1 OVERVIEW
EVB-I94124ADI is the specific development tool for I94100 series. User can use EVB-I94124ADI to
develop and verify the application program easily.
EVB-I94124ADI includes two portions. One is I94124ADI evaluation board and the other is Debug
Adaptor (Nu-Link-Me). Thus, users do not need other additional ICE or debug equipment.
Introduction to EVB-I91240ADI Board1.1
EVB-I94124ADI uses the I94124ADI as the target microcontroller. The EVB-I94124ADI board consists
of I94124ADI Platform and Nu-Link-Me ICE Bridge. Figure 1-1 shows the EVB-I94124ADI board.
The left portion of this board is the I94124ADI Platform that includes the target chip I94124ADI MCU
which embedded ARM® Cortex®-M4 core with DSP extensions and a Floating Point Unit (FPU) and the
other related on-board application parts and connectors.
The right portion of this board is a Nu-Link-Me ICE Bridge based on the SWD (Serial Wire Debug)
interface connected with the target chip, allowing user to program the application code to the flash of
target chip through the USB port from PC Host.
Figure 1-1 EVB-I94124ADI Board
I94100 Series MCU Features1.2
I94124ADI in LQFP64 7x7 package
ARM®Cortex®-M4 core running up to 200 MHz with DSP extensions and FPU (Floating
Point Unit)
Built-in LDO for wide operating voltage ranged from 1.6 V to 3.6 V
512 Kbytes Flash
192 Kbytes SRAM
GPIO
Peripheral DMA (PDMA)
Timer
PWM
WDT and WWDT

EVB-I94124ADI
August 30, 2017 Page 6of 19 Rev 1.0
EVB-I94124ADI USER MANUAL
Maker Nu-mbed NUC472 User Manual
RTC
UART
I2C
SPI
I2S
USB 1.1 Full-Speed Device
CRC
ADC
DMIC
DPWM
VAD
EVB-I94124ADI Board Features1.3
On board Nu-Link-Me ICE Bridge (Mass storage as USB Disk drive) for drag and drop
programming
I94124 extended interface connectors
USB 1.1 Full-Speed Device
Two push-buttons: one is for reset and the other one is for user-defined
One LEDs: one is for power indication

EVB-I94124ADI
August 30, 2017 Page 7of 19 Rev 1.0
EVB-I94124ADI USER MANUAL
Maker Nu-mbed NUC472 User Manual
2 EVB-I94124ADI BOARD OVERVIEW
Front View2.1
Figure 2-1 shows the main components and connectors from the front side of EVB-I94124ADI board.
The following lists components and connectors from the front view:
Target Chip: I94124ADI (U1)
Nu-Link-Me ICE Bridge: ICE Controller NUC12SRE3DE (U2), USB connector (CN2) to
PC Host
I94124ADI extended interface connectors (JP4, JP5, JP6 and JP7)
USB: USB 1.1 Full-Speed Device connector (CN1)
Push-buttons (SW1, SW2)
LED (POWER1)
External power connectors (JP2 and SP3)
I94120ADI
Microcontroller
Reset Button
User Button
USB MicroB
Device USB MicroB
Debug / Power
3.3V
Voltage Regulator
Power
LED
Pin Header
Pin Header
Evaluation Board Debugger
NCU12SRE3AN
ICE Controller
32.768 kHz
XTAL 12.000 MHz XTAL
Power
Header
Ground
Header
Figure 2-1 Front View of EVB-I94124ADI Board

EVB-I94124ADI
August 30, 2017 Page 8of 19 Rev 1.0
EVB-I94124ADI USER MANUAL
Maker Nu-mbed NUC472 User Manual
Rear View2.2
Figure 2-2 shows the rear side of EVB-I94124ADI board.
Figure 2-2 Rear View of EVB-I94124ADI Board

