nuVita 3052 User manual
3052
Instruction manual
Video baby monitor
EN
3052
Thank you for purchasing NUVITA 3052 Video Baby Monitor. Please retain your original dated sales receipt for
your records. For warranty service of your product, you will need to provide a copy of your dated sales receipt
to conrm warranty status. Registration is not required for warranty coverage.
This digital video Baby Monitor is compliant with all relevant standards regarding electromagnetic elds and is,
when handled as described in the User’s Guide, safe to use. Therefore, always read the instructions in this User’s
Guide carefully before using the device.
Choose a location for the Baby Unit that will provide the best view of your baby in their cot. Place the Baby Unit
on a at surface, such as a dresser, desk, or shelf or mount the Unit to a wall securely using the keyhole slots on
the underside of the stand.
Strangulation Hazard: Children have strangled in cords. Keep this cord out of the reach of the children
(more than 1 meter away).
WARNING
1.
2.
3.
4.
5.
6.
Only use the provided power adapter.
Adult assembly is required. Keep small parts away
from children when assembling.
This product is not a toy. Do not allow children to
play with it.
This Baby Monitor is not a substitute for
responsible adult supervision.
Keep this User’s Guide for future reference.
Do not cover the Baby Monitor with a towel or
blanket.
WARNING
Never use extension cords with power adapters.
Only use the power adapters provided.
Test this monitor and all its functions so that you
are familiar with it prior to actual use.
Do not use the Baby Monitor near water.
Do not place the Baby Monitor near a heat source.
Do not touch the plug contacts with sharp or
metal objects.
7.
8.
9.
10.
11.
1.
2.
Connect the power adapter to the Baby Camera. Press and hold the
POWER button to turn it ON.
Press and hold the POWER button on Parent Display to turn it ON.
Connect with the power adapter when in low battery status.
ATTENTION
Charge the Parent Display for 16 hours before FIRST USE.
Strangulation Hazard: Children have strangled in cords. Keep this
cord out of the reach of the children (more than 1 meter away).
SETUP
BUTTON FUNCTION
Speaker Volume (Parent Unit)
Press or
(when Pan & Tilt icon NOT SEEN on
screen)
Camera Pan Left / Right
Press or
Camera Tilt Up / Down
Press or
(when Pan & Tilt icon SEEN on screen)
ON/OFF BUTTON
Switch ON/OFF
Press Hold 3 seconds
Screen Sleep/Wake
Quick Press One time
TALK / VIEW BUTTON
TALK
Press Hold to talk
VIEW
Quick Press One time back to View
mode
MENU
BACK
OK
ZOOM
When the room is dark, the image will be in black and white, due to the infrared function of the Baby Unit
NIGHT VISION
To add camera, to be
done on rst pairing or
when you add a new
camera:
MENU FUNCTION (PARENT DISPLAY)
1.
2.
3.
4.
5.
On Parent unit,
press MENU.
Select “Camera”.
Select “Add camera”.
Press “OK”.
On Baby unit, press
Hold Pairing Button.
32
54
On Parent unit,
press MENU.
Select “View”.
Press OK.
Select camera to
view.
VIEW
1.
2.
3.
4.
On Parent unit,
press MENU.
Select “Lullabies”.
Press OK.
Select lullaby on
the list to play. It
will automatically
single cycle once
LULLABIES
1.
2.
3.
4.
you chose one of lullaby; If chose All, it will automatically repeat all lullabies list.
On Parent unit,
press MENU.
Select “Feeding
Timer”.
Press OK.
Select the time
lap for feeding OR
Select “Setting” to
FEEDING TIMER
1.
2.
3.
4.
5.
6.
set the time lap.
Count Down Timer appears on Screen.
Alarm for 5 seconds after count down.
42
42
42
SETTING
Language Setting1.
Select “Language Setting”.
Brightness Setting2.
Select brightness level. Press or .
Date & Time3.
Set date and time.
High-Low Temperature Alarm Setting4.
Baby Camera detects Baby room temperature. Set
the Room Temperature Limit . Alarm for 5 seconds
when over / below limits.
Temperature unit °C/°F5.
Select °C/°F
Frequency6.
Select wireless frequency 60Hz or 50Hz. Pick the
frequency with less interference.
