIFICATION SHEET
REFERENCE QTY. REMARKS Project
Location
Architect
Engineer
Contractor
Submitted by Date
TYPICAL SPECIFICATION
Range hood shall be Broan Model 42000.
Unit shall be ducted vertically into 7" round ductwork.
Motor to be permanently lubricated. RPM not to exceed
2750.
Unit shall have two-speed fan switch and separate light
switch.
Sides shall be mitered and bottom edge hemmed - with no
sharp edges.
Air delivery shall be no less than 190 CFM and sound level
no greater than 6.0 sones. All air and sound ratings shall
be certified by HVI.
Unit shall be U.L. listed.
50H 99041057J
42000 SERIES
TWO-SPEED
7" ROUND
RANGE HOOD
SPECIFICATIONS
Broan-NuTone LLC, 926 West State Street, Hartford, WI 53027 (1-800-637-1453)
VOLTS AMPS RPM SONES CFM DUCT
120 2.0 1750 6.0 190 7" Round
HVI-2100 CERTIFIED RATINGS comply with
new testing technologies and procedures
prescribed by the Home Ventilating Institute,
for off-the-shelf products, as they are
available to consumers. Product performance
is rated at 0.1 in. static pressure, based on
tests conducted in AMCA’s state-of-the-art
test laboratory. Sones are a measure of
humanly-perceived loudness, based on
laboratory measurements.