EVB-I94124ADI
August 30, 2017 Page 9of 19 Rev 1.0
EVB-I94124ADI USER MANUAL
Maker Nu-mbed NUC472 User Manual
Power Supply2.3
The EVB-I94124ADI supplied by an external 5 Volt DC power supply connected to Micro USB
connectors (CN1 and CN2) or 1.6 Volt to 3.6 Volt DC power supply connected to Pin Header (JP2).
On-board reverse current protection diodes will ensure safe operation in case power is provided
through both USB connectors at the same time. If the board is powered via a USB connector, it is not
recommended to apply an additional power supply to VCC pin header (JP2), because there is no
protection against reverse current into the external power supply. Figure 2-3 shows EVB-I94124ADI
power supply concept.
Micro
USB
Header
LDO
3V3
I94124ADI
USB_VBUS (5V) USB_VBUS (5V)
ICE_VBUS (5V)
3V3_ICE (3.3V)
VCC (3.3V) EVB-I94124ADI NU-LINK-ME
Micro
USB
5V
NUC12SR
E3AN
CN2
CN1 U1 U2
JP2
PD3
PD2
PD1
U3
Figure 2-3 Power Supply Concept
Pin Assignment for Extended Connectors
2.4
The EVB-I94124ADI provides the I94124ADI target chip on-board and extended connectors (JP4,
JP5, JP6 and JP7) for LQFP64-pin. The Figure 2-4 shows the I94124ADI extended connectors.
Please note that JP7.2, JP5.18, JP4.2 and JP6.18 can be used to power an external circuit.

EVB-I94124ADI
August 30, 2017 Page 10 of 19 Rev 1.0
EVB-I94124ADI USER MANUAL
Maker Nu-mbed NUC472 User Manual
Figure 2-4 I94124ADI Extended Connectors

EVB-I94124ADI
August 30, 2017 Page 11 of 19 Rev 1.0
EVB-I94124ADI USER MANUAL
Maker Nu-mbed NUC472 User Manual
Table 2-1 Extended Connector JP7 Interface with I94124ADI GPIO
Header
I94124ADI
Header
I94124ADI
Pin No.
Pin Name
Pin No
Pin Name
JP7
JP7.1
-
GND
JP7
JP7.2
-
VCC
JP7.3
1
PB.0
JP7.4
2
PB.1
JP7.5
3
PB.2
JP7.6
4
PB.3
JP7.7
5
PB.4
JP7.8
6
nRESET
JP7.9
7
PB.5
JP7.10
8
PB.6
JP7.11
9
PB.7
JP7.12
10
PB.8
JP7.13
11
PB.9
JP7.14
12
LDO_CAP
JP7.15
13
VSS
JP7.16
14
AVSS
JP7.17
15
VDD
JP7.18
16
AVDD
Table 2-2 Extended Connector JP5 Interface with I94124ADI GPIO
Header
I94124ADI
Header
I94124ADI
Pin No.
Pin Name
Pin No
Pin Name
JP5
JP5.1
17
PC.0
JP5
JP5.2
18
PC.1
JP5.3
19
PC.2
JP5.4
20
PC.3
JP5.5
21
PC.4
JP5.6
22
PC.5
JP5.7
23
PC.6
JP5.8
24
PC.7
JP5.9
25
PC.8
JP5.10
26
PC.9
JP5.11
27
PC.10
JP5.12
28
PC.11
JP5.13
29
PC.12
JP5.14
30
PC.13
JP5.15
31
PC.14
JP5.16
32
USB_VDD33
JP5.17
-
GND
JP5.18
-
VCC

