Nuvoton ISP/ICP 2-in-1 Programmer User manual

ISP/ICP 2-in-1 Programmer
© 2011 Nuvoton Technology Corporation. All Rights Reserved
Brief Introduction
The “ISP/ICP 2-in-1 Programmer”, as shown in the following picture, can function as an ISP Programmer or an ICP
Programmer. For detailed information of the ISP Programmer and the ICP Programmer, please refer to their
respective user manuals.
Auto Key
(For off-line operation, press to do 'Update Chip')
Green/Red LEDs
(To show programming result)
1
2
3
4
5
ISP/ICP Interface
As an ISP Programmer
As an ICP Programmer
ISP Interface:
Pin-5: (PL) (Pull-low control)
Pin-4: RST (Reset control to 8051 MCU)
Pin-3: VCC (Power supply from target system)
Pin-2: DTA (Serial data to/from 8051 MCU)
Pin-1: GND (Ground)
ICP Interface:
Pin-5: VPP (Programming voltage to 8051 MCU)
Pin-4: CLK (Serial clock to 8051 MCU)
Pin-3: VCC (Power supply from target system)
Pin-2: DTA (Serial data to/from 8051 MCU)
Pin-1: GND (Ground)

ISP/ICP 2-in-1 Programmer
© 2011 Nuvoton Technology Corporation. All Rights Reserved
V2.2 of “ISP/ICP 2-in-1 Programmer”
V2.2 of the “ISP/ICP 2-in-1 Programmer”, as shown in the following picture, has the following differences compared
with the first version:
V2.2 has the VCC pin, The 3rd pin of the ISP/ICP interface, designed as bi-directional power input and output. When
the programmer is connected to PC (for on-line operation), the VCC pin can output power to the target chip for
ISP/ICP programming. In off-line operation, the VCC pin should be powered from the target system for the
programmer to operate.
V2.3 of “ISP/ICP 2-in-1 Programmer”
V2.3 of the “ISP/ICP 2-in-1 Programmer”, as shown in the following picture, has better noise immunity compared
with the V2.2.

ISP/ICP 2-in-1 Programmer
© 2011 Nuvoton Technology Corporation. All Rights Reserved
V2.4 of “ISP/ICP 2-in-1 Programmer”
V2.4 of the “ISP/ICP 2-in-1 Programmer”, as shown in the following picture, Replaced 10 kΩwith 2 kΩon R13/R14
and modified reset circuit with FP6810-44.