Default Setting10.
Select ON / OFF to Restore Factory Default Setting
Power Saving9.
Select ON / OFF. Parent Display sleep automatically
within 10 seconds in idle status. Press to wake
up Display.
Motion Detecting7.
Select ON/OFF to receive alarm once any
movement detected by Baby Camera.
VOX8.
Select Sensitivity Level / OFF to receive alarm once
any sound detected.
1.
2.
3.
4.
5.
Clean the Baby Monitor with a slightly damp cloth or with an anti-static cloth.
Never use cleaning agents or abrasive solvents.
Do not clean any part of the product with thinners or other solvents and chemicals – this may cause
permanent damage to the product which is not covered by the warranty.
Keep the Baby Monitor away from hot, humid areas or strong sunlight, and don’t let it get wet.
If something does go wrong, please do not try to repair it yourself – contact Customer Service for assistance
CLEANING
At the end of the product lifecycle, you should not dispose of this product with normal household waste. Take this
product to a collection point for the recycling of electrical and electronic equipment. The symbol on the product,
user’s guide and/or box indicates this.
Some of the product materials can be reused if you take them to a recycling point. By reusing some parts or raw
materials from used products you make an important contribution to the protection of the environment.
Please contact your local authorities in case you need more information on the collection points in your area.
The internal battery should be disposed of with the Parent unit in an environmentally-friendly manner according
to your local regulations.
DISPOSAL OF THE DEVICE (ENVIRONMENT)
Baby Camera
Wireless connection
Camera Resolution
Video resolution
Rotation angle
Power input
ON/OFF Switch
Speaker
High Sensitivity
Microphone
Temperature &
Relative Humidity Sensor
Motion Detection
FHSS 2.4G
1.0MP
VGA
Horizontal 270 degrees,
Vertical 90 degrees
USB
Yes
Yes
Yes
Yes
Yes
Parent Display
LCD
MIC
Speaker
Battery
5 inches (480*272) TFT
built-in
8Ω/1W X1
3.7V 1500mA
(4 hours Always-On)
System features
Power input
Remote pan, tilt, and zoom
Remote Volume control
infrared night vision
Music player (local)
Two-way communication
Extra Screen/Camera
connection
USB
support
5 levels adjustable
support
support
support
Supports 4 cameras/4
screens
PROUCT SPECIFICATION
WARRANTY TERMS AND CONDITIONS
1.
2.
3.
1.
2.
The product has undergone aesthetic damage due
to improper use not in accordance with instructions
in the manual.
This product has been modied and/or tampered
with.
The cause of the failure was due to poor
maintenance of the individual components and/
or accessories and/or supplies (e.g. oxidation and/
or scaling due to the retention of water or other
liquids, sediment blocking the sensor, leak of
corrosive liquid from batteries).
Costs related to replacements and/or repair of parts
subject to wear or costs for ordinary maintenance
of the product.
The costs and risks involved in transporting the
product to and from the store where you purchased
The manufacturer, distributor and all the parties
involved in the sale do not assume any liability for losses
and economic damage from any malfunction of the
product. In accordance with current regulations the
manufacturer, distributor and all the parties involved
in the sale are not responding in any case for damages,
including direct, indirect ones, loss of net income, loss
of savings and additional damage and other details
consequences going beyond the damage caused by the
breach of warranty, contract, strict liability, wrongdoing
or due to other causes, resulting from the use or
inability to use the product and/or paper and electronic
documents, including the lack of service.
For further information on the help service visit the
website www.nuvitababy.com
This product benets of a warranty of 24 months on
material and manufacturing defects, starting from the
date of purchase (see sales slip).
The warranty of 24 months does not include damages
caused by the usual use of parties identied as
“consumable” (e.g., batteries, brush heads or parts
subject to usury).
The legal guarantee of 24 months is void if:
The following is excluded from the legal guarantee of
24 months:
or otherwise authorized collection centre to receive
the products under warranty.
Damage caused by or resulting from improper
installation or improper use not in accordance with
the directions in the instruction manual.
Damage due to natural disasters, accidental events
or adverse conditions not compatible with the
product.
Defects that have a negligible eect on product
performance.
3.
4.
5.