EVB-I94124ADI
August 30, 2017 Page 12 of 19 Rev 1.0
EVB-I94124ADI USER MANUAL
Maker Nu-mbed NUC472 User Manual
Table 2-3 Extended Connector JP4 Interface with I94124ADI GPIO
Header
I94124ADI
Header
I94124ADI
Pin No.
Pin Name
Pin No
Pin Name
JP4
JP4.1
-
GND
JP4
JP4.2
-
VCC
JP4.3
33
PB.15
JP4.4
34
PB.14
JP4.5
35
PB.13
JP4.6
36
PD.0
JP4.7
37
PD.1
JP4.8
38
PD.2
JP4.9
39
PD.3
JP4.10
40
PD.4
JP4.11
41
PD.5
JP4.12
42
PD.6
JP4.13
43
PD.7
JP4.14
44
PD.8
JP4.15
45
PD.9
JP4.16
46
PD.13
JP4.17
47
PD.14
JP4.18
48
PD.15
Table 2-4 Extended Connector JP6 Interface with I94124ADI GPIO
Header
I94124ADI
Header
I94124ADI
Pin No.
Pin Name
Pin No
Pin Name
JP6
JP6.1
49
PA.0
JP6
JP6.2
50
PA.1
JP6.3
51
PA.2
JP6.4
52
PA.3
JP6.5
53
PA.4
JP6.6
54
PA.5
JP6.7
55
PA.6
JP6.8
56
PA.7
JP6.9
57
PA.8
JP6.10
58
PA.9
JP6.11
59
PA.10
JP6.12
60
PA.11
JP6.13
61
PA.12
JP6.14
62
PA.13
JP6.15
63
PA.14
JP6.16
64
PA.15
JP6.17
-
GND
JP6.18
-
VCC

EVB-I94124ADI
August 30, 2017 Page 13 of 19 Rev 1.0
EVB-I94124ADI USER MANUAL
Maker Nu-mbed NUC472 User Manual
System Configuration2.5 2.5.1 5V Power Source
CN2:USB connector in Nu-Link-Me to program code and supplies 5V power from PC Host.
CN1:USB 1.1 device connector on EVB-I94124ADI board to supply 5V power from PC
Host.
Power
Source
Component
Comment
ICE_VBUS
CN2
CN2 supplies the 5V power from PC Host.
USB_VBUS
CN1
CN1 supplies the 5V power from PC Host.
2.5.2 3.3V Power Source
JP2: External power source supplies 1.6V ~ 3.6V to EVB-I94124ADI board.
U3: The voltage regular converts the 5V source to 3.3V and supplies it to EVB-I94124ADI
board.
Power
Source
Component
Comment
VCC
JP2
JP2 supplies the 1.6V ~ 3.6V power from external power
source.
3V3_ICE
U3
U4 convert USB_VBUS or ICE_VBUS to 3.3V and supplies
it to I94124ADI platform board.
2.5.3 USB Connectors
CN2:USB connector (ICE) in Nu-Link-Me that connects to a PC’s USB Host port to
program code and supply power.
CN1:USB 1.1 connector on EVB-I94124ADI board for USB device application use.
2.5.4 Extended Connectors
JP4, JP5, JP6 and JP7: Extended connectors interface pins on the EVB-I94124ADI board.
2.5.5 Push-Buttons
SW1: Reset button to reset the target chip on EVB-I94124ADI board.
SW2: Only for application use. User defined.
2.5.6 LED
POWER1: The power LED indicates that the EVB-I94124ADI board is powered.

EVB-I94124ADI
August 30, 2017 Page 14 of 19 Rev 1.0
EVB-I94124ADI USER MANUAL
Maker Nu-mbed NUC472 User Manual
2.5.7 Power Connectors
JP2: VCC (Range: 1.6V to 3.6V) connectors on the EVB-I94124ADI board.
JP3: GND connectors on the EVB-I94124ADI board.
2.5.8 Clock Source
X1:12 MHz crystal. (By removing resistor R4 and R5, the crystal can be disconnected from
PB.5 and PB.6)
X2:32.768 kHz crystal. (By removing resistor R6 and R9, the crystal can be disconnected
from PC.0 and PC.1)
2.5.9 ICE Bridge Connector
JP1: ICE bridge connector on EVB-I94124ADI board side.
JP8: ICE bridge connector on NU-LINK-ME board side.
2.5.10 Others
JP9: Reserved.
SW3: Reserved.

EVB-I94124ADI
August 30, 2017 Page 15 of 19 Rev 1.0
EVB-I94124ADI USER MANUAL
Maker Nu-mbed NUC472 User Manual
Components Placement2.6
Figure 2-5 and Figure 2-6 show the front and rear placement of EVB-I94124ADI board.
Figure 2-5 Front Placement
Figure 2-6 Rear Placement

EVB-I94124ADI
August 30, 2017 Page 16 of 19 Rev 1.0
EVB-I94124ADI USER MANUAL
Maker Nu-mbed NUC472 User Manual
3 EVB-I94124ADI SCHEMATICS
This chapter contains the schematics for I94124ADI and Nu-Link-Me (On-board Debugger).
I94124ADI3.1
Figure 3-1 shows the I94124ADI, Pin Headers, Buttons and LED.
Figure 3-1 I94124ADI Circuit
AVDD
R2
0R R0603
R8
330R
R0603
R3
0R R0603
VCC
C6
1uF/6.3V
C0603
C5
10nF
C0603
P16
P32 USB_VDD33P32
P15 VDDP15
R1
0R R0603
X2
32.768K
XTAL-3.4MM-2P
VCC
C11
20pF C0603
C10
20pF C0603
D-
D+ R10 27R
R0603
R12 27R
R0603
USB_D-PB14P34 USB_D+PB13P35
P13 GND
P14 GND
XT1_OUTPB5P7
R5
0R R0603
XT1_INPB6
C7
1uF/6.3V
C0603
R6
0R R0603
R9
0R R0603
X32_OUTPC0P17 X32_INPC1
P12 LDO_CAP
VCC
ICE_DAT
ICE_CLK
nRESET
GND
PA15P64
VDD
R11
10K
R0603
Push-Button
SW2
SW PUSHBUTTON
12
POWER1
GREEN
LED0805
C12
10uF/10V
TANT-A
Title
Size Document Number Rev
Date: Sheet of
1.0
I94124ADI MCU
B
Wednesday, August 30, 2017
EVB-I94124ADI 1 2
Nuvoton
USER
CN1
Micro USB Type_B
VBUS 1
D- 2
D+ 3
GND 5
ID 4
Shield
0
JP5
NC
1 2
3 4
5 6
7 8
910
11 12
13 14
15 16
17 18
JP6
NC 12 34 56 78 910 1112 1314 1516 1718
JP4
NC
1 2
3 4
5 6
7 8
910
11 12
13 14
15 16
17 18
JP7
NC 12 34 56 78 910 1112 1314 1516 1718
USB_VBUS
C13
1uF/6.3V
C0603
R13
1M
R0603
C14
3300pF
C0603
USB_VBUSPB15P33
P26PC9 P24PC7 P22PC5 P20PC3
VCCP32USB_VDD33
P30PC13 P28PC11P27 PC10
P25 PC8
P23 PC6
P21 PC4
P19 PC2
GND
P31 PC14
P29 PC12
P34PB14
P38PD2 P36PD0
P42PD6 P40PD4
P46PD13 P44PD8
P48PD15
JP2 NC
1 2
3 4
nRESETP6
ICE_DATPD9P45 ICE_CLKPD8P44
JP1
NC
1 2
3 4
5 6
7 8
910
P37 PD1
P35 PB13
P39 PD3
P41 PD5
P45 PD9
P43 PD7
P33 PB15
P47 PD14
GND
VDD
nRESETP6
R7
10K
R0603
C9
20pF C0603
X1
12MHz
XTAL3-1
C8
20pF C0603
U1
I94124ADI
LQFP64_7X7
USB_VDD33 32
PC.14 31
PC.13 30
PC.12 29
PC.11 28
PC.10 27
PC.9 26
PC.8 25
PC.7 24
PC.6 23
AVDD
16 VDD 15 AVSS 14 VSS 13 LDO_CAP 12 PB.9 11 PB.7
9
PB.8
10 PB.6
8PB.5 7PB.4 5PB.3 4PB.2 3PB.1 2PB.0 1
PA.15
64 PA.14
63 PA.13
62 PA.12
61 PA.11
60 PA.10
59 PA.9
58 PA.8
57 PA.7
56 PA.6
55 PA.5
54 PA.4
53 PA.3
52 PA.2
51 PA.1
50 PA.0
49
PD.15 48 PD.14 47 PD.13 46
PD.9 45 PD.8 44 PD.7 43 PD.6 42 PD.5 41 PD.4 40 PD.3 39 PD.1 37 PD.0 36
PB.13 35 PB.14 34 PB.15 33
PD.2 38
PC.0 17
PC.1 18
PC.2 19
PC.5 22
PC.3 20
PC.4 21
nRESET
6
USB Device
PB8P10 ICE_TXD
PB9P11 ICE_RXD
ICE_TXD
ICE_RXD
VCC
Reset
Crystal
JP3 NC
1 2
3 4
P56 PA7
P54 PA5
P52 PA3
P50 PA1
VCC
P60 PA11
P58 PA9
P64 PA15
P62 PA13
P51PA2 P49PA0
P53PA4 P55PA6
GND
P63PA14 P61PA12 P59PA10 P57PA8
ICE CONNECT I/F
GND
P1PB0 P3PB2 P5PB4 P7PB5 P9PB7 P11PB9 P13VSS P15VDD
VCC
P2 PB1
P4 PB3
P6 nRESET
P8 PB6
P10 PB8
P12 LDO_CAP
P14 AVSS
P16 AVDD
P32
P31
P30
P29
P28
P27
P26
P25
P24
P23
P22
P21
P20
P19
P18
P17
SW1
SW PUSHBUTTON
P16 P1 P2 P3 P4 P5 P6 P7 P8 P9 P10 P11 P12 P13 P15 P14
P18
P49
P50
P51
P52
P53
P54
P8
P55
P56
P57
P58
P59
P60
P61
P62
P63
P64
P48 P47 P46 P45 P44 P43 P42 P41 P40 P39 P38 P37 P36 P35 P34 P33
LED
Connectors
R4
0R R0603
VCC
GND
RESET
Power & Ground
Bypass CAP
VCC
ICE_DAT
ICE_CLK
nRESET
VCC
C1
10nF
C0603
P17 PC0 P18PC1
C2
1uF/6.3V
C0603
C4
1uF/6.3V
C0603
C3
10nF
C0603

EVB-I94124ADI
August 30, 2017 Page 17 of 19 Rev 1.0
EVB-I94124ADI USER MANUAL
Maker Nu-mbed NUC472 User Manual
Nu-Link-Me3.2
Figure 3-2 shows the Nu-Link-Me circuit, which is a USB-to-SWD bridge used to program code to the
target chip.
Figure 3-2 Nu-Link-Me Circuit
Crystal
ICE_DAT
ICE_CLK
nRESET
ICE_DAT
ICE_CLK
nRESET
IDLE1
ICPLED
ICELED
RP1
8P4R-330R
8P4RA
1 2
3 4
5 6
7 8
BUSY1
C16
20pF
C0603
X3
12MHz
XTAL3-1
C15
20pF
C0603
LED Display
ICE_VBUS
3V3_ICE
3V3_ICE
3V3_ICE
3V3_ICE
3V3_ICE
12 IDLE1
RED
LED0805
12 BUSY1
GREEN
LED0805
VCOM_EN
ICE_TXD
ICE_RXD
CLK
DAT
3V3
RST
GND
ICE_RXD
5V
Title
Size Document Number Rev
Date: Sheet of
1.0
NULINK-ME
A4
Wednesday, August 30, 2017
EVB-I94124ADI 22
Nuvoton
R16
27R R0603
12M_O
USB_VBUS1 2
PD3
SS24A
RB060L
TICERST
TICECLK
JP8
NC
1 2
3 4
5 6
7 8
910
JP9
NC
1
2
3
4
5
ICE_USBDM
ICE_USBDP
2 3
4
1
LM1117
DEBUG_CLK
DEBUG_DAT
DEBUG_RST
R19
1M
R0603
C19
3300pF
C0603
ICE_TXD
ICE_RXD
TICETXD
TICERXD
CN2
Micro USB Type_B
VBUS 1
D- 2
D+ 3
GND 5
ID 4
Shield
0
R18
27R
R0603
R17
27R
R0603
ICE_USBDM
ICE_USBDP
ICE_VBUS
ICE CONNECT IF
DEBUG CONNECT IF
12M_I
ICE_DAT
VCOM_EN
ICE_RXD
ICE_TXD
VCOM SW
1 2 3 4
ON
SW3
HPS604-E
TICERXD
TICETXD
VCOM_EN
VCC
GND
nRESET
ICE_CLK
ICE_DAT
ICE_TXD
RTDA2
0R
R0603
TICEDAT
U2
NUC12SRE3AN
PA0/ADC0 44
PA1/ADC1 45
PA2/ADC2 46
PA3/ADC3 47
PA4/ADC4 48
INT0/PB14
1
CPO1/PB13
2
CPO0/PB12
3
VBUS
17
VDD33
18
D-
19
D+
20
PB0/RX0
21
PB1/TX0
22
PB2/RTS0
23
PB3/CTS0
24
PC2/SDI00
26
PC1/SPCLK0
27
PC0/SS00
28
PC11/SDO10 33
PC10/SDI10 34
PC9/SPCLK1 35
PC8/SS10 36
PA15/PWM3 37
PA14/PWM2 38
PA13/PWM1 39
X32I
4
X32O
5
I2C1SCL/PA11
6
I2C0SDA/PA8
9I2C1SDA/PA10
7
I2C0SCL/PA9
8
RX1/PB4
10
TX1/PB5
11
RTS1/PB6
12
CTS1/PB7
13
PC3/SDO00
25
AVSS 43
ICE_CK 42
ICE_DAT 41
PA12/PWM0 40
LDO
14
VSS
16 VDD
15
ADC/PA5 49
ADC6/PA6 50 ADC7/PA7 51
AVDD 52
CPN0/PC7 53
CPP0/PC6 54
CPN1/PC15 55
CPP1/PC14 56
INT1/PB15 57
XT1_Out 58
XT1_In 59
/RESET 60
VSS1 61
VDD1 62
PVSS 63
STADC/TM0/PB8 64
PE5
29
PB11/TM3
30
PB10/SS01/TM2
31
PB9/SS11/TM1
32
12 ICE1
RED
LED0805
12 ICP1
YELLOW
LED0805
C18
1uF/6.3V
C0603
C17
0.1uF
C0603
3V3_ICE
R20
10K
R0603
C24
10uF/10V
TANT-A
C22
10uF/10V
TANT-A
DEBUG_RST
RESET
12M_I 12M_O DEBUG_RST
3V3_ICE
3V3_ICE
C23
10uF/10V
TANT-A
BUSY1
IDLE1
ICPLED
ICELED
Power
USB
C20
1uF/6.3V
C0603
C21
0.1uF
C0603
TICERST
TICECLK
RTCK1
100K
R0603
RTDA3
33R
R0603
RTDA1
100K
R0603
RRSET1
100K
R0603
DEBUG_DAT
DEBUG_CLK
3V3_ICE
1 2
PD1
SS24A RB060L
ICE_VBUS 1 2
PD2
SS24A
RB060L
VCC
3V3_ICE
U3
AMS1117-3V3
IN
3
GND
1
OUT
2
OUT
4
R14 0R R0603
R15 0R R0603

EVB-I94124ADI
August 30, 2017 Page 18 of 19 Rev 1.0
EVB-I94124ADI USER MANUAL
Maker Nu-mbed NUC472 User Manual
4 REVISION HISTORY
Date
Revision
Description
2017.08.30
1.0
1. Initially issued.

EVB-I94124ADI
August 30, 2017 Page 19 of 19 Rev 1.0
EVB-I94124ADI USER MANUAL
Maker Nu-mbed NUC472 User Manual
Important Notice
Nuvoton Products are neither intended nor warranted for usage in systems or equipment, any
malfunction or failure of which may cause loss of human life, bodily injury or severe property
damage. Such applications are deemed, “Insecure Usage”.
Insecure usage includes, but is not limited to: equipment for surgical implementation, atomic
energy control instruments, airplane or spaceship instruments, the control or operation of
dynamic, brake or safety systems designed for vehicular use, traffic signal instruments, all
types of safety devices, and other applications intended to support or sustain life.
All Insecure Usage shall be made at customer’s risk, and in the event that third parties lay
claims to Nuvoton as a result of customer’s Insecure Usage, customer shall indemnify the
damages and liabilities thus incurred by Nuvoton.
